This Service Manual is a property of Samsung Electronics Co .,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law.
© Samsung Electronics Co., Ltd. AUG. 2004
Printed in Korea
AK82-00662A
DVD-VCR COMBINATION
Chassis : Kaiser Karaoke
SV-DVD240P
SERVICE
If you want to know additional information which is not included on this Service Manual, please refer to the
DVD-V940K Training Manual (AK82-00557A).
DVD-VCR COMBINATION
Manual
CONTENTS
1. Precautions
2. Alignment and Adjustment
3. Exploded Views and Parts List
4. Electrical Parts List
5. Block Diagram
6. Schematic Diagrams

Advertisement

Table of Contents
loading

Related Manuals for Samsung SV-DVD240P

Summary of Contents for Samsung SV-DVD240P

  • Page 1 4. Electrical Parts List 5. Block Diagram 6. Schematic Diagrams This Service Manual is a property of Samsung Electronics Co .,Ltd. © Samsung Electronics Co., Ltd. AUG. 2004 Any unauthorized use of Manual can be punished under applicable Printed in Korea International and/or domestic law.
  • Page 2 IMPORTANT SERVICE GUIDE ◆ MODE SWITCH (PROGRAM SWITCH) ASSEMBLY POINT 1) When installing the ass’y deck on the Main PCB, be sure to align the assembly point of mode switch. ASSEMBLY POINT VCR MAIN PCB Fig. 1 ◆ HOW TO EJECT THE CASSETTE TAPE (If the tape is stuck in the unit) 1) Turn the Gear Worm Œ...
  • Page 3 Metal Part cal return path to the chassis. Any current measured must not exceed 0.5mA. Reverse the instrument power cord plug in the out- ohmmeter let and repeat the test. See Fig. 1-1. Fig. 1-2 Insulation Resistance Test Samsung Electronics...
  • Page 4 (5) antenna wiring. Always inspect in all areas tinuously and new instructions are issued whenev- for pinched, out-of-place, or frayed wiring, Do not er appropriate. change spacing between a component and the printed-circuit board. Check the AC power cord for damage. Samsung Electronics...
  • Page 5 Components identi- fied by shading, by( ) or by ( ) in the circuit dia- gram are important for safety or for the characteris- tics of the unit. Always replace them with the exact replacement components. Samsung Electronics...
  • Page 6 (6) Do not remove a replacement ESD device from its protective package until immediately before your are ready to install it.(Most replacement ESD devices are packaged with leads electrically short- ed together by conductive foam, aluminum foil or comparable conductive materials). Samsung Electronics...
  • Page 7 ◆ Be sure to put on a wrist strap grounded to the sheet. ◆ Be sure to lay a conductive sheet made of copper etc. Which is grounded to the table. Samsung Electronics...
  • Page 8 3) Make solder land 2 points short on Pick-up. (See Fig. 1-4) 4) Disassemble the Pick-up. Note : If the assembly and disassembly are not done in correct sequence, the Pick-up may be damaged. SOLDER LAND 2 POINTS SHORT PICK-UP ASS'Y Fig. 1-4 Samsung Electronics...
  • Page 9 - When the adjustment is completed, be sure to turn the power off. 2-1-1(a) Location of adjustment button of remote control STANDBY/ON OPEN/CLOSE X-Point (Tracking Center) Adjustment ; NVRAM Option Setting ; KARAOKE SEARCH Head Switching Adjustment ; KARAOKE VOLUME PROG / TRK Fig. 2-1 Samsung Electronics...
  • Page 10 Alignment and Adjustments 2-1-1(b) TEST location for adjustment mode setting SHORT Fig. 2-2 VCR Main PCB (Top View) Samsung Electronics...
  • Page 11 Fig. 2-4 <Table 2-1 NVRAM Option Table> MODELS OPTION NUMBERS SV-DVD240P 6, 9, 10, 12, 17, 18, 19, 20, 30, 33, 34, 35, 36, 37, 39, 40, 42, 47, 48, 52, 54, 57, 61, 63, 65, 66, 68 Samsung Electronics...
  • Page 12 Alignment and Adjustments 2-2 DVD Adjustment 2-2-1 Location of Test Point Pin 29 of RIC1 Fig. 2-5 Location of test Point (Main PCB - Top Side) Samsung Electronics...
  • Page 13 Adjustment Spec. Test Point Adjustment Location TDV-533 “Pin 29 of RIC1” Ass’y Deck - Top Side Chapter 14 Flat Waveform (DVD Main PCB - Top Side) (See Fig. 2-6) (See Fig. 2-5) Fig. 2-6 Ass’y Deck (Top Side) Samsung Electronics...
  • Page 14 If you cannot obtain a Flat waveform, then the unit is defective. Note : The Deck must be in a horizontal position. Use both “A” and “B” screws to adjust. Typical Waveform before Adjustment Waveform after Correct Adjustment Fig. 2-7 Envelope Waveform Samsung Electronics...
  • Page 15 Fig. 2-8 Location of Tape Transport Adjustment PINCH ROLLER FE HEAD CYLINDER ASS'Y GUIDE ROLLER "S" GUIDE ROLLER "T" POST TENSION #8 GUIDE POST #9 GUIDE POST #3 GUIDE POST MAIN BASE ACE HEAD CAPSTAN SHAFT Fig. 2-9 Tape Travel Diagram Samsung Electronics...
  • Page 16 HEIGHT ADJUST X-POSITION ADJUSTING SLIT SCREW (B) SCREW (D) AZIMUTH ADJUST X-POSITION LOCKING Fig. 2-10 Location of ACE Head Adjustment Screw AUDIO HEAD VIDEO HEAD 0 ~ 0 .25 mm CONTROL HEAD Fig. 2-11 ACE Head Height Adjustment Samsung Electronics...
  • Page 17 Fig. 2-12 Tape Guide Check c. AUDIO AZIMUTH ADJUSTMENT 1) Load alignment tape (Mono scope) and playback the 7KHz signal. 2) Connect channel-1 scope probe to audio output. 3) Adjust screw (B) to achieve maximum audio level. (See Fig. 2-10) Samsung Electronics...
  • Page 18 5) Insert the (-) driver into the X-Point adjustment hole and adjust it so that envelope waveform is maximum. Test point : W325 (Audio Output) W324 (Envelope) W323 (H’D S/W -Trigger) W322 (Control Pulse) AUDIO OUTPUT ENVELOPE HEAD SWITCHING CONTROL PULSE Fig. 2-13 Location of Test point (VCR Main PCB-Top View) 2-10 Samsung Electronics...
  • Page 19 5) If the section B in Fig. 2-15 does not meet the specification, adjust the guide roller T up or down. a b c d c,b,d/a Fig. 2-14 Envelope Waveform Adjustment H'D SWITCHING PULSE ENVELOPE Fig. 2-15 Adjustment Points Samsung Electronics 2-11...
  • Page 20 ) driver to obtain a flat video RF envelope as shown in Fig. 2-16. IDEAL ENVELOPE S HEIGHT TOO HIGH S HEIGHT TOO LOW T HEIGHT TOO HIGH T HEIGHT TOO LOW GUIDE ROLLER S GUIDE ROLLER T Fig. 2-16 Guide Roller S, T Height Adjustment 2-12 Samsung Electronics...
  • Page 21 2) If excessive tape wrinkle is observed, perform the following adjustments in Playback mode : ◆ Tape wrinkle at the guide roller S, T section : Linearity adjustment. ◆ Tape wrinkle at tape guide flange : ACE head assembly coarse adjustment. Samsung Electronics 2-13...
  • Page 22 4) Transportation of accurate driving force is done by gears. (Gear Center Ass’y) Note : If the spec. does not meet the followings specifications, replace the holder clutch ass’y and then recheck. <Table 2-4> MODE TORQUE g/cm GAUGE 42 ± 11 Cassette Torquemeter 145 ± 30 Cassette Torquemeter 2-14 Samsung Electronics...
  • Page 23 3-4 DVD Mechanical Parts - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-8 Notice You can search for the updated part code through ITSELF web site. URL; http://itself.sec.samsung.co.kr Samsung Electronics...

  • Page 24: Cabinet Assembly

    Exploded View and Parts List 3-1 Cabinet Assembly Samsung Electronics...
  • Page 25 DOOR-SPRING;04-SNYCOM,SUS304,T0.32,H7.0, C012 AC61-62032A SPRING ETC-MASK;SV-C130,SUS,4.4,-,-,-,-, C015 AK64-00536B CABINET-TOP;SV-DVD440,PCM,T0.5,W430,L223 LD61A AC61-00340A HOLDER-LED;X-11,POM(K300),-,-,-,NTR,- P001 AC92-01555B ASSY PCB-MAIN;SV-DVD240/XEV,KARAOKE P002 AK92-00415B ASSY PCB-DVD;SV-DVD240P/XEV,DVD MAIN PCB P020 AK97-00814A ASSY-CONNECTOR BOARD;HIPS,DVD-V540/XSA,- P021 AK61-00344A CONNECTOR BOARD;SV-DVD240/XEV,HIPS 94HB, P025 AC39-10019A CBF-POWER CORD;KKP-419C,H03VVH2-F,VDE/KE S602A AC61-00341A HOLDER-TR;X-11,POM(K300),-,-,-,NTR,- W001 6003-000275 SCREW-TAPTITE;BH,+,B,M3,L10,BLK ,SWCH101...

  • Page 26: Vcr Mechanical Parts (Top Side)

    3-2 VCR Mechanical Parts (Top Side) G001 K490 K502 K530 G555 G530 B474 G450 G510 B473 G420 G480 K546 K250 K240 K248 B411 B410 K350 K110 B440 K182 B448 K340 K330 B452 G546 K470 K140 K188 G527 G070 G520 G060 Samsung Electronics...
  • Page 27 BAND-BRAKE ASS’Y;TS-10,-,-,-,-,-,- K330 AC66-30550A LEVER-S.BRAKE ASSY;-,POM+SUS,-,-,-,X-9 K340 AC66-30549A LEVER-T.BRAKE ASSY;-,POM+SUS,-,-,-,X-9 K350 AC61-00106A SPRING ETC-BRAKE;TS-10,SUS304-WPB,-,-,-, K470 AC66-00020A SLIDER-FL DRIVE;TS-10,SECC ,T1.0,-,-,SIL K490 AC61-00120A HOLDER-FL CASS. ASS’Y;TS-10,-,-,-,-,-,- K502 AC61-60561A SPRING ETC-FL.LEVER-LR;X-9,SUS304 WPB,OD K530 AC66-00034A LEVER-FL ARM ASS’Y;TS-10,-,-,-,-,-,-,- K546 AC61-50658A GUIDE-CASS. DOOR;X-9,POM,-,-,-,NTR Samsung Electronics...

  • Page 28: Vcr Mechanical Parts (Bottom Side)

    Exploded View and Parts List 3-3 VCR Mechanical Parts (Bottom Side) G542 B462 B456 B460 B560 B500 B458 B464 B488 B484 B468 B475 K222 K200 K225 K221 B478 B570 Samsung Electronics...
  • Page 29 AC97-02195A ASSY-LEVER LOADING S;SECC+POM+SUS,X-11,F B500 AC97-02196A ASSY-LEVER LOADING T;SECC+POM+SUS,X-11,F B560 AC81-00004A MOTOR-CAPSTAN;THRUST END PLAY-0.2,MR-FG B570 AC60-10514A SCREW-CAPSTAN;-,-,M2.6,L6,PH,+,-,-,-,- G542 AC66-60051A BELT-PULLEY;-,5CM-70,2 * 2,-,71.3,-,X-9 K200 AC61-21012A HOLDER-CLUTCH ASSY;X-9,ABS,-,-,-,BLK,- K221 AC66-20581A GEAR-CENTER ASSY;X-9,POM,M=O.5,-,-,GRY,- K222 AC60-30306A FASTENER-WASHER SLIT;-,-,ID2.1,OD5.0,T0. K225 AC66-00006A LEVER-UP DOWN;TS-10,POM,-,-,-,-,NAT,- Samsung Electronics...

  • Page 30: Dvd Mechanical Parts

    Exploded View and Parts List 3-4 DVD Mechanical Parts H212 H102 H205 H900 H204 H202 H903 H903 H210 H241 H211 H207 H206 H206 H904 H904 H203 H209 H107 H105 H106 H103 H903 H108 H104 H109 Samsung Electronics...
  • Page 31 H206 AK61-00032A HOLDER-CAM SKEW;DP-9,POM,-,-,-,BLACK,- H207 AK31-00014A MOTOR SPINDLE;DP-15,3000RPM,-,-,-,- H209 AK64-00491A CHASSIS SUB;DP-15,POM,-,-,-,-,- H210 AK31-00005A MOTOR-FEED ASSY;-,DP-9,-,-,-,-,-,-,-,-,- H211 AK97-00638A ASSY-PICK UP;-,SOH-DT2,TRINO ASSY PICK U H212 AK61-00253A HOLDER-CHUCK;DP-15,POM,-,-,-,-,- H241 AK41-00156B FFC-PU;DP-15,-,FFC,24,T0.3,RIGHT H900 6003-001157 SCREW-TAPTITE;PWH,+,B,M2,L6,ZPC(YEL),SWR H903 6001-001370 SCREW-MACHINE;CH,+,M1.7,L3.0,ZPC(YEL),SW H904 6002-001086 SCREW-TAPPING;PH,+,B,M1.7,L5.0,ZPC(YEL), Samsung Electronics...
  • Page 32 Exploded View and Parts List MEMO 3-10 Samsung Electronics...
  • Page 33 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,- C506 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608 C333 2401-000408 C-AL;10uF,20%,16V,GP,TP,3.5x5,2.5 C507 2401-000909 C-AL;22uF,20%,16V,GP,TP,5x5,2.5 C334 2203-000975 C-CER,CHIP;47nF,10%,25V,X7R,TP,1608,- C508 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608 C334A 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608 C510 2401-001502 C-AL;47uF,20%,16V,GP,TP,6.3x5,2.5 C335 2203-001652 C-CER,CHIP;470nF,+80-20%,16V,Y5V,TP,1608 C511 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608 Samsung Electronics This Document can not be used without Samsung’s authorization...
  • Page 34 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608 CK71 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608 C695 2203-000357 C-CER,CHIP;0.15NF,5%,50V,C0G,TP,1608 CK72 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5 C701 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 CK73 2401-000588 C-AL;1uF,20%,50V,GP,TP,3x5,2.5 C702 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608 CK74 2401-002183 C-AL;220uF,20%,16V,GP,TP,8x9,5mm C703 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,TP,1608,- CK75 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5 Samsung Electronics This Document can not be used without Samsung’s authorization...
  • Page 35 IC-OP AMP;4560,SOP,8P,173MIL,DUAL,100V/m Q3A01 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T ICK2 1201-000163 IC-OP AMP;4560,SOP,8P,173MIL,DUAL,100V/m Q3A02 0501-000303 TR-SMALL SIGNAL;KSA733,PNP,250mW,TO-92,T ICK3 1201-000163 IC-OP AMP;4560,SOP,8P,173MIL,DUAL,100V/m Q3A03 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9 ICK4 1204-001730 IC-ECHO;M65855P,DIP,16P,300MIL,PLASTIC Q3A04 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400mW,T0-9 Samsung Electronics This Document can not be used without Samsung’s authorization...
  • Page 36 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608 R552 2007-000913 R-CHIP;43Kohm,5%,1/10W,TP,1608 R331 2007-000079 R-CHIP;1.8Kohm,5%,1/10W,TP,1608 R553 2007-000093 R-CHIP;20Kohm,5%,1/10W,TP,1608 R333 2007-001039 R-CHIP;56Kohm,5%,1/8W,TP,2012 R570 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 R334 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608 R571 2007-000098 R-CHIP;56Kohm,5%,1/10W,TP,1608 R335 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM R601 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 Samsung Electronics This Document can not be used without Samsung’s authorization...
  • Page 37 2001-000938 R-CARBON;68OHM,5%,1/8W,AA,TP,1.8X3.2MM RK54 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608 R7K09 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 RK55 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 R7K10 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 RK56 2007-000103 R-CHIP;120Kohm,5%,1/10W,TP,1608 R7K11 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 RK61 2001-000679 R-CARBON;36KOHM,5%,1/8W,AA,TP,1.8X3.2MM R7K12 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 RK63 2007-000081 R-CHIP;2.7Kohm,5%,1/10W,TP,1608 Samsung Electronics This Document can not be used without Samsung’s authorization...
  • Page 38 AR29 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 AR30 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608 AR31 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 AR32 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608 AR35 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 AR40 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 AR41 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608 AR42 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 AR43 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608 Samsung Electronics This Document can not be used without Samsung’s authorization...
  • Page 39 2007-000312 R-CHIP;10ohm,5%,1/4W,TP,3216 CCC08 2401-001479 C-AL;470uF,20%,10V,GP,TP,6.3*11mm,5 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608 CCC09 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608 MC10 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608 CCC10 2401-001479 C-AL;470uF,20%,10V,GP,TP,6.3*11mm,5 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608 CCC13 2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608 CCC15 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608 MCE1 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5 Samsung Electronics This Document can not be used without Samsung’s authorization...
  • Page 40 R-CHIP;12Kohm,0.5%,1/10W,TP,1608 2203-001103 C-CER,CHIP;6.8nF,10%,50V,X7R,TP,1608,- 2007-001694 R-CHIP;12Kohm,0.5%,1/10W,TP,1608 2203-001634 C-CER,CHIP;33nF,10%,50V,X7R,TP,1608,1.6m 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 2203-001607 C-CER,CHIP;0.22nF,5%,50V,NP0,-,1608 2007-000134 R-CHIP;33Kohm,5%,1/10W,TP,1608 2203-005148 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 RCL23 3301-000314 BEAD-SMD;120ohm,1.6x0.8x0.8mm,150mA,,,, 1204-002260 IC-PAL/NTSC DECODER;ES6629FD,PQFP,208P,2 RE10 2401-001479 C-AL;470uF,20%,10V,GP,TP,6.3*11mm,5 VBD1 3301-001461 BEAD-SMD;300ohm,1.6x0.8x0.8mm,300mA,TP, Samsung Electronics This Document can not be used without Samsung’s authorization...
  • Page 41 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD VZ11 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD VZ12 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD VZ20 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD VZ21 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD VZ22 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD VZ23 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD 0403-001083 DIODE-ZENER;UDZ9.1B,8.85-9.23V,200MW,UMD Samsung Electronics This Document can not be used without Samsung’s authorization...
  • Page 42 Electrical Parts List MEMO 4-10 Samsung Electronics This Document can not be used without Samsung’s authorization...
  • Page 43 DIC4 IC601 (M37760E) IC602 EEPROM (TC74VHCT125) DIC3 (24C02) Level Shifter VCR Main Micom EPROM ICK4/ICK5 IC701 DIC2 Karaoke (PT6961) (MBM29LV800BA) LED Drive IMB Flash Memory MIC Jack STEREO (DT701) Samsung Electronics This Document can not be used without Samsung’s authorization...
  • Page 44 Block Diagram MEMO Samsung Electronics This Document can not be used without Samsung’s authorization...

  • Page 45: Table Of Contents

    6-13 DVD Audio/Video - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6-14 <Component Side> Samsung Electronics This Document can not be used without Samsung’s authorization...
  • Page 46 Schematic Diagrams 6-1 S.M.P.S. Samsung Electronics This Document can not be used without Samsung’s authorization...

  • Page 47: Power Drive

    Schematic Diagrams 6-2 Power Drive Samsung Electronics This Document can not be used without Samsung’s authorization...

  • Page 48: Display/Function

    Schematic Diagrams 6-3 Display/Function Samsung Electronics This Document can not be used without Samsung’s authorization...

  • Page 49: System Control/Servo

    Schematic Diagrams 6-4 System Control/Servo Samsung Electronics This Document can not be used without Samsung’s authorization...

  • Page 50: A/V

    Schematic Diagrams 6-5 A/V Samsung Electronics This Document can not be used without Samsung’s authorization...

  • Page 51: Hi-Fi

    Schematic Diagrams 6-6 Hi-Fi Samsung Electronics This Document can not be used without Samsung’s authorization...

  • Page 52: A2/Nicam

    Schematic Diagrams 6-7 A2/NICAM Samsung Electronics This Document can not be used without Samsung’s authorization...
  • Page 53 Schematic Diagrams 6-8 TM Samsung Electronics This Document can not be used without Samsung’s authorization...

  • Page 54: Input-Output

    Schematic Diagrams 6-9 Input-Output 6-10 Samsung Electronics This Document can not be used without Samsung’s authorization...

  • Page 55: Karaoke

    Schematic Diagrams 6-10 Karaoke Samsung Electronics 6-11 This Document can not be used without Samsung’s authorization...

  • Page 56: Dvd Av Decoder

    Schematic Diagrams 6-11 DVD AV Decoder 6-12 Samsung Electronics This Document can not be used without Samsung’s authorization...

  • Page 57: Dvd Servo

    Schematic Diagrams 6-12 DVD Servo Samsung Electronics 6-13 This Document can not be used without Samsung’s authorization...

  • Page 58: Dvd Audio/Video

    Schematic Diagrams 6-13 DVD Audio/Video 6-14 Samsung Electronics This Document can not be used without Samsung’s authorization...
