Summary of Contents for Asus MB16ACM
- Page 1 MB16AC/MB16ACR/ MB16ACM Portable USB Monitor Hybrid Signal Solution User Guide...
-
Page 2: Table Of Contents
Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing. -
Page 3: Notices
Notices Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received including interference that may cause undesired operation. -
Page 4: Safety Information
Safety information • Before setting up this Portable USB Monitor, carefully read all the documentation that came with the package. • To prevent fire or shock hazard, never expose this Portable USB Monitor to rain or moisture. • Never try to open this Portable USB Monitor cabinet. • Before using this Portable USB Monitor, make sure all cables are correctly connected and the power cables are not damaged. -
Page 5: Care & Cleaning
Refer to the following sources for additional information and for product and software updates. ASUS websites The ASUS websites worldwide provide updated information on ASUS hardware and software products. Refer to http://www.asus.com Optional documentation Your product package may include optional documentation that may have been added by your dealer. -
Page 6: Takeback Services
Takeback services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for our customers to be able to responsibly recycle our products, batteries and other components as well as the packaging materials. -
Page 7: Welcome
Welcome! ® Thank you for purchasing the ASUS Portable USB Monitor! The latest ASUS Portable USB Monitor provides great portability and simplicity to your daily life, enhancing both of your viewing experience and style. Package contents Check your package for the following items:... -
Page 8: Monitor Introduction
Monitor introduction 1.3.1 Front view Menu Blue Light Filter Pen hole • Use the attached pen to insert into the hole, the monitor can stand up directly without the smart cover. Power button/Power LED • Press this button to turn the monitor on/off. • The color definition of the power indicator is as the below table. -
Page 9: Quickfit Function
Auto rotation function is only working under Windows OS by installing DisplayWidget software. Alignment Grid2 Photo size: Provides photographers and other users to accurately view and edit their photos in real size on the screen. ASUS USB Type-C Monitor MB16AC/MB16ACR/MB16ACM... -
Page 10: Monitor Standing Positions
Monitor standing positions You can stand up the monitor by several positions with the smart cover. ASUS USB Type-C Monitor MB16AC/MB16ACR//MB16ACM... -
Page 11: Connect The Usb Monitor With System
Type-C In case the computer does not support Type-C interface but only USB3.0 interface, please install the official driver from ASUS website firstly. Please make sure the USB Type-C cable and Type-C to A adapter is connected between the USB monitor and the system. -
Page 12: Announcements
When place this product together with computer in the bag, must have the computer power off to avoid possible hard drive damage problem. ASUS USB Type-C Monitor MB16AC/MB16ACR//MB16ACM... -
Page 13: Osd (On-Screen Display) Menu
button, according to the indicators on the menu, to make your changes. Select the to return to previous menu or to accept and return to previous menu. ASUS USB Type-C Monitor MB16AC/MB16ACR/MB16ACM... -
Page 14: Osd Function Introduction
3.1.2 OSD Function Introduction Splendid This function contains eight sub-functions that you can select for your preference. ASUS MB16A Splendid Standard Mode USB 1920x1080@60Hz Standard Mode sRGB Mode Scenery Mode Theater Mode Game Mode Night View Mode Reading Mode Darkroom Mode • Standard Mode: This is the best choice for document editing with... - Page 15 (2) Slowly roll your eyes (3) Move your eyes diagonal. • High energy blue light may lead to eye strain and AMD (Age-Related Macular Degeneration). Blue light Filter to reduce 70% (max.) harmful blue light to avoiding CVS (Computer Vision Syndrome). ASUS USB Type-C Monitor MB16AC/MB16ACR/MB16ACM...
- Page 16 Color Select the image color you like from this function. ASUS MB16A Color Standard Mode USB 1920x1080@60Hz Brightness Contrast Saturation Color Temp. Skin Tone • Brightness: The adjusting range is from 0 to 100. • Contrast: The adjusting range is from 0 to 100.
- Page 17 0 to faster 100. • Aspect Control: Adjusts the aspect ratio to “Full”, “4:3”,“1:1”. • VividPixel: ASUS Exclusive Technology that brings lifelike visuals for crystal-clear and detail-oriented enjoyment. The adjusting range is from 0 to 100.
- Page 18 ASUS MB16A System Setup Standard Mode USB 1920x1080@60Hz plendid Demo Mode Auto Rotation GamePlus QuickFit ECO Mode OSD Setup Language More ASUS MB16A System Setup Standard Mode USB 1920x1080@60Hz Key Lock Information Power Indicator Power Key Lock All Reset • Splendid Demo Mode: Activate the demo mode for the Splendid function.
- Page 19 Chrosshair, Timer and Display Alignment function. • Press to confirm the function you choose. Select to go off, and exit. GamePlus main menu GamePlus Crosshair Timer Display Alignment （Practive Mode） GamePlus-Crosshair GamePlus-Timer Position ASUS USB Type-C Monitor MB16AC/MB16ACR/MB16ACM...
- Page 20 • QuickFit: See page 1-3 for details. • ECO Mode: Activate the ecology mode for power saving. • OSD Setup: Adjusts the OSD Timeout, DDC/CI, and Transparency of the OSD screen. • Language: Select OSD language. The selections are: English, French, German, Spanish, Italian, Dutch, Russian, Poland, Czech, Croatia, Hungary, Romania, Portugal, Turkey, Simplified Chinese, Traditional Chinese, Japanese, Korean, Persian, Thai and Indonesian.
- Page 21 “Brightness”, “Contrast”, “Auto Rotation”, “Color Temp.”, “QuickFit”, “GamePlus” and set as shortcut key. MyFavorite Load/Save all settings on the monitor. ASUS MB16A MyFavorite Standard Mode USB 1920x1080@60Hz Setting 1 Load Setting 2 Save Setting 3 Setting 4 ASUS USB Type-C Monitor MB16AC/MB16ACR/MB16ACM...
-
Page 22: Specifications
3.2 Specifications Model MB16AC/MB16ACR/MB16ACM Panel Size 15.6” (16:9, 39.62cm) wide screen Resolution 1920 x 1080 Brightness (Typ.) 220 cd/m Contrast (Typ.) 800:1 Display Colors 262 K Digital Input DisplayPort™ Alt Mode for USB Type-C™ Colors Dark Gray Power Consumption ≦ 8 W Operating Temp. -
Page 23: Troubleshooting (Faq)
• Move electrical devices that may cause electrical interference. Screen image has color • Inspect the USB Type-C cable and make sure defects (white does not look that none of the pins are bent. white) ASUS USB Type-C Monitor MB16AC/MB16ACR/MB16ACM 3-11... - Page 24 *1: White color background will consume higher power, so it’s better to use white color background to test the power limit from source USB Type-C device. *2: If MB16AC/MB16ACR/MB16ACM does not re-start when adjusting to value 100, that means source USB Type-C device has sufficient power supply.
-
Page 25: Supported Timing List
IBM Modes, Factory Preset Timing Resolution Refresh Rate Horizontal Frequency 640x350 70Hz 31.469kHz 720x400 70Hz 31.469kHz VESA Modes, User Available Timing Resolution Refresh Rate Horizontal Frequency 848x480 60Hz 31.02kHz 1280x720 60Hz 44.772kHz 1280x800 60Hz 49.702kHz 1920x1080 60Hz 66.587kHz ASUS USB Type-C Monitor MB16AC/MB16ACR/MB16ACM 3-13...
