Electro-Voice AC-One Owner's Manual

Audio controller
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
OWNER'S MANUAL
AC
ONE
AUDIO CONTROLLER

Advertisement

loading

Related Manuals for Electro-Voice AC-One

Summary of Contents for Electro-Voice AC-One

  • Page 1 OWNER’S MANUAL AUDIO CONTROLLER...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with a damp cloth. Do not block any of the ventilation openings. Install in accordance with the manufactures instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus that produce heat.
  • Page 3 INTRODUCTION Introduction ............9 Front Panel .

  • Page 4: Front Panel

    FRONT PANEL 1. Input “A” and “B” level controls These controls are normally set to their “0"-marked (detent) center position. If needed or desired, the controls can be used to individually adjust the input levels of the channels “A” and “B”. The green “Signal” LEDs indicate that audio signals are present at the inputs. The red “Peak” LEDs light whenever the audio signal is clipped inside the AC which might result in distortion.
  • Page 5 FRONT PANEL 7. Sub Out Mono control The control is normally set to its center (0dB) position. This control is used to adjust the loudness level of the summed low-frequency audio signal of the two channels “A” and “B”, which serves to feed a connected monaural sub woofer power amplifier. The “Mute” switch attenuates the Sub Out Mono audio signal, which allows to easily check the entire sound reinforcement system.

  • Page 6: Rear Panel

    REAR PANEL 11. Input connectors of channel “A” (CH A IN) and channel “B” (CH B IN) The AC Controller’s inputs are electronically balanced (pin2 = +, pin3 = -, pin1 = shield). The OUT-connectors are parallel-wired with their corresponding IN-connectors. This thru-connection allows to easily and conveniently feed additional gear with the original input audio signals.

  • Page 7: Specifications

    Technical Specifications AC All level and frequency controls in center position, Lo-EQ and Hi-EQ controls at 0dB, MID-EQ control at -4dB, unless otherwise specified. Note: 0dBu = 0.775V Crossover Mode Frequency, sweepable Filter Type LO-Cut Filter Type Frequency, sweepable Equalization LO-EQ MID-EQ HI-EQ...
  • Page 8 BLOCKDIAGRAM...
