Summary of Contents for Arris VIP5662
- Page 1 VIP5662 IPTV Receiver Installation Guide...
- Page 2 This manual includes the manufacturer’s recommended safeguards and all the information needed to connect your receiver to both your in-home IP network and your entertainment system. The safety and installation information was developed and provided primarily by the receiver manufacturer, ARRIS Enterprises, Inc. VIP5662 IPTV Receiver Installation Guide...
- Page 3 Do not place it in a sealed enclosure without providing for adequate airflow. • Use only the power adapter and cord supplied to connect the VIP5662 to your home AC power outlet. • Do not plug the AC power adapter into a switched power outlet.
-
Page 4: Table Of Contents
Troubleshooting ............11 VIP5662 IPTV Receiver Installation Guide... -
Page 5: Introduction
Introduction Congratulations on receiving your ARRIS VIP5662 IPTV Receiver. The VIP5662 provides these extraordinary home entertainment features: • Ultra High Definition TV (UHDTV), with up to twice the color resolution and up to six times the sharpness of standard TV when connected to a UHD-capable TV •... -
Page 6: Overview
Blinking blue: Receiver is pairing with the RCU Solid blue: Receiver is paired with the RCU RECORD No light: Not recording Solid red: Recording is in progress POWER No light: Receiver is off Solid green: Receiver is on VIP5662 IPTV Receiver Installation Guide... -
Page 7: Rear Panel
Activity LED: Flashes amber with data traffic. BLUETOOTH Press and release to initiate Bluetooth remote control unit PAIRING pairing with receiver. Hold the button for 10 seconds to unpair the Bluetooth remote control unit and the receiver. VIP5662 IPTV Receiver Installation Guide... -
Page 8: Remove Hard Drive Procedure
Remove Hard Drive Procedures To remove the Hard Drive from the VIP5662, perform the following procedure: Turn unit off. Flip unit upside down. Grip levers on either side of hard drive compartment and squeeze to release. Slide hard drive out of compartment then lift up to remove. -
Page 9: Insert Hard Drive Procedure
Insert Hard Drive Procedures To insert the Hard Drive into the VIP5662, perform the following procedure: Turn unit off. Flip unit upside down. Slide hard drive cover-side up into compartment until you hear it click. VIP5662 IPTV Receiver Installation Guide... -
Page 10: Connecting Your Tv Receiver
Connecting Your TV Receiver This section describes alternative methods for connecting the VIP5662 to your home entertainment system. Instructions and diagrams are included for the following connections: • Digital Audio/Video • Component Video and Digital Audio • Composite Video and Stereo Audio Before you move or change components on your entertainment system, always disconnect power from the receiver. - Page 11 OPTICAL connection for the audio. Common Cabling Examples The following cabling diagrams illustrate common sample audio/video (A/V) connections. When connecting other components to your receiver, refer to the other component installation manuals for additional connection information. VIP5662 IPTV Receiver Installation Guide...
-
Page 12: Digital Audio/Video Connections
• If your HDTV has a DVI input, you can use an HDMI-to-DVI converter to connect to the VIP5662 HDMI connector. DVI video carries video signals only. Use the optical audio or stereo audio connectors to provide audio output. VIP5662 IPTV Receiver Installation Guide... -
Page 13: Component Video And Digital Audio Connections
Breakout cable to the correct inputs on your HDTV (as shown). If your HDTV or A/V receiver has an optical audio input available, use a Digital Optical Audio cable to connect from the VIP5662 to the correct input on your HDTV or receiver (as shown). -
Page 14: Composite Video And Stereo Audio Connections
Breakout cable to the correct inputs on your HDTV (as shown). Do not connect the unit through a VCR. Video signals fed through VCRs may be affected by copyright protection systems and the picture will be distorted on the television. VIP5662 IPTV Receiver Installation Guide... -
Page 15: Troubleshooting
Check the batteries in the remote control. Install new batteries if needed. Video or audio To improve video quality, upgrade your connection (from quality is poor or composite analog to component+digital audio to HDMI). missing. VIP5662 IPTV Receiver Installation Guide... - Page 16 Verify that the home theater receiver is set to a surround sound audio mode (Dolby Digital, Dolby Pro Logic® II, Dolby Pro Logic). Verify that the home theater receiver is properly configured to work with all connected speakers. VIP5662 IPTV Receiver Installation Guide...
- Page 17 According to 47 CFR, Parts 2 and 15 for Class B Personal Computers and Peripherals; and/or CPU Boards and Power Supplies used with Class B Personal Computers, ARRIS Enterprises, Inc, 3871 Lakefield Drive, Suwanee, Georgia 30024, declares under sole responsibility that the product identifies with 47 CFR Part 2 and 15 of the FCC Rules as a Class B digital device.
- Page 18 Software. The Software is never sold. ARRIS licenses the Software to the original customer and to any subsequent licensee for personal use only on the terms of this License. ARRIS and its third party licensors retain the ownership of the Software.
- Page 19 ARRIS is not responsible for any third party software that is provided as a bundled application, or otherwise, with the Software or that is downloaded to, or otherwise installed on, the Product. This product is protected by certain intellectual property rights of Ericsson Corporation. Use or distribution of such technology outside of this product is prohibited without a license from Ericsson Corporation or an authorized Ericsson Corporation subsidiary.
- Page 20 ARRIS IPTV Set-top Model VIP5602/5662 For instructions on how to obtain a copy of any source code being made publicly available by ARRIS related to software used in these ARRIS products you may send your request in writing to: ARRIS Software Pedigree Operations 2450 Walsh Avenue, Santa Clara, CA 95051, USA The ARRIS website http://opensource.arris.com also contains information regarding ARRIS’...
- Page 21 ARRIS Enterprises, Inc. (“ARRIS”). ARRIS reserves the right to revise this publication and to make changes in content from time to time without obligation on the part of ARRIS to provide notification of such revision or change. ARRIS provides this guide without warranty of any kind, either implied or expressed, including but not limited to the implied warranties of merchantability and fitness for a particular purpose.
- Page 24 Visit our website at: www.arris.com 598967-001-b 02/2017...
