308-1425B FAQS ................................................................................................................. 1
AC Power ............................................................................................................................... 2
Batteries ................................................................................................................................ 2
Weather Station Factory Restart .................................................................................. 2
Outdoor Temperature Sensor ......................................................................................... 3
Compatible Outdoor sensors ............................................................................................. 3
Quick Connect ..................................................................................................................... 3
Outdoor Temperature Signal Strength ............................................................................ 3
Dashes show for Outdoor Temperature .......................................................................... 3
Power Requirements .......................................................................................................... 3
Inaccurate Outdoor Temperature Reading ..................................................................... 3
Intermittent Outdoor Temperature .................................................................................. 4
Outdoor Temperature is stuck or HH.H, LL.L ................................................................. 4
Outdoor sensor drains batteries quickly ......................................................................... 4
Outdoor Humidity goes to dashes when temperature is cold. .................................... 5
Outdoor sensor fell. The sensor no longer works .......................................................... 5
Temperature/Humidity Trend Arrows .............................................................................. 5
MIN/MAX Temperature readings ...................................................................................... 6
Heat Index/Dew Point ........................................................................................................ 6
Mounting/Positioning Outdoor sensor ............................................................................. 6
Position Weather Station ................................................................................................... 7
Distance/Resistance/Interference .................................................................................... 7
Temperature Alerts ........................................................................................................ 8
Weather Station .................................................................................................................. 9
Power Requirements .......................................................................................................... 9
12-Hour or 24-Hour time format ..................................................................................... 9
Fahrenheit/Celsius .............................................................................................................. 9
Backlight ............................................................................................................................... 9
Dashes, HH.H, LL.L or stuck Indoor Temperature/Humidity ....................................... 9
Inaccurate Indoor Temperature Reading ........................................................................ 9
Set Time Alarm.................................................................................................................... 9
Activate/Deactivate time alarm .......................................................................................10
Snooze Alarm .....................................................................................................................10
No WWVB Tower Icon ...........................................................................................................10
Time is off by hours ...............................................................................................................10
La Crosse Technology, Ltd.
30 8- 14 25 B F AQ S
CO N T E NT S
www.lacrossetechnology.com/support
Page 1
Advertisement
Table of Contents
Related Manuals for La Crosse Technology 308-1425B
Summary of Contents for La Crosse Technology 308-1425B
-
Page 1: Table Of Contents
The links below will work in most PDF viewers and link to the topic area by clicking the link. We recommend Adobe Reader version 10 or greater available at: http://get.adobe.com/reader CO N T E NT S 308-1425B FAQS ......................... 1 AC Power ..........................2 Batteries ..........................2 Weather Station Factory Restart .................. 2 Outdoor Temperature Sensor .................. -
Page 2: Ac Power
15 minutes to establish a strong connection. 10. Do not press buttons for 15 minutes. For optimum 433MHz transmission, place the outdoor sensor no more than 300 feet (91 meters, open air) from the weather station. La Crosse Technology, Ltd. www.lacrossetechnology.com/support Page 2... -
Page 3: Outdoor Temperature Sensor
You may choose to use Lithium batteries for temperatures below -20°F/-28.8°C. Inaccurate Outdoor Temperature Reading Explanation: High outdoor temperature readings are generally a location issue. Low outdoor temperature readings are power related or a sensors going bad. La Crosse Technology, Ltd. www.lacrossetechnology.com/support Page 3... -
Page 4: Intermittent Outdoor Temperature
Check the distance resistance between the outdoor sensor and weather station. Outdoor sensors at the end of the range may work while batteries are fresh but not after they drain a bit. La Crosse Technology, Ltd. www.lacrossetechnology.com/support Page 4... -
Page 5: Outdoor Humidity Goes To Dashes When Temperature Is Cold
Note: Be sure to order the correct model and frequency to avoid receiving the incorrect item. Call La Crosse Technology® Store at 608-785-7939 or e-mail from the store website if you are unsure about the correct item to order. Each item carries the original new product warranty and includes access to La Crosse Technology®... -
Page 6: Min/Max Temperature Readings
Mount at least 6 feet in the air for a strong RF (radio frequency) signal. Do not mount the outdoor sensor on a metal fence. This significantly reduces the effective range. La Crosse Technology, Ltd. www.lacrossetechnology.com/support Page 6... -
Page 7: Position Weather Station
When considering the distance between the outdoor sensor and the weather station (200 feet open air), cut that distance in half for each wall, window, tree, bush or other obstruction in the signal path. Closer is better. La Crosse Technology, Ltd. www.lacrossetechnology.com/support Page 7... -
Page 8: Temperature Alerts
When temperature alert sounds, the corresponding alert icon (bell) will flash. The alert beeps once every minute, until the temperature is out of alert range. Press any button to stop alert. The alert symbol will still show. La Crosse Technology, Ltd. www.lacrossetechnology.com/support Page 8... -
Page 9: Weather Station
Look for heat sources such as sunlight, door or window frames or reflected heat or cold near the weather station. Check batteries and AC power cord. Set Time Alarm La Crosse Technology, Ltd. www.lacrossetechnology.com/support Page 9... -
Page 10: Activate/Deactivate Time Alarm
2. TIME ZONE: EST will flash. Press and release the ▲ or ▼ buttons to select a different Time Zone: AST=Atlantic, EST= Eastern, CST= Central, MST= Mountain, PST= Pacific, AKT= Alaska, HAT=Hawaiian time zone. Confirm with the TIME SET button and move to DST. La Crosse Technology, Ltd. www.lacrossetechnology.com/support Page 10... - Page 11 This is due to the graph having a limited number of bars per time. The graph will correct itself within 1-2 days. The pressure graph will scroll to prevent LCD burnout. Moon phase La Crosse Technology, Ltd. www.lacrossetechnology.com/support Page 11...
- Page 12 Press any button 20 times. Leave the batteries out of the display for 2 hours. Insert batteries into the weather station. Weather station drains batteries quickly Test a new set of alkaline batteries. Write down the date of installation and the voltage of the batteries. La Crosse Technology, Ltd. www.lacrossetechnology.com/support Page 12...
- Page 13 Remove batteries from weather station. Press any button 20 times. Leave the weather station unpowered for 1-2 hours. Install fresh alkaline batteries with correct polarity. La Crosse Technology, Ltd. www.lacrossetechnology.com/support Page 13...
