- Page 1 OWNER’S MANUAL DVD Home Theater System Please read this manual carefully before operating your set and retain it for future reference. DH6630T (DH6630T, S63T2-S, S63S2-C, S63T1-W) DH6630T-FB.DEGYLLK_ENG_3201.indd 1 2013-12-10 10:01:14...
- Page 2 This product shall not be placed in a built- in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instruction has been adhered to. DH6630T-FB.DEGYLLK_ENG_3201.indd 2 2013-12-10 10:01:15...
- Page 3 CAUTION: The apparatus shall not be exposed to water (dripping or splashing) and no objects filled with liquids, such as vases, shall be placed on the apparatus. DH6630T-FB.DEGYLLK_ENG_3201.indd 3 2013-12-10 10:01:15...
-
Page 4: Table Of Contents
– USB Connection – Improving poor FM reception – OPTICAL In connection Sound adjustment – Home theater speaker ez setup – Setting the surround mode Antenna Connection Advanced Operations – Recording to USB Using a Bluetooth wireless technology DH6630T-FB.DEGYLLK_ENG_3201.indd 4 2013-12-10 10:01:15... - Page 5 – Listening to music of a Bluetooth device – Listening to music on this unit using Bluetooth device Troubleshooting Troubleshooting Appendix Maintenance – Handling the Unit – Notes on Discs Area Code List Language code List Trademarks and Licenses Specifications DH6630T-FB.DEGYLLK_ENG_3201.indd 5 2013-12-10 10:01:15...
-
Page 6: Getting Started
Speaker cables (5) Listen to sounds from TV, DVD and Digital device with vivid 5.1 (2.1 or 2.0) ch mode. Bluetooth® Listens to music stored on your bluetooth device. HDMI Cable (1) Video cable (1) Optical cable (1) DH6630T-FB.DEGYLLK_ENG_3201.indd 6 2013-12-10 10:01:16... -
Page 7: Introduction
If you try to play a DVD with a different regional operation and indicates that the function explained code from your unit, the message “Check in this owner’s manual is not available on that Regional Code” appears on the TV screen. specific media. DH6630T-FB.DEGYLLK_ENG_3201.indd 7 2013-12-10 10:01:16... -
Page 8: Playable File Requirement
When setting the option to Live File y Playable Audio format : “AC3”, “PCM”, “MP3”, “WMA”, System, you cannot use it on LG players. y Sampling frequency : within 32 to 48 kHz (MP3), (Mastered/ Live File System : Disc format system... -
Page 9: Remote Control
- You can control the sound in the menu or exits the setup level, input source, and power menu. switching of LG TVs as well. Hold POWER (TV) and press PR/ TITLE: If the current DVD title has CH (W/S) button repeatedly a menu, the title menu appears until the TV turns on or off. -
Page 10: Front Panel
1/! (POWER) Connects a USB device. Switches the unit ON or OFF. e R (OPEN/CLOSE) Opens or closes the disc tray. f T (PLAY/PAUSE) Starts playback. Pauses playback temporarily, press again to exit pause mode. DH6630T-FB.DEGYLLK_ENG_3201.indd 10 2013-12-10 10:01:17... -
Page 11: Rear Panel
(Interface for digital audio and video) d Antenna Connector h OPTICAL IN FM- Connects the FM wired antenna Connects to optical audio equipment. e AUX (L/R) INPUT Connects to an external source with 2 channel audio outputs. DH6630T-FB.DEGYLLK_ENG_3201.indd 11 2013-12-10 10:01:17... -
Page 12: Connecting
Base Screw Speaker Speaker cables 1. Attach the pole to the base, then secure the connection with a supplied screw. Note Make sure speaker cable unfolded or in straight condition before insert it to the hole. DH6630T-FB.DEGYLLK_ENG_3201.indd 12 2013-12-10 10:01:17... - Page 13 Do not catch the speaker cord between the Be careful that the speaker speakers and the pole. does not fall down. Otherwise it may result in the speaker malfunctioning and causing personal injury and/ or property damage. DH6630T-FB.DEGYLLK_ENG_3201.indd 13 2013-12-10 10:01:18...
-
Page 14: Attaching The Speakers To The Unit
PC monitor screen. Please use the speakers far away from either TV screen or PC monitor. 2. Connect the wires to the speakers. Connect the other end of each wire to the correct speaker according to the color coding: DH6630T-FB.DEGYLLK_ENG_3201.indd 14 2013-12-10 10:01:18... -
Page 15: Positioning The System
But it is better to place the subwoofer near the front speakers. Turn it slightly toward the center of the room to reduce the wall reflections. Unit DH6630T-FB.DEGYLLK_ENG_3201.indd 15 2013-12-10 10:01:19... -
Page 16: Connections To Your Tv
When the HDMI connection with HDCP is not verified, TV screen is changed to black or green screen or the snow noise may occur on the screen. In this case, check the the HDMI connection, or disconnect the HDMI cable. DH6630T-FB.DEGYLLK_ENG_3201.indd 16 2013-12-10 10:01:19... -
Page 17: Video Connection
Cable. Yellow Some functions of this unit are controlled by the TV’s remote control when this unit and LG TV’s with SIMPLINK are connected through HDMI connection. Controllable functions by LG TV’s remote control; Play, Pause, Scan, Skip, Stop, Power Off, etc. -
Page 18: Resolution Setting
ENTER to confirm your selection. Note If your TV does not accept the resolution you have set on the player, you can set resolution to 480p (or 576p) as follows: Press Z STOP for more than 5 seconds. DH6630T-FB.DEGYLLK_ENG_3201.indd 18 2013-12-10 10:01:20... -
Page 19: Optional Equipment Connection
If your TV has only one output for audio function by pressing P RADIO&INPUT. (mono), connect it to the left (white) audio jack on the unit. 4. Turn on the portable player or external device and start it playing. DH6630T-FB.DEGYLLK_ENG_3201.indd 19 2013-12-10 10:01:20... -
Page 20: Usb Connection
External HDD, Card readers, Locked devices, or hard type usb devices are not supported. y USB port of the unit cannot be connected to PC. The unit can not be used as a storage device. DH6630T-FB.DEGYLLK_ENG_3201.indd 20 2013-12-10 10:01:20... -
Page 21: Optical In Connection
To select the AUX OPT directly. 3. Listen sound with 5.1(2.1 or 2)ch speaker. 4. To escape from AUX OPT by using the OPTICAL. Function is retuned to previous one. To the digital optical output jack of your component DH6630T-FB.DEGYLLK_ENG_3201.indd 21 2013-12-10 10:01:21... -
Page 22: Antenna Connection
Connecting Antenna Connection Connect the supplied FM antenna for listening to the radio. Connect the FM Wire antenna to the FM antenna connector. Note Be sure to fully extend the FM wire antenna. DH6630T-FB.DEGYLLK_ENG_3201.indd 22 2013-12-10 10:01:21... -
Page 23: System Setting
2. Use WSAD to select a language then press b ENTER. b ENTER To confirm menu. The confirm menu will appear. Select 3. Use AD to select the [Enter] then press b ENTER to finish the language setup. DH6630T-FB.DEGYLLK_ENG_3201.indd 23 2013-12-10 10:01:21... -
Page 24: Language
Select when a 16:9 wide TV is connected. Display Mode The Display Mode setting works only when the TV Aspect mode is set to 4:3. [Letterbox] Displays a wide picture with bands on the upper and lower portions of the screen. DH6630T-FB.DEGYLLK_ENG_3201.indd 24 2013-12-10 10:01:21... -
Page 25: Audio
4. Adjust options using WSAD buttons. and press b ENTER. Press b ENTER again to 5. Returns to the previous menu by pressing x stop. Adjust the volume to match the volume RETURN. of test signals memorized in the system. DH6630T-FB.DEGYLLK_ENG_3201.indd 25 2013-12-10 10:01:21... -
Page 26: Lock (Parental Control)
Rating one (1) has the most restrictions and rating eight (8) is the least restrictive. [Unlock] If you select unlock, parental control is not active and the disc plays in full. 4. Press b ENTER to confirm your rating selection. DH6630T-FB.DEGYLLK_ENG_3201.indd 26 2013-12-10 10:01:21... -
Page 27: Others
2. Input a password and press b ENTER. 3. Select the first character using WS buttons. 4. Press b ENTER and select the second character using WS buttons. 5. Press b ENTER to confirm your Area code selection. DH6630T-FB.DEGYLLK_ENG_3201.indd 27 2013-12-10 10:01:21... -
Page 28: Operating
[Photo] option when the USB device is not the USB storage device or disc automatically. connected or a disc is not inserted. y The DTS is not supported. In case of DTS audio format, audio is not output. DH6630T-FB.DEGYLLK_ENG_3201.indd 28 2013-12-10 10:01:21... -
Page 29: Other Operations
- Audio CD/ MP3/ WMA : Track/ All/ Random/ Off In the pause mode, press SCAN (c or v) to select Slowing down the playing the required speed. (DVD, DivX speed only) The DivX file cannot be slow down reverse playback. DH6630T-FB.DEGYLLK_ENG_3201.indd 29 2013-12-10 10:01:21... -
Page 30: To Display The Dvd Menu
4. Press x RETURN to exit the On-Screen display. To start playing at any chosen time on the file or title. 1. Press m INFO/DISPLAY during playback. 2. Press WS to select the time clock icon and “--:--:--” appears. DH6630T-FB.DEGYLLK_ENG_3201.indd 30 2013-12-10 10:01:22... -
Page 31: Marked Playback
4. Select the play mode by using the and press ENTER. [Mark Play] Marked playback. [Current Play] Normal playback. Note If you want to select all files on the list, select [Select All] and press b ENTER. DH6630T-FB.DEGYLLK_ENG_3201.indd 31 2013-12-10 10:01:22... -
Page 32: Viewing A Photo File
Viewing a particular show. b ENTER Select file. d Rotate – Press ENTER to rotate the photo. Returning to the x RETURN Close [Home Menu]. e Go to list – Press ENTER to return [Photo] menu. DH6630T-FB.DEGYLLK_ENG_3201.indd 32 2013-12-10 10:01:22... -
Page 33: Sleep Timer Setting
Power Resume - Optional Even if the power suddenly goes out, turn on the unit and then it plays a position where the contents is being played. System will periodically save current playback status. DH6630T-FB.DEGYLLK_ENG_3201.indd 33 2013-12-10 10:01:22... -
Page 34: Radio Operations
6. Repeat the steps 2 to 5 to store other stations. Deleting all the saved stations 1. Press and hold CLEAR for two seconds. “ERASE ALL” will flash up on the unit display. 2. Press CLEAR to erase all saved of the radio stations. DH6630T-FB.DEGYLLK_ENG_3201.indd 34 2013-12-10 10:01:22... -
Page 35: Sound Adjustment
LOUDNESS sound. You can enjoy the sound BYPASS without equalizer effect. You can enjoy the harmonious P-FRONT sound. This mode is suited (POWER FORNT) for front-positioned speakers -Optional when they are all placed in a row. DH6630T-FB.DEGYLLK_ENG_3201.indd 35 2013-12-10 10:01:22... -
Page 36: Advanced Operations
The making of unauthorized copies of copy- protected material, including computer programs, files, broadcasts and sound recordings, may be an infringement of copyrights and constitute a criminal offense. This equipment should not be used for such purposes. Be responsible Respect copyrights. DH6630T-FB.DEGYLLK_ENG_3201.indd 36 2013-12-10 10:01:22... -
Page 37: Using A Bluetooth Wireless Technology
Cascade if the connection was made via display depending on the type of Bluetooth Bluetooth® wireless technology. device.Your unit appears as “LG Audio”. Available Devices : Mobile phone, MP3, Laptop, 3. Enter the PIN code. PDA (This units be supported the Stereo Headset.) PIN code : 0000 4. -
Page 38: Listening To Music On This Unit Using
Sound output from the speakers is stopped. Press and hold m INFO/DISPLAY repeatedly. Note Bluetooth information is changed as follows. You cannot use VOL (volume), SOUND EFFECT, Local Bluetooth Device Address Device Name SPEAKER LEVEL in this mode. None DH6630T-FB.DEGYLLK_ENG_3201.indd 38 2013-12-10 10:01:22... - Page 39 Bluetooth and the unit gets out of the operating range of Bluetooth. y The device with Bluetooth wireless technology is disconnected, if you turn off the main unit or put the device away from the main unit more than 10m. DH6630T-FB.DEGYLLK_ENG_3201.indd 39 2013-12-10 10:01:22...
-
Page 40: Troubleshooting
The remote control doesn’t work There is an obstacle in the path between the remote control and well / at all the unit. Remove the obstacle. The battery in the remote control are flat. Replace the battery with new ones. DH6630T-FB.DEGYLLK_ENG_3201.indd 40 2013-12-10 10:01:22... -
Page 41: Appendix
Maintaining the Unit The unit is a high-tech, precision device. If the optical pick-up lens and disc drive parts are dirty or worn, the picture quality could be diminished. For details, please contact your nearest authorized service center. DH6630T-FB.DEGYLLK_ENG_3201.indd 41 2013-12-10 10:01:22... -
Page 42: Area Code List
Jamaica Philippines Ukraine Costa Rica Japan Poland United States Croatia Kenya Portugal Uruguay Czech Republic Kuwait Romania Uzbekistan Denmark Libya Russian Vietnam Federation Ecuador Luxembourg Zimbabwe Saudi Arabia Egypt Malaysia Senegal El Salvador Maldives Ethiopia Mexico DH6630T-FB.DEGYLLK_ENG_3201.indd 42 2013-12-10 10:01:22... -
Page 43: Language Code List
Kurdish 7585 Scots Gaelic 7168 Xhosa 8872 Estonian 6984 Laothian 7679 Serbian 8382 Yiddish 7473 Faroese 7079 Latin 7665 Serbo-Croatian 8372 Yoruba 8979 Fiji 7074 Latvian, Lettish 7686 Shona 8378 Zulu 9085 Finnish 7073 Lingala 7678 DH6630T-FB.DEGYLLK_ENG_3201.indd 43 2013-12-10 10:01:23... -
Page 44: Trademarks And Licenses
The Bluetooth® word mark and logos are owned by the Bluetooth® SIG, Inc. and any use of such marks by LG Electronics is under license. The terms HDMI and HDMI High-Definition Other trademarks and trade names are those of Multimedia Interface, and the HDMI logo are their respective owners. -
Page 45: Specifications
167 W (3 Ω at 1 kHz) Surround mode Surround 167 W + 167 W (3 Ω at 1 kHz)) Subwoofer 167 W (3 Ω at 60 Hz) Tuner FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz DH6630T-FB.DEGYLLK_ENG_3201.indd 45 2013-12-10 10:01:23... - Page 46 3 Ω Input Power 167 W Max. Input Power 334 W Net Dimensions (W x H x D) (133 x 352 x 325) mm Net Weight 5.2 kg Design and specifications are subject to change without notice. DH6630T-FB.DEGYLLK_ENG_3201.indd 46 2013-12-10 10:01:23...
