LF503EM7F
EN Owner's Manual
ES Manual del Propietario
EN
Need help?
Please call toll free or visit our web site below
ES
¿Necesita ayuda?
Llame por favor sin costo ó visite nuestro sitio web en
1 866 309 8819
http://www.emersonaudiovideo.com/support/
Advertisement
Table of Contents
Related Manuals for Emerson LF503EM7F
Summary of Contents for Emerson LF503EM7F
- Page 1 EMERSON AND THE G-CLEF LOGO ARE REGISTERED TRADEMARKS OF EMERSON RADIO CORP., MOONACHIE, NEW JERSEY, U.S.A. LF503EM7F EN Owner's Manual ES Manual del Propietario Need help? Please call toll free or visit our web site below ¿Necesita ayuda? Llame por favor sin costo ó visite nuestro sitio web en 1 866 309 8819 http://www.emersonaudiovideo.com/support/...
-
Page 2: Table Of Contents
English Contents 1 Notice 5 Making more use with your TV ..................................Displaying the Main Menu 2 Important Picture ........................ Sound Positioning the TV Setup Regulatory Notices Autoprogram Environmental Care Channel list # Batteries usage Add channels Preparing to Move / Ship the Unit Antenna Confirmation Features 3 Getting Started... - Page 3 English Register Online at http://www.emersonaudiovideo.com/support/ today to get the most benefits from your purchase. Registering your model with Emerson makes you eligible for all of the valuable benefits such as software upgrades and important product notifications. Register Online at http://www.emersonaudiovideo.com/support/...
- Page 4 Funai is not liable for these types of accidents or injuries Brand Model # Screw dimension noted below. SANUS LF503EM7F F80B M6 x 0.472" (12mm) VuePoint • Install the Wall Mount Bracket on a sturdy vertical wall. • Your TV meets the VESA standard for wall mounting.
-
Page 5: Notice
EMERSON and the G-CLEF logo are registered trademarks of The user could lose the authority to operate this apparatus if an Emerson Radio Corp. in the U.S. and Canada, used under license by unauthorized Change or Modification is made. Funai Electric Co., Ltd. and Funai Corporation, Inc. -
Page 6: Important
End of Life Directives temperature of this Unit may increase slightly. This is not a malfunction. Emerson pays a lot of attention to produce environmental-friendly • Avoid a place with drastic temperature changes. products in green focal areas. Your new TV contains materials which •... -
Page 7: Getting Started
This feature allows you to Block children’s access to inappropriate Programs. Model Quantity Size Closed Caption decoder ● LF503EM7F M4 x 0.787”(20mm) Built-in Closed Caption decoder displays text for Closed Caption supported Programs. MTS / SAP tuner ● Audio can be selected from the Remote Control. -
Page 8: Attaching The Base
English Attaching the Base Installing the Remote Control Batteries You must attach the base to the Unit to have it as a table top Unit. Be sure the front and rear of the base match the proper direction. For large screen TVs, at least 2 people are required for these steps. Slide the battery cover off the back of the Remote Control. -
Page 9: Remote Control
English Remote Control a B (POWER / STANDBY) Turns the TV On from Standby or Off to Standby mode. b PIC/SOUND MODE Optimizes Picture and Sound quality. c CC Selects Closed caption settings (Off, On, CC w/ mute). d 0 - 9 (NUMBER keys) Used to enter a Channel / Program number. -
Page 10: Control Panel
English a VOL J / K Control Panel Adjusts the Volume. In the Menu screen, moves the Cursor Left (J) / Right (K). VOL J : Volume Down VOL K : Volume Up b CH H / I Selects a Channel. In the Menu screen, moves the Cursor Up (H) / Down (I). -
Page 11: Connecting The Antenna, Cable Or Satellite
English Connecting the Antenna, Cable or Satellite Connecting a Set-top Box, Blu-ray Disc / DVD Recorder via Composite Connectors and Analog Audio Be sure your Antenna or another Device is connected properly before Do Not place your Recorder too close to the Screen because some plugging in the AC Power Cord. -
Page 12: Selecting Your Connection Quality
This Unit can be connected to your Device that has a DVI Terminal. Use an HDMI-DVI Conversion Cable for this Connection and it requires Emerson HDMI supports HDCP (High-bandwidth Digital Contents Protection). HDCP is ● a form of Digital Rights Management that protects High-Definition content in Blu-ray Discs Audio Cable for Analog Audio signal as well. -
Page 13: Component Analog Video Connection
English Component Analog Video Connection Digital Audio Output Connection Component Analog Video Connection offers Better Picture quality for If you connect this Unit to an External Digital Audio Device, you can enjoy Video Devices connected to the Unit. multi-channel Audio like 5.1ch Digital Broadcasting sound. If you connect to the Unit’s Component Video (Y/Pb/Pr) Input jacks, Use a Digital Audio Coaxial Cable to connect the Unit to External Digital connect Analog Audio Cables to the Analog Audio (L/R) Input jacks. -
Page 14: Pc Connection
English PC Connection Note(s) Please purchase the HDMI-DVI Conversion Cable that has a ferrite core. HDMI Connection ● The following operations may reduce noise. ● This Unit can be connected to your PC that has an HDMI terminal. Attach a ferrite core to the AC Power Cord of your PC. –... -
Page 15: Initial Setup
English These Operations are accessible by Remote Control. Use H I to select the desired Location setting, then press OK. Some may also be accessible by the Main Unit's Control Panel. Home is the ENERGY STARN qualified setting. Initial Setup Initial setup Retail This section will guide you through the Unit’s Initial setting which includes... -
Page 16: Use Your Tv
English 4 Use your TV Switching Channels Switching on your TV and putting it in Standby mode Remote Control Remote Control To Turn the TV On from Standby or Off to Standby Press B on the Side of the Unit or the Remote Control. ●... -
Page 17: Watching Channels From An External Device
English Watching Channels from an External Device Sleep Timer Sleep Timer can set the Unit to go into Standby mode after an incremental Switching Each Input Mode can easily switch with the Remote Control period of time. between TV (DTV or Analog TV) and External Devices when they are connected to the Unit. -
Page 18: Create A List Of Favorite Channels
English Create a list of favorite channels Changing Picture Format You can create lists of your preferred TV channels so that you can find Display Modes can be Selected when your TV receives a those channels easily. 16:9 or 4:3 Video Signal. Press OK while viewing a TV program. -
Page 19: Tv Screen Information
English For 4:3 Video signal TV Screen information You can display the currently selected channel or other information such as the aspect ratio on the TV screen. In the Digital mode, the detailed broadcasting information for the current off the air channel, such as Program title, are displayed. Normal 16:9 Movie expand... -
Page 20: Making More Use With Your Tv
English 5 Making more use with your TV Use H I to Select the desired Menu and an item, then press OK or use H I J K to determine the setting. This section describes the overview of the Main Menu displayed when you press MENU. -
Page 21: Picture
English You can set a Particular Picture Quality using Advanced Picture ● settings. Before you begin: Color alignment Normal Picture You must set Home in Location. L p. 30 Medium Sound Noise reduction Otherwise, personalized Picture and Sound settings will not be Setup Ambient light sensor memorized after the Unit goes into Standby Mode. -
Page 22: Sound
English You can select Audio Output through a Digital Audio Output connector. Sound to Output Multichannel Signals (When the Audio of the Content Before you begin: Multichannel Digital output is PCM, it will be Output in PCM format You must set Location to Home. L p. 30 even if Multichannel is selected.) Otherwise, personalized Picture and Sound settings will not be to Output PCM format... -
Page 23: Setup
English Setup Autoprogram Before you begin: Please wait while the system is scanning for channels. Make sure the Unit is connected to Antenna or Cable. Auto programming may take more than 20 minutes Press MENU and use H I to select Setup, then press OK. to complete. -
Page 24: Add Channels
English Features Add channels This function lets you add the off the air Analog TV or Analog Cable Display Setup using Home Menu and use H I to select Features, channels that were not added by the Autoprogram due to reception then press OK. - Page 25 English Cable / NTSC (Analog) TV Operation Note(s) Closed Caption will NOT be displayed when you are using an HDMI Connection. ● The primary Closed Captions and Digital caption service that you can switch differs depending on the broadcast format. ●...
-
Page 26: Child And Ratings Lock
English Channel lock Child and Ratings Lock Particular Channels or External Input modes can be invisible in this You can prevent your children from watching certain Programs or certain function. Channels by locking the TV Controls and by using Ratings. Use H I to Select Channel lock, then press OK. - Page 27 English To set the Sub ratings (displayed in the right column) Setting US Movie and TV Ratings As for TV-Y7, TV-PG, TV-14 or TV-MA, you can further set the Sub US Movie Ratings Lock is the Rating System created by MPAA. ratings to Block Specific Elements within programs.
-
Page 28: Pc Settings
English Canadian English or Canadian French Ratings PC settings You can select the Rating for Canadian English or Canadian French This function lets you adjust the PC screen position, clock and phase broadcasting. during PC Input. Use H I to Select Canadian English rating or Canadian French Use J K to adjust Clock setting to stabilize the PC screen and Phase rating, then press OK. -
Page 29: Fun-Link (Hdmi Cec)
English Device list fun-Link (HDMI CEC) This function lets you see the product model number or name of This function allows you to operate the linked functions between our Connected Devices. brand Devices with a fun-Link feature and this Unit connecting through Use H I to Select the desired fun-Link devices listed on the TV screen, an HDMI cable. -
Page 30: Setting Your Location To Home
English Language Setting your Location to Home You can set the Location of your TV to Home or Retail. Choosing Home Press MENU and use H I to select Language, then press OK. gives you full flexibility to change predefined settings for Picture and Sound. -
Page 31: Usb
English Picture (JPEG) Use H I to select the desired file, then press OK. Your TV is fitted with a USB Connection that enables you to view JPEG photos or watch Motion JPEG files stored on a USB Memory Stick. Picture Connect the USB Memory Stick to the USB terminal on the back of Image1.jpg... -
Page 32: Upgrade Your Tv Software
Note(s) The TV starts up with the New Software. ● Only FAT / DOS-formatted portable memory is supported. ● For further assistance, please contact the Call Center. Use only Software Upgrades that can be found on the Emerson website. ●... -
Page 33: Useful Tips
English 7 Useful tips Question Answer Check the Antenna or Cable Connection to the Main Unit. ● Check the Batteries on the Remote Control. ● Re-insert or replace the AAA Batteries with their Polarities (+/–) as indicated on the Remote Control Battery area. ●... -
Page 34: Troubleshooting Tips
You see a Distorted Picture or Hear an Unusual Sound. (Analog TV - NTSC Universal Remote Control does not work properly. signal) Refer to the User Manual of the Universal Remote Control for the Emerson ● You may be getting interference from electrical appliances, automobiles, ●... -
Page 35: Information
English 8 Information Glossary Maintenance Analog TV (NTSC) Cabinet Cleaning Acronym that stands for National Television Systems Committee and the Wipe the front panel and other exterior surfaces of the Unit with a soft ● name of Analog broadcasting standards. cloth. -
Page 36: Specifications
English 9 Specifications Model # LF503EM7F Picture Type FHD (Full HD) (1920 x 1080 pixels 60Hz) Aspect Ratio 16:9 Viewing Angles 176° (V) by 176° (H) Built-in Digital / Analog Tuner ATSC (Digital) / NTSC (Analog) Sound Mono / Stereo... -
Page 37: Warranty
English 10 Warranty LIMITED WARRANTY NINETY (90) DAY LABOR / ONE (1) YEAR PARTS WARRANTY COVERAGE: This warranty does not apply (a) to damage caused by accident, abuse, misuse, neglect, misapplication, or non-supplied product, This warranty obligation is limited to the terms as set forth below. - Page 38 EMERSON AND THE G-CLEF LOGO ARE REGISTERED TRADEMARKS OF EMERSON RADIO CORP., MOONACHIE, NEW JERSEY, U.S.A. FUNAI CORPORATION, Inc. 19900 Van Ness Avenue, Torrance, CA 90501 A6AU0UH ★★★★★...
