Sony MDR-EX310SL Operating Instructions

Stereo
Headphones
MDR-EX310SL
©2010 Sony Corporation Printed in Thailand

1


1
Earbud
耳塞
Tactile dot
觸點
3
Stay-in design
入耳式設計


Sectional View
Coloured parts
組件圖示 彩色部分
Pressure-relieving
urethane cushion
氨基鉀酸酯釋壓泡棉


4-260-432-11(1)
English
Stereo headphones
Features
Operating Instructions
使用說明書
 13.5mm dynamic type driver units reproduce vocal and instrumental sound with vivid
clarity
 Newly developed stay-in design for a more secure fit
 Closed type vertical in-the-ear headphones for wearing comfort
 4 sizes of hybrid silicone rubber earbuds for secure fit and long-term wearing comfort
(SS, S, M, L)
3 sizes of noise isolation earbuds for effective attenuation of ambient noise (S, M, L)
 Handy carrying pouch supplied
 Convenient cord adjuster supplied
How to use
Using the supplied cord adjuster (see fig. )
You can adjust the cord length by winding the cord on the cord adjuster.
(The cord can be wound to the cord adjuster up to 50 cm. If you wind more, the cord
comes off from the cord adjuster easily.)
1
Wind the cord.
2
Push cord into slot hole to secure in place.
Note
Do not wind the plug or split section of the cord, as it will strain the cord and may cause a wire break.
Using the extension cord (see fig. )
Insert the stereo mini plug fully into the jack until you hear a click.
Wearing the headphones (see fig. )
1
Determine right and left headphone and hold them as in the illustration.
There is a tactile dot on the unit marked  to distinguish the left side.
2
Fit the headphones into your ears snugly, as in the illustration.
3
Adjust the headphone to fit snugly in your ear.
2
 Tip
The stay-in design uses a thermoplastic elastomer that is pliable to fit the hollow of your
ear. If it does not stabilize, adjust its position.
Installing the earbuds correctly (see fig. )
If the earbuds do not fit your ears correctly, low-bass sound may not be heard. To enjoy
better sound quality, change the earbuds to another size or type, or adjust the earbuds
position to sit on your ears comfortably and fit your ears snugly. If the earbuds do not fit
your ears, try another size or type. Confirm the size of the earbuds by checking the
colour inside (see fig. - for hybrid silicone rubber earbuds and - for noise
isolation earbuds).
When you change the earbuds, install them firmly on the headphones to prevent the
earbud from detaching and remaining in your ear.
About hybrid silicone rubber earbuds (see fig. -)
Earbud sizes (inside colour)
Small

SS
(Red)
To clean the hybrid silicone rubber earbuds
2
Remove the earbuds from the headphones, and wash them with a mild detergent
solution.
About noise isolation earbuds (see fig. -)
Supplied noise isolation earbuds provides a snug fit for effective attenuation of ambient
noise.
Earbud sizes (inside colour)
Small

S
(Orange)
Notes
 Prolonged use of the noise isolation earbuds may strain your ears due to their snug fit. If you have
experience discomfort or pain in your ears, discontinue use.
 The pressure-relieving urethane cushion is extremely soft. Therefore, do not pinch or pull the
urethane cushion. If the urethane cushion is broken or detached from the earbuds, it will not take its
correct position and the earbuds will lose their noise isolation function.
 The pressure-relieving urethane cushion may deteriorate due to long-term storage or use. If the
pressure-relieving power is lost and the urethane cushion becomes hard, the earbuds may lose their
noise isolation function.
 Do not wash the noise isolation earbuds. Keep them dry, and avoid accumulation of water in the
pressure-relieving urethane-cushions. Not doing so may cause early deterioration.
To detach an earbud (see fig. -)
While holding the headphone, twist the parts inside of the earbud and pull the earbud
off.
 Tip
If the earbud slips and cannot be detached, wrap it in a dry soft cloth.
To attach an earbud (see fig. -)
Push the parts inside of the earbud into the headphone until the projecting part of the
headphone is fully covered.

Specifications
Type:
Driver unit:
Power handling capacity:
Impedance:
Sensitivity:
Frequency response:

Cord:
Plug:
Mass:
Supplied accessories
Hybrid silicone rubber earbuds (SS (2), S (2), M (2), L (2)) / Noise isolation earbuds
(S (2), M (2), L (2)) / Carrying pouch (1) / Cord adjuster (1) / Extension cord (90 cm,
Gold-plated stereo mini jack  Gold-plated L-type stereo mini plug) (1) /
Operating Instructions (1)
* IEC = International Electrotechnical Commission
Design and specifications are subject to change without notice.
Precautions
 Please keep your headphones clean at all times especially inside the rubber earbud.
(see fig. )
If any dust or ear wax is inside the earbud, you may experience some listening
difficulties.
 Listening with headphones at high volume may affect your hearing. For traffic safety,
do not use while driving or cycling.
 Handle the driver units carefully.
 Do not put weight or pressure on the headphones as it may cause the headphones to
deform during long storage.
 The earbuds may deteriorate due to long-term storage or use.
 Install the earbuds firmly onto the headphones. If an earbud accidentally detaches and
is left in your ear, it may cause injury.
 Store the earbuds where children cannot reach in order to prevent from accidental
ingestion or choking.
Note on static electricity
In particularly dry air conditions, mild tingling may be felt on your ears. This is a result
of static electricity accumulated in the body, and not a malfunction of the headphones.
The effect can be minimized by wearing clothes made from natural materials.
Optional replacement earbuds can be ordered from your nearest Sony dealer.
Large

S M L
(Orange) (Green) (Light blue)
Large

M L
(Green) (Light blue)
Closed, dynamic
13.5 mm, dome type (CCAW adopted)
100 mW (IEC*)
16 Ω at 1 kHz
105 dB/mW
5 – 25,000 Hz
0.6 m, OFC litz cord neck-chain
Gold-plated stereo mini plug
Approx. 7 g with out cord
繁體中文
立體聲耳機
特點
 13.5mm 動態類型激勵單元可再現生動、清晰的歌聲與樂器聲
 新研發的入耳式設計，可更穩固服貼
 密閉型垂直入耳式耳機，便於舒適佩戴
 4 種尺寸的混合矽膠耳塞貼合更牢固，且長時間聆聽也不會感到不適（SS、S、M、L）
3 種尺寸的噪音隔離耳塞，可有效衰減環境噪聲（S、M、L）
 隨附攜帶式保護袋
 隨附便利導線長度調節器
使用方法
如何使用附帶的導線長度調節器（見圖 ）
您可透過將導線捲繞到導線長度調節器來調節導線長度。
（導線最多可繞到導線長度調節器上達 50 cm。如果在達到最大長度下繼續捲繞，則導
線會很容易從導線長度調節器中滑出。 ）
1
捲繞導線。
2
將導線推入槽孔以固定到位。
注意
請勿捲繞插頭或導線的分叉部分，否則可能會拉壞導線並造成線芯斷裂。
）
如何使用延長線（ 見圖
將立體聲迷你插頭完全插入插孔，直到聽到定位聲為止。
佩戴耳機（見圖 ）
1
確定左右耳機，並如圖所示拿著。
標記  的耳機上具有易於辨識為左邊的觸點設計。
2
如圖所示，將耳機舒適地塞入您的耳朵。
3
調整耳機使其舒適地貼合您的耳朵。

提示
入耳式設計採用柔韌的熱塑性彈性體，可貼合耳道。如果不穩固，請調節其位置。
正確安裝耳塞（見圖 ）
如果耳塞無法正確貼合您的耳朵，您便可能無法聽到重低音。為了享受更佳音質，請更
換耳塞尺寸或型式， 或調整耳塞的位置以舒適貼合您的耳朵。如果耳塞不適合您的耳形，
請更換耳塞尺寸或型式。檢查內部顏色以確認耳塞尺寸（如果使用混合矽膠耳塞請見圖
-，如果使用噪音隔離耳塞請見圖 -） 。
當您更換耳塞時，請將其牢固地安裝在耳機上以防止耳塞脫落在您耳朵內。
關於混合矽膠耳塞（見圖 -）
耳塞尺寸（內部顏色）
小 
SS（紅色） S（橘色） M（綠色） L（淺藍色）
清潔混合矽膠耳塞
將耳塞從耳機體上拆下，並以中性清潔劑溶液清洗。
關於噪音隔離耳塞（見圖 -）
附件噪音隔離耳塞可緊貼耳朵，有效衰減環境噪聲。
耳塞尺寸（內部顏色）
小   大
S（橘色） M（綠色） L（淺藍色）
注意
 長期使用噪音隔離耳塞可能會拉傷耳朵，因為耳塞緊貼耳朵。如果耳朵感到不適或疼痛，請暫停使
用。
 氨基鉀酸酯釋壓泡棉非常柔軟。因此，切勿擠壓或拉出氨基鉀酸酯泡棉。如果氨基鉀酸酯泡棉損壞
或與耳塞分離，則耳塞位置不正確，將失去噪音隔離功能。
 氨基鉀酸酯釋壓泡棉可能會因為長期存放或使用而損壞。如果失去釋壓能力，且氨基鉀酸酯泡棉變
硬，則耳塞可能失去噪音隔離功能。
 請勿清洗噪音隔離耳塞。使耳塞保持乾燥，並避免氨基鉀酸酯釋壓泡棉積水。否則可能會導致過早
老化。
拆掉耳塞的方式（見圖 -）
拿著耳機，然後轉動耳塞內側部分，把耳塞拔出來。
 提示
如果耳塞較滑無法拆下，請用柔軟乾布將其包住。
安裝耳塞的方式（見圖 -）
將耳塞內側部分推入耳機裡，直到完全覆蓋耳機突出部分為止。
規格
型式： 封閉式，動態
激勵單元： 13.5 mm，圓頂型（採用 CCAW）
功率處理容量： 100 mW (IEC*)
阻抗： 1 kHz 時 16 Ω
靈敏度： 105 dB/mW
頻率響應： 5 – 25000 Hz
導線： 0.6 m，OFC 項鍊式絞合線
插頭： 鍍金立體聲迷你插頭
質量： 約 7 g（不含導線）
附件
混合矽膠耳塞（SS (2)， S (2)， M (2)， L (2)）/ 噪音隔離耳塞（S (2)， M (2)， L (2)）
/ 攜帶袋 (1) / 導線長度調節器 (1) / 延長線（90 cm，鍍金立體聲迷你插孔  鍍
金 L 型立體聲迷你插頭）(1) / 使用說明書 (1)
* IEC = 國際電工委員會
設計和規格如有變更，恕不另行通知。
注意事項
 請隨時保持耳機的清潔，尤其是橡膠耳塞的內部（見圖 ） 。
如果耳塞有灰塵或耳垢，您可能會無法順利聆聽音樂。
 戴著耳機用很高的音量收聽可能會影響您的聽力。為了交通安全，切勿在駕車或騎車
時使用耳機。
 小心處理激勵單元。
 請勿在耳機上放置重物或加壓，否則可能導致耳機在長期存放時變形。
 耳塞可能會因為長期存放或使用而損壞。
 將耳塞牢固地安裝在耳機上。如果耳塞不小心脫落在您耳朵內，可能會造成傷害。
 將耳塞存放在小孩拿不到的地方，以免誤食或窒息。
靜電注意事項
在特別乾燥的空氣條件下，耳朵可能會感到輕微刺痛。這是由於體內積聚的靜電所致，
而非耳機故障。穿著天然材料製成的衣服可將此影響減到最少。
可向附近的 Sony 經銷商訂購選購的替換耳塞。
 大
