Manual Release Key; Lockable - Merlin WeatherDrive MR555MYQ Installation And Operating Instructions Manual

8
THE RELEASE HANDLE & CORD
DO NOT DISENGAGE THE OPENER TO MANUAL
OPERATION WITH CHILDREN , PERSONS OR
OTHER OBJECTS INCLUDING MOTOR VEHICLES
WITHIN THE DOORWAY : (The door is under significant
tension and if the door has developed a fault or incorrect
tension, it may be unsafe and may fall rapidly.)
The manual release mechanism enables the door to be
manually operated during power outages or in an emergency.
The RED Manual Release cord is preassembled to the
opener. When the opener is installed the handle should be no
higher then 1.8 metres from the floor. The cord may need to
be extended.
KEY LOCKABLE RELEASE
9
The use of the Key Lockable Release is
for use in Commercial Applications
ONLY, and not to be used when installed
in a residential Application (refer safety
standard AS/NZS 60335.2.95). An
alternative exit path from the building
MUST BE AVAILABLE when using the
Key Lockable Feature
• Turn OFF the opener mains power (so the door
cannot be activated).
• Insert the key into the Maual Release handle and
Lock or Unlock as required (an 8 mm allen key
can be used to extend the handle if needed).
• Keep the key in a safe place.
• Two keys are provided, if a replacement is needed,
refer to a locksmith.
OPERATING THE MANUAL RELEASE
10
NOTE: Ensure the Key Lockable Release is not locked.
To disengage the opener
Pull the release cord down firmly,
(opener will make a clicking noise).
To re-engage the opener
Pull the release cord down firmly,
(opener will make a clicking noise).
Disable all locks and remove any ropes connected to the garage door.
Take care when operating the manual release as an open door may fall rapidly due to weak or
broken springs, or being out of balance.
Rope
Insert key into
Release Handle
Lock or unlock
as required
8 mm allen key
(not provided)
Unlock
7
Manual release
warning label
Release handle
Overhand knot
