PRODUCT SPECIFICATION …………………………………………. 21 BEFORE CALLING SERVICE ………………………………………… 22 GLOSSARY ………………………………………………………... 23 APPENDIX ………………………………………………………... 24 MOUNTING THE TV BASE ………………………………………. 25 SYMBOL DANGEROUS VOLTAGE: The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”...
WARNING: To prevent fire or shock hazard, do not expose the TV to rain or moisture. Dangerously high voltages are present inside the TV. Do not open the cabinet. Refer servicing to qualified personnel only.
Don't place the TV in confined spaces or in a box when using it. Unplug immediately if other foreign materials are put inside TV box or if the TV fell down. Prohibit/Avoid opening TV cabinet...
Page 5
Avoid direct sunlight, dusty, high humidity and smoky areas. Call service personnel to clean the internal part of the TV once a year. Do not place the display near water, such as bathtub, washbasin, kitchen sink laundry tub, swimming pool or in a damp basement.
13. The TV should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company.
Page 7
Please, make sure to connect the power plug to the wall outlet socket after connecting the TV to the adapter! 22. Objects and Liquid Entry – Care should be taken so that objects do not fall...
TV to the power cord! Install the base stand; place the TV on a solid surface. Ensure that the TV is placed in a position to allow free flow of air. Do not cover the ventilation openings on the back cover.
Page 9
Insert the power cord in the wall socket having an AC power supply. You can see LED states at the front panel. If the LED color is Green, means the TV set is power on. If the LED color is Orange, which means this TV set is in standby state.
(ex: Press VIDEO button to select “Composite Rear” if you have connected a video recorder to Composite Rear socket.) Note: The MUTE key on the remote control works on both TV internal speaker and the earphone output. SPDIF Component...
MENU 6 INPUT Source key: Press to select the input source. Power key: Press to turn on / off (standby) the TV set. 7 POWER (Please re-turn on TV after the Power-ON status LED had changed to the orange color and finished flashing.)
POWER Press to power ON/OFF (standby) TV.(Note:1.TV is never completely power off unless physically unplugged. 2.Press to turn on TV after the power on status LED had changed to the amber color and stopped flashing. ) VIDEO Press repeatedly to choose S-...
SETUP MENU The Setup menu in TV mode shows as below. In others source modes, the Setup menu only shows Menu Language and Aspect Ratio items. 1. Tuning Band: Select TV source signal from the Air (antenna) or Cable (CATV).
7. Menu Language: Select the menu display language. (English / Espanol / Francais) 8. Aspect Ratio: Select the display aspect ratio. (Normal/Zoom/Wide/Cinema) 9. Favorite Channel Mode: When favorite channel mode on user can edit favorite channel table in favorite channel set option. VIDEO MENU The Video menu in most source modes shows as below.
5. Digital Audio Output: Digital audio output format selection, user can choose RAW (default) or PCM format or off. 6. TV Speaker: Choose to turn on / off the TV internal speaker. The digital audio output signals、earphone output signals will not be turn-off even though the TV speaker is off.
2. Sleep Timer: Enable or disable the TV standby timer. User can set the TV standby timer as off / 5 min / 10 min / 15 min/ 30 min / 45 min / 60 min/ 90 min / 120 min / 180min/ 240min.
Page 17
4. Password Set: Change the 4-numeral parental control password. Three steps are required for changing the password: Enter Old Password -> Enter New Password -> Confirm New Password. Note: This item is only available in TV, Composite and S-Video source modes. The default password is 『0 0 0 0』.
Page 18
Digital Captions: Select the close caption options ( Service 1-6, Text 1-4 and CC 1-4) in digital TV mode. When select service 1 to service 6 you canmodulate parameters in the Digital Close Caption. 7. Digital Close Caption: Provide numerous options for setting the digital close caption style.
Page 19
【Size】: Digital close caption font size, which can be set as Small、Normal or Large. 【Font】: Digital close caption font style, which can be chosen as Default or Font 1 ~ 7. 【Text Color】: Giving Red / Green / Blue/ Yellow / Magenta / Cyan / Black / White Colors.
Do not rub or strike the screen with anything hard as this may scratch, mar, or damage the screen permanently. Unplug the power cord before cleaning the screen. Dust the TV by wiping the screen and the cabinet with a soft, clean cloth. If the screen requires additional cleaning, use a clean, damp cloth.
Page 21
˙Reorient or relocate the receiving antenna. ˙Increase the separation between the equipment and the TV. ˙Connect the equipment into wall power outlet on a circuit different from that to which the receiver is connected.
Channel Coverage: VHF: 2 through 13 UHF: 14 through 69 Cable TV: Mild band (A - 8 through A - 1, A through Super band (J through W) Hyper band (AA through ZZ, AAA, BBB) Ultra band (65 through 94, 100 through 125)
TV again. *Check antenna connections at the rear of the TV to see if it is properly connected to the TV. *Possible broadcast station trouble. Try another channel. *Adjust the contrast and brightness settings.
(usually containing a second language translation for the displayed program). Sleep Timer You can set a time period for which the TV will automatically turn itself off. S-Video Input You can connect your TV set to a high-resolution video source (such as Super VHS video-cassette recorder, Laser Disc player and DVD Home Theater Set) in- order to provide maximum consumer viewing satisfaction.
MOUNTING THE TV BASE The TV base will be separated with the TV unit. You should Install the base before you use the TV unit. Place the TV on its face on a soft blanket. Install the base stand with three screws.
