PictureMate Parts
LCD menu screen
Turn PictureMate on or off
Navigate
menu
options
Click to print
Control Panel
Paper support
Front
USB port for computer
Handle
Back
Save photos to an external
storage drive (CD-R, Zip disk,
or flash memory drive)
Go back or
stop
printing
Memory card light
(flashes when reading
card; on when card is
in printer)
Memory card door
Output tray
EXT/IF (USB) port for PictBridge
camera, external drive, or
optional Bluetooth Adapter
Power cable
Photo cartridge door
Accessories
PictureMate Print Pack (part# T5570)
Includes 100 sheets of PicureMate Photo Paper and a
PictureMate Photo Cartridge
PictureMate Carrying Case (part# ARC1B)
Soft case that holds PictureMate, power cable, extra
PictureMate Print Pack, and more
Epson Bluetooth Photo Print Adapter
(part# C12C824142)
Allows printing wirelessly from Bluetooth-enabled cell
phones, PDAs, or computers to PictureMate

Printer Specifications

Printing
Nozzle
configuration
90 nozzles × 6: yellow, magenta, cyan,
photo black, red, blue
Print direction
Bidirectional with logic seeking
Control code
ESC/P Raster, EPSON Remote command
Input buffer
64KB
Mechanical
Paper capacity
20 sheets of PictureMate Photo Paper
Dimensions
Storage
Width: 10.0 inches (256 mm)
Depth: 6.1 inches (154 mm)
Height: 6.4 inches (163 mm)
Printing
Width: 10.0 inches (256 mm)
Depth: 12.0 inches (305 mm)
Height: 6.4 inches (163 mm)
Weight
5.5 lb (2.5 kg) without photo cartridge
Electrical
Input voltage
108 to 132 V
Rated frequency
50 to 60 Hz
Input frequency
49.5 to 60.5 Hz
Rated current
0.4 A
4/04
PictureMate
PictureMate
- 1
