012C
WELLS MANUFACTURING
10 Sunnen Dr., St. Louis, MO 63143
telephone: 314-678-6314
fax: 314-781-2714
www.wellsbloomfield.com
OWNERS MANUAL
BUILT-IN
SINGLE-WELL
MODULAR
WARMERS
with
INFINITE SWITCH
CONTROL
MODELS
MOD100
MOD100D
MOD-100
Includes
INSTALLATION
USE & CARE
EXPLODED VIEW
PARTS LIST
WIRING DIAGRAM
IMPORTANT: DO NOT DISCARD THIS MANUAL
This manual is considered to be part of the appliance and is to be given to the OWNER or
MANAGER of the restaurant, or to the person responsible for TRAINING OPERATORS of
this appliance. Additional manuals are available from your WELLS DEALER.
THIS MANUAL MUST BE READ AND UNDERSTOOD BY ALL PERSONS USING OR
INSTALLING THIS APPLIANCE. Contact your WELLS DEALER if you have any
questions concerning installation, operation or maintenance of this equipment.
2M-308029 Rev. (-)
11
p/n
M012C.01
0124
Advertisement
Related Manuals for Wells MOD100D
Summary of Contents for Wells MOD100D
- Page 1 Additional manuals are available from your WELLS DEALER. THIS MANUAL MUST BE READ AND UNDERSTOOD BY ALL PERSONS USING OR INSTALLING THIS APPLIANCE. Contact your WELLS DEALER if you have any questions concerning installation, operation or maintenance of this equipment.
- Page 2 The prices charged for information and other details concerning warranty. by Wells Manufacturing for its products are based upon the SERVICE POLICY AND PROCEDURE GUIDE and ADDITIONAL WARRANTY EXCLUSIONS Resetting of safety thermostats, circuit breakers, over cleaning schedules, are customer responsibility.
- Page 3 PARTS & SERVICE CUSTOMER SERVICE DATA INTRODUCTION Thank You for purchasing this Wells Manufacturing appliance. Proper installation, professional operation and consistent maintenance of this appliance will ensure that it gives you the very best performance and a long, economical service life.
- Page 4 FEATURES & OPERATING CONTROLS A. INFINITE SWITCH 1. On INFINITE SWITCH CONTROLLED warmers, power is applied to the heating element based on the control knob position, which varies the duty cycle of the heating element. 2. The desired temperature is controlled by rotating the TEMPERATURE CONTROL KNOB.
- Page 5 Damage Do not operate this appliance if the control panel is damaged. Call to the appliance may result if your Authorized Wells Service Agent for service. these instructions are not followed. The technical content of this manual, including any wiring diagrams, schematics, parts breakdown illustrations and/or adjustment procedures, is intended for use by qualified technical personnel.
- Page 6 INSTALLATION UNPACKING & INSPECTION NOTE: DO NOT discard the carton or other packing Carefully remove the appliance from the carton. Remove all materials until you have protective plastic film, packing materials and accessories from the inspected the appliance for Appliance before connecting electrical power or otherwise performing hidden damage and tested it any installation procedure.
- Page 7 INSTALLATION For “top-mounted” warmers (i.e. warmers mounted from above the counter top): a. Verify that provided sealants are applied to the underside of the warmer top flange prior to setting the unit into the cutout. b. After installation, verify that the tabs on the Wellsloks are turned out to lock the warmer into the counter c.
- Page 8 CAUTION: between the change in wet or dry operation. SHOCK HAZARD c. Wells Manufacturing recommends operating WET for consistent food heating. DO NOT splash or pour water d. If your wet-operation warmer is allowed to run dry, turn it onto control panel or wiring.
- Page 9 Never use metal implements, wire brushes, abrasive scratch pads or steel wool to clean stainless steel. Warmer pans, insets and other vessels are subject to a harsher environment. Wells Manufacturing uses an very high quality stainless steel (#304DDQ) for our food warmer pans.
- Page 10 Contact your Authorized Wells Service Agency to inspect warmer if water or grease contamination is suspected. 6. Close drain valve. Add proper amount of warm water. Turn control...
- Page 11 CLEANING INSTRUCTIONS WEEKLY CLEANING INSTRUCTIONS CAUTION: CHEMICAL BURN PREPARATIONS: Remove any insets, pans and/or adapter tops. HAZARD Drain or remove water from well if used for wet operation. Deilimng chemicals may be caustic. Wear appropriate FREQUENCY: Weekly, or whenever lime or scale is seen personal protective equipment.
- Page 12 Drain valve damaged or pan(s) Contact your Authorized Wells leaking Service Agency for repairs There are no user-serviceable components in this appliance. In all instances of damage or malfunction, contact your Authorized Wells Service Agency for repairs. WIRING DIAGRAM...
- Page 13 P2-WL0069, 208V INSULATION 2H-31882 WS-65184 2C-31734 2H-36196 (sold by the foot) P2-30401 P2-45066 P2-45067 MOD-100 5P-21709 P2-45186 P2-30402 GASKET-WASHER P2-31033 2E-30562 (240V) 2I-Z12311 2E-30570 (120V) P2-40843 2K-33996X MOD100D WS-50385 I7-Z12221 2K-31040 GASKET-WASHER 2I-Z12311 2R-44373 2K-33996X WELLS WELLS MODEL:MOD100 (D) IL2092b...
- Page 14 PARTS & SERVICE DESCRIPTION PART NO. Always use an inset. DO NOT place food directly ADAPTERS & INSETS into the warmer pan. ADAPTER TOP, convert 12” x 20” warmer to hold two 7 qt. insets WS-21502 ADAPTER TOP, convert 12” x 20” warmer to hold two 4 qt.
- Page 15 12” x 20” warmers only, adapt to wood counter authorized replacement parts, up to 1¾” thick 5P-22593* contact your Wells authorized service agency, or call: Wellslok Extension Kits for UL Listed units approved for installation in wood counter tops Wells Manufacturing One well units require one kit / Two and three well units require 10 Sunnen Dr.,...
- Page 16 WELLS MANUFACTURING 10 Sunnen Dr., St. Louis, MO 63143 telephone: 314-678-6314 fax: 314-781-2714 www.wellsbloomfield.com...
