Everex StepNote NC1502 Specifications

Everex recommends Windows Vista™ Home Premium
Everex StepNote NC1502 Detailed Product Specification
®
StepNote NC1502, Genuine Windows Vista™ Home Basic, 1.5GHz VIA C7
RW with Double Layer support, 15.4" WXGA Widescreen Display with DiamondBrite Technology, VIA Chrome9™ HC IGP, WLAN 802.11b/g, 1-year
standard limited warranty, UPC: 853031001498

Operating System

• Genuine Windows Vista™ Home Basic
Processor
®
• 1.5GHz VIA C7 -M Processor
(128KB L2 Cache, 1.5GHz, 400MHz)
Chipset
• Northbridge: VIA VN896
• Southbridge: VIA VT8237A
Memory
• Configured with 512MB DDR2 533MHz SDRAM
• Total Slots: 2 SO-DIMM
• Maximum Capacity: 2GB
Hard Disk Drive
• Size: 80GB
• Bus: Serial-ATA (SATA-150)
• Rotation: 5400RPM
• Height: 9.5mm

Optical Disk Drive

• DVD-ROM/DVD+/-RW with Double Layer support
(Maximum speed and compatibility: 4X DVD+R DL,
4X DVD-R DL, 6X DVD-RW, 8X DVD+RW, 8X
DVD+R, 8X DVD-R, 8X DVD-ROM, 24X CD-RW,
24X CD-R, 24X CD-ROM)
Display
• 15.4" Diagonal WXGA Widescreen Display with
DiamondBrite Technology
• TFT Active Matrix LCD
• Native Resolution: 1280 x 800
Graphics
• VIA Chrome9™ HC IGP
• DirectX 9.0 Support
• Memory: 64MB shared (default), 128MB Maximum
shared memory
Sound
• Built-in Speaker
• VIA VT1708A Vinyl High-Definition Audio Codec
(Analog: 24-Bits Max Resolution, 192kHz Max
Sampling; Digital: 24-Bits Max Resolution, 96kHz
Max Sampling)

Input Devices

• 86-key US keyboard with Hot Keys Functions
• Touchpad Pointing Device with Integrated Vertical
and Horizontal Scroll Functions
Copyright 2007. Everex and the Everex logo are trademarks of Everex Systems, Inc. All other company and product names may be trademarks of their respective companies. All specifications are subject to change without notice. Published materials may contain inaccuracies and typographical
errors. Everex does not warrant the accuracy or completeness of the materials or the reliability of any advice, opinion, statement or other information displayed or distributed through Everex. Reliance on any such opinion, advice, statement, memorandum, or information shall be at the sole
discretion of the user. Everex reserves the right to correct any errors or omissions in any portion of these materials at any time without notice. The information and materials presented and the references made available, are provided "As Is" without any representation or warranty, express or
implied, of any kind, including, but not limited to, warranties of merchantability, non infringement, or fitness for any particular purpose, some jurisdictions do not allow for the exclusion of implied warranties, so the above exclusions may not apply.
Everex StepNote NC1502 Detailed Specification-v1.1, 2/26/2007 4:34:00 PM
®
-M Processor, 512MB DDR2 SDRAM, 80GB SATA HDD, DVD-ROM/DVD+/-
Communications
• Soft Data Fax Modem with SmartCP
(V.92, 56kbps, actual speeds may vary)
• VIA VT6103L Rhine II Fast Ethernet Adapter
(10/100 Base-TX Ethernet)
• Atheros AR5005G Wireless Network Adapter
802.11b/g
Expandability
• N/A
Ports
• Video: 1 VGA output port
• Audio: 1 Microphone input port, 1 Headphone
output port
• Data: 3 USB 2.0 ports, RJ-45 LAN port, RJ-11
Modem port
System Physical Description
• Dimensions: 14.06" (357mm) x 10.67" (271mm) x
1.02" (26mm) front ~ 1.54" (39mm) rear (L x W x
H)
• Weight: Starting at 5.3lbs (2.41kg) depending
upon configuration
• Indicators: Power, Battery Status, HDD/ODD
Status, WLAN Status, Caps Lock Status, Scroll Lock
Status, Num Lock Status
• Physical Security: Provision for Kensington Lock
• Software Security: Fixed Disk Boot Sector
Protection, Password on Boot
AC Adapter
• 65W (20V@3.25A) Auto sensing external AC
Adapter (100-240V~1.5A, 50-60Hz)
• Dimensions: 4.25" (107mm) x 1.75" (44.45mm) x
1.13" (28.70mm) (L x W x H)
• Weight: 0.7lb (0.32kg)
Battery
• 3-Cell (11.1V, 2200mAh) rechargeable, removable
Lithium-Ion Battery
• Dimensions: 8.15" (207mm) x 1.57" (40mm) x
0.79" (20mm) (L x W x H)
• Weight: 0.45lb (0.2kg)

Preinstalled Software

• CyberLink DVD Suite
• Norton Internet Security™ 2007 (90-day
subscription service included)
