Page 2
• A pplications and their functions may vary by country, region, or hardware specifications. Samsung is not liable for performance issues caused by applications from any provider other than Samsung. • S amsung is not liable for performance issues or incompatibilities caused by edited registry settings or modified operating system software.
Page 3
No part of this guide may be reproduced, distributed, translated, or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording, or storing in any information storage and retrieval system, without the prior written permission of Samsung Electronics.
Page 4
About this manual Trademarks • S AMSUNG and the SAMSUNG logo are registered trademarks of Samsung Electronics. ™ ™ ™ ™ ™ • T he Android logo, Google , Google Maps , Google Mail , YouTube , Google Play ™...
Table of Contents Getting started Transferring files Securing the device Device layout Upgrading the device Buttons Package contents Installing the SIM or USIM card and Communication battery Phone Charging the battery Contacts Inserting a memory card Turning the device on and off Messaging Email Holding the device...
Page 6
Video Player YouTube About Settings FM Radio Wi-Fi Bluetooth Data usage Application & media stores More settings Play Store Home screen mode Samsung Apps Blocking mode Game Hub Sound Display Storage Utilities Power saving mode Memo Battery S Planner Application manager...
Getting started Device layout Front camera Earpiece Proximity sensor Power button Touch screen Home button Menu button Back button Multipurpose jack Microphone Headset jack GPS antenna Speaker Flash Rear camera Volume button Back cover Main antenna...
Getting started • D o not cover the antenna area with your hands or other objects. This may cause connectivity problems or drain the battery. • D o not use a screen protector. This causes sensor malfunctions. • D o not allow water to contact the touch screen. The touch screen may malfunction in humid conditions or when exposed to water.
• A ppearances and specifications are subject to change without prior notice. • Y ou can purchase additional accessories from your local Samsung retailer. Make sure they are compatible with the device before purchase. • O ther accessories may not be compatible with your device.
Getting started Installing the SIM or USIM card and battery Insert the SIM or USIM card provided by the mobile telephone service provider, and the included battery. Only microSIM cards work with the device. Remove the back cover. Be careful not to damage your fingernails when you remove the back cover. Do not bend or twist the back cover excessively.
Page 11
SIM card slot, take the device to a Samsung Service Centre to remove the memory card. • U se caution not to lose or let others use the SIM or USIM card. Samsung is not responsible for any damages or inconveniences caused by lost or stolen cards.
Page 12
Getting started Removing the SIM or USIM card and battery Remove the back cover. Pull out the battery. Pull out the SIM or USIM card.
Use the charger to charge the battery before using it for the first time. A computer can be also used to charge the device by connecting them via the USB cable. Use only Samsung-approved chargers, batteries, and cables. Unapproved chargers or cables can cause the battery to explode or damage the device.
Page 14
• I f the device is not charging properly, take the device and the charger to a Samsung Service Centre. After fully charging, disconnect the device from the charger. First unplug the charger from the device, and then unplug it from the electric socket.
Getting started Reducing the battery consumption Your device provides options that help you save battery power. By customising these options and deactivating features in the background, you can use the device longer between charges: • W hen you are not using the device, switch to sleep mode by pressing the Power button. •...
Page 16
Do not remove the memory card while the device is transferring or accessing information. Doing so can cause data to be lost or corrupted or damage to the memory card or device. Samsung is not responsible for losses that result from the misuse of damaged memory cards, including the loss of data.
Getting started Formatting the memory card A memory card formatted on a computer may not be compatible with the device. Format the memory card on the device. On the Home screen, tap Apps → Settings → Storage → Format SD card → Format SD card →...
Getting started Holding the device Do not cover the antenna area with your hands or other objects. This may cause connectivity problems or drain the battery. Locking and unlocking the device When not in use, lock the device to prevent unwanted operation. Pressing the Power button turns off the screen and puts the device into lock mode.
Basics Indicator icons The icons displayed at the top of the screen provide information about the status of the device. The icons listed in the table below are most common. Icon Meaning No signal Signal strength Roaming (outside of normal service area) GPRS network connected EDGE network connected UMTS network connected...
Basics Icon Meaning Error occurred or caution required Battery power level Using the touch screen Use only fingers to use the touch screen. • D o not allow the touch screen to come into contact with other electrical devices. Electrostatic discharges can cause the touch screen to malfunction.
Page 21
Basics Dragging To move an icon, thumbnail, or preview to a new location, tap and hold it and drag it to the target position. Double-tapping Double-tap on a webpage, map, or image to zoom in a part. Double-tap again to return.
Page 22
Basics Flicking Flick left or right on the Home screen or the Applications screen to see another panel. Flick up or down to scroll through a webpage or a list, such as contacts. Pinching Spread two fingers apart on a webpage, map, or image to zoom in a part. Pinch to zoom out.
Basics Control motions Simple motions allow easy control of the device. Before using motions, make sure the motion feature is activated. On the Home screen, tap Apps → Settings → Motion, and then drag the Motion switch to the right. Excessive shaking or impact to the device may result in unintended inputs.
Page 24
Basics Picking up When you pick up the device after it has been idle for some time or when the screen has turned off, it vibrates if you have missed calls or new messages. Turning over Turn over the device to mute ringtone, pause media playback, or mute the FM radio (when using the speaker).
Basics Shaking • S hake the device to search for Bluetooth devices, or computers in Kies via Wi-Fi. • S hake the device to update the list of emails or information from Yahoo News, Yahoo Finance, or AccuWeather. Updates will not work for widgets on the Home screen.
Basics • B locking mode: Activate or deactivate blocking mode. In blocking mode, the device will block notifications. To select which notifications will be blocked, tap Settings → Blocking mode. • S ync: Activate or deactivate auto-syncing of applications. The available options may vary depending on the region or service provider.
Page 27
Basics Moving an item Tap and hold an item and drag it to a new location. To move it to another panel, drag it to the side of the screen. Removing an item Tap and hold an item, and drag it to the rubbish bin that appears at the top of the Home screen.
Basics Using applications This device can run many different types of applications, ranging from media to Internet applications. Opening an application On the Home screen or the Applications screen, select an application icon to open it. Opening from recently-used applications Press and hold the Home button to open the list of recently-used applications.
Page 29
Pinch on the screen, tap and hold a panel preview, and then drag it to a new location. Installing applications Use application stores, such as Samsung Apps, to download and install applications. Uninstalling applications → Uninstall, and then select an application to uninstall it.
Entering text Use the Samsung keyboard or the voice input feature to enter text. Text entry is not supported in some languages. To enter text, you must change the input language to one of the supported languages.
Page 31
Basics Entering uppercase before entering a character. For all caps, tap it twice. Changing language keyboards Add languages to the keyboard, and then slide the space key left or right to change language keyboards. Handwriting Tap and hold , tap , and then write a word with a finger.
Basics Copying and pasting Tap and hold over text, drag to select more or less text, and then tap to copy or to cut. The selected text is copied to the clipboard. To paste it into a text entry field, place the cursor at the point where it should be inserted, and →...
Select the network in the networks list, and then tap Forget. Setting up accounts Google applications, such as Play Store, require a Google account, and Samsung Apps requires a Samsung account. Create Google and Samsung accounts to have the best experience with the device.
Connecting with Samsung Kies Samsung Kies is a computer application that manages media libraries, contacts, and calendars, and syncs them with Samsung devices. Download the latest Samsung Kies from the Samsung website. Connect the device to the computer using the USB cable.
Basics Connecting as a media device Connect the device to the computer using the USB cable. Open the notifications panel, and then tap Connected as a media device → Media device (MTP). Tap Camera (PTP) if your computer does not support Media Transfer Protocol (MTP) or not have any appropriate driver installed.
Page 36
Basics Setting a pattern On the Applications screen, tap Settings → Lock screen → Screen lock → Pattern. Draw a pattern by connecting four dots or more, and then draw the pattern again to verify it. Set a backup unlock PIN to unlock the screen when you forget the pattern. Setting a PIN On the Applications screen, tap Settings →...
Turn on the screen by pressing the Power button or the Home button, and enter the unlock code. If the unlock code is forgotten, take the device to a Samsung Service Centre to reset it. Upgrading the device The device can be upgraded to the latest software.
Communication Phone Use this application to make or answer a call. Tap Phone on the Applications screen. Making calls Making a call Use one of the following methods: • K eypad: Enter the number using the keypad, and then tap . •...
Page 39
Communication Finding contacts Enter a name, phone number, or email address to find a contact in the contacts list. As characters are entered, predicted contacts appear. Select one to place a call to it. Making an international call Tap and hold 0 until the + sign appears. Enter the country code, area code, and phone number, and then tap .
Page 40
Communication Adding contacts To add a phone number to the contacts list from the keypad, enter the number and tap Add to Contacts. Viewing call logs Tap Logs to view the history of incoming and outgoing calls. → View by, and then select an option. To filter a call log, tap Fixed dialling number The device can be set to restrict outgoing calls only to numbers with specified prefixes.
Page 41
Communication Rejecting a call When a call comes in, drag outside the large circle, or press and hold the headset button. To send a message when rejecting an incoming call, tap Reject call with message. To create → Call settings → Set reject messages. the rejection message, tap Automatically rejecting calls from unwanted numbers →...
Page 42
Communication Video calls Making a video call Enter the number or select a contact from the contacts list, and then tap to make a video call. During a video call The following actions are available: • S witch camera: Switch between the front and rear camera. •...
Communication Swapping images Drag an image of either party onto the other party’s image to swap the images. Contacts Use this application to manage contacts, including phone numbers, email addresses, and others. Tap Contacts on the Applications screen. Managing contacts Creating a contact and enter contact information.
Page 44
Communication Editing a contact Select a contact to edit, and then tap Deleting a contact → Delete. Setting a speed dial number → Speed dial setting, select a speed dial number, and then select a contact for it. To remove a speed dial number, tap and hold it, and then tap Remove. Searching for contacts Use one of the following search methods: •...
Page 45
→ Merge with Samsung. Contacts synced with Samsung Contacts appear with in the contacts list. If a contact is added or deleted on the device, it is also added to or deleted from Samsung Contacts, and vice versa. Importing contacts →...
Page 46
Communication Contact groups Adding contacts to a group . Select contacts to add, and then tap Done. Select a group, and then tap Managing groups , and then take one of the following actions: • C reate: Make a new group. •...
Communication Messaging Use this application to send text messages (SMS) or multimedia messages (MMS). Tap Messaging on the Applications screen. You may incur additional charges for sending or receiving messages while you are outside your home service area. For details, contact your service provider. Sending messages , add recipients, enter a message, and then tap Use the following methods to add recipients:...
Communication Viewing incoming messages Incoming messages are grouped into message threads by contact. Select a contact to view the person’s message. Listening to a voice message Tap and hold 1 on the keypad, and then follow the instructions from your service provider. Email Use this application to send or view email messages.
Page 49
Communication Sending scheduled messages → Schedule sending. Tick Schedule sending, set a While composing a message, tap time and date, and then tap Done. The device will send the message at the specified time and date. • I f the device is turned off at the scheduled time, is not connected to the network, or the network is unstable, the message will not be sent.
Communication Google Mail Use this application to quickly and directly access the Google Mail service. Tap Google Mail on the Applications screen. • T his application may not be available depending on the region or service provider. • T his application may be labelled differently depending on the region or service provider.
Communication Labels Google Mail does not use actual folders, but uses labels instead. When Google Mail is launched, it displays messages labelled Inbox. to view messages in other labels. To add a label to a message, select the message, tap , and then select the label to assign. Talk Use this application to chat with others via Google Talk.
Communication Switching between chats Scroll left or right. Deleting chat history → Clear chat history. Chats are automatically saved. To delete the chat history, tap Google+ Use this application to stay connected with people via Google’s social network service. Tap Google+ on the Applications screen. This application may not be available depending on the region or service provider.
Tap ChatON on the Applications screen. This application may not be available depending on the region or service provider. Create the buddies list by entering phone numbers or email addresses of Samsung accounts, or selecting buddies from the list of suggestions.
Web & network Internet Use this application to browse the Internet. Tap Internet on the Applications screen. Viewing webpages Tap the address field, enter the web address, and then tap Go. to share, save, or print the current webpage while viewing a webpage. Opening a new page →...
Web & network History → History to open a webpage from the list of recently-visited webpages. To clear the → Clear history. history, tap → History → Most visited to open a webpage from the list of most visited webpages. Saved pages →...
• D o not use the Bluetooth feature for illegal purposes (for example, pirating copies of files or illegally tapping communications for commercial purposes). Samsung is not responsible for the repercussion of illegal use of the Bluetooth feature. To activate Bluetooth, on the Applications screen, tap Settings → Bluetooth, and then drag...
Page 57
Web & network Pairing with other Bluetooth devices On the Applications screen, tap Settings → Bluetooth → Scan, and detected devices are listed. Select the device you want to pair with, and then accept the auto-generated passkey on both devices to confirm. Sending and receiving data Many applications support data transfer via Bluetooth.
Media Music Player Use this application to listen to music. Tap Music Player on the Applications screen. • S ome file formats are not supported depending on the device’s software version. • S ome files may not play properly depending on the encoding method used. Playing music Select a music category, and then select a song to play.
Media Creating playlists Make an own selection of songs. → Create playlist. Enter a title and tap OK. Tap Add music, Tap Playlists, and then tap select songs to include, and then tap Done. → Add to playlist. To add the currently-playing song to a playlist, tap Playing music by mood Play music grouped by mood.
Page 60
Media Taking photos Taking a photo Tap the image on the preview screen where the camera should focus. When the subject is in focus, the focus frame turns green. Tap to take the photo. Switch between the Indicates which front and rear camera. storage is in use.
Page 61
Media • A utumn color: Use this setting for red-shifted background scenery. • T ext: Use this setting for books or posters. • C andlelight: Use this setting for images of bright light against a dark background. •...
Page 62
Media Panoramic photos A panoramic photo is a wide landscape image consisting of multiple shots. → Shooting mode → Panorama. and move the camera in one direction. When the blue frame aligns with the viewfinder, the camera automatically takes another shot in a panoramic sequence. To stop shooting, tap Taking videos Taking a video...
Page 63
Media Recording mode Switch between the Indicates which front and rear camera. storage is in use. Change the ash Switch between still setting. and video mode. Change recording mode. Select among various e ects that are Open the video player available.
Page 64
Media Configuring settings for Camera to configure settings for Camera. Not all of the following options are available in both still camera and video camera modes. The available options vary depending on the mode used. • E dit shortcuts: Reorganise shortcuts to frequently-used options. •...
Page 65
Media • W hite balance: Select an appropriate white balance, so images have a true-to-life colour range. The settings are designed for specific lighting situations. These settings are similar to the heat range for white-balance exposure in professional cameras. •...
Media Gallery Use this application to view images and videos. Tap Gallery on the Applications screen. • S ome file formats are not supported depending on the software installed on the device. • S ome files may not play properly depending on the encoding method used. Viewing images Launching Gallery displays available folders.
Page 67
• B uddy photo share: Send the image to a person whose face is tagged in the image. • P rint: Print via a USB or Wi-Fi connection. The device is only compatible with some Samsung printers. • R ename: Rename the file.
Media Setting as wallpaper → Set as to set the image as wallpaper or to assign it to a When viewing an image, tap contact. Tagging faces → Face tag → On. A yellow frame appears around the When viewing an image, tap recognised face.
Media Deleting videos → Delete, select videos by ticking, and then tap Delete. Sharing videos → Share via, select videos by ticking, tap Done, and then select a sharing method. YouTube Use this application to watch videos from the YouTube website. Tap YouTube on the Applications screen.
Media Sharing videos Select the video to view, tap , and then select a sharing method. Uploading videos Select your account, tap , select a video, enter information for the video, and then tap FM Radio Listen to music and news on the FM radio. To listen to the FM radio, you must connect a headset, which serves as the radio antenna.
Page 71
Media Scanning radio stations → Scan, and then select a scan option. The FM radio scans and saves available stations automatically. Select the radio station you want from the stations list and tap to return to the FM radio screen. Adding stations to the favourites list Scroll to a radio station, and then tap to add the station to the favourites list.
Application & media stores Play Store Use this application to purchase and download applications and games that are able to run on the device. Tap Play Store on the Applications screen. This application may not be available depending on the region or service provider. Installing applications Browse applications by category, or tap to search with a keyword.
Game Hub Use this application to access games. Tap Game Hub on the Applications screen. This application may not be available depending on the region or service provider. Scroll left or right and select a game to download from Samsung Apps.
Utilities Memo Use this application to record important information to save and view at a later date. Tap Memo on the Applications screen. Composing memos , enter a memo, and then tap Save. → To change the background colour, tap →...
Page 75
• : Lock the memo so that others cannot view it. • : Print the memo via a USB or Wi-Fi connection. The device is only compatible with some Samsung printers. S Planner Use this application to manage events and tasks.
Page 76
Utilities To add an event or task more briefly, tap a date to select it and tap it again. Enter a title and specify which calendar to use or sync with. Then tap Edit event details or Edit task details to add more details, such as how often the event repeats, when it has an advance alert, or where it takes place.
Page 77
Utilities Syncing with Google Calendar On the Applications screen, tap Settings → Google under Accounts → a Google account → Sync Calendar. To manually sync for updating, on the Applications screen, tap S Planner → → Sync. → Settings → Calendars, select the Google To display synced events or tasks, tap account, and then tap Done.
Utilities Clock Use this application to set alarms, check the time in any location in the world, measure the duration of an event, set a timer, or use as the desk clock. Tap Clock on the Applications screen. Turn this alarm on or off. Alarm Setting alarms Tap Create alarm, set a time for the alarm to go off, select days for the alarm to repeat, and...
Page 79
Utilities Stopping alarms Drag outside the large circle to stop an alarm. Drag outside the large circle to repeat the alarm after a specified length of time. Deleting alarms Tap and hold the alarm, and then tap Delete. World clock Creating clocks Tap Add city, and then enter a city name or select a city from the cities list.
Utilities Calculator Use this application for simple or complex calculations. Tap Calculator on the Applications screen. Rotate the device to landscape orientation to display the scientific calculator. If Screen → Scientific calculator. rotation is disabled, tap To see the calculation history, tap to hide the keypad.
Page 81
Utilities Playing voice memos Select a voice memo to play. • : Adjust the playback speed. • : Trim the voice memo. • : Adjust the volume by dragging the volume bar up or down. • : Stop playback. •...
Utilities Here are several examples of spoken commands: • O pen music • L aunch calculator • C all Lulu mobile • D ial Lulu work • C heck schedule Tips for better voice recognition •...
Utilities Searching with images → Search with camera. Aim the rear camera at an image, To search with an image, tap and then tap This feature is available only for English. Google Now Launch Google search to view Google Now cards that show the current weather, public transit info, your next appointment, and more when you are most likely to need it.
Utilities Viewing files Select a folder to open it. To go back to the parent folder, tap . To return to the root directory, tap In a folder, tap , and then use one of the following options: • S elect all: Select all files or folders to apply the same option to them at once. •...
Travel & local Maps Use this application to pinpoint the location of the device, search for places, or get directions. Tap Maps on the Applications screen. This application may not be available depending on the region or service provider. Searching for locations , enter an address, and then tap .
Travel & local Getting directions for a destination , and then select a method to enter starting and ending locations: • M y current location: Use current location for starting location. • C ontacts: Select from the contacts list. •...
Travel & local Navigation Use this application to search for a route to a destination. Tap Navigation on the Applications screen. • N avigation maps, your current location, and other navigational data may differ from actual location information. You should always pay attention to road conditions, traffic, and any other factors that may affect your driving.
Settings About Settings Use this application to configure the device, set application options, and add accounts. Tap Settings on the Applications screen. Wi-Fi Activate the Wi-Fi feature to connect to a Wi-Fi network and access the Internet or other network devices. To use options, tap •...
Settings Setting Network notification The device can detect open Wi-Fi networks and display an icon on the status bar to notify when available. On the Settings screen, tap Wi-Fi → → Advanced and tick Network notification to activate this feature. Wi-Fi Direct Wi-Fi Direct connects two devices directly via a Wi-Fi network without requiring an access point.
Settings To use more options, tap • D ata roaming: Set the device to use data connections when you are roaming. • R estrict background data: Set the device to disable sync in the background while using a mobile network. •...
• H elp: Learn more about USB, Wi-Fi, and Bluetooth tethering. Set up and connect to virtual private networks (VPNs). Kies via Wi-Fi Connect the device to Samsung Kies via a Wi-Fi network. Home screen mode Select a Home screen mode (basic or easy).
Settings Sound Change settings for various sounds on the device. • V olume: Adjust the volume level for call ringtones, music and videos, system sounds, and notifications. • D evice ringtone: Select a ringtone to alert you to incoming calls. •...
Settings • S mart stay: Set the device to prevent the display backlight from turning off while you are looking at the display. • F ont style: Change the font type for display text. • F ont size: Change the font size. •...
Settings Application manager View and manage the applications on your device. Location services Change settings for location information permissions. • U se wireless networks: Set the device to allow location data collection or to determine the location of your lost or stolen device via Wi-Fi or mobile network. •...
• R emote controls: Set the device to allow control of your lost or stolen device remotely via the Internet. To use this feature, you must sign in to your Samsung account. – Account registration: Add or view your Samsung account.
• F ind my mobile web page: Access the Find my mobile website ( findmymobile.samsung.com ). You can track and control your lost or stolen device on the Find my mobile website. • S et up SIM card lock: –...
Page 97
• D ownload offline speech recognition: Download and install language data for offline voice input. Samsung keyboard To change the Samsung keyboard settings, tap The available options may vary depending on the region or service provider. • P ortrait keyboard types: Change the keyboard layout.
Page 98
– Character preview: Set the device to display a large image of each character tapped. – Key-tap sound: Set the device to sound when a key is touched. • T utorial: Learn how to enter text with the Samsung keyboard. • R eset settings: Reset Samsung keyboard settings.
Page 99
Settings • S how body of message: Set the device to display the text of a new message received while in driving mode. • W ake up command: Set the device to start voice recognition by saying a wake up command while using S Voice.
Settings Text-to-speech output • P referred TTS engine: Select a speech synthesis engine. To change the settings for speech synthesis engines, tap • S peech rate: Select a speed for the text-to-speech feature. • L isten to an example: Listen to the spoken text for an example. •...
Settings Motion Activate the motion recognition feature and change the settings that control motion recognition on your device. • S mart alert: Set the device to alert you if you have missed calls or new messages when you pick up the device. •...
Settings Accessibility Accessibility services are special features for those with certain physical disabilities. Access and alert the following settings to improve accessibility to the device. • A uto-rotate screen: Set the interface to rotate automatically when you rotate the device. •...
Settings • E nhance web accessibility: Set applications to install web scripts to make their web content more accessible. • M ono audio: Enable mono sound when listening to audio with one earbud. • T urn off all sounds: Mute all device sounds. •...
Settings • T ransition animation scale: Select a speed for switching between screens. • A nimator duration scale: Select how long pop-up windows will be shown. • D isable hardware overlays: Set the device to hide hardware overlays. •...
• R estart your device to clear any temporary software bugs. • E nsure that your device software is upgraded to the latest version. • I f the touch screen is scratched or damaged, take it to your local Samsung Service Centre.
Page 106
Troubleshooting Your device freezes or has fatal errors If your device freezes or hangs, you may need to close programs or reset the device to regain functionality. If your device is frozen and unresponsive, press and hold the Power button for 6-8 seconds.
Page 107
Troubleshooting Audio quality is poor • E nsure that you are not blocking the device’s internal antenna. • W hen you are in areas with weak signals or poor reception, you may lose reception. Move to another area and try again. When dialling from contacts, the call is not connected •...
Page 108
Contact a Samsung Service Centre. Error messages appear when opening music files Some music files may not play on your Samsung device for a variety of reasons. If you receive error messages when opening music files on your device, try the following: •...
Page 109
• I f you are a Windows XP user, ensure that you have Windows XP Service Pack 3 or higher installed on your computer. • E nsure that you have Samsung Kies 2.0 or Windows Media Player 10 or higher installed on your computer.
Page 110
Some content may differ from your device depending on the region, service provider, or software version, and is subject to change without prior notice. www.samsung.com English (LTN). 08/2013. Rev. 1.0...
