- Page 1 OWNER’S MANUAL Micro Hi-Fi Audio Please read this manual carefully before operating your set and retain it for future reference. MODEL CM1560DAB (CM1560DAB, CMS1560F) www.lg.com MFL71379809 Copyright © 2019 LG Electronics Inc. All Rights Reserved. 1908_Rev01...
- Page 2 Getting Started Safety Information CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK) CAUTION: This product employs a Laser System. NO USER-SERVICEABLE PARTS INSIDE REFER To ensure proper use of this product, please read SERVICING TO QUALIFIED SERVICE PERSONNEL.
- Page 3 Getting Started Symbols CAUTION: The apparatus should not be exposed to water (dripping or splashing) and no objects filled with liquids, such as vases, should be placed on the Refers to alternating current(AC). apparatus. Refers to direct current(DC). CAUTION: Do not use high voltage products around this product.
-
Page 4: Table Of Contents
Table of Contents Table of Contents Operating Basic Operations – CD/USB Operations Other Operations Getting Started – Programmed Playback – Deleting Programmed list Safety Information – Selecting a folder Unique Features – Displaying file information Playable file Requirement (ID3 TAG) –... - Page 5 Table of Contents Troubleshooting Troubleshooting Appendix Main unit Speakers Maintenance – Handling the Unit – Notes on Discs Trademarks and Licenses...
-
Page 6: Getting Started
Getting Started Unique Features BLUETOOTH Listens to music stored on your Bluetooth device. -
Page 7: Playable File Requirement
You have to set the disc format option to [Mastered] y This unit recognizes up to 1,000 files. in order to make the discs compatible with the LG players when formatting rewritable discs. When y External HDD, card readers, locked devices, or hard setting the option to Live File System, you cannot use type USB devices are not supported. -
Page 8: Remote Control
Getting Started Remote control • • • • • • • • • • • • • • a • • • • • • • • • • • • • 1 (Standby) : Switches the unit ON or OFF. SLEEP : Sets the system to turn off automatically at a specified time. - Page 9 Getting Started • • • • • • • • • • • • • • b • • • • • • • • • • • • • • • • • • • • • • • • • • • c • • • • • • • • • • • • • PROGRAM/MEMORY : TUNING -/+ : - Stores radio stations.
-
Page 10: Front Panel
Getting Started Front Panel a 1/! (Standby/On) b R (Open) Switches the unit ON or OFF. Uses it when inserting or removing a CD. F (Function) c Display window Selects the function or input source. d Volume Knob Y/U (Skip/Search) Adjusts volume of speaker. -
Page 11: Rear Panel
Getting Started Rear Panel R (6 Ω) L (6 Ω) a DAB+/FM ANTENNA b SPEAKERS (L/R) terminals c POWER IN... -
Page 12: Connecting
Connecting > Caution Connecting to speakers y Make sure children do not put their hands or any objects into the *speaker duct. * Speaker duct : A hole for plentiful bass Connecting the speakers to the sound on speaker cabinet (enclosure) unit y Use the speaker supplied with this unit only. -
Page 13: Optional Equipment Connection
Connecting Optional Equipment PORT. IN Connection Connect an output (earphone or line out) of portable Connection device (MP3 or PMP etc) to the PORT. IN connector. USB Connection Connect a USB device to the USB ports on the unit. Portable cable MP3 player etc. -
Page 14: Operating
Operating Note Basic Operations y The display changes in the following order. MP3/WMA CD AUDIO CD CD/USB Operations RPT 1 RPT 1 RPT 1 1. Insert the disc by pressing R on the unit or connect the USB device to the USB port. RPT*DIR RPT DIR 2. -
Page 15: Other Operations
Operating Other Operations Deleting Programmed list Deleting function only works in the edit mode. 1. Press PROGRAM/MEMORY on the remote Programmed Playback control in stop status. 2. Select a song by pressing PROGRAM/MEMORY The program function enables you to store your or PRESET/FOLDER W/S on the remote favorite files from any disc or USB device. -
Page 16: Selecting A Folder
Operating Selecting a folder Displaying file information (ID3 TAG) 1. Press PRESET/FOLDER W/S on the remote control repeatedly until a desired folder appears. While playing an MP3 file containing file information, 2. Press d/M on the remote control or T on the you can display the information by pressing INFO on unit to play it. -
Page 17: Sleep Timer Setting
Operating Sleep Timer Setting DEMO Press SLEEP repeatedly to select delay time In the power on state, adjust the volume level of the between 10 and 180 minutes. After the delay time, main unit to minimum and then press and hold F on the unit will be turned off. -
Page 18: Auto Power On
Operating AUTO POWER On Auto function change This unit automatically turns on by an input source : This unit recognizes input signals such as Bluetooth, Bluetooth and then changes suitable function automatically. If you try to connect your Bluetooth device, this When you try to connect Bluetooth unit turns on and the unit will be connected your Bluetooth device. -
Page 19: Sound Adjustment
Operating Note Sound adjustment y On some speakers, sound may not be heard or heard in low sound depending on the sound mode. This system has a number of pre-set surround sound fields. The displayed items for the equalizer may be y Maybe you need to reset the sound mode, different depending on sound sources and effects. -
Page 20: Using A Bluetooth® Wireless Technology
Bluetooth was made via Bluetooth wireless technology. device display depending on the type of Available Devices : Mobile phone, MP3, Laptop, PDA. Bluetooth device. Your unit appears as “LG- y Version: 2.1 + EDR CM1560DAB(XX)” . y Codec: SBC... - Page 21 Operating Note y When using Bluetooth technology, you have to make a connection between the unit and the Bluetooth device as close as possible and keep the distance. However, it may not work well in certain situations as described below: - There is a obstacle between the unit and the Bluetooth device.
-
Page 22: Radio Operations
Operating Radio Operations Presetting the Radio Stations You can preset 50 stations for FM/DAB+. Before tuning, make sure to turn down the volume. Listening to the radio 1. Press F on the remote control or on the unit until FM/DAB+ appears in the display window. 1. -
Page 23: Seeing Information About A Radio Station
Operating Seeing information about a Listening to the DAB+ Radio station You can change the display information of the currently broadcasting DAB+ channel. The FM tuner is supplied with the RDS (Radio Data Press DAB+ MODE on the remote control System) facility. -
Page 24: Troubleshooting
Troubleshooting Troubleshooting Problem Cause & Correction y Turn off the power of this unit and the connected external device (TV, Woofer, DVD-player, Amplifier, etc.) and turn it on again. The unit does not work y Disconnect the power cord of this unit and the connected external device properly. -
Page 25: Appendix
Appendix Main unit General Power requirements Refer to the main label. Refer to the main label. Power consumption Networked standby : 0.5 W (If all network ports are activated.) Dimensions (W x H x D) Approx. 150 mm x 181 mm x 210 mm Operating temperature 5 °C to 35 °C Operating humidity... -
Page 26: Speakers
Appendix Speakers Front Type 1 Way 1 Speaker 6 Ω Impedance Rated Input Power Max. Input Power 10 W Dimensions (W x H x D) Approx. 132 mm x 181 mm x 140 mm y Design and specifications are subject to change without notice. -
Page 27: Maintenance
Appendix Maintenance Notes on Discs Handling Discs Handling the Unit Never stick paper or tape on the disc. Storing Discs When shipping the unit After playing, store the disc in its case. Do not Please save the original shipping carton and packing expose the disc to direct sunlight or sources of heat materials. -
Page 28: Trademarks And Licenses
Trademarks and Licenses The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by LG Electronics is under license. Other trademarks and trade names are those of their respective owners.
