PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE USING THIS
Panasonic Canada Inc.
5770 Ambler Drive
Mississauga, Ontario
L4W 2T3
Tel: (905) 624-5010
www.panasonic.com
© Panasonic Appliances Microwave Oven (Shanghai) Co., Ltd. 2016
F0003BR11CP_Eng.indd 1
Operating Instructions
PRODUCT, AND SAVE THIS MANUAL FOR FUTURE USE.
Inverser le manuel pour lire les instructions en français.
Microwave Oven
Household Use Only
Model No. NN-ST966B
NN-ST966W
NN-ST766B
NN-ST766W
1200 W
F0003BR11CP
PA0616-11217
Printed in China
2017/12/20 9:26:12
Advertisement
Table of Contents
Related Manuals for Panasonic NN-ST966B
Summary of Contents for Panasonic NN-ST966B
- Page 1 Inverser le manuel pour lire les instructions en français. Panasonic Canada Inc. 5770 Ambler Drive Mississauga, Ontario F0003BR11CP L4W 2T3 PA0616-11217 Tel: (905) 624-5010 Printed in China www.panasonic.com © Panasonic Appliances Microwave Oven (Shanghai) Co., Ltd. 2016 F0003BR11CP_Eng.indd 1 2017/12/20 9:26:12...
-
Page 2: Table Of Contents
Table of Contents Safety Information Microwave Oven Safety ..................1 Important Safety Instructions ................2-5 Installation and Grounding Instructions ............5-6 Safety Precautions ................... 7-8 Operation Control Panel ....................... 12 Starting to Use Your Oven................... 13 Setting the Clock ....................13 Child Safety Lock.................... -
Page 3: Microwave Oven Safety
Microwave Oven Safety Your safety and the safety of others are very important. We have provided important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. It is used to alert you to poten- tial hazards that can kill or hurt you and others. -
Page 4: Important Safety Instructions
Thank you for purchasing a Panasonic Microwave Oven. Your microwave oven is a cooking appliance and you should use as much care as you use with a stove or any other cooking appliance. When using electric appliance, basic safety precautions should be followed, including the following:... - Page 5 IMPORTANT SAFETY INSTRUCTIONS (continued) 16. Some products such as whole eggs with or without shell, narrow neck bottles and sealed containers — for example, closed glass jars — may explode and should not be heated in this oven. 17. To reduce the risk of fire in the oven cavity: (a) DO NOT overcook food.
- Page 6 IMPORTANT SAFETY INSTRUCTIONS (continued) WARNING TO AVOID THE RISK OF SHOCK: DO NOT remove outer panel from oven. Repairs must be done only by a qualified service person. TO REDUCE THE RISK OF EXPOSURE TO MICROWAVE ENERGY: DO NOT tamper with, or make any adjustments or repairs to Door, Control Panel Frame, Safety Interlock Switches, or any other part of oven.
-
Page 7: Installation And Grounding Instructions
Panasonic trim kit available from a local Panasonic dealer, or online from the Panasonic Canada eStore. Follow all instructions packed with the trim kit. 3. Use of a non-Panasonic trim kit will void the Manufacturer’s warranty for the Microwave oven. - Page 8 (120 V, 60 Hz). Using a higher voltage is dangerous and may result in a fire or oven damage. Using a lower voltage will cause slow cooking. Panasonic is NOT responsible for any damages resulting from the use of the oven with any voltage other than specified.
-
Page 9: Safety Precautions
SAFETY PRECAUTIONS Follow These Safety Precautions When Cooking in Your Oven. IMPORTANT Proper cooking depends upon the power, the time setting and quantity of food. If you use a smaller portion than recommended but cook at the time for the recommended portion, fire could result. 1) HOME CANNING / STERILIZING / DRYING FOODS / SMALL QUANTITIES OF FOODS •... - Page 10 SAFETY PRECAUTIONS (continued) 5) GLASS TRAY / COOKING CONTAINERS / FOIL • Cooking containers get hot during microwaving. Heat is transferred from the HOT food to the container and the Glass Tray. Use pot holders when removing containers from the oven or when removing lids or plastic wrap covers from cooking containers, to avoid burns.
-
Page 11: Cookware Guide
Cookware Guide Item Microwave Comments Yes for Small strips of foil can be molded around thin parts of meat or Aluminum Foil Shielding poultry to prevent overcooking. Arcing can occur if foil is too close only to oven wall or door and damage to your oven will result. Browning dishes are designed for microwave cooking only. -
Page 12: Care And Cleaning Of Your Microwave Oven
Care and Cleaning of Your Microwave Oven Caution: After cooking, the oven should be cleaned with a soft cloth moistened with soapy water. If the oven is not cleaned occasionally to eliminate grease, it can accumulate and cause the oven to "Smoke and fire"... -
Page 13: Oven Components Diagram
Oven Components Diagram External Air Vent Waveguide Cover (do not remove) Internal Air Vent Door Release Button Door Safety Lock System Warning Label Exhaust Air Vent Menu Label Control Panel Power Supply Cord Identification Plate Power Supply Plug Glass Tray Roller Ring Heat/Vapor Barrier Film (do not remove) -
Page 14: Control Panel
Control Panel * The control panels of NN-ST966B/ ST966W/ST766B/ ST766W have same key layout. Display Window Sensor Reheat Pad (page 20) Popcorn Pad Sensor Cook Pad (page 17) (page 20) Power Level Pad Keep Warm Pad (page 15) (page 16) -
Page 15: Starting To Use Your Oven
Starting to Use Child Safety Lock Your Oven This feature prevents the electronic oper- ation of the oven until cancelled. It does not lock the door. Step1. • Plug into a properly To set: • Press Start 3 times. grounded electrical The indication light outlet. -
Page 16: Function Features
Function Features This unique function of your Panasonic microwave oven allows you to establish the initial non-cooking features of your Oven. This microwave oven has the functions below: LB/KG CHOICE: The oven has both imperial and metric weight measurements. BEEP CHOICE: The oven has both Beep On and Beep Off mode. -
Page 17: Selecting Microwave Power & Cook Time
Selecting 3-Stage Cooking Microwave Power This feature allows you to program & Cook Time 2-3 Stages of cooking continuously. Example: Continually set P10 for 5 Example: To cook at P6 (MEDIUM) minutes, P7 for 3 minutes power for 1 minute 30 seconds and P4 for 5 minutes. -
Page 18: Quick 30 Feature
Quick 30 Feature Keep Warm Feature This feature allows you to set or add This feature will keep food warm for up to cooking time in 30 seconds increments up 30 minutes after cooking. to 5 minutes. Example: To keep 2 cups of gravy warm To Set Cooking Time: Step1. -
Page 19: Popcorn Feature
Popcorn Feature More/Less Feature For Popcorn: Example: To pop 3.5 oz. (99 g) of popcorn By using More Pad or Less pad, the Step1. • Press Popcorn until programs can be adjusted to cook popcorn the desired size for a longer or shorter time if desired. appears in the display window. -
Page 20: Inverter Turbo Defrost Feature
Inverter Turbo Defrost Feature This feature allows you to automatically defrost foods such as: meat, poultry and seafood simply by entering the weight. Conversion Chart: Example: To Defrost 1.5 pounds of meat Follow the chart to convert ounces or Place food on microwave safe dish. hundredths of a pound into tenths of a pound. - Page 21 Defrosting Tips & Techniques (continued) MANUAL AFTER DEFROSTING DEFROST FOOD DURING DEFROSTING TIME at P3 Stand Time Rinse (min/kg) (min/lb) Fish and Seafood [up to 1.4 kg (3 lbs.)] Crabmeat Break apart/Rearrange Fish Steaks 8 to 12 4 to 6 Turn over 5 min.
-
Page 22: Sensor Reheat Feature
Sensor Reheat Sensor Cook Feature Feature This sensor feature allows you to reheat This sensor feature allows you to cook food food without setting time. The oven without setting time. The oven simplifies simplifies programming. programming. Example: To reheat a plate of food Example: To cook Frozen Entrées Step1. -
Page 23: Sensor Cook Chart
Sensor Cook Chart Recipe Serving/Weight Hints 0.5 - 1 cup Place inside a microwave safe serving bowl with 1. Oatmeal (40 - 80 g ) no cover. Follow manufacturers’ directions for preparation. Follow manufacturers’ directions for preparation 2. Breakfast Sau- 2 - 8 links of precooked breakfast sausage. -
Page 24: Microwave Recipes
Microwave Recipes OMELET In a 2-qt. casserole dish, melt the butter for Basic omelet 40 seconds at P10. Add onion and garlic and cook for 1 minute at P10. Stir in flour, 1 tablespoon butter or margarine mustard, salt and pepper, and gradually 2 eggs add the milk. -
Page 25: Timer Feature (Kitchen Timer/Stand Time/Delay Start)
Timer Feature To Set Stand Time: This feature allows you to program the oven as a kitchen timer. It can also be Example: To cook at P6 power for used to program a standing time after 3 minutes, with stand time cooking is completed and/or to program a of 5 minutes. - Page 26 Timer Feature (continued) To Set Delay Start: Example: To delay the start of cooing NOTES: for 5 minutes, and cook at P6 power for 3 minutes. 1. When each stage finishes, a two-beep signal sounds. At the end of the pro- Step1.
-
Page 27: Microwave Shortcuts
Microwave shortcuts FOOD POWER TIME DIRECTIONS (in mins.) To separate refrigerated 30 sec. Remove wrapper and place in microwave Bacon, safe dish. After heating, use a plastic spatula (HIGH) 450 g (1 pound) to separate slices. To soften Brown Sugar 20 - 30 Place brown sugar in microwave safe dish 250 ml (1 cup) - Page 28 Microwave shortcuts (continued) FOOD POWER TIME DIRECTIONS (in mins.) To cook baked Potato, Pierce each potato with a fork 6 times spac- (170 - 220 g) ing around surface. Place potato or potatoes (6 - 8 oz. each) around the edge of paper-towel-lined glass 3½...
-
Page 29: Food Characteristics
Food Characteristics Cooking Techniques Bone and Fat Piercing Both bone and fat affect cook- Foods with skins or mem- ing. Bones may cause irregular branes must be pierced cooking. Meat next to the tips scored or have a strip of skin of bones may overcook while peeled before cooking to al- meat positioned under a large bone, such... - Page 30 Cooking Techniques (continued) Covering Turning As with conventional cooking, moisture It is not possible to stir some foods to distrib- evaporates during microwave cooking. Cas- ute the heat evenly. At times, microwave en- serole lids or plastic wrap are used for a ergy will concentrate in one area of the food.
-
Page 31: Before Requesting Service
Before Requesting Service These things are normal: The oven causes Some radio, TV, Wi-Fi, cordless telephone, baby monitor, interference with my blue tooth or other wireless equipment interference might occur when you cook with the microwave oven. This inter- ference is similar to the interference caused by small appli- ances such as mixers, vacuums, blow dryers, etc. -
Page 32: Warranty
Over-The-Range cooktop light bulbs are excluded from coverage under this warranty. In the case where the microwave oven is built-in, the warranty will be voided if using a non-Panasonic trim kit. THIS EXPRESS, LIMITED WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. -
Page 33: Quick Guide To Operation
Quick Guide to Operation Feature How to Operate To set Thru Clock (page 13) Press once. Enter time of day. Press once. To Use Child To Set: To Cancel: Safety Lock Press 3 times. Press 3 times. (page 13) To Use Thru Power and Time (page 15) -
Page 34: Specifications
Specifications NN-ST966B NN-ST966W NN-ST766B NN-ST766W Power Source: 120 V 60 Hz Power Consumption: 12.3 A 1,460 W Cooking Power:* 1,200 W Outside Dimensions 606 mm x 356 mm x 493 mm 555 mm x 304 mm x 493 mm (23 7/8” x 14” x 19 7/16”) (21 7/8”...
