Plustek eScan Quick Start Manual

Plustek eScan
Quick Start Guide
1
Unpack and Assemble
1
2
4
5
* Pad module may vary upon
scanner model.
3
Scanning a Document
1. Load documents in scanner
Set the documents
face-down and top first.
4
Save to PC/Mobile
1. Select the receiver/device.
2. Tap to send.
Note: Scanner and the receiving
device must be on the same
network subnet.
Save to PC
Download and install
eScan
Client software, Windows and
Mac, from System Settings >
Downloads > Client Application
via USB.
Save to Mobile
Download and install Plustek
eScan app from Apple App Store
/ Google Play Store.
Paper
3
Chute
Cover
Panel
Release
Button
Install the paper chute by opening
the upper panel unit and remove
all packing materials.
2. Scan
Tap
toggle and make adjustments as
needed.
Tap button to scan.
2
Connecting the eScan
Connecting with Ethernet
(RJ45) cable.
2
1
5
PWR PC SEND RECV SVNC READY VOIP LINE1 LINE2
INTERNET
Note: Please make sure internet access is available for eScan to
retrieve date and time.
To change time zone, tap System Settings >
> Date & time
3. Preview
Select images to delete and rotate.
To edit, double tap on the scanned
buttons to
image.
Tap button to insert new
scanned image.
Tap button to select all the
scanned images.
5
Save to FTP / SMB (Network)
1. Enter IP
credentials. Or select a server
from the list on the bottom of
the screen.
2. Tap /
3. Select desired destination path.
4. Tap / to send the scanned
documents.
5. Tap / to exit.
Browse "Quick Connect"/ " " tab
for history and quickly connect.
Note: When saving to an SMB
network share, the shared folder
must be accessible to the eScan,
on the same network subnet.
Video Tutorials
To setup wireless connection, tap
System Settings > General >
Wi-Fi to enable.
6
4
1
3 3
2 2
4. Save to USB
Tap on the USB button to save
the scanned document to the
USB flash drive.
Note: It is advised to wait for
3-5 seconds once the saving
process
remove the USB flash drive.
address and
to connect.
General > About
is completed, then
