Summary of Contents for Element PLX-4202
- Page 1 PLX-4202B and PLX-5002B High Definition Plasma TV 20070515...
-
Page 2: Table Of Contents
........................Preparation for Using Your New TV... -
Page 3: Important Safety Instructions
6. CLEAN ONLY WITH DRY CLOTH Unplug the TV from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a dry cloth for cleaning. 7. DO NOT BLOCK ANY VENTILATION OPENINGS Slots and openings in the cabinet back or bottom are provided for ventilation, to ensure reliable operation of the TV and to protect it from overheating. - Page 4 15. POWER SOURCE This TV should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company . For TVs intended to operate from battery power, or other sources, refer to the operating instructions.
-
Page 5: Preparation For Using Your New Tv
Understanding your TV You can operate your TV using the buttons on the side of the TV or on the remote control. The terminals on the back of the TV provide all the connections for other equipments to your TV. - Page 6 Preparation for Using Your New TV Back View of TV H DMI 2 H DMI 1 V G A COMPONENT 1 AU DIO I N COMPONENT 2 HDMI INPUT PC AUDIO INPUT VGA INPUT COMPONENT INPUT DIGITAL AUDIO OUTPUT ANTENNA INPUT...
-
Page 7: Connecting Your Tv
Caution: Do not plug the TV in until you have finished connecting all of your equipment. Connecting to A/V equipment To enjoy its multimedia features, you can connect your TV to A/V equipment such as VCD, DVD, STB, Satellite receiver, Camcorder, Audio amplifier etc., and select signal input sources using your remote control. Connect the devices as shown below. -
Page 8: Connecting To A Computer
Preparation for Using Your New TV Connecting to a Computer You can use your TV as a monitor for your computer by connecting through its 15pin standard RGB interface and PC audio interface(AUDIO INPUT4). Connect the devices as shown below. -
Page 9: Connecting To A Cable Converter Box
Follow the connections shown below. With the switch in the position, you can directly tune any nonscrambled channels on your TV. With the switch in the position, tune your TV to the output of the Converter/Descrambler box(usually channel 3 or 4) and use the box to tune scrambled channels. -
Page 10: Using The Remote Control
Using the Remote Control Preparing the remote control for use Installing the remote control batteries 1. Open the battery cover on the back of the remote control. 2. Install two AAA size(1.5V) batteries. Match the + and - signs on the batteries to the signs on the battery compartment. -
Page 11: Learning About The Remote Control
ENTER VOL+ VOL- SLEEP MTS SAP MTS SAP TIME - 10- Power indicator INPUT: Switch between TV, Video, S-Video,Component,HDMI,VGA ZOOM: Select Screen Mode AUDIO: Select the sound mode GUIDE: ATSC tuners feature Electronic Programming Guide (EPG) function DISPLAY: Display current Status... -
Page 12: Understanding The Tv Features
Basic Operations Power ON/OFF 1) Connect the TV to power outlet . If the power indicator is red, it means that the TV is off. You need to press the Power button the remote control to turn on the TV, and the power indicator will display blue. -
Page 13: Basic Operations
To select a channel : Press the channel numbers one by one to select channel directly. For example, to select channel 120, Use [MENU] button Pressing [ MENU ] button will display TV OSD menu. Use [RECALL] button Pressing [RECALL] button to return the last channelviewed. - Page 14 Pressing [ TIME ] button you can view the current time. Use [GUIDE] button Use [P-LOCK] button Pressing the [ GUIDE] button the TV will show a program list, including the programs in recent days and you can view when the programs will be showing - 13 -...
-
Page 15: Menu Operation
Menu operation Video mode adjustment 1.Press MENU. The OSD appears. 2.Press to highlight Video, then press to enter the Video menu. 3.Press or highlight an option, then press or to adjust the option. You can adjust: ◆ Brightness-Increases the brightness to add more light to dark areas of the picture. -
Page 16: Setup
(6) Reset Default Every TV has an original setting before leaving the factory. You can remove any adjustments you made to the TV by resetting back to DEFAULTS. Parental When you first use this function, the default Password is [0000]. - Page 17 The Motion Picture Association of America(MPAA) uses a rating system to qualify motion picture content. Television broadcasters employ a rating system to qualify the content of televison programs as well. The MPAA and TV ratings work with the V-CHIP feature and allow you to block out programming above the rating limits you determine.
-
Page 18: Tv Settings
2) Use a clean cellulose sponge or chamois cloth dampened with a solution of mild detergent and warm water to clean the TV screen and trim. Do not use too much water as water spilled into the cabinet can cause damage to the TV. -
Page 19: Troubleshooting
The remote control does not operate Disorder display at power on Customer important notice: If the TV can not be operated,please unplug the power and restart . Possible Solutions Make sure the power cord is plugged in, then press [Power]. -
Page 20: Specifications
Appendix Specifications Model PLX-4202B 42 inches Diagonal display size Television system American TV standard ATSC /NTSC system Audio multiplex BTSC system VHF: 2~13 Digital Terrestrial Broadcast (8VSB): 2 9 Channel coverage Digital cable (64/256 QAM): 1 35 PC mode 640 480/60Hz,800 600/60Hz,1024 768/60Hz...
