Everex StepNote SA2053T Specifications

Everex recommends Windows Vista™ Home Premium
Everex StepNote SA2053T Detailed Product Specification
®
StepNote SA2053T, Genuine Windows Vista™ Home Premium, Intel
DVD-ROM/DVD+/-RW with Double Layer support, 12.1" WXGA Widescreen Display with DiamondBrite Technology, Intel
950, WLAN 802.11b/g, 1-year standard limited warranty, UPC: 853031001481

Operating System

• Genuine Windows Vista™ Home Premium
Processor
•
® ®
Intel Pentium Dual-Core Processor T2080
(1MB L2 Cache, 1.73GHz, 533MHz)
Chipset
•
®
Northbridge: Intel 943GML
•
®
Southbridge: Intel ICH7-M
Memory
•
Configured with 1GB DDR2 533MHz SDRAM
•
Total Slots: 1 SO-DIMM
•
Maximum Capacity: 1GB
Hard Disk Drive
•
Size: 100GB
•
Bus: Serial-ATA (SATA-150)
•
Rotation: 5400RPM
•
Height: 9.5mm

Optical Disk Drive

•
DVD-ROM/DVD+/-RW with Double Layer support
(Maximum speed and compatibility: 4X DVD+R DL, 4X
DVD-R DL, 6X DVD-RW, 8X DVD+RW, 8X DVD+R, 8X
DVD-R, 8X DVD-ROM, 24X CD-RW, 24X CD-R, 24X CD-
ROM)
Display
•
12.1" Diagonal WXGA Widescreen Display with
DiamondBrite Technology
•
TFT Active Matrix LCD
•
Native Resolution: 1280 x 800
Graphics
• ®
Intel Graphics Media Accelerator (GMA) 950
•
Windows Vista™ Aero Glass support
•
Memory: Up to 224MB share via DVMT 3.0 (Dynamic Video
Memory Technology)
Sound
•
Built-in Stereo Speakers
•
Built-in Microphone
•
Realtek ALC262-VC-GR High-Definition Audio Codec
(Analog: 20-Bits Max Resolution, 192kHz Max Sampling;
Digital: 24-Bits Max Resolution, 96kHz Max Sampling)

Input Devices

•
84-key US keyboard with Hot Keys Functions
•
Touchpad Pointing Device with Integrated Vertical and
Horizontal Scroll Functions
Communications
•
Motorola SM56 Data Fax Modem
(V.92, 56kbps, actual speeds may vary)
•
Realtek RTL8139 Family Fast Ethernet NIC
(10/100 Base-TX Ethernet)
•
Ralink RT2571WF Wireless Network Adapter 802.11b/g
Copyright 2007. Everex and the Everex logo are trademarks of Everex Systems, Inc. All other company and product names may be trademarks of their respective companies. All specifications are subject to change without notice. Published materials may contain inaccuracies and typographical
errors. Everex does not warrant the accuracy or completeness of the materials or the reliability of any advice, opinion, statement or other information displayed or distributed through Everex. Reliance on any such opinion, advice, statement, memorandum, or information shall be at the sole
discretion of the user. Everex reserves the right to correct any errors or omissions in any portion of these materials at any time without notice. The information and materials presented and the references made available, are provided "As Is" without any representation or warranty, express or
implied, of any kind, including, but not limited to, warranties of merchantability, non infringement, or fitness for any particular purpose, some jurisdictions do not allow for the exclusion of implied warranties, so the above exclusions may not apply.
Everex StepNote SA2053T Detailed Specification-v1.3, 3/2/2007 11:44:00 AM
® ®
Pentium Dual-Core Processor T2080, 1GB DDR2 SDRAM, 100GB SATA HDD,
Expandability
•
1 ExpressCard 54 (Also fits ExpressCard 34)
•
4-in-1 Media Card Reader
(Secure Digital, Multi Media Card, Memory Stick, Memory
Stick PRO)
Ports
•
Video: 1 VGA output port
•
Audio: 1 Microphone input port, 1 Headphone output port
•
Data: 1 IEEE1394 (4-pin), 3 USB 2.0 ports, RJ-45 LAN
port, RJ-11 Modem port
System Physical Description
•
Dimensions: 11.69" (297mm) x 8.39" (213mm) x 1.31"
(33.3mm) front ~ 1.44" (36.5mm) rear (L x W x H)
•
Weight: 3.86lbs (1.75kg) when equipped with 3-cell
battery
•
Indicators: Power, WLAN Status, HDD/ODD Status, Caps
Lock Status, Num Lock Status, Battery Status
•
Switches: Power, WLAN
•
Physical Security: Provision for Kensington Lock
AC Adapter
•
65W (20V@3.25A) Auto sensing external AC Adapter (100-
240V~1.5A, 50-60Hz)
•
Dimensions: 4.25" (107mm) x 1.75" (44.45mm) x 1.13"
(28.70mm) (L x W x H)
•
Weight: 0.7lb (0.32kg)
•
3-Prong US Power Cord

Primary Battery

•
3-Cell (11.1V, 2000mAh) rechargeable, removable
Lithium-Ion Battery
•
Dimensions: 7.99" (203mm) x 1.65" (42mm) x 0.79"
(20mm) (L x W x H)
•
Weight: 0.38lb (0.17kg)
Additional Battery (Included)
•
6-Cell (11.1V, 4400mAh) rechargeable, removable
Lithium-Ion Battery
•
Dimensions: 7.99" (203mm) x 1.65" (42mm) x 0.79"
(20mm) (L x W x H)
•
Weight: 0.71lb (0.32kg)

Preinstalled Software

•
CyberLink DVD Suite
• Norton Internet Security™ 2007 (90-day subscription
service included)
®
Graphics Media Accelerator
Page 1 of 1
