Page 1 SIMPLY CLE VER ŠkodaFabia OWNER´ S MANUAL...
Page 2 Introduction You have opted for a Škoda - our sincere thanks for your confidence in us. Your new Škoda offers you a vehicle featuring the most modern engineering and a wide range of equipment which you will undoubtedly wish to use to the full during your daily motoring. We therefore recommend that you read this Owner's Manual attentively to enable you to become familiar with your vehicle and all that it offers as quickly as possible.
Page 3 Introduction On-board literature The other chapters of the Owner's Manual are also important, however, for proper treatment of your car - in addition to regular The on-board literature for your vehicle consists of this “Owner's care and maintenance - helps to retain its value and in many Manual”...
Page 4 Introduction Technical Data includes the most important identification data of your vehicle.
Page 5 Introduction...
Page 6: Table Of Contents
Contents Contents Layout of this Owner's Manual The windscreen wiper and washing system . Communication ..... . . Rear-view mirror ..... . Universal telephone connection* .
Page 7 Contents Driving Tips The battery ..........Windscreen Wiper and Washer System .
Page 8 Contents...
Page 9: Layout Of This Owner's Manual (Explanations)
Layout of this Owner's Manual (explanations) Layout of this Owner's Manual (explanations) The Owner's Manual has been systematically designed, in order to make WARNING it easy for you to find and absorb the information you require. The most important notes are marked with the heading Warning. Chapters, table of contents and subject index These Warning notes draw your attention to a serious risk of acci- The text of the manual are divided into relatively short sections which are...
Page 10: Using The System
Using the system Using the system Safety Driving Tips General Maintenance Breakdown assistance Technical Data...
Page 11 Cockpit Fig. 1 Certain items of equipment shown in the illustration are only fitted to particular model versions or are optional items of equipment.
Page 12: Cockpit
Cockpit Cockpit An overview − Electric power-operated window* ....Light switch, control dial for the instrument lighting and control dial for the headlight beam range regulatiion ..54, 56 This general view is designed to help you to quickly Bonnet release lever .
Page 13: Instruments And Indicator/Warning Lights
Instruments and Indicator/Warning Lights Instruments and Indicator/Warning Lights General view of the instrument cluster Fig. 2 Instrument cluster Engine revolutions counter ⇒ page 13 − with Service Interval Display ⇒ page 15 Coolant temperature gauge ⇒ page 13 Digital clock ⇒ page 16 and multi-functional indicator* ⇒ page 17 Fuel gauge ⇒...
Page 14: Engine Revolutions Counter
Instruments and Indicator/Warning Lights Engine revolutions counter Cold range If the pointer is still in the left-hand area of the scale it means that the engine has not yet reached its operating temperature. Avoid running at ⇒ page 12, fig. 2 The start of the red zone in the revolutions counter high engine speeds, at full throttle and at severe engine loads.
Page 15: Speedometer With Counter For Distance Driven
Instruments and Indicator/Warning Lights The fuel tank has a capacity of about 45 litres. The warning symbol  The distance which you have driven with your vehicle is shown in kilom- the instrument cluster lights up when the pointer reaches the reserve eters (km).
Page 16: Service Interval Display
Instruments and Indicator/Warning Lights Service Interval Display The Service Interval Display for vehicles with fixed service intervals ⇒ fig. 4 A key symbol appears in the trip counter display once the due date for a service is reached and one of the following service work: OIL (change the engine oil) INSP (Inspection service) The display disappears within 3 minutes after starting the engine.
Page 17: Digital Clock
Instruments and Indicator/Warning Lights Resetting Service Interval Display Caution We recommend having this resetting performed by a Škoda Dealer. We recommend that you do not reset the Service Interval Display yourself Škoda dealer: otherwise this can result in the service interval display being incorrectly •...
Page 18: Multi-Functional Indicator* (Onboard Computer)
Instruments and Indicator/Warning Lights Setting minutes Note – Turn the reset button to the right. In certain national versions the displays appear in the Imperial system of measures. WARNING The clock should not be adjusted while driving for safety reasons Memory but only when the vehicle is stationary.
Page 19 Instruments and Indicator/Warning Lights Using the system Single-trip memory (memory 1) The single-trip memory collates the driving information from the moment the ignition is switched on until it is switched off. New data will also flow into the calculation of the current driving information if the trip is continued within 2 hours after switching off the ignition.
Page 20 Instruments and Indicator/Warning Lights The following readouts of the selected memory will be set to zero by The outside temperature appears in the display when the ignition is button switched on. • Average fuel consumption The correct outside temperature will be indicated with a delay of 5 •...
Page 21 Instruments and Indicator/Warning Lights Current fuel consumption from a particular time of day you must first erase the memory at this ⇒ page 18, fig. moment in time by pressing the button The current fuel consumption level is shown in the display in litres/100 km. The maximum time indicated in both switch positions is 99 hours and 59 This information can help you to adapt your style of driving to the fuel minutes.
Page 22: Information Display
Instruments and Indicator/Warning Lights Information display* The display of text is possible in the following languages: Czech, English, German, French, Italian, Spanish, Portuguese. Introduction You can have the relevant language set by a Škoda dealer. The following information can be shown in the display (depending on the equipment installed on the vehicle): ⇒...
Page 23 Instruments and Indicator/Warning Lights Menu – You can select the menu through the rocker switch . The selected information is displayed after pressing the button for a short time or after releasing the rocker switch (after about 4 seconds). You can select the following information (depending on the equipment installed on the vehicle): ⇒...
Page 24: Auto Check Control
Instruments and Indicator/Warning Lights Door ajar warning, luggage compartment door and Radio display bonnet ajar warning Fig. 13 Information display: Radio display Fig. 12 Information display: Door warning These displays appear in addition to the normal information in the radio display.
Page 25 Instruments and Indicator/Warning Lights The red symbols indicate danger (priority 1) while the yellow symbols indi- You must depress the brake pedal first and press the Shiftlock button at cate a warning (priortity 2). Information for the driver may also appear in the same time in order to move the selector lever out of these positions.
Page 26 Instruments and Indicator/Warning Lights Yellow symbols – Investigate the function indicated. – Obtain professional assistance. A yellow symbol signals a warning. Meaning of the red symbols:  ⇒ page 35 Faults in the brake surface  Coolant level too low/coolant tempera- ⇒...
Page 27 Instruments and Indicator/Warning Lights One warning signal will sound if a yellow symbol appears. If several operational faults of priority 2 exist, the symbols appear one after the other and are each illiminated for about 2 seconds. Check the relevant function as soon as possible. Navigation system* The controls for the navigation system, radio, CD player are located in the centre console on both sides of the monitor screen.
Page 28: Warning Lights
Instruments and Indicator/Warning Lights Warning lights An overview The warning lights indicate certain functions if necessary faults. Fig. 16 Instrument cluster with warning lights   ⇒ page 29 Interlocking of the rear seat backrests* ⇒ page 29 Turn signal lights (to the left) ...
Page 29 Instruments and Indicator/Warning Lights   ⇒ page 30 ⇒ page 34 Power steering* Electronic stability programme (ESP)*   ⇒ page 30 ⇒ page 34 EPC fault light (petrol engine) Antilock brake system (ABS)*   ⇒ page 30 ⇒...
Page 30 Instruments and Indicator/Warning Lights Turn signal system  The warning light will light up permanently if the backrest comes loose while driving. Either the left  or right  indicator light flashes depending on the posi- tion of the turn signal lever. WARNING The indicator light flashes at twice its normal rate if a turn signal light fails.
Page 31 Instruments and Indicator/Warning Lights stop the car immediately and switch the engine off - risk of engine There is a system fault in the engine control system if the warning light  damage! does not go out or comes on or flashes while driving. The engine manage- ment system selects an emergency programme which enables you to drive to the nearest Škoda dealer while adopting a gentle style of driving.
Page 32 Instruments and Indicator/Warning Lights Coolant temperature/coolant level  WARNING •  The warning light comes on for a few seconds when the ignition is Take care when opening the coolant expansion bottle. If the switched on. engine is hot, the cooling system is pressurized - risk of scalding. It is best to allow the engine to cool down before removing the cap.
Page 33 Instruments and Indicator/Warning Lights Engine oil  The warning light will go out if the bonnet is left open for more than 30 seconds. If no engine oil has been replenished, the warning light will come on again after driving about 100 km. The warning light ...
Page 34 Instruments and Indicator/Warning Lights Light bulbs*  Luggage compartment door*  The warning light  comes on if a light bulb is damaged: The warning light  comes on when the ignition is switched on if the tail- gate is open. •...
Page 35 Instruments and Indicator/Warning Lights The fact that the TCS system operates together with the ABS means that The warning light comes on for a few seconds after the ignition has been the TCS warning light will also come on if the ABS system is not operating switched on or when starting the engine.
Page 36 Instruments and Indicator/Warning Lights For further information on the brake system ⇒ page 154, “Brakes”. WARNING (continued) Handbrake applied brake fluid level in the reservoir ⇒ page 191, “Brake fluid”. If the fluid level has dropped below the MIN marking, do not drive any The warning light ...
Page 37 If you do not fasten the seat belt, a long warning signal sounds for 6 The passenger front airbag and also possibly the passenger side seconds. airbag which have been switched off by a Skoda dealer using the The following text will be displayed in the information display*: vehicle system tester: •...
Page 38: Unlocking And Locking
Unlocking and locking Unlocking and locking Keys Description Fig. 18 Radio-oper- ated key ⇒ fig. 17 Two keys without radio control or a radio-operated key* ⇒ fig. 18 and a key without radio control are provided with the vehicle. Fig. 17 Set of keys The keys fit in all vehicle locks.
Page 39 Unlocking and locking Changing the key battery WARNING • Always withdraw the key whenever you leave the vehicle - even if it is only for a short time. This is particularly important if children are left in the vehicle. The children might otherwise start the engine or operate electrical equipment (e.g.
Page 40: Locking
Unlocking and locking Electronic immobiliser dealer. You should, however, proceed as follows if you wish to replace the battery yourself: The electronic immobiliser prevents the vehicle being – Fold open the key. operated by an unauthorised person. – Use a screwdriver to carefully lever off the front part of the key An electronic chip is integrated in the head of the key.
Page 41: Child Safety Locks
Unlocking and locking Switching child safety lock on Note – Use the vehicle key to turn the slit in the rear door to the left in • The opened door cannot be locked with the securing knob. This ⇒ fig. the direction of the arrow prevents the possibility of forgetting the key in the locked vehicle.
Page 42 Unlocking and locking • Convenience operation of windows In the event of an accident in which the airbags are deployed, the locked doors are automatically unlocked in order to enable rescuers to One can open and close the electrically powered windows when opening gain access to the vehicle.
Page 43 Unlocking and locking • The boot lid is then unlocked. WARNING • The switched on interior lights come on over the door contact. • If the vehicle is locked from the outside and the safe securing The safe securing system is deactivated. system is activated, there must not be any person and animals in •...
Page 44 Unlocking and locking The following applies if you have locked your vehicle using the button Note • It is not possible to open the doors or the boot lid from the outside The opened driver door cannot be locked. It must be locked separately (safety feature, e.g.
Page 45 Unlocking and locking Emergency locking of the door Boot lid Fig. 24 Rear door: Fig. 25 Lever for Emergency locking of unlocking the boot lid the door An emergency locking mechanism which is visible after opening the door is located on the face end of the rear doors. (Applies only for vehicles with central locking.) Locking ⇒...
Page 46: Remote Control
Unlocking and locking • The boot lid is closed by slamming it closed. The function of the hand grip above the licence plate is deactivated when starting off or at a speed of more than 5 km/hour for vehicles with Open the boot lid by pulling on the actuating lever if it is not completely central locking.
Page 47 Unlocking and locking • The battery must be replaced, ideally by the Škoda dealer, if the central locking or anti-theft alarm system does react to the remote control at less than 3 metres away. Unlocking and locking car Fig. 28 Radio-oper- ated key The radio-operated key differs according to the equipment installed on the vehicle.
Page 48 Unlocking and locking Folding out of the key WARNING (continued) – Press button it is then not possible to open either a door or a window from the inside. The locked doors make it more difficult for rescuers to get Folding up of the key into the vehicle in an emergency - hazard! –...
Page 49: Anti-Theft Alarm System
Unlocking and locking • Anti-theft alarm system* A drop in voltage of the on-board power supply An alarm is immediately triggered if either of the two battery terminals is disconnected while the anti-theft alarm system is activated. The anti-theft alarm system increases the level of protection against people seeking to break into the vehicle.
Page 50: Power Windows
Unlocking and locking Power windows* Closing a window – A window is closed through pulling lightly on the respective switch in the door. The closing process stops when one Switch releases the switch. – Pulling of the switch in the driver's door to the stop will cause the window to be closed completey, automatically.
Page 51 Unlocking and locking Closing windows with the key WARNING (continued) – Turn the key in the lock of the driver door into the closing posi- again. You should nevertheless take particular care when closing tion and hold it there until all of the windows are closed. the windows! A person may otherwise suffer severe injuries as a result of getting an arm, for example, jammed in the window! •...
Page 52: Electric Sliding/Tilting Roof
Unlocking and locking ⇒ fig. 30 Proceed as follows to close the window fully: The sliding/tilting roof is operated by means of the control dial and only functions when the ignition is switched on. The control dial has a • Turn the key in the lock of the driver door into the closing position and number of fixed positions.
Page 53 Unlocking and locking Convenience operation The wind noise in the comfort position is less than when the roof is fully opened. You can also close an open sliding/tilting roof from the outside. The sun screen is also opened automatically when the roof slides open. You can slide the sun screen into the opened or closed position by hand –...
Page 54 Unlocking and locking You can close the sliding/tilting roof by hand if the system is defect. – Carefully remove the plastic covering using a screwdriver. – Remove the crank from its holder, insert it in the opening down to the stop and then turn it to close or open the sliding/tilting roof.
Page 55: Lights And Visibility
Lights and Visibility Lights and Visibility Lights Switching off all lights – Turn the light switch into position O. Switching lights on and off Low beam comes on only if the ignition is switched on. The low beam is switched off automatically when the engine is started and after switching the ignition off;...
Page 56 Lights and Visibility • The switching on of the described lights should only be undertaken in Caution accordance with the legal requirements. The rear fog light should only be switched on if visibility is particularly poor (conform with any varying legal provisions) to avoid dazzling vehicles behind your vehicle.
Page 57 Lights and Visibility Headlight range adjustment  Note Once the low beam is switched on you can then adapt the Headlights fitted with Xenon bulbs adapt automatically to the load and range of the headlights to the load of the vehicle. driving state of the vehicle (e.g.
Page 58 Lights and Visibility   Please comply with any legal requirements when using the hazard Right and left turn signal light warning light system. ⇒ fig. – Push the lever upwards or downwards – If you only wish to flash three times (the so-called conven- Note ience turn signal*), push the lever briefly up to the upper or Switch on the hazard warning light system if, for example:...
Page 59: Interior Lighting
Lights and Visibility Interior lighting Information concerning the function of the lights. • The turn signal system only operates when the ignition is switched   on. The corresponding indicator light in the instrument cluster also Front interior lighting and storage compartment on flashes.
Page 60 Lights and Visibility Interior lighting at the rear* (estate vehicle, sedan) – On the version without reading lights press the switch the right, the symbol O appears.  Reading lights ⇒ page 58, fig. 37 – Press on one of the switches in order to switch the right or left reading light on or off.
Page 61: Visibility
Lights and Visibility Visibility Front door warning light* Rear window heater Fig. 39 Front door: Warning light Fig. 40 Switch for rear ⇒ fig. The warning light is located in the door trim panel below window heater The warning light goes on every time the door is opened. ...
Page 62: The Windscreen Wiper And Washing System
Lights and Visibility The windscreen wiper and washing Sun visors system Using the sun visors can contribute to increasing road safety. Windscreen wipers You can operate the windscreen wipers and automatic wipe/wash using the windscreen wiper lever. Fig. 41 Sun visor: swivelling out You can pull the sun visors for the driver and front passenger out of their fixture and swivel them toward the doors in the direction of the arrow...
Page 63 Lights and Visibility – Set with the switch the desired break between the indi- – Letting go of the lever will cause the windscreen wash system vidual wiper strokes to stop and the wiper to continue for another 1 - 3 wiper strokes (depending on the period of spraying of the wind- Slow wipe screen).
Page 64 Lights and Visibility Replacing wiper blades for the windscreen wipers screen may result in damage both to the blades and the motor of the wind- screen wipers! Headlight cleaning system* The headlights are being cleaned after the windscreen wiper has wiped for the fifth time, the low beam or main beam are switched on and the ⇒...
Page 65 Lights and Visibility Juddering or smearing of the wiper blades could be due to wax residues Taking off the wiper blade left on the windscreen by vehicle washing in automatic vehicle wash ⇒ fig. – Fold the window wiper arm away systems.
Page 66: Rear-View Mirror
Lights and Visibility Rear-view mirror Adjusting left and right exterior mirrors*  – Turn the rotary knob to position . The movement of the mirror You can adjust the exterior mirrors electrically*. surface is identical to the movement of the rotary knob. The right hand exterior mirror is adjusted at the same time on vehi- cles with electrically operated power windows.
Page 67: Front Seats
Seats and Stowage Seats and Stowage Front seats WARNING (continued) tant for the front seat passenger. You will be exposed to increased Basic information risk of injury if it becomes necessary to apply the brake or in the event of an accident. If an airbag is deployed, you may suffer fatal injuries when adopting an incorrect seated position! The front seats have a wide range of different settings and can thus be •...
Page 68 Seats and Stowage Adjusting the front seats Adjusting angle of backrest – Relieve any pressure on the backrest (do not lean on it) and turn the handwheel to adjust the angle of the backrest. The driver's seat should be adjusted in such a way that the pedals can be pressed to the floor with slightly bent legs.
Page 69: Head Restraints
Seats and Stowage Head restraints Adjusting the height of a head restraint – Grasp the side of the head restraint with both hands and push ⇒ fig. it up or down in direction of arrow 47. Best protection is achieved if the top edge of the head restraint is at the same ⇒...
Page 70: Middle Rear Head Restraint
Seats and Stowage WARNING WARNING • The head restraints must be correctly adjusted in order to offer The head restraint on the middle rear seat must always be in the effective protection for the occupants in the event of an accident. upper locked position when someone is sitting there.
Page 71: Rear Seats
Seats and Stowage Rear seats – The system is switched off by turning the control dial to the home position “0”. Folding the rear seats forwards Caution • You should not kneel on the seats or otherwise apply pressure at specific points in order to avoid damaging the heating elements of the seat heaters.
Page 72 Seats and Stowage The rear seats and the seat backrest can be folded forwards to WARNING increase the volume of the luggage compartment ⇒ page 72. • Both parts of the bank can be folded forward individually on vehi- The belt lock and pelvic belt must be in their original position cles with a divided rear seat*.
Page 73: Pedals
Seats and Stowage Pedals Remove the rear seats You should use only footmats which do not obstruct the movement of the pedals and have an anti-slip protection. Operation of the pedals must not be hindered! WARNING • Greater pedal distances may be needed when there is a fault in the brake system.
Page 74 Seats and Stowage – Attach the items of luggage to the lashing eyes or the safety WARNING (continued) net* ⇒ page 74. • Never drive with the boot lid slightly ajar or even fully opened otherwise exhaust gases may get into the interior of the vehicle - In the event of an accident, there is such a high kinetic energy which is risk of poisoning! produced by small and light objects that they can cause severe injuries.
Page 75 Seats and Stowage Lashing eyes WARNING (continued) suitable lashing straps which are firmly attached to the lashing eyes. Never attach a child seat to the lashing eyes. Folding double hooks* Fig. 55 Luggage compartment: Lashing eyes Eyes are located on the sides of the loading area for lashing the goods to ⇒...
Page 76 Seats and Stowage Fixing of the floor covering of the luggage Luggage net* compartment Fig. 58 Luggage compartment: Luggage Fig. 57 Luggage compartment: Fixing of the floor covering The luggage net is designed for the tranportation of lighter objects. A loop (Fabia), a hook (estate car) or a folding handle with a hook (Sedan) is located on the floor covering of the luggage compartment.
Page 77 Seats and Stowage The luggage compartment cover* WARNING You can use the luggage compartment cover behind the No objects should be placed on the luggage compartment cover, head restraints for storing light and soft items. the vehicle occupants could be endangered if there is sudden braking or the vehicle collides with something.
Page 78: Net Partition (Estate)
Seats and Stowage Net partition (Estate)* – Pull the luggage compartment cover in direction of arrow ⇒ page 76, fig. – Hang the luggage compartment cover in the recesses on the Use behind the rear seats side of the luggage compartment. –...
Page 79 Seats and Stowage Unrolling WARNING (continued) – Fold down the rear seat backrests slightly forwards • First check for yourself that the cross road is inserted into the ⇒ page 70, which makes it possible to clear the access for mounts in the front position! unrolling the net partition.
Page 80 Seats and Stowage Use behind the front seats – Pull the net partiton net at the plate out of the housing ⇒ fig. – Insert the cross rod into the mount first on the one side and push the cross rod forward. –...
Page 81: The Roof Luggage Rack System
Seats and Stowage The roof luggage rack system* Removing and installing net partition housing Description Pay attention to the following points if you wish to transport luggage or other items on the roof of your vehicle: • A special roof luggage rack system was developed for the vehicle. That is why you should only use one of the roof luggage rack which has been released for use by Škoda Auto.
Page 82 Seats and Stowage Note Note • A roof rail is obtainable from a Skoda dealer if hasn't been fitted onto an The figure is not valid for an estate car. • estate car at the works. If you have any questions, please contact a Škoda dealer.
Page 83: Drinks Can Holder
Seats and Stowage Drinks can holder* Note holder Fig. 67 Dash panel: Fig. 68 Windscreen: Drinks can holder Note holder The drinks can holder is designed to place 0.33 litre drinks cans The note holder is designed for attaching a car park ticket in parking areas.
Page 84: Ashtray At The Front
Seats and Stowage Ashtray at the front* Ashtray at the rear* Fig. 70 Centre Fig. 69 Centre console: Ashtray at the console: Ashtray at the rear front Removing the ashtray insert Removing the ashtray insert – Fold out the ashtray cover and pull out the ashtray insert in the –...
Page 85: Cigarette Lighter* And Power Socket
Seats and Stowage Cigarette lighter* and power socket* – Insert the plug of the electrical appliance into the socket of the cigarette lighter. Cigarette lighter The 12 volt power socket can also be used to supply power to electrical accessories with a power uptake up to 180 watts. You can also use the socket on the cigarette lighter for other electrical appliances.
Page 86: Storage Compartments
Seats and Stowage Storage compartments Power socket in the luggage compartment (Estate car*, Sedan*) An overview You will find the following storage facilities in your vehicle: ⇒ page 86 Storage compartment on the front passenger side* ⇒ page 87 Storage compartments on the driver's side ⇒...
Page 87 Seats and Stowage Storage compartment on the front passenger side* Opening and closing the storage compartment on the front passenger side ⇒ fig. 73 – Pull the handle in the lid in direction of arrow and pull the lid down. –...
Page 88 Seats and Stowage Cooling of storage compartment on front passenger Storage compartments on the driver's side side* The storage compartment is for vehicles fitted with an air- conditioning system with a closable inlet for cooled air. Fig. 76 Dash panel: Storage compartments on the driver's side Fig.
Page 89 Seats and Stowage You can use the storage compartment, for example, to temper drinks WARNING (continued) cans, etc. • The pull-out storage compartment must always be kept closed If you do not use the air inlet in the storage compartment, the end when driving for safety reasons.
Page 90 Seats and Stowage Storage compartment in the front doors Storage compartment in the luggage compartment (Estate car)* Fig. 79 Stowage compartment in door Fig. 80 Luggage panel compartment: Storage compartments WARNING There are storage compartments situated on the right and the left in the luggage compartment.
Page 91 Seats and Stowage Rear armrest with stowage compartment* The armrest includes a stowage compartment. You open the compartment by pressing the button on the front side of the armrest and raising the ⇒ fig. cover Clothes hooks* Fig. 81 Rear seats: Armrest Fig.
Page 92: Heating
Heating and air conditioning system Heating and air conditioning system Heating Controlling blower – Turn the blower switch into one of the positions, 1 to 4, in order to switch the blower on. Using the system – Turn the blower switch into position 0 in order to switch the The heating system delivers air into the interior of the blower off.
Page 93 Heating and air conditioning system • Control dial   as required or to any desired position WARNING (continued) between these symbols • up. The risk of having an accident increases. Switch recirculated Close the air outlet vents 3 air mode off as soon as the windows begin misting up. •...
Page 94 Heating and air conditioning system • ⇒ page 93, fig. 85 Air outlet vents Open air outlet vents 3 and 4 The control dial can be set to other positions as required. Recirculated air mode In recirculated air mode air is sucked out of the interior of the vehicle and then fed back into the interior.
Page 95: The Air Conditioning System
Heating and air conditioning system You can set the air supply to the individual vents with the air distribution The heating effect is dependent upon the coolant temperature, thus full ⇒ page 91, fig. control 84. Air outlet vents 3 and 4 can also be opened heat output only occurs when the engine has reached its operating or closed individually.
Page 96 Heating and air conditioning system Controlling blower Note – Turn the blower switch into one of the positions, 1 to 4, in We recommend that you do not smoke in the vehicle when the recircu- order to switch the blower on. lating air mode is operating since the smoke which is drawn at the evap- orator from the interior of the vehicle forms deposits in the evaporator of –...
Page 97 Heating and air conditioning system Blower switch in position 2 Note Turn the air distribution control into the position  • The whole heat output will be needed to unfrost the windscreen and side windows. No warm air will be fed to the footwell. This can lead to Close the air outlet vents 3 restriction of the heating comfort.
Page 98 Heating and air conditioning system • Recirculated air mode Open the air outlet vents 3 and 4 • Switch on the air conditioning system by pressing button In recirculated air mode air is sucked out of the interior of • Switch on recirculated air mode by pressing button the vehicle and then fed back into the interior.
Page 99 Heating and air conditioning system Air outlet vents You can set the air supply to the individual vents with the air distribution ⇒ page 95, fig. control 86. Air outlet vents 3 and 4 can also be opened or closed individually. Unwarmed or cooled air will flow out of the air outlet vents according to the ⇒...
Page 100 Heating and air conditioning system • The cooling system has switched off automatically for a short time because the coolant temperature of the engine is too hot ⇒ page 13. If you are not able to rectify the operational problem yourself, or if the cooling capacity decreases, switch the air conditioning system off.
Page 101: Setting Steering Wheel Position
Starting-off and Driving Starting-off and Driving Setting steering wheel position* You can set the height and the forward/back position of the steering wheel to the desired position. – Adjust the driver seat ⇒ page 66. ⇒ fig. 88 – Pull the lever below the steering column down ⇒...
Page 102: Ignition Lock
Starting-off and Driving - heating glow plugs on, ignition switched on WARNING (continued) • You should not switch on any major electrical components during the the steering wheel firmly in the 12 o'clock position or in another heating period otherwise the vehicle battery will be drained unnecessarily. way (e.g.
Page 103: Starting Engine
Starting-off and Driving The engine running noises may louder at first be louder for a short time WARNING after starting the cold engine until oil pressure can be built up in the • hydraulic valve clearance compensation. This is quite normal and is not When driving, the ignition key must always be in the position an operating problem.
Page 104: Switching The Engine Off
Starting-off and Driving You should not switch on any major electrical components during For the sake of the environment the heating period otherwise the vehicle battery will be drained unnecessarily. Never warm up the engine when the vehicle is standing. Drive off right away.
Page 105: Shifting (Manual Gearbox)
Starting-off and Driving Shifting (manual gearbox) WARNING (continued) • The brake booster only operates when the engine is running. Greater physical effort for braking is required when engine is switched off. Because if you do not stop as normal, this can cause an accident and severe injuries.
Page 106: Handbrake
Starting-off and Driving • Depress the clutch pedal fully when changing gears, in order to avoid The handbrake warning light  lights up when the handbrake is applied, unnecessary wear and damage. provided the ignition is on. A warning signal sounds and the following text appears in the display* if you have inadvertently driven off with the handbrake applied: Handbrake "Handbrake on"...
Page 107: Parking Aid
Starting-off and Driving Parking aid* Activating The parking aid is activated automatically when reverse gear is engaged and the ignition is turned on. This is confirmed by a brief acknowledge- The parking aid provides a warning of obstacles behind ment signal. the vehicle.
Page 108: Cruise Control System (Ccs)
Starting-off and Driving Cruise control system (CCS)* Storing a speed Introduction The cruise control system (CCS) maintains a constant speed, more than 30 km/h (20 mph), once it has been set, without you having to depress the accelerator pedal. This is only possible within the range which is permitted by the power output and braking power of the engine.
Page 109 Starting-off and Driving The stored speed will be cancelled in the memory. You then have to re- – If you press and hold the button, the speed of the car is store the desired speed. reduced continuously. Once the car has reached the desired speed, release the button.
Page 110 Starting-off and Driving WARNING First ensure that it is not too high for the traffic conditions which exist at that moment before resuming the stored speed. Switching off the cruise control system completely ⇒ page 107, fig. 94 – Move the slide switch up to the stop into the OFF position.
Page 111: 4-Speed Automatic Gearbox
Automatic gearbox* Automatic gearbox* 4-speed automatic gearbox – Press and Shiftlock button in the selector lever, move the selector lever to P and then release the Shiftlock button. Information for driving with an automatic gearbox The engine can only be started when the selector lever is in position P or N ⇒...
Page 112 Automatic gearbox* Selector lever positions P - Parklock The driven wheels are locked mechanically in this position. The Parklock must only be engaged when the vehicle is stationary ⇒ If you wish to move the selector lever into or out of this position, you must press the Shiftlock button in the handle of the selector lever and at the same time depress the brake pedal.
Page 113 Automatic gearbox* 3 - Position when driving in hilly areas WARNING We recommend this position if driving with the selector lever in position D • would, in certain circumstances, result in the gearbox frequently shifting Never move the selector lever into position R or P when driving between the gears.
Page 114 Automatic gearbox* Selector lever lock Kickdown function The kickdown function provides you with maximum accel- Automatic selector lever lock  eration power. With the ignition on, the selector lever is locked when it is in the positions P and N. You must depress the brake pedal first and press the Shiftlock Depressing the accelerator pedal beyond the pressure point casues the button at the same time in order to move the selector lever out of these automatic gearbox to shift down into a lower gear (in line with vehicle...
Page 115 Automatic gearbox* down at higher engine speeds than is the case for the economy-oriented If the gearbox has switched over to emergency mode, drive to the programmes. nearest Škoda dealer in order to have the fault rectified. Selecting the most appropriate driving programme for the particular style of driving is a continuous process.
Page 116: Communication
Communication Communication Universal telephone connection* – Plug the adapter cable into the mobile phone socket. The power socket is located under the front passenger storage compartment. – Switch on the ignition. – Wait for approximately 15 seconds, switch off ignition. –...
Page 117: Mobile Phones And Two-Way Radio Systems
Communication Mobile phones and two-way radio WARNING (continued) systems which has been incorrectly installed, the result can be excessive electromagnetic fields which may cause harm to your health. • Please always pay full attention to the traffic situation around The installation of mobile phones and two-way radio systems in a vehicle you! should generally be undertaken by a Škoda dealer.
Page 118: Safety
Passive Safety Safety Passive Safety Basic information Safety equipment The safety equipment is part of the occupant protection Driving the safe way and it can reduce the risk of injuries in accident situations. Passive safety measures reduce the risk of injury in acci- “Do not put at risk”...
Page 119 Passive Safety • should be observed when using the equipment and how you and the Fasten the seat belt correctly. Also inform your occupants to properly fasten the seat belts ⇒ page 126, “How are seat belts correctly people travelling with you can make full use of the existing safety equip- ment.
Page 120: Correct Seated Position
Passive Safety Correct seated position Correct seated position for the driver Correct seated position for the driver is important for safe and relaxed driving. Fig. 99 The correct head restraint adjust- ment for the driver For your own safety and to reduce the risk of injury in the event of an acci- dent, we recommend the following setting.
Page 121 Passive Safety • Adjust the head restraint so that the top edge of the head restraint is WARNING (continued) ⇒ page 119, fig. at the same level as the upper part of your head • must always be correctly fastened in order to provide an optimal Fasten the seat belt correctly ⇒...
Page 122 Passive Safety Correct seated position for the occupants on the rear Examples of an incorrect seated position seats An incorrect seated position can lead to severe injuries or Occupants on the rear seats must sit upright, keep the feet death for the occupants. in the footwell and must have their seat belts correctly Seat belts offer their optimum protection only if the webbing of the seat fastened.
Page 123 Passive Safety • occupy the luggage compartment. WARNING • If the occupant adopts an incorrect seated position, he is exposed to life-threatening injuries, in case he is hit by a deployed airbag. • Before setting off, please adopt the correct seated position and do not change this seated position while the car is moving.
Page 124: Seat Belts
Seat belts Seat belts Why seat belts? also contribute to reducing the kinetic energy. The energy produced is thus absorbed and there is less risk of injury. Accident statistics prove that seat belts which are fastened and properly adjusted reduce the risk of an injury and enhance the chance of survival in a major accident ⇒...
Page 125: The Physical Principle Of A Frontal Collision
Seat belts The physical principle of a frontal As soon as the vehicle is moving, so-called kinetic energy (the energy of motion) is produced both in terms of the car as well as in terms of the collision occupants. The magnitude of this kinetic energy depends essentially on the speed at which the vehicle is travelling and on the weight of the vehicle and the occupants.
Page 126: Important Safety Information Regarding The Use Of Seat Belts
Seat belts Important safety information regarding WARNING (continued) the use of seat belts • The belt webbing must always be kept clean. Soiled belt webbing may impair proper operation of the inertia reel The correct use of the seat belts considerably reduces the ⇒...
Page 127: How Are Seat Belts Correctly Fastened
Seat belts How are seat belts correctly fastened? – Correctly adjust the front seat and the head restraint before fastening your seat belt ⇒ page 119, “Correct seated posi- tion”. Fastening a three-point seat belt – Slowly pull the belt webbing at the tongue of the lock over your Fasten your seat belt before starting! chest and pelvis ⇒...
Page 128 Seat belts – Then pull firmly on the belt to ensure that the seat belt height WARNING (continued) adjuster has correctly locked in place. • A seat belt which is hanging too loose can result in injuries as your body is moved forward by the kinetic energy produced in an accident and is then suddenly held firm by the belt.
Page 129 Seat belts ⇒ fig. – Press the red button in the belt lock 106. The spring force causes the tongue of the lock to jump out. – Guide the belt back with your hand to enable the inertia reel to wind up the belt webbing more easily.
Page 130: Belt Tensioners
Seat belts The belt tensioner is deployed in the event of a frontal collision of major WARNING severity. A powder charge is ignited in the inertia reels during deployment. • The belt webbing is pulled into the inertia reels by a mechanical system The pelvic belt must always sit firmly across the pelvis;...
Page 131: Airbag System
Airbag system Airbag system • Description of the airbag system the airbag indicator light does not go out after about 3 seconds after the ignition is switched on • the airbag indicator light goes out and comes on again after the ignition General information on the airbag system is switched on •...
Page 132 Airbag system Deployment factors WARNING (continued) It is not possible to state globally which deployment conditions apply to the • The service life of the airbag system is 15 years from the date of airbag system in every situation as the circumstances which exist in the manufacture of the vehicle.
Page 133: Front Airbags
Airbag system Front airbags Vehicles with an airbag system for the driver and front passenger* are recognisable by the lettering “AIRBAG” on the padded centre of the ⇒ fig. 109 steering wheel and on the right hand side of the dash panel Description ⇒...
Page 134 Airbag system Function of the front airbags The specially developed airbag allows the gas to flow out of the inflated airbag in a controlled manner (depending on the load of the particular car Risk of injury to the head and chest area is reduced by fully occupant) in order to cushion head and chest areas.
Page 135: Side Airbags
Airbag system WARNING (continued) WARNING removing system components because of other repair work (e.g. • Never transport children on the front seat of a vehicle without removing the steering wheel) must only be carried out by a Škoda using a proper restraint system. If airbags are deployed in the event dealer.
Page 136 Airbag system Function of the side airbags The side airbags are housed in the upholstery of the backrests of the front ⇒ fig. 113 seats and are marked with the lettering “AIRBAG” on the upper Risk of injury to the upper part of the body is reduced by part.
Page 137 Airbag system Important safety information on the side airbag WARNING (continued) Correct use of the airbag system considerably reduces the • Only hang light items of clothing on the clothes hooks to the risk of injury! vehicle. Never leave any heavy or sharp-edged objects in the pockets of the items of clothing.
Page 138: Deactivating An Airbag
Airbag system Deactivating an airbag Monitoring the airbag system The functionality of the airbag system is also monitored electronically, when one airbag has been switched off Deactivating airbags An airbag which has been switched off by a Škoda dealer using the vehicle system tester: If any airbags have been deactivated, switch them on •...
Page 139 Airbag system Switch for the front seat passenger airbags* Deactivating airbags – Switch off the ignition. – Turn the slot of the airbag switch using the ignition key in the ⇒ page 138, direction of the arrow to the position OFF fig.
Page 140 Airbag system In cases where the front passenger airbag or side passenger airbag is switched off the airbag indicator light comes on for a few seconds after switching on the ignition, goes out for about a second and then comes on again.
Page 141: Transporting Children Safely
Transporting children safely Transporting children safely What you should know about We recommend that you use child safety seats from the Škoda range of genuine accessories. These child seats were developed and also tested transporting children! for use in Škoda vehicles. They fulfil the standard ECE-R 44. An introduction to the subject WARNING Always comply with national legal provisions and instructions...
Page 142 Transporting children safely WARNING (continued) WARNING (continued) • otherwise this may result in injuries to the stomach and neck areas. Safety belts must be checked to ensure that they are running Comply with the national legal requirements. properly. One should also ensure that the belt is not damaged by •...
Page 143 Transporting children safely Use of child safety seats on the front passenger seat WARNING (continued) Child safety seats should always be attached to the rear • This is also clearly stated on the sticker which is located on the seats. ⇒...
Page 144 Transporting children safely Child safety and side airbags* Side airbags* offer the vehicle occupants enhanced protection in the event of a collision from the side. Children must never be seated in the deployment area of The side airbags are inflated in fractions of a second in order to be able to side airbags.
Page 145: Child Seat
Transporting children safely Use of child seats WARNING (continued) • Do not place any objects within the deployment area of the side An overview of the usefulness of child seats on each of the seats airbag - risk of injury! according to the EG guidelines 77/541 and ECE 44 standard: Child seat Front passenger...
Page 146 Transporting children safely Child seats of Group 0/0+ WARNING (continued) − by allowing a Škoda dealer to do this − or by using the switch for the front passenger airbag* ⇒ page 138. • The national legal provisions in certain countries require that both the front and side passenger airbags be deactivated.
Page 147 Transporting children safely Child safety seats in Group 2 Child seats in Group 1 are for babies and small children up to 4 years of age with a weight of between 9 and 18 kilograms. It is best for children in the lower range of this group, to use a child seat which allows the child to sit with its back to the direction of travel.
Page 148 Transporting children safely WARNING (continued) WARNING belt must run across the pelvis and fits snugly; it must not run over • When transporting a child on the front passenger seat, please the belly. Tighten the belt webbing over your hip if necessary. comply with the appropriate national regulations regarding the use •...
Page 149: Attaching A Child Seat Using The "Isofix"* System
Transporting children safely Attaching a child seat using the There are two fixing eyes between the backrest and the seat itself on both of the outer rear seats for fixing the “ISOFIX” system child “ISOFIX”* system seat in place. – Insert the mounting funnels onto the locking eyes ⇒...
Page 150 Transporting children safely WARNING (continued) • Ask a Škoda dealer whether a child seat which you bought for another vehicle is recommended for use in a Škoda before using an “ISOFIX” system. • Certain child seats which use the “ISOFIX” system can be attached with standard three-point seat belts.
Page 151 Transporting children safely...
Page 152: Driving Tips
Intelligent Technology Driving Tips Intelligent Technology • Electronic stability programme (ESP)* Electronic Differential Lock (EDL) • Traction control system (TCS) • Antilock brake system (ABS) General Operating principle The ESP switches on automatically when the engine is started and then conducts a self-test.
Page 153 Intelligent Technology • The ESP warning light ⇒ page 34 lights up in the instrument cluster when Changes to vehicle (e.g. on engine, on the brakes, on chassis or other there is a fault on the ESP. assignment of tyres and wheels) can influence the function of the ESP ⇒...
Page 154 Intelligent Technology mitted to the road surface is automatically adapted by reducing the engine Note speed. This occurs at all speeds. • All four wheels must be fitted with the same tyres in order to achieve The TCS operates in combination with the ABS ⇒ page 155, “Antilock problem-free operation of the TCS.
Page 155: Brakes
Intelligent Technology which is being braked. The vehicle can continue to be driven and has the a great deal in towns and over short distances or if you adopt a sporty style same characteristics as a vehicle not fitted with EDL. of driving, it may be necessary to have the thickness of the brake pads inspected at a Škoda dealer between the service inspections.
Page 156: Brake Booster
Intelligent Technology Brake booster Low brake fluid level An insufficient level of brake fluid may result in problems in the brake system. The level of the brake fluid is monitored electronically ⇒ page 35, The braking force boosts the pressure which you generate with the brake “Brake system ”.
Page 157: Power Steering
Intelligent Technology Power steering* Operating principle As soon as the vehicle speed has increased to about 20 km/hour an auto- matic test procedure is conducted during which you will be able to hear a The power steering enables you to steer the vehicle with less physical pumping noise for about 1 second.
Page 158: Driving And The Environment
Driving and the Environment Driving and the Environment The first 1 500 kilometres and then speed is marked by the beginning of the red zone on the scale of the revo- lutions counter. Shift up into the next higher gear on a vehicle fitted with afterwards manual gearbox before the red zone is reached.
Page 159: Catalytic Converter
Driving and the Environment New brake pads – Do not tow-start the vehicle over a distance of more than 50 metres ⇒ page 222, “Tow-starting a vehicle”. Allow for the fact that new brake pads do not achieve their full braking effi- ciency until approximately 200 kilometres.
Page 160: Driving In An Economical And Environmentally Conscious Manner
Driving and the Environment The technical requirements for low fuel usage and economic efficiency of For the sake of the environment the vehicle have already been built into the vehicle at the works. Special attention has been given to minimising negative effects on the environ- Even if the exhaust system is operating properly, a sulphur-like exhaust ment.
Page 161 Driving and the Environment Shifting gears and saving energy Only depress the accelerator pedal slowly if your vehicle is fitted with an automatic gearbox in order to automatically select an economic driving Shifting up early saves on fuel. programme. You will achieve good fuel economy by shifting up early and shifting down late.
Page 162 Driving and the Environment You should avoid fully exploiting the top speed of your vehicle wherever A poorly tuned engine can result in a fuel consumption which is 10% possible. Fuel consumption, pollutant emissions and vehicle noises higher than normal. increase disproportionally at high speeds.
Page 163 Driving and the Environment Avoid driving short distances An important factor in this connection is also the ambient temperature. ⇒ fig. 130 shows the different fuel consumptions for the same Short distances result in an above-average high fuel distance, on the one hand at +20°C and on the other hand at -10°C. Your vehicle has a higher fuel consumption in winter than in summer.
Page 164: Environmental Compatibility
Driving and the Environment Environmental compatibility your vehicle causes it to use about 1 l more fuel than normal at a speed of 100 - 120 km/h, even when you are not carrying a load on the roof. Environmental protection has played a major role in the design, selection of materials and manufacture of your new Škoda.
Page 165: Motoring Abroad
Driving and the Environment Motoring abroad Headlights with Xenon lamps are designed for driving in countries with traffic on the right or on the left. Have this done always at a Škoda dealer. General Note Other circumstances may exist abroad. You can obtain further information regarding masking over or converting the headlights from your Škoda dealer.
Page 166: Towing A Trailer
Towing a trailer Towing a trailer Towing a trailer WARNING (continued) the relevant details relating to retrofitting such equipment. There is Technical requirements a risk of an accident if the towing device is not properly fitted! The towing device must satisfy certain technical require- ments.
Page 167 Towing a trailer Driving Tips Distribution of the load Distribute the load in the trailer in such a way that any heavy items are Particular caution is required when towing a trailer. located as close as possible to the axle. Secure the items to prevent them slipping.
Page 168: Detachable Towing Device
Towing a trailer Detachable towing device* before negotiating a downhill section to allow the engine to also act as a brake. Engine overheating Please keep a check on the coolant temperature gauge if you have to negotiate a lengthy slope in a low gear at a high engine speed when the outside temperature is very high ⇒...
Page 169 Towing a trailer WARNING (continued) that the safety of the towing device is no longer assured - risk of an accident. Note • Do not carry out any modifications or repairs to the ball head or to any other components on the towing device. •...
Page 170: General Maintenance
Care and cleaning General Maintenance Care and cleaning General Care of the exterior of vehicle Proper care retains the value of your vehicle. Washing the vehicle Regular and proper care retains the value of your vehicle. It may also be Frequent washing protects your vehicle.
Page 171 Care and cleaning Washing vehicle by hand WARNING It is important to first soften the dirt with plenty of water and rinse it off as When washing your vehicle in the winter: Water and ice in the brake thoroughly as possible before washing your vehicle by hand. system can affect the braking efficiency - risk of accident.
Page 172 Care and cleaning Wax treatment For the sake of the environment Only wash your vehicle at washing bays specifically reserved for this Good wax treatment is an effective way of protecting the paintwork from purpose. This ensures that no water which may be contaminated by oil harmful environmental influences and minor mechanical damage.
Page 173 Care and cleaning Chrome parts Plastic parts First clean the chrome parts with a damp clotch and then polish them with External plastic parts are cleaned by normal washing. Plastic parts and a soft, dry cloth. If it does not prove to be adequate, use a chrome care synthetic leather can also be treated with special solvent-free plastic product from Škoda original accessories.
Page 174 Care and cleaning Locks Caution Never remove snow or ice from the windows with warm or hot water - risk We recommend that you use the spray from Škoda original accessories of formation of cracks in the glass! with regreasing and anticorrosive effect for de-icing locks. Note The headlight lenses When washing your vehicle, ensure that as little water as possible gets...
Page 175 Care and cleaning Protection of hollow spaces WARNING All the cavities of your vehicle which are at risk from corrosion are One should remember when cleaning the wheels that moisture, ice protected for life by a layer of protective wax applied in the factory. and road salt may adversely affect braking efficiency - risk of an accident! This wax protection does not require to be inspected or re-treated.
Page 176: Care Of The Interior Of Vehicle
Care and cleaning Fabric covers of electrically heated seats Caution • Engine cleaning may be only be undertaken when the ignition is off. Do not clean the seat covers moist as this may result in damage to the • It is recommended to cover the generator before washing the engine seat heating system.
Page 177 Care and cleaning – Remove fresh stains which are oil based (e.g. butter, mayon- Note naise, chocolate etc.) with an absorbent cloth or household • Use a care cream with light blocker and impregnation effect regularly cleaning paper or with the cleaner from the care set if the stain and each time after cleaning the leather.
Page 178 Care and cleaning WARNING (continued) • Seat belts which have damage to the webbing, the connections, the inertia reel or the lock should be replaced by a Škoda dealer. • Inertia reel belts must be completely dried before being reeled Using the system Safety Driving Tips...
Page 179: Fuel
Fuel Fuel Petrol You can make unlimited use of fuel which has a higher octane number than that required by the engine. There will, however, be no advantages gained by this in terms of engine performance and fuel consumption! Grades of petrol The handling, performance and life of your engine are determined to a significant extent by the quality of the fuel.
Page 180 Fuel Fuel additives When using biofuel pay attention to the following points: • You must not use fuel additives, so-called “flow improvers” (petrol and The Performance may be reduced slightly if you switch to driving with similar products) in diesel fuel. biofuel.
Page 181: Refuelling
Fuel Prewarming fuel The vehicle is fitted with a fuel filter prewarming system. This secures operation of a vehicle using diesel fuel down to an environmental temper- ature of -25°C. Biofuel We recommend refuelling with diesel fuel at temperatures below -10°C. Caution It is not permitted to add the various fuel additives on the market, including petrol, to diesel fuel in order to improve its flow properties.
Page 182 Fuel – The fuel filler cap on the fuel filler tube must be locked to the continue refuelling - otherwise the expansion chamber in the fuel tank will also be filled with fuel. Fuel might flow out of the tank when it heats up. right using the vehicle key and the key then removed (only valid for vehicles which do not have remote unlocking of the fuel filler flap next to the driver's seat).
Page 183: Inspecting And Replenishing
Inspecting and Replenishing Inspecting and Replenishing Engine compartment Opening and closing the bonnet. Bonnet remote release Fig. 135 Radiator grille: handle Fig. 134 Bonnet release lever Bonnet remote release – Pull the unlocking lever below the dash panel on the driver's ⇒...
Page 184 Inspecting and Replenishing Opening the bonnet WARNING (continued) ⇒ page 182, fig. – Unlock the bonnet 134. • Stop your vehicle immediately while driving if you notice that the lock is not properly engaged and close the bonnet properly - –...
Page 185 Inspecting and Replenishing WARNING (continued) WARNING (continued) • Hazard! Therefore remove any jewellery beforehand, tie up your If your vehicle is fitted with a manual gearbox, move the gear- hair and wear tight fitting clothing. shift lever into Neutral, or if it is fitted with automatic gearbox, move •...
Page 186: Engine Oil
Inspecting and Replenishing Engine oil Overview of the engine compartment The main inspection points Engine oil specifications The grade of engine oil should be selected in accordance with precise specifications. The engine of your vehicle has been factory-filled with a high-grade oil which you can use throughout the year - except in extreme climatic regions.
Page 187 Inspecting and Replenishing Inspecting the engine oil level Engine oil specifications for models with flexible service intervals (QG1) The dipstick indicates the level of oil in the engine. Engine oil specifications Petrol engines VW 503 00 VW 506 01 Diesel engines VW 506 00 This does not apply for PDi engines (a unit injection engine).
Page 188 Inspecting and Replenishing Checking the oil level trip during the summer months, towing a trailer or negotiating a high mountain pass, but not above this. – Park the vehicle on a horizontal surface. The warning light in the instrument cluster* will indicate ⇒ page 32 –...
Page 189 Inspecting and Replenishing – Carefully screw on the cap of the filler opening and push the WARNING (continued) dipstick in fully. • Wear an eye protection - risk of caustic burns due to oil splashes. • WARNING Oil is toxic! Store old oil in a safe place out of the reach of chil- •...
Page 190: Cooling System
Inspecting and Replenishing Cooling system Your Škoda dealer can also supply you with the correct coolant additives. Caution Coolant • Other coolant additives may cause operational problems which, The job of the coolant is to cool the engine. in particular, involves significantly reducing the anticorrosion effect. •...
Page 191 Inspecting and Replenishing – Open the bonnet ⇒ Replenishing the coolant in “Working in the engine compart- ment” on page 183. – Switch the engine off. – Check the level of coolant in the coolant expansion bottle ⇒ page 189, fig. 140.
Page 192: Brake Fluid
Inspecting and Replenishing The radiator fan may continue running for up to 10 minutes after the WARNING (continued) engine has been switched off - even if the ignition is also off. It may also • switch on suddenly after a certain time, if The coolant additive and thus all of the coolant is harmful to your health.
Page 193 Inspecting and Replenishing Replacing brake fluid The brake fluid reservoir is located on the left of the engine compartment. The brake fluid reservoir on right-hand steering models is positioned on the other side of the engine compart- Brake fluid absorbs moisture. This causes the fluid to absorb moisture ment.
Page 194: The Battery
Inspecting and Replenishing The battery The battery is located in the engine compartment below a cover*. – Pull off the catch on the side of the battery cover , place the Working on the battery battery cover at about 45° and remove the battery cover in ⇒...
Page 195 Inspecting and Replenishing WARNING (continued) Caution • or a shield! There is the danger of suffering blindness! If any You must only disconnect the battery if the ignition is switched on, battery electrolyte gets into your eye, rinse out your eye immedi- otherwise the electrical system (electronic components) of the vehicle ately with clear water for several minutes.
Page 196 Inspecting and Replenishing Battery with a charge level indicator, the so-called Caution magic eye* If the vehicle has not been driven for more than 3 to 4 weeks, the battery will discharge gradually as a result from electrical components such as the central control unit which are not switched off.
Page 197 Inspecting and Replenishing Charging the battery It is, however, necessary to disconnect both cables before charging the battery with high amperages, so-called “quick-charging”. A properly charged battery is essential for reliably starting “Quick-charging” a battery is dangerous ⇒ in “Working on the battery” the engine.
Page 198: Windscreen Wiper And Washer System
Inspecting and Replenishing Windscreen Wiper and Washer System Operation Operating measure ⇒ page 50 Electrical power window (operational faults) Enter radio code number see Radio Operating Instructions ⇒ page 16 Setting clock ⇒ page 17 Data in the multi-functional indicator* are deleted.
Page 199 Inspecting and Replenishing ated spirits must not be more than 15 %. Please note, however, that the antifreeze protection at this concentration is only adequate down to -5°C. WARNING Read and observe the warning notes ⇒ page 183 before working in the engine compartment.
Page 200: Wheels And Tyres
Wheels and Tyres Wheels and Tyres Wheels Unidirectional tyres* The direction of rotation of the tyres is marked by arrows on the wall of the tyre. This indicates the direction of rotation of the tyre, and it is essential General comments that the tyres are fitted on to run in this direction.
Page 201 Wheels and Tyres Tyre life Always check the inflation pressure of tyres when cold. Do not reduce the higher pressure of warm tyres. Adapt the inflation pressure of the tyres accordingly if your vehicle is carrying a significantly higher payload. Driving style Fast cornering, sharp acceleration and braking (squealing tyres) increase wear-and-tear on your tyres.
Page 202 Wheels and Tyres Wear indicators WARNING (continued) planing” (uncontrolled movements of the vehicle - “swimming” on a wet road surface). Changing wheels around Fig. 147 Tyre tread with wear indicators The base of the tread of the original tyres has wear indicators 1.6 mm high, installed at right angles to the direction of travel.
Page 203 Wheels and Tyres New tyres and wheels Diameter of wheel in inches Load index Tyres and wheel rims are important design elements. One should there- Speed symbol fore use the tyres and wheel rims which have been released for use by Škoda Auto.
Page 204 Wheels and Tyres Wheel bolts WARNING • Wheels and wheel bolts are matched to each other in terms of design. Only use those tyres or wheel rims which have been approved Each time you fit other wheels - e.g. light alloy wheels or wheels with for your model of Škoda Auto vehicle.
Page 205 Wheels and Tyres Winter tyres Please contact your Škoda dealer If there are any points which are not clear who will be able to provide you with information regarding the maximum speed for your tyres. The handling of your vehicle will be significantly improved when driving on wintry roads and at temperatures below 7 °C if you fit winter tyres.
Page 206 Wheels and Tyres important on wet roads. Please refer to the notes ⇒ page 212, “Spare Note wheel*”. We recommend that you use snow chains from the Škoda genuine You should have the defective tyre replaced as soon as possible and accessories.
Page 207: Accessories, Changes And Replacement Of Parts
Technical changes • Škoda accessories which have been released for use and original Skoda parts can be obtained from Škoda dealers. They will install them professionally and correctly. Interference on the electronic components and their software can lead to •...
Page 208 Accessories, changes and replacement of parts WARNING Work or modifications on your vehicle, which have been carried out unprofessionally, can cause operational faults - risk of accident! Using the system Safety Driving Tips General Maintenance Breakdown assistance Technical Data...
Page 209 Accessories, changes and replacement of parts...
Page 210: Breakdown Assistance
Breakdown assistance Breakdown assistance Breakdown assistance First-aid box* and warning triangle* and fixing them to the floor of the luggage compartment using velcro fasteners. Room for the warning triangle and first-aid box on vehicles of the type Estate car is found in the well under the carpet of the luggage compart- ment behind the spare wheel.
Page 211: Vehicle Tool Kit
Breakdown assistance The vehicle tool kit and the lifting jack are stored in a locable plastic box WARNING ⇒ fig. in the spare wheel 150. There is also space here for the removable ball for the trailer towing device*. If the fire extinguisher is not correctly attached, in case of sudden manoeuvres or an accident it can be “thrown”...
Page 212: Spray For Repairing A Tyre
Breakdown assistance Spray for repairing a tyre* Note Vehicles which do not have a spare wheel have the spray bottle stored in a box under the luggage compartment floor. Tyre repair kit* The tyre repair kit is intended for the repair of minor tyre defects. The tyre repair kit contains a compressor, inflation bottle, operating instructions and accessories.
Page 213: Spare Wheel
Breakdown assistance • Spare wheel* Do not drive with this spare wheel at more than 80 km/h - risk of acci- dent. Avoid accelerating at full throttle, sharp braking and fast cornering. • The spare wheel is stowed in the spare wheel well in the The inflation pressure for this spare wheel is identical to the inflation pressure of the standard tyres.
Page 214 Breakdown assistance – If a trailer is coupled, uncouple it. – In the case of light alloy wheels remove the wheel trim cap ⇒ page 215. – Take the vehicle tool kit and the spare wheel ⇒ page 210 – Slacken the wheel bolts ⇒ page 216. out of the luggage compartment.
Page 215 Breakdown assistance Full wheel trim* – Stow and attach the replaced wheel in the spare wheel well. – Stow the vehicle tool kit in the space provided. – Check the tyre pressure on the spare wheel just mounted as soon as possible. –...
Page 216 Breakdown assistance Wheel bolts with caps* Caution • The caps are designed to protect the wheel bolts. Use the pressure of your hand, do not knock on the full wheel trim! Heavy knocks mainly on the points where the full wheel trim has not been inserted into the wheel, can result in damage to the guide and centering elements of the full wheel trim.
Page 217 Breakdown assistance Slackening and tightening wheel bolts WARNING Slacken the wheel bolts before jacking up the vehicle. Slacken the wheel bolts only a little (about one turn) as long as the vehicle has not yet been jacked up - risk of an accident!. Note •...
Page 218 Breakdown assistance – Position the lifting jack by selecting the jacking point - lower sill WARNING (continued) ⇒ page 216, - which is closest to the wheel to be removed • fig. 157. It is important to support the vehicle with suitable supporting blocks if you wish to work under the lifted vehicle - risk of injury! –...
Page 219: Jump-Starting
Breakdown assistance – Slacken the wheel bolt, or tighten it firmly ⇒ page 216. Jump-starting – Reinstall the full wheel trim/wheel cap after removing the adapter or place the cap onto the safety wheel bolt. Initial steps – Have the tightening torque checked with a torque wrench as You can use the battery of another vehicle for jump-starting yours if the soon as possible.
Page 220 Breakdown assistance • Switch off any mobile phone, pay attention to the instructions for use Connecting negative terminal and engine block of the mobile phone in such a situation. – Attach one end to the negative terminal of the battery •...
Page 221: Tow-Starting And Towing Vehicle
Breakdown assistance Driver of the towed vehicle WARNING (continued) – Switch the ignition on so that the steering wheel is not blocked • Do not affix the cable end to parts of the fuel and brake and you can also operate the turn signal lights, the headlight system.
Page 222 Breakdown assistance Front towing eye damage resulting at the points to which you attach the tow rope or tow bar when you attempt to tow a vehicle which is not standing on a paved road. The towing eye is stored in the box for the vehicle tool kit. Caution If the gearbox of your vehicle no longer contains any oil because of a defect, your vehicle must only be towed in with the driven wheels raised...
Page 223 Breakdown assistance Rear towing eye – Stick a screwdriver through the opening of the protective grille ⇒ fig. 160 (near the licence plate) and press downwards thereby pressing off the spring clip on the protective grille. Grab the edge of the protective grille by the hand at the same time (arrow ) and loosen it.
Page 224 Breakdown assistance Towing of a vehicle with an automatic gearbox – Switch on the ignition. – Wait until both vehicles are moving then release the clutch Please refer to the notes ⇒ page 220. pedal slowly. The car can be towed in with a tow bar or a tow rope. Refer at the same –...
Page 225: Fuses And Light Bulbs
Fuses and light bulbs Fuses and light bulbs Electric fuses – Find out which fuse belongs to the component which is not operating ⇒ page 225, “Fuse assignment in the dash panel”. – Defect fuses can be detected by their melted metal strips. Replacing fuses Replace the defect fuse by a new fuse of the same ampere Defect fuses must be replaced.
Page 226 Fuses and light bulbs Colour Maximum amperage No. Power consumer Amperes yellow Not assigned white 10 Central control unit green 11 The air conditioning system 12 Not assigned Caution 13 Automatic gearbox • Never attempt to “repair” fuses and also do not replace them with a 14 Not assigned fuse of a higher amperage - risk of fire! This may also cause damage at 15 Not assigned...
Page 227 Fuses and light bulbs No. Power consumer Amperes No. Power consumer Amperes Right main beam Instrument cluster, ESP Engine electronics Brake lights Control unit for ABS, TCS Power supply for the diagnostics, air-conditioning control unit for ESP system Not assigned Interior lighting Not assigned Door warning light...
Page 228: Bulbs
Fuses and light bulbs No. Power consumer Amperes For power consumers, e.g. the radio, which can be operated with the ignition switched off as long as the ignition key is not withdrawn. Radio, navigation system For vehicles with an electrical power window system Electrical power window (at the front on the right) It is 15 amps for a vehicle with a 1.2 litre engine.
Page 229 Fuses and light bulbs The set of light bulbs can be stowed in the spare wheel well. Others Bulb Fitted with a xenon headlight Reading lights Change of light bulbs on Xenon lights (low beam lights, parking lights and Luggage compartment light main beam lights) should be undertaken by a Škoda dealer.
Page 230 For vehicles with a 2.0 litre/85 kW engine, we recommend that you have at the front the light bulbs for the main beam lights, low beam lights and parking lights changed by a Skoda dealer. Fig. 166 Front head- light: Installing the light...
Page 231 Fuses and light bulbs Main beam – We recommend that you have the headlight setting checked by a Skoda dealer after replacing the light bulb. Parking light at the front Fig. 167 Structure of the light bulb of the main beam light –...
Page 232 – Plug in plug 169. – We recommend that you have the headlight setting checked Low beam by a Skoda dealer after replacing the light bulb. Turn signal light (at the front) Fig. 169 Structure of the light bulb of the low beam light –...
Page 233 Fuses and light bulbs – Insert the new light bulb and turn it fully to the right. – Recreate the plug connection. – Insert the lamp holder with new light bulb into the headlight. – Press the light into the glove compartment from below. Secure the lamp holder by turning it to the right.
Page 234 Fuses and light bulbs Licence plate light Front door warning light* Fig. 173 Remove the Fig. 174 Remove the licence plate light front door warning light – Open the tailgate and screw off the light glass. We recommend having the light bulb replaced by a Škoda dealer. –...
Page 235 Fuses and light bulbs Rear light unit Rear light unit (Estate car, Sedan) Fig. 176 Remove the Fig. 175 Remove light light bulb holder bulb holder (estate car, sedan) – Open the boot lid/luggage compartment door. – Open the boot lid/luggage compartment door. –...
Page 236 Fuses and light bulbs Luggage compartment light Boot light (Sedan) Fig. 177 Remove the Fig. 178 Remove the luggage compartment boot light (sedan) light – Open the tailgate and remove the luggage compartment cover. ⇒ fig. – Insert a screwdriver into the slot under the light 178.
Page 237 Fuses and light bulbs...
Page 238: Technical Data
General Technical Data General Identification data Vehicle identification number (VIN) The vehicle identification number - VIN (vehicle body number) is stamped into the engine compartment on the right hand shock absorber dome. This number is also located on a sign on the lower left hand edge below the windscreen.
Page 239 General • Please note that the information stated in the official vehicle registra- tion documents always takes priority.
Page 240: Index
Index Index Automatic gearbox ....110 Button on the driver's door Emergency programme ... . . 114 Central locking system .
Page 241 Index Cleaning ......169 Diesel engines Electronic stability programme (ESP) ..151 Starting engine .
Page 242 Index Fog lights ......55 Hazard warning light system ... . . 56 ISOFIX system .
Page 243 Index Locking of the door Power windows ..... . . 49 in an emergency ....44 Central locking system .
Page 244 Index Safety instructions Starting the engine ....102 The roof luggage rack system ... . 80 Engine compartment .
Page 245 Index Wheel bolts ......203 Safety ......217 Underbody protection .
Page 246 SIMPLY CLE VER ŠkodaService ŠkodaGenuine Parts ŠkodaGenuine Accessories...
Page 247 The noise level and wear and tear are also inﬂu- Make your contribution - for the sake of enced by how you personally handle your vehi- www.skoda-auto.com the environment. cle. This Owner ´ s Manual tells you how to drive...

Skoda Fabia 2005 Owner's Manual

Layout of this Owner's Manual (Explanations)

Using the System

Safety

Driving Tips

General Maintenance

Breakdown Assistance

Technical Data

Index

Quick Links

Related Manuals for Skoda Fabia 2005

Summary of Contents for Skoda Fabia 2005

Table of Contents
