Software Version: ... INTENDED USE This user manual is intended for anyone who uses an EchoStar satellite receiver. It can be used by both first-time and experienced users of satellite receivers who want to install, use and maintain their receiver.
SER MANUAL EchoStar International Corporation has to the best of her abilities, everything done to supply you with the most up-to-date information. EchoStar International Corporation makes no warranties with respect to the information provided by this user manual and specifically disclaims any implied warranties of merchantability or fitness for any particular purpose.
TO USE THE ELECTRONIC PROGRAM GUIDE (EPG) TO SET THE USER PREFERENCES Maintenance HARDWARE MAINTENANCE SOFTWARE MAINTENANCE END OF LIFE DISPOSAL Troubleshooting GENERAL EPG RELATED TV AND RADIO RELATED REMOTE CONTROL UNIT (RCU) RELATED INSTALLATION RELATED Digital Satellite Receiver Preface 4-14 4-16 4-18 5-10 5-14 Page...
Page 6
Appendix 1 LNB CONFIGURATION MATRIX LNBF CONFIGURATION MATRIX USER DEFINED LNB(F) MATRIX Appendix 2 INTRODUCTION THE BATTERIES THE KEYS PROGRAM THE TV, VCR AND AUX KEY SPECIAL SETUP FUNCTIONS SPECIAL FUNCTIONS TROUBLESHOOTING EQUIPMENT CODES Page A1-1 A1-1 A1-1 EchoStar D-2400IP...
Only use an approved extension (convenience) lead suitable for the electrical power con- sumption of the installed equipment. Digital Satellite Receiver Safety Information Section 1 Page 1 - 1...
Member States relating to low voltage and electrical safety. The double insulation symbol. This symbol tells you that the receiver is electrically safe within the normal use of the receiver as stated in the safety chapter. Page 1 - 2 IF NOT AVOIDED COULD RESULT IN EchoStar D-2400IP...
ENVIRONMENTAL REMARK Dispose the packaging in an environmental safe manner. Please inform yourself on local regulations with respect to the disposal of reusable materials. Digital Satellite Receiver Preparation Section 2 HE PLASTIC PACKAGING MAY Page 2 - 1...
Please refer to the user manuals of your terrestrial antenna, dish, TV, video recorder and/or audio equipment to make sure this equipment is properly installed and configured before you install the receiver. EchoStar recommends that you follow at least the following instructions: 5.1. THE TERRESTRIAL ANTENNA 1. Make sure: The terrestrial antenna is in good condition and well aligned for the best reception (avoid corroded contacts);...
1. On the rear panel of the receiver find the SERIAL PORT connector. 2. Install a serial cable between the SERIAL PORT connector (receiver) and the serial port connection of the PC. Digital Satellite Receiver AKE SURE THAT IT IS SAFE TO PROCEED WITH THE INSTALLATION COAXIAL CABLES...
Section 3 CONNECT A DISH It is possible to connect the different dish configurations with the use of RF coaxial cables. Only the most common configurations are discussed. If in doubt, please ask the EchoStar service department for advice. WARNING...
Page 13
Failing to do so can cause damage to the equipment. 3. Install the polarotor power cable to the + 5V and GND connectors (receiver). 4. Install the polarotor skew cable to the SKEW connector (receiver). Digital Satellite Receiver LNB(F) OLAROTOR Installation...
The receiver display shows: - first a moving dot; - then it shows - - - - The TV shows the first page. EchoStar D-2400IP...
Page 15
RCU, press the OK key. 29. Go to the Search Channels field. 30. On the RCU, press the OK key to advance. Digital Satellite Receiver Installation SWITCH INSTALLATIONS Section 3...
Page 16
29. Repeat the procedure for the middle and Western Satellite. 30. Set the West limit ( key), refer to step 25. 31. Go to the Autosat field. 32. On the RCU, press the OK key to advance. Page 3 - 6 UTOSAT EchoStar D-2400IP...
Page 17
OK key. 27. Go to the Program Satellites field. 28. On the RCU, press the OK key to advance. Digital Satellite Receiver Installation ANUAL SELECTION Section 3 Page 3 - 7...
Page 18
25. Wait for the search to complete: a. the receiver display shows a moving dot; b. the search completed popup menu appears. 26. On the RCU, press the OK key to end the initial setup procedure. Page 3 - 8 EchoStar D-2400IP...
FAMILIARIZATION THE RECEIVER The digital satellite receiver has 2 Common Interface slots and an embedded Viaccess smart card reader. The front panel gives you the control over the basic functions. The rear panel gives you various connections to connect the audio and video equipment as well as a terrestrial and dish antenna.
Page 20
PC; The LNB IN connector (F-type), for the connection of a dish to the receiver, to receive the digital broadcasts; The IF OUT connector (F-type), for the connection of a loop through cable; EchoStar D-2400IP...
Page 21
1.3. THE REMOTE CONTROL UNIT (RCU) The EchoStar Quattro is a programmable RCU that also can control your TV, VCR, DVD and/or Audio set. The EchoStar Quattro requires two AA/R6 alkaline batteries to operate. ON/STANDBY To switch to standby or on.
MENU key to reverse from a menu page to the sub menu bar; you can easily leave with the EXIT key. Page 4 - 4 keys to scroll the selectable items. keys to navigate between the left and right column of selectable keys let you make a selection in the EchoStar D-2400IP...
Parental Lock page; button, that gives you access to the Local Time page; button, that gives you access to the TV System page. Digital Satellite Receiver Familiarization The main menus are divided in sub menus, selection pages and option fields.
Page 24
To lock the installation menu for unauthorized users. Channel lock To lock or unlock all locked selections at once. Master hide To hide or unhide all hidden selections at once. Change PIN Code To access the change PIN code page. EchoStar D-2400IP...
Page 25
EPG and the timers, it is necessary to set the local time correctly. You can customize: 2.1.5. TV SYSTEM PAGE This menu page allows you to customize the TV settings used for the receiver, you can customize: Digital Satellite Receiver Familiarization Old password To type in the factory default or personal PIN code.
Program Satellites page (for motorized dish); button, that gives you access to the User LNB Setting page; button, that gives you access to the About EchoStar information page; button, that gives you access to the System Upgrade page;...
Page 27
This sub menu allows you to customize the system setup to match your installation. Note that the menu page is dynamic which means that it changes with the selections you make. You can customize: Digital Satellite Receiver Familiarization System To set the dish type you use.
Page 28
The satellite offset will affect all satellite positions, this means that all scanned positions will change which might result in total loss of signal for all satellites. Search Channels To confirm the selections you made and advance to the Search Channels page. EchoStar D-2400IP...
Page 29
You can customize: 2.2.5. ABOUT ECHOSTAR The About EchoStar menu gives all the where-to-contact-Information about EchoStar and the status information about the receiver. You can view: Digital Satellite Receiver Familiarization User’s LNB...
Page 30
Section 4 2.2.6. SYSTEM UPGRADE PAGE This menu page allows you to upgrade the receiver’s software. EchoStar provides software updates Over-The-Air (OTA) which means that you can upgrade your system via the satellite. If you are not able to receive the satellite/transponder, you always can upgrade the software through the SERIAL PORT (RS232) at the rear of the receiver and the downloaded software from the EchoStar website.
Page 31
CI-module and related smart card. Note that this page can show differently for other CI-modules and related smart cards. EchoStar has no control over the information provided by the related service provider, therefor no specific information is given. Section 4...
Current Sat To access the list of all scanned TV channels available on the current selected satellite. Favorites To access to your own favorite lists. You can rename the favorites to something meaningful to yourself, e.g. Film, Sport, Kids. EchoStar D-2400IP...
Page 33
The Group options are available in the all modes. The Group option allows you to group the lists in different ways. The availability of the Group options is mode dependent, the available options are: Digital Satellite Receiver Familiarization None No edit option is selected.
EPG. Digital channels that transmit EPG offer you program information in advance for a certain period of time. Dependent of the service provider, EPG is offered in different ways. After you have entered the EPG, you can select the different EPG options, these are: EchoStar D-2400IP...
4.1. THE TIMERS Digital Satellite Receiver Familiarization The event timers are a kind of alarm clock. An event timer reminds you when a program or a timed VCR recording starts. You can set the next timers: VCR timer, to automatically switch over to the timed program before it really starts.
If the volume +/- key is pressed, the volume button is shown (see the radio InfoBanner). 5.2. THE RADIO INFOBANNER The radio InfoBanner shows the information related to the actual channel. The radio InfoBanner can show the same information as discussed with the TV InfoBanner. Page 4 - 18 EchoStar D-2400IP...
Page 37
5.3.1. ALT AUDIO 5.3.2. SUBTITLE 5.3.3. SATELLITE LIST Digital Satellite Receiver Familiarization If transmitted, you can set per channel your alternate audio. You can call up the pop-up menu with the alternative audio key on the remote control unit.
Normally, you only can view a scrambled channel with the applicable CI-module and/or smart card inserted in a CI-slot or Viaccess smart card reader. Digital Satellite Receiver keys to scroll the selectable items. keys to navigate between the left and right column of selectable...
Page 40
OK to accept the character; c. select the button to get lower case characters and numbers; d. select the button e. on the RCU, press the OK key to confirm. Page 5 - 2 EchoStar D-2400IP...
Page 41
7. On the RCU, press the OK key to confirm. 8. Either: a. press the WHITE key to end the session, or b. select the next channel you want to move. Digital Satellite Receiver Operation Section 5 Page 5 - 3...
Page 42
8. You can restore all the locks on the channels: a. On the RCU, press the MENU key; b. Select the Parental Lock menu; c. Enter the correct PIN-code as requested; d. Set the channel lock to On. Page 5 - 4 EchoStar D-2400IP...
Page 43
1. In the Edit menu, select the RENAME option. 2. Read the available help text for information. 3. Go to the channel you want to rename. 4. On the RCU, press the OK key. Digital Satellite Receiver keys to set the Operation Section 5...
Page 44
1. Make the hide function available for edit: a. On the RCU, press the MENU key; b. Select the Parental Lock menu c. Enter the correct PIN-code as requested; 2. Set the Master Hide to Off. Page 5 - 6 EchoStar D-2400IP...
The main difference is that you can setup and organize the favorite lists as required. EchoStar has already pre-named the favorite lists to help you getting started. It is however possible to change the name of the favorite list to something that is meaningful to you.
Page 46
10. On the RCU, press the OK key. Note a red bullet appears behind the selection and the cursor advances to the next item. 11. If you want to undo the selection, select again and press the OK key. Page 5 - 8 EchoStar D-2400IP...
Page 47
OK to accept the character; c. select the button to get lower case characters and numbers; d. select the button e. on the RCU, press the OK key to confirm. Digital Satellite Receiver Operation Section 5 Page 5 - 9...
The EPG information is not always available. Sometimes the service provider (who sends the EPG information) supplies only the program name, the now/next infor- mation or sometimes nothing at all. EchoStar has no influence on this matter. Make sure the local time is set otherwise you can not view EPG information because it needs the correct time (Refer to the Local Time menu).
Page 49
VCR also to the same time as on the receiver. Please refer to the user’s guide of your VCR how to record from a satellite receiver. On quite a lot of VCRs you have to select the so called external channel (E1) NOTE You cannot set a timer in the past or on a program that has already begun.
4. Delete the timer: a. use the key, to go to the Store Settings; b. read the available help text for information; c. press the OK key to confirm the deletion. Page 5 - 12 EchoStar D-2400IP...
1. On the RCU, press the 2. In the Satellites List pop-up menu, select the required satellite. 3. On the RCU, press the OK key. Note that the dish moves towards the selected satellite. Digital Satellite Receiver key. key. key. key. key.
3. Read the available help text for information. 4. Make the selections. 5. On the RCU: a. press the MENU key to save the settings; b. press the EXIT key to leave the menu. Page 5 - 14 menu; menu. menu; menu. menu; menu. EchoStar D-2400IP...
2. Press the OK key and make the selections. 3. Read the available help text for information. 4. On the RCU: a. press the MENU key to save the settings; b. press the EXIT key to leave the menu. Digital Satellite Receiver Operation menu; menu. menu;...
2. Press the OK key and make the selections. 3. Read the available help text for information. 4. Go to the Check Signal field. 5. On the RCU, press the OK key. Digital Satellite Receiver Maintenance IF USED CLEANING AGENTS CANNOT GET IN THE RECEIVER menu;...
OK key, to select the 2. In the About EchoStar information menu you can look up the factory and receiver information. 3. Read the available help text for information. Page 6 - 2 menu;...
NOTE EchoStar offers on a regular basis software updates via the satellite and the EchoStar website. If you have trouble to get a download with the latest software version, please ask your retail seller or dealer for assistance. 2.5. TO DO A FACTORY RESET...
Page 58
RCU, press the OK key to confirm. 5. On the RCU, use the numeric keys to enter the Position. 6. Select the Location. 7. On the RCU, press the white key. Page 6 - 4 menu; menu. EchoStar D-2400IP...
Select List = All Channels d. Select Group = None e. Select Sort = None f. Select Edit = Add TP 3. On the RCU, press the OK key. Digital Satellite Receiver Maintenance Section 6 Page 6 - 5...
Page 60
Select Group = None e. Select Sort = None f. Select Edit = Add PID 3. On the RCU, press the OK key. 4. Select the applicable transponder. 5. On the RCU, press the OK key. Page 6 - 6 EchoStar D-2400IP...
Specialized companies can recycle your equipment to increase the amount of reusable materials and to minimize the amount of materials to be disposed of. Please inform yourself on local regulations on disposal of your equipment. Digital Satellite Receiver Maintenance Section 6...
Problem 1. No picture or sound in the TV or radio mode. 2. Bad picture or noisy sound in the TV or radio mode. Digital Satellite Receiver Troubleshooting Possible cause What to do? Main power cable is damaged or not connected.
On the RCU, press the SAT key. Program the SAT mode with code 0222, see the appendix for instructions. Close the sun blinds or get closer to the receiver. Aim at the receiver display. install a RCU extender. Insert new batteries. EchoStar D-2400IP...
7. During (initial) setup of the receiver, no channels are found. Digital Satellite Receiver Troubleshooting Possible cause What to do? You did not select the correct audio/video channel on your TV.
A signal frequency range (11.70-12.40ghz) intended for direct TV broadcast by satellite channels. A unit that is connected to a satellite receiver in order to unscramble a picture that is protected by encryption. Standard which describes the method of transmitting digital audio.
Page 69
Receiver RS232 connection Satellite SCART cable Digital Satellite Receiver A LNB with an integrated Feedhorn. So the LNBF comes as one single unit. The Moving Picture Experts group is founded by the ISO to provide a basis for the coding and compression of moving pictures.
Equipment inside a satellite responsible for receiving a single uplinked channel and rebroadcasting it back to Earth. In the satellite industry, vertical is used to indicate the direction in which the received signal is polarized. Normally you will find that it is abbreviated as V. EchoStar D-2400IP...
In the User LNB setting menu, you can define your own LNB(F). You can use the list below to note the settings. User LNB(F) LO Frequency ..,..User ... 1 User ... 2 ..,..Digital Satellite Receiver LNB(F) Configuration matrix LO Selection 13/18V 9,750 13/18V 9,750 5,150...
For future use it is recommended that you make a note of the equipment codes and the serial number in the fields below: The RCU is already pre-programmed for the EchoStar receiver with code 0222. TV key: _ _ _ _...
Page 76
EchoStar Quattro, Programmable Remote Control Unit Appendix 2 i key If the function is available, this key activates the display/information function for TV, VCR and DVD equipment. Satellite list key This key is not used. Volume +/- keys This key is used to control the volume level for the selected equipment.
You can program the SAT mode keys to control a number of satellite receivers. The RCU is default programmed to control the EchoStar satellite receiver that came in the same box. NOTE Some codes are quite similar. If your device does not respond or does not function properly with one of the codes, try another code listed under your brand.
VCR, AUX) must be sacrificed in this case. It is not possible to sacrifice the SAT key. It is also possible to control another (up to 16) EchoStar receivers that use the equipment code 0222. This is done with use of the address feature in the SAT mode.
EchoStar Quattro, Programmable Remote Control Unit 5.1. SETUP A SECOND TV OR VCR NOTE The procedure to assign a second TV or VCR is identical, therefor only the procedure to assign the second TV is given. On the RCU, press the TV key continuously until the indicator stays on.
EchoStar Quattro, Programmable Remote Control Unit Appendix 2 6.3. REAL-TIME MACROS This feature allows you to program a macro on any key. With a macro you can assign a chain of key strokes to any key on the RCU, also on a mode key. The macros are recorded and played real-time, which means the actual time between key strokes will also be recorded.
EchoStar Quattro, Programmable Remote Control Unit 6.4.2. FULL FACTORY RESET On the RCU, press the SAT key continuously until the indicator stays on. Keep the SAT key pressed. Use the numerical keys to enter code 9 8 1 and note that the indicator blinks four times.
EchoStar Quattro, Programmable Remote Control Unit Appendix 2 EQUIPMENT CODES 8.1. ECHOSTAR SATELLITE RECEIVERS AD2000 IP 0453 AD3000 series 0222 D2500 IP 0511 DSB1100 1086 DSB2000 0853 DSB9800 0871 DVR-7000 series 0222 IR700 0312 LT7500 0465 LT80+ 0688 LT8700 0454...
Page 83
EchoStar Quattro, Programmable Remote Control Unit 8.2. ECHOSTAR KEY ASSIGNMENTS (CONTINUED) DSB2000 DSB9800 TONE- Radio guide select X- Favorite MUTE- MUTE- Volume Mute Volume Mute Channel up Cursor up Channel Cursor down DOWN IRD Volume up Cursor left Volume Cursor right down IRD ->EXIT- IRD...
Page 84
EchoStar Quattro, Programmable Remote Control Unit Appendix 2 8.2. ECHOSTAR KEY ASSIGNMENTS (CONTINUED) DSB2000 DSB9800 C- Function D- Function subtitling +- Add. Info, subtitling TV/SAT Select TV or D2500 I.P. AD2000 I.P. Power/Stby Power/Stby Select SAT Select SAT mode Select TV...
Page 85
EchoStar Quattro, Programmable Remote Control Unit D2500 I.P. AD2000 I.P. MUTE- MUTE- Volume Mute Volume Mute Channel up Channel up Channel Channel DOWN IRD DOWN IRD Volume up Volume up Volume Volume down IRD down IRD TV/DBS- Select TV or...
Page 86
EchoStar Quattro, Programmable Remote Control Unit Appendix 2 D2500 I.P. AD2000 I.P. Speaker ALT- Audio language UHF-Select TV or DBS Background 8.3. AMPLIFIERS Arcam 0641 Bush 0421 Cyrus 0683 Denon 0272 Goodmans 0421, 0847 0668, 1177 Kenwood 0772 Philips 0641 8.4.
