Regency Horizon
WARNING:
If the information in these instructions
are not followed exactly, a fire or
explosion may result causing property
damage, personal injury or loss of life.
WARNING: For Outdoor Use Only.
Installation and service must be
performed by a qualified installer,
service agency, or the gas supplier.
WARNING:
Do not store or use gasoline, or other flammable vapors and liquids, in the vicinity of this or any
other appliance.
An LP-cylinder not connected for use shall not be stored in the vicinity of this or any other appliance.
Tested by:
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
920-275a
HZO60 Outdoor
®
Gas Fireplace
If you smell gas:
• Shut off gas to the appliance.
• Extinguish any open flame.
• If odour continues, leave the area immediately.
• After leaving the area, call your gas supplier or fire
department.
Failure to follow these instructions could result in fire or
explosion, which could cause property damage, personal
injury, or death.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
DANGER - FIRE OR EXPLOSION HAZARD
Owners &
Installation Manual
MODELS: HZO60-NG11
HZO60-LP11
www.regency-fire.com
10.19.21
Advertisement
Table of Contents
Related Manuals for Regency Horizon HZO60
Summary of Contents for Regency Horizon HZO60
- Page 1 Owners & Regency Horizon HZO60 Outdoor ® Installation Manual Gas Fireplace MODELS: HZO60-NG11 HZO60-LP11 www.regency-fire.com WARNING: DANGER - FIRE OR EXPLOSION HAZARD If the information in these instructions If you smell gas: are not followed exactly, a fire or • Shut off gas to the appliance.
- Page 2 To the New Owner: Congratulations! You are the owner of a state-of-the-art Gas Fireplace by REGENCY ® . The Horizon® HZO60 Outdoor fireplace has been designed to provide you with all the warmth and charm of a fire at the flick of a switch. The Horizon® HZO60 Outdoor fireplace has been approved by Warnock Hersey/Intertek for both safety and efficiency.
-
Page 3: Table Of Contents
Wall Switch & Battery Installation (included with unit) .23 Wiring Diagram ............24 Conversion from NG to LP...........25 Optional Hardwire Kit Installation ........27 AC Adaptor Installation ..........30 Inner Panel Removal / Installation .......31 Glass Crystal / Basalt Volcanic Stones Installation ..32 Regency Horizon HZO60 Gas Fireplace ®... -
Page 4: Safety Decal
This is a copy of the label that accompanies each HZO60 Outdoor Fireplace. We have printed a copy of the contents here for your review. NOTE: Regency units are constantly being improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one. -
Page 5: Dimensions
Note: Gas Connection/Electrical connections if using optional Hardwire Kit are located on left hand side of appliance. ALL PICTURES / DIAGRAMS SHOWN THROUGHOUT THIS MANUAL ARE FOR ILLUSTRATION PURPOSES ONLY. ACTUAL PRODUCT MAY VARY DUE TO PRODUCT ENHANCEMENTS. Regency Horizon HZO60 Gas Fireplace ®... -
Page 6: Unit Dimensions - Hzo60 See Through
UNIT DIMENSIONS - HZO60 SEE THROUGH " 1744 " 1608 " [1535] " " 1495 Gas Connection Access Panel Note: Gas Connection/Electrical connections if using optional Hardwire Kit are located on left hand side of appliance. Regency Horizon ® HZO60 Gas Fireplace... -
Page 7: Installation
This general checklist does not contain all pertinent installation details or specifics and does not supersede the guidelines in this manual. Your Regency dealer/installer should use it in conjunction with manual instructions. Please follow all local codes and jurisdictions in authority. - Page 8 REGENCY GAS INSTALLATION CHECKLIST Finishing If applicable, is only noncombustible material installed in the noncombustible areas? Do clearances meet installation and manual requirements? Do the mantels and/or projections comply with the installation manual? If applicable, was the solid fuel fireplace warning plate installed?
-
Page 9: Important Message
The appliance should be enclosed. LATED SPACE AND SHALL NOT BE USED IN A BUILDING, GARAGE OR ANY 4) Inspect the burner before each use of the appliance for blockage and any signs of OTHER ENCLOSED AREA. deterioration. Regency Horizon HZO60 Gas Fireplace ®... -
Page 10: Installation Checklist
Open ventilation/airflow space comes from walls and roof/ceiling. Open floor space around the unit must not be considered ventilation/airflow space. Open side at least 25% of total wall area *SEE IMPORTANT INSTALLATION NOTES NEXT PAGE 10 | Regency Horizon ® HZO60 Gas Fireplace... -
Page 11: Important Information For Outdoor Fireplace Installations
This will create a pressure zone • Only Regency approved media should be used in the firebox (i.e. at the firebox and will prevent the unit from venting stones/glass) •... -
Page 12: Minimum Clearances To Combustibles
Wall to Wall (Minimum) must be installed on the walls of the chase, not on F: Alcove Depth 36" (914mm) Front to Back Wall (Maximum) the appliance. Notes: 0" No Hearth Required Alcove 12 | Regency Horizon ® HZO60 Gas Fireplace... -
Page 13: Framing Dimensions Single Sided
Important Note: Four (4) ventilation grills must be used for all enclosures. See this manual for further details. This is to alleviate moisture and allow for air to circulate. Minimum recommended size: 20" sq (508 mm²) ea. Regency Horizon HZO60 Gas Fireplace... -
Page 14: Framing Dimensions See Through
Important Note: Four (4) ventilation grills must be used for all enclosures. See this manual for further details. This is to alleviate moisture and allow for air to circulate. Minimum recommended size: 20" sq. (508 mm²) ea. 14 | Regency Horizon ® HZO60 Gas Fireplace... -
Page 15: Mantel Clearances (Single Sided & See Through)
Opening MANTEL LEG CLEARANCES (SINGLE SIDED AND SEE THROUGH) 16" (406mm) 16" (406mm) 9" (229mm) 9" (229mm) 5" (127mm) 5" (127mm) HZO60 5" (127mm) 5" (127mm) 9" (229mm) 9" (229mm) 16" (406mm) 16" (406mm) Regency Horizon HZO60 Gas Fireplace ®... -
Page 16: Non-Combustible Requirements
17-1/4" (438 mm) and width is 58-7/8" (1535 mm). If this option is chosen, the faceplate cannot be used. See diagram 1 on next page showing the 4 vertical openings. 70-1/2" (1791mm) Non-combustible Material 58-7/8" (1495 mm) Combustible Material 5-3/4" 5-3/4" (146mm) (146mm) 16 | Regency Horizon ® HZO60 Gas Fireplace... -
Page 17: Framing & Finishing
4 vertical openings for faceplate 64-3/16" Diagram 1 Regency Horizon HZO60 Gas Fireplace ®... -
Page 18: Data System
Maximum Input 64,000 Btu/h (18.76 kW) Pilot Ignitor HZO60-LP11 SYSTEM DATA Note: If you have an incorrect flame pattern, contact your Regency dealer for further Max. Supply Pressure 14" WC (3.49 kpa) ® instructions. Min. Supply Pressure 11" WC (2.73 kpa) -
Page 19: Unit Assembly Prior To Installation
Nailing Area Nailing Strip tandoffs installed Note: Depending on the material used for finishing, the nailing strips must be set accordingly so that the finished material is always at the 1-1/2" edge of the flange. Regency Horizon HZO60 Gas Fireplace ®... -
Page 20: Converting Unit From Single Sided To See Through
3. Remove 2 screws on each side (in locations shown below) retain these screws and replace after back firebox panel is removed. Remove 4 screws 8. Proceed with framing and installation instructions to complete install. 20 | Regency Horizon ® HZO60 Gas Fireplace... -
Page 21: Drain Installation (Recommended)
Threaded Elbow Threaded @ 90° Reducer (PVC) (PVC) Reducer and elbow can be purchased from your local hardware store. Drain hole location at base of the unit Regency Horizon HZO60 Gas Fireplace ®... -
Page 22: Hzo60 Enclosure Vent Installation
This is to alleviate moisture and allow for air to circulate. Minimum recommended size: 20" sq. (508 mm²) ea. If using the grills offered by Regency, follow the instructions noted below: Frame the opening for the upper vent (377-060) at 16" x 1-1/4" - secure the upper vent to the framing with 6 screws. -
Page 23: Wall Switch & Battery Installation (Included With Unit)
(polarity not important). WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this ap- pliance may result in property damage or personal injury. Regency Horizon HZO60 Gas Fireplace ®... -
Page 24: Wiring Diagram
NOTE: 4 AA batteries must be installed in the battery pack to operate the burner switch. Do not use a 9 volt battery. Optional 0.886.001 Proflame Valve Standard Main On/Off Switch 1 of 10 or Optional Wall Switch 0.584.622 (Includes Pilot Ground) 24 | Regency Horizon ® HZO60 Gas Fireplace... -
Page 25: Conversion From Ng To Lp
Turn the unit off and allow to cool to room temperature. Turn off gas supply. 5. Remove the wire clip below the pilot cap. 1. R emove glass crystals and log set, if installed. 2a. L ocate and remove 22 screws to remove the burner tray. 2b. Remove 2 screws to remove the burner end (see below). Pilot retainer clip 6. Pull off the pilot cap to expose the pilot orifice. Using a 5/32" allen key, remove pilot orifice and replace with LP pilot orifice. 3. R emove 2 screws and slide burner tube to the left (away from the orifice) to remove. Pilot Cap Burner orifice Regency Horizon HZO60 Gas Fireplace ® 919-767 04.08.21... - Page 26 OUTDOOR SERIES installation 7. Re-install pilot cap. 8. Adjust air shutter to 1/4 inch open by loosening the screw on the air shutter. Retighten screw after adjustment. 9. Remove 8 screws on valve access cover. 10. Remove Hi/Lo pressure regulator by removing 2 screws as shown below. Reverse steps to install LP pressure regulator. (Be sure diaphragm and spring are removed from the original regulator.) HI/LO Pressure Regulator 11. Attach the label “This unit has been converted to LP” near or on top of the serial # decal. 12. Replace yellow “NG” label with red “LP” label. Make appropriate gas connections. 13. Reverse Steps 1-6 14. C heck all gas connections under normal operating pressure, for leaks, with soapy water. NOTE: If soap bubbles, this would indicate a gas leak. 15. Check inlet and outlet pressures. 16. Check operation of flame control. 26 | Regency Horizon ® HZO60 Gas Fireplace...
-
Page 27: Optional Hardwire Kit Installation
Once electrical wiring is complete,Secure both the GFI circuit and white blanking plate to the electrical box using 2 screws each. Diagram 1 GFI Circuit Blanking Install electrical box into the outer box with 4 screws. Plate Regency Horizon HZO60 Gas Fireplace ® 919-774a 01.25.21... - Page 28 Outer cover 14. Turn on gas and electrical supply and test unit. 15. PTO100 Only: If a second AC adaptor is required to power a second burner, repeat steps 5-9. 28 | Regency Horizon ® HZO60 Gas Fireplace 919-774a 01.25.21...
- Page 29 OUTDOOR SERIES installation WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury. Regency Horizon HZO60 Gas Fireplace ® 919-774a...
-
Page 30: Ac Adaptor Installation
6. Turn on gas and electrical supply and test unit. Valve cover plate 2. Locate the 'DC supply' wire on the wiring harness,the wire will be clearly marked. DC supply wire from wiring harness AC adaptor 30 | Regency Horizon ® HZO60 Gas Fireplace 919-783 05.02.17... -
Page 31: Inner Panel Removal / Installation
7. Remove white protective film from stainless steel panels. Reverse steps to 4. Repeat on other side to remove opposite panel. reinstall panels into unit. 8. Clean all stainless steel panels as per instructions above. Regency Horizon HZO60 Gas Fireplace ®... -
Page 32: Glass Crystal / Basalt Volcanic Stones Installation
The Burner should not be visible when the flame is out. NOTE: Basalt Volcanic Stones are NOT to be placed anywhere on the Pilot assembly area. Glass Crystals/Firebeads to be installed on the burner prior to installing stones. 32 | Regency Horizon ® HZO60 Gas Fireplace... -
Page 33: Optional Log Set Installation
3. Install Log/Twig D on the left side of the burner, orient Log/Twig D across Log/Twig A in the same way and in a similar position as shown in Diagram 4. Diagram 4 Regency Horizon HZO60 Gas Fireplace ® 919-764... - Page 34 (Mirrors Log E from previous step). Diagram 7 7. Install Log/Twig B on the left side, orient Log/Twig B in the same way and in a similar position as shown in Diagram 8. Diagram 8 34 | Regency Horizon ® HZO60 Gas Fireplace 919-764 10.18.21...
- Page 35 Diagram 11 (mirror Log C as installed on the left side). Diagram 11 11. Install Log/Twig F on the left side of the burner, orient Log/Twig F in the same way and in a similar position as shown in Diagram 12. Diagram 12 Regency Horizon HZO60 Gas Fireplace ® 919-764...
- Page 36 Diagram 14 WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this ap- pliance may result in property damage or personal injury. 36 | Regency Horizon ® HZO60 Gas Fireplace...
-
Page 37: Optional Faceplate Installation
There are 3 slots on each tab so the faceplate to accommodate different finishing materi- als. Trim Piece To remove - reverse steps. Install logo onto faceplate. Final Install 02.08.21 919-814a Regency Horizon HZO60 Gas Fireplace ®... -
Page 38: Optional Leaf / Burner Cover Installation
Optional finishing trim is not supplied with the PTO50/HZO60 - if purchased, place finishing trim on unit between unit and finishing material. Note: Optional trim is not available for the PTO80 and PTO100. 02.18.21 919-779a OUTDOOR BURNER 38 | Regency Horizon ® HZO60 Gas Fireplace... -
Page 39: Glass Wind Shield Installation
To install the glass wind shields - slot the glass pieces (x2) into the space between the burner tray cover and the bottom access panel. NOTE: If setting unit up as a see-through repeat procedure on opposite side of burner. Burner Tray Cover Glass Wind Shield Bottom Access Panel Glass Wind Shield Installed (2 pieces) Regency Horizon HZO60 Gas Fireplace ®... -
Page 40: Operation
Unit will repeat step 2. SHUTDOWN PROCEDURE 1. Turn ON/OFF switch. 2. If service is to be performed - you must discon- nect both sources of power to the unit, the main power and battery. 40 | Regency Horizon ® HZO60 Gas Fireplace... -
Page 41: Copy Of Lighting Plate Instructions
COPY OF LIGHTING PLATE INSTRUCTIONS The lighting plate is located on the underside of the table top on the unit. Regency Horizon HZO60 Gas Fireplace ®... -
Page 42: Maintenance
Failure to do this will result in burn stains on panels which you will be unable to remove. 4. The heater is finished in a heat resistant paint and should only be refinished with heat resistant paint. Regency® uses StoveBright Paint - Metallic Black #6309. -
Page 43: Valve Assembly Replacement
6. Remove the two (2) burner end caps by lifting out as shown. 14. Remove orange EV1 wire and ground wire connected to the gas valve. 15. Remove green EV2 wire connected to the gas valve. Ground wire location (Ground wire not shown) Regency Horizon HZO60 Gas Fireplace ®... - Page 44 19. Replace valve assembly gasket if necessary. 20. Rotate HI/LO modulating valve all the way to the left for HI position. 21. Install new valve assembly and reverse steps 11-1. 22. Test gas connections for leaks. 44 | Regency Horizon ® HZO60 Gas Fireplace...
-
Page 45: Gas Maintenance - Recommended Annual Routine
Flame sensor (electronic ignition models) • Batteries (remote handheld, remote receiver, volt models) • Flame electrode DC sparker, change as needed) • Burner orifice • Burner media (change as needed) • Thermocouple (millivolt models) • Air shutter setting • Thermopile (millivolt models) • Wiring Gas Leak Tests • Check main gas line connection to valve • Check shut off valve connections • Check connection at gas valve outlet • Check connection at main burner orifice • Check pilot fuel line at valve and at pilot assembly 920-324 09.14.20 Regency Horizon HZO60 Gas Fireplace ®... -
Page 46: Parts
Stainless Cover Plate 326-034 Panel Clip 940-488/P Front Glass (each) 646-138 Stainless Back Panel 646-113 Rear Panel 646-125 Rear Panel Bracket 646-136 Glass Clip 646-137 Glass Slider Part Not Shown See next page 46 | Regency Horizon ® HZO60 Gas Fireplace... - Page 47 (Hardwire Kit) 911-233 Blank Adaptor Plate White (Hardwire Kit) 911-088 Box Switch Rectangular Two Gang (Hard- wire Kit) 911-090/P Power Adaptor AC/DC 7V 0.584.851 (Hardwire Kit) 910-178 Grommet Strain Relief (Hardwire Kit) Not shown Regency Horizon HZO60 Gas Fireplace ®...
- Page 48 48 | Regency Horizon ® HZO60 Gas Fireplace...
-
Page 49: Optional Accessories
Conversion Kit - LP 646-910 Stainless Steel Faceplate (Each) 946-710 Slate/Gray Volcanic Stones 946-711 Ivory/Tan Volcanis Stones 326-930 Ceramic Log Set (2 Sets required) 646-934 Stainless Steel Burner Cover 646-936 Stainless Steel Burner Trim 646-950 Hardwire Kit Regency Horizon HZO60 Gas Fireplace ®... -
Page 50: Warranty
All claims must be complete and provide full details as requested by FPI to receive consideration for evaluation. Incomplete claims may be rejected. 50 | Revision Date: February 2019 Regency Outdoor Products Warranty Regency Horizon ® HZO60 Gas Fireplace... - Page 51 Freight damages for products or parts are not covered under the terms of the warranty. Products made or provided by other manufacturers and used in conjunction with the FPI appliance without prior authorization from FPI may void this warranty. Revision Date: February 2019 Regency Outdoor Products Warranty Regency Horizon HZO60 Gas Fireplace ®...
- Page 52 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form at http://www.regency-fire.com/Customer-Care/Warranty-Registration.aspx...
- Page 53 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
- Page 54 54 | Regency Horizon ® HZO60 Gas Fireplace...
- Page 56 Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial #: ____________________________________________________________ Printed in Canada Regency Horizon is a trademark of FPI Fireplace Products International Ltd. © Copyright 2021, FPI Fireplace Products International Ltd. All rights reserved.
