- Page 1 HKB95540NB User Manual USER MANUAL...
-
Page 2: Table Of Contents
www.aeg.com CONTENTS 1. SAFETY INFORMATION..................2 2. SAFETY INSTRUCTIONS..................5 3. INSTALLATION.....................7 4. PRODUCT DESCRIPTION.................12 5. DAILY USE......................13 6. HINTS AND TIPS....................16 7. CARE AND CLEANING..................17 8. TROUBLESHOOTING..................18 9. TECHNICAL DATA..................... 20 10. ELECTROLUX / AEG MAJOR APPLIANCES - WARRANTY CONDITIONS... 21 FOR PERFECT RESULTS Thank you for choosing this AEG product. - Page 3 ENGLISH instructions in a safe and accessible location for future reference. 1.1 Children and vulnerable people safety This appliance can be used by children aged from 8 • years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.
- Page 4 www.aeg.com CAUTION: The cooking process has to be supervised. • A short term cooking process has to be supervised continuously. WARNING: Danger of fire: Do not store items on the • cooking surfaces. Metallic objects such as knives, forks, spoons and lids •...
-
Page 5: Safety Instructions
ENGLISH for use as suitable or hob guards incorporated in the appliance. The use of inappropriate guards can cause accidents. 2. SAFETY INSTRUCTIONS 2.2 Electrical Connection This appliance is suitable for the following markets: BH IQ KW OM QA WARNING! Risk of fire and electric ZA AE NG shock. - Page 6 www.aeg.com access to the mains plug after the • Do not change the specification of this installation. appliance. • If the mains socket is loose, do not • Make sure that the ventilation connect the mains plug. openings are not blocked. •...
-
Page 7: Installation
ENGLISH • Use only stable cookware with the • Deactivate the appliance and let it correct shape and diameter larger cool down before you clean it. than the dimensions of the burners. • Disconnect the appliance from the • Make sure cookware is centrally electrical supply before maintenance. - Page 8 www.aeg.com The rating plate is on the bottom of the Liquid gas hob. Use the rubber pipe holder for liquid gas. Always engage the gasket. Then Model ........continue with the gas connection. PNC ......... The flexible pipe is prepared for apply Serial number ......
- Page 9 ENGLISH 3.4 Adjustment of minimum level WARNING! Information for authorised installer only. To adjust the minimum level of the burners: 1. Light the burner. 2. Turn the knob on the minimum position. 3. Remove the knob and using thin screwdriver lift up and remove the plastic magnet holder.
- Page 10 www.aeg.com If the pilot lights turn on after connecting the hob to the mains, turn on and off the control knob and wait until min. 100 mm min. 650 mm the residual heat indicator min. 55 mm goes out. 30 mm 3.6 Connection cable 830 mm To replace the connection cable use only...
- Page 11 ENGLISH min 30 mm min 5 mm (max 150 mm) 60 mm A. Removable panel B. Space for connections CAUTION! Install the appliance only on a worktop with flat surface. Kitchen unit with oven The electrical connection of the hob and 3.8 Installing hob under the the oven must be installed separately for safety reasons and to let easy remove...
-
Page 12: Product Description
www.aeg.com 4. PRODUCT DESCRIPTION 4.1 Cooking surface layout Semi-rapid burner Multi Crown burner Auxiliary burner Control panel Control knobs Window for Hob²Hood infrared signal 4.2 Control panel layout Use the sensor fields to operate the Minute Minder and Hob²Hood. The displays, indicators and sounds tell which functions operate. -
Page 13: Daily Use
ENGLISH 4.3 Control knob A. Residual heat indicator. WARNING! Symbol Description There is a risk of burns from residual heat. no gas supply / off posi‐ tion The residual heat indicator lights up when you turn off ignition position / maxi‐ the burner. - Page 14 www.aeg.com 5.1 Burner overview 1. Push the control knob down and turn it counterclockwise to the maximum gas supply position ( ). 2. Keep the control knob pushed for equal or less than 10 seconds. This lets the thermocouple warm up. If not, the gas supply is interrupted.
- Page 15 ENGLISH The hob is supplied with the The function has no effect progressive valves. They on the operation of the make the flame regulation burners. more precise. Hob²Hood WARNING! If you do not switch the knob It is a manual function which connects to the off position, after two the hob to a special hood.
-
Page 16: Hints And Tips
www.aeg.com 6. HINTS AND TIPS 6.3 Diameters of cookware WARNING! Refer to Safety chapters. Use cookware with diameters applicable to the 6.1 Cookware size of burners. CAUTION! Burner Diameter of Do not use cast iron pans, cookware clay or earthenware pots, (mm) grill or toaster plates. -
Page 17: Care And Cleaning
ENGLISH To find the full range of cooker hoods Other remotely controlled which work with this function refer to our appliances may block the consumer website. The AEG cooker signal. Do not use any hoods that work with this function must remotely controlled have the symbol appliances at the time when... -
Page 18: Troubleshooting
www.aeg.com The shape of pan supports and the Do not lift the pan supports amount of burners can be different in at an angle, as this will put other models of the appliance. strain on the metal pins. This can cause damage to the 7.4 Cleaning the hob pins and cause them to break. - Page 19 ENGLISH 8.1 What to do if... Problem Possible cause Remedy There is no spark when you The hob is not connected to Check if the hob is correctly try to activate the spark gen‐ an electrical supply or it is connected to the electrical erator.
-
Page 20: Technical Data
www.aeg.com 8.3 Labels supplied with the accessories bag Stick the adhesive labels as indicated below: MOD. MOD. MOD. TYPE PROD.NO. IP20 PROD.NO. PROD.NO. SER.NO. 0049 SER.NO SER.NO 03 IT DATA DATA MADE IN ITALY A. Stick it on Guarantee Card and send C. -
Page 21: Electrolux / Aeg Major Appliances - Warranty Conditions
ENGLISH 9.3 Other technical data Gas original: G20 (2H) 20 mbar 10,9 kW TOTAL POW‐ Gas replace‐ G30/G31 (3B/P) 30/30 mbar 745 g/h ment: Electric supply: 220-240 V ~ 50-60 Hz Appliance cate‐ II2H3B/P gory: II2H3+ I3B/P Gas connec‐ R 1/2" tion: Appliance class:... - Page 22 www.aeg.com warranty claims, collection, return 6. Electrolux shall not be responsible in and installation (Built-in and gas terms of this warranty for the appliances) of the appliance will replacement or repair of any part of be free of charge within South the equipment which may have been Africa if installed by an damaged in transit if delivery is...
- Page 23 ENGLISH Service and Spares In the event of your appliance requiring a service or if you wish to purchase spare parts, contact your local Electrolux Service Centre by telephoning: 011 897 4600 / 0800 222 825 (Tollfree in South Africa) https://www.aeg.co.za/ https://www.aeg.co.za/support/warranties/ https://www.aeg.co.za/support/contact-us/...
- Page 24 867345207-H-172021...
