- Page 1 User's Guide Guía del usuario Manuel de l’utilisateur Gebruikersgids OC40FMX Guida per l’utente Руководство пользователя Guia do usuário OM1100675 دﻟﯾل اﻟﻣﺳﺗﺧدم www.omnimount.com | USA: 1-800-MOUNT-IT (1-800-668-6848) Europe: +31 (0)33-45 45 600 English, Español, Français, Deutsch, Italiano, русский язык, Português, ,مدختسملا ليلدčeština, Használati utasítás, Polski, Οδηγός χρήστη, Türkçe. תירבע...
- Page 2 ENGLISH DISCLAIMER - WARNING INFORMATION Disclaimer – Ergotron, Inc. has extended every eff ort to ensure the accuracy and completeness of this manual; OmniMount is a registered trademark and brand of Ergotron, Inc. However, Ergotron, Inc. does not claim that the information covers all installation or operational variables.
- Page 3 ﻻ ﺗﺣﺎول ﺗرﻛﯾب ھذا اﻟﻣﻧﺗﺞ أو ﺗﺟﻣﻌﯾﮫ ﻓﻲ ﺣﺎﻟﺔ وﺟود ﺗﻠف أو ﻧﻘص ﺑﻣﺳﺗﻠزﻣﺎﺗﮫ. ﻓﻲ ﺣﺎﻟﺔ اﻟﺣﺎﺟﺔ ﻻﺳﺗﺑدال أﯾﺔ ﻗطﻊ ﻏﯾﺎر أو أﺟﮭزة، اﻟرﺟﺎء اﻻﺗﺻﺎل ﺑﺧدﻣﺔ اﻟﻌﻣﻼء ﻋﻠﻰ اﻟرﻗم 8486-866-008-1 أو ﻋﺑر اﻟﻣوﻗﻊinfo@omnimount.com. ﻛﻣﺎ ﯾﺟب ﻋﻠﻰ اﻟﻌﻣﻼء اﻟدوﻟﯾﯾن اﻟراﻏﺑﯾن ﻓﻲ...
- Page 4 Mounts TVs with these hole patterns: 75, 100, 200 mm 75, 100, 200 mm TV Weight Capacity: < 40 lbs (18.14 kg) CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY. SERIOUS INJURY OR PROPERTY DAMAGE MAY OCCUR! PRECAUCIÓN: NO SUPERE LA CAPACIDAD DE PESO MÁXIMA INDICADA. PODRÍA OCURRIR DAÑOS MATERIALES GRAVES O LESIONES FÍSICAS.
- Page 5 4 mm M6 x 8 mm M4 x 12 mm M6 x 25 mm M8 x 25 mm M8 x 10 mm M4/M6/M8 x 2.5 mm M7 x 55 mm 13 mm Stud Finder Ø 7/32" (5.6mm) Ø 3/8" (9.5mm) WOOD STUD CONCRETE ESTRUCTURA DE MADERA...
- Page 6 Determine mounting location. Determinación del lugar de montaje. Déterminez l’emplacement de pose. Montageposition bestimmen Stabilire l’ubicazione di montaggio. Определите место монтажа. Determine o local de montagem. .ﺣدد ﻣوﺿﻊ اﻟﺗرﻛﯾب WOOD STUD CONCRETE ESTRUCTURA DE MADERA CONCRETO MONTANT DE BOIS BÉTON HOLZPFOSTEN MASSIVBETON ASSE DI LEGNO...
- Page 7 Find the one size screw that fi ts your TV. You will use the 4 screws of that size. Use the 4 washers that fi t your screw size. Spacers may be used to help screws/brackets attach without interference. WARNING: When using included M4 hardware with this mount, the maximum weight of the TV/Monitor being attached must follow VESA MIS-D specifi...
- Page 8 These extenders will allow you to mount TV’s with a 200mm x 200mm hole pattern. Attach each extender to the TV plate using shown hardware. Once this step is complete, refer to the previous step for attaching the TV plate to the 4 mm M6 x 8 mm M4 x 12 mm...
-
Page 9: Wood Stud Installation
WOOD STUD INSTALLATION CONCRETE WALL INSTALLATION WOOD STUD CONCRETE ESTRUCTURA DE MADERA CONCRETO MONTANT DE BOIS BÉTON HOLZPFOSTEN MASSIVBETON ASSE DI LEGNO CEMENTO ДЕРЕВЯННАЯ СТОЙКА БЕТОН COLUNA DE MADEIRA CONCRETO دﻋﺎﻣﺔ ﺧﺷﺑﯾﺔ ﺧرﺳﺎﻧﺔ Ø 3/8" (9.5mm) Ø 7/32" (5,5 mm) 888-61-279-W-01 rev. - Page 10 CONCRETE WALL INSTALLATION WOOD STUD INSTALLATION WOOD STUD CONCRETE ESTRUCTURA DE MADERA CONCRETO MONTANT DE BOIS BÉTON HOLZPFOSTEN MASSIVBETON ASSE DI LEGNO CEMENTO ДЕРЕВЯННАЯ СТОЙКА БЕТОН COLUNA DE MADEIRA CONCRETO دﻋﺎﻣﺔ ﺧﺷﺑﯾﺔ ﺧرﺳﺎﻧﺔ 13 mm 13 mm M7 x 55 mm M7 x 55 mm 10 of 15 888-61-279-W-01 rev.
- Page 11 MOUNT TV TO WALL We recommend that you make all AV and power connections before you hang your TV NOTE: IF YOUR TV IS OR EXCEEDS 70" PLEASE CHECK YOUR TV MANUAL TO ENSURE THAT YOUR TV CAN BE USED IN A TILTED ORIENTATION. 4 mm Level monitor before securing screws.
- Page 12 Route your cables through the cable channel attached to the extension. Be careful of possible pinch points and feel free to use extra cable bundling or zip ties for a clean installation. To change tilt angle, loosen knob, adjust and tighten knob. Para cambiar el ángulo de inclinación, afl...
- Page 13 OmniMount. En caso de no respetar las instrucciones de cuidado de los productos por parte de OmniMount, se invalidará...
- Page 14 5 anni dalla data di vendita al primo acquirente. Per o enere i servizi legati alla garanzia, occorre restituire il prodo o o il componente dife oso al negozio presso il quale è stato acquistato, dove si vendono prodo i OmniMount della stessa tipologia. Il negozio al de aglio, a sua scelta, riparerà...
- Page 15 5 anos a partir da data de venda para o comprador original. Para obter o serviço de garantia, devolva o produto ou componente defeituoso para a loja onde foi comprado ou para qualquer outra loja varejista que venda produtos OmniMount do mesmo tipo. A loja varejista deve então, de acordo com sua preferência, reparar o produto, encaminhá-lo para um local de reparos independente, substituir o produto ou reembolsar o preço pago pela compra, menos o valor diretamente...
