VHIM-2GSX-L3
GIGABIT ETHERNET
EXPANSION MODULE
QUICK INSTALLATION GUIDE
9033694-01
NOTICE! ONLY QUALIFIED
PERSONNEL SHOULD PERFORM
INSTALLATION PROCEDURES.
Enterasys Networks reserves the right to make changes
in specifications and other information contained in
this document without prior notice. The reader should
in all cases consult Enterasys Networks to determine
whether any such changes have been made.
The hardware, firmware, or software described in this
manual is subject to change without notice.
IN NO EVENT SHALL ENTERASYS NETWORKS BE
LIABLE FOR ANY INCIDENTAL, INDIRECT,
SPECIAL, OR CONSEQUENTIAL DAMAGES
WHATSOEVER (INCLUDING BUT NOT LIMITED TO
LOST PROFITS) ARISING OUT OF OR RELATED TO
THIS DOCUMENT, WEB SITE, OR THE
INFORMATION CONTAINED IN THEM, EVEN IF
ENTERASYS NETWORKS HAS BEEN ADVISED OF,
KNEW OF, OR SHOULD HAVE KNOWN OF, THE
POSSIBILITY OF SUCH DAMAGES.
Enterasys Networks, Inc.
500 Spaulding Turnpike
Portsmouth, NH 03801
2002 Enterasys Networks, Inc.
All Rights Reserved
Printed in the United States of America
Order Number: 9033694-01 April 2002
LANVIEW is a registered trademark of
Enterasys Networks. ENTERASYS
NETWORKS, NETSIGHT, MATRIX, WEBVIEW,
and any logos associated therewith, are trademarks of
Enterasys Networks.
SPECTRUM is a registered trademark of Aprisma
Management Technologies, Inc.
All other product names mentioned in this
manual may be trademarks or registered
trademarks of their respective companies.
FCC NOTICE
This equipment has been tested and found to comply
with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference when the equipment is operated in a
commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if
not installed and used in accordance with this user's
guide, may cause harmful interference to radio
communications. Operation of this equipment in a
residential area is likely to cause harmful interference
in which case the user will be required to correct the
interference at his own expense.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
WARNING: Changes or modifications made to this
device which are not expressly approved by the party
responsible for compliance could void the user's
authority to operate the equipment.
INDUSTRY CANADA NOTICE
This digital apparatus does not exceed the Class A
limits for radio noise emissions
from digital apparatus set out in the Radio Interference
Regulations of the Canadian
Department of Communications. Le présent appareil
numérique n'émet pas de bruits radioélectriques
dépassant les limites applicables aux appareils
numériques de la class A prescrites dans le
Règlement sur le brouillage
radioélectrique édicté par le ministère des
Communications du Canada.
VCCI NOTICE
Class A ITE Notice
WARNING: This is a class A product. In a domestic
environment this product may cause radio interference
in which case the user may be required to take
adequate measures.
EC CONFORMANCE DECLARATION
European contact:
Enterasys Networks Ltd.
Nexus House, Newbury Business Park
London Road, Newbury
Berkshire RG14 2PZ, England
This information technology product complies with
ISO/IEC Guide 22 and EN45014. It conforms to the
following specifications:
EN55022(1988)/CISPR-22(1985) Class A
EN50082-1: IEC 1000-4-2, 3, 4, 6
This information technology product complies with
the requirements of the Low Voltage Directive
73/23/EEC and the EMC Directive 89/336/ EEC and
carries the CE Mark accordingly.
SAFETY WARNING
Before installing or removing the VHIM-2GBC-L3,
first disconnect the switch from the main power supply.
For full safety instructions, please refer to the user
guide that accompanies the switch.
Warning:
CLASS I LASER
Optical Safety for Fiber
DEVICE
Optic Modules
When using a fiber optic media expansion module,
never look at the transmit laser while it is powered on.
Also, never look directly at the fiber TX port and fiber
cable ends when they are powered on.
Avertissment:
DISPOSITIF
Ports pour fibres
LASER DE
optiques –sécurité sur le
CLASSE I
plan optique
Ne regardez jamais le laser tant qu'il est sous tension.
Ne regardez jamais directement le port TX
(Transmission) à fibres optiques et les embouts de
câbles à fibres optiques tant qu'ils sont sous tension.
Warnhinweis:
Faseroptikanschlüsse –
LASERGERÄT
Optische Sicherheit
DER KLASSE
Niemals ein Übertragungslaser betrachten, während
dieses eingeschaltet ist.
Niemals direkt auf den Faser-TX-Anschluß und auf die
Faserkabelenden schauen, während diese eingeschaltet
sind.
SPECIFICATIONS
Ports 2 1000Base-SX
Communication Mode Full duplex mode and flow control
Network Interface SC connector,
850 nm short-wavelength transceiver
62.5/125 or 50/125 micron multimode fiber cable
Switch Method Store-and-forward
Queue Buffer 16 Mbytes
Size 4.82 x 3.57 x 1.08 in.
(12.25 x 90.70.5 x 2.74 cm)
Power Consumption 2.4W maximum
Temperature Operating: 32° to 131° F (0° to 55° C)
Storage: -40° to 131° F (-25° to 55° C)
Humidity
Operating: 5% to 95%
Emissions
FCC Class A, VCCI class A, BSMI class A
EN55022 Class A, C-Tick class A, CE Mark
Immunity
IEC 1000-4-2/3/4/6
Standards IEEE 802.3z Gigabit Ethernet
ISO/IEC 8802-3
CABLE TYPES AND SPECIFICATIONS
Cable Type
Cat. 3,4,5 100 m
10Base-T
100-ohm UTP (328 ft.)
100 m
100Base-T Cat. 5 100-ohm
(328 ft.)
100 m
1000Base-T Cat. 5e 100-ohm
(328 ft.)
50/125 µm or
See table
1000Base-SX 62.5/125 µm
below
multimode fiber
See table
1000Base-LX MMF or SMF
below
1000Base-SX Fiber
Diameter Bandwidth
62.5/125 µm MMF 160 MHz/km
200 MHz/km
50/125 µm MMF 400 MHz/km
500 MHz/km
1000Base-LX Fiber
Diameter Bandwidth
9 µm SMF N/A
62.5/125 µm MMF 500 MHz/km
50/125 µm MMF 400 MHz/km
500 MHz/km
I
Note: Network diameter is defined as the wire distance
between two end stations in the same collision domain.
Max.
Connector
Length
RJ-45
RJ-45
RJ-45
SC or ST
SC or ST
Range
2-220 m (7-722 ft.)
2-275 m (7-902 ft.)
2-500 m (7-1641 ft.)
2-550 m (7-1805 ft.)
Range
2 m – 5 km (16,404 ft.)
2-550 m (7-1805 ft.)
2-550 m (7-1805 ft.)
2-550 m (7-1805 ft.)
