Epson PowerLite 830p Quick Setup

Epson ® PowerLite
Quick Setup
C
onnect the pro j e c t o r
to your notebook
Follow these instructions to connect the projector to
your notebook. For other setup options and complete
instructions, see your User's Guide.
1
Locate the required cables:
Power cord
2
Connect the computer cable to the Computer1/Component port
on the projector.
3
Connect the other end to your notebook's video-out
or monitor port.
NOTE: If your notebook has a DVI connector, you need to either
use a DVI-to-VGA adapter with the included computer cable (see
your computer's documentation), or purchase an optional DVI
cable (for a higher-quality image). See your User's Guide.
T
u rn on your equipment
1
Connect the power cord to the projector, then plug the other end
into a grounded electrical outlet.
2
Turn on your notebook.
® 830p
VGA computer cable
3
Remove the projector's lens cover.
4
Press the Power button
to turn on the projector.
The Power light flashes green
while the projector warms up
and adjusts the focus. Then
the light stays green.
NOTE: For faster startup, you can enable the Direct Power On feature.
See the User's Guide.
A
djust the image
1
If you've turned on your notebook and you don't see an image,
press the Source Search button on the projector to select the
image source.
image source
NOTE: If you still see a blank screen or have other display problems,
see the troubleshooting tips on the back of this sheet.
2
Press the Zoom (W or T) buttons to reduce or enlarge the image.
3
If your image looks like
to one side of the screen at an angle. Place it directly in front of the
center of the screen, facing the screen squarely, or press the
Tracking buttons on the projector.
4
If your image looks like
on the projector.
Power button
Power light
Select an
Zoom
to adjust the
image size
or , you've placed the projector off
or , press the or Sync buttons
or
