Sony VGN-FS540P VAIO Specifications

The perfect blend of premium display technologies and mobility.
Highly Mobile
Design
The VAIO ® FS Notebook
delivers full-size, full-feature
performance and extended
battery life 8 within an incred-
ibly slim, lightweight design.
Easy to carry with sleek,
modern styling, it projects a
professional, sophisticated
image when you're on the
road.
Model
VGN-FS540P
HARDWARE
Processor
Intel ® Pentium ® M Processor 730
(1.60GHz 1 , 2MB L2 Cache)
Front Side Bus Speed
533MHz
Chipset
Intel 915GM
®
Integrated Wireless LAN
Intel PRO/Wireless 2200BG
®
3
Network Connection(802.11b/g)
LCD
15.4" WXGA (1280x800) with
XBRITE™ technology
Hard Drive
2
80GB
4200rpm Ultra ATA
Memory
512MB PC-2700 333MHz DDR
(512MB x 1 - Expandable up to 1GB)
Graphics
Intel ® 915GM Integrated Graphics
128MB Dynamic Video Memory
(shared with main memory)
Graphics Interface
VGA out w/ Smart Display Sensor
DVD+R Double Layer / DVD±RW
4
Drive
Double Layer
+R
DVD+R Write (2.4x MAX)
4
DVD±RW
-RW
DVD-R Write (8x MAX); DVD-RW Write (4x MAX)
+RW
DVD+R Write (8x MAX); DVD+RW Write (4xMAX)
CD-RW
CD-R Write (24x MAX); CD-RW Write (10x MAX)
Modem
Integrated V.90 Modem with RJ-11
interface
Ethernet
10BASE-T/100BASE-TX Ethernet
with RJ-45 interface
Audio
Windows ® sound system compatible,
Built-in stereo speakers
Audio Interface
Monaural mini microphone jack,
Headphone jack
Digital Content Smart Display
Production Sensor
With Sony's original multi-
Take the guesswork out of set-
media software, you have ting up an additional display or
the power to easily create,
projector.
customize and distribute Display Sensor, your VAIO
impactful presentations, Notebook automatically adjusts
the video output for compatible
videos and training materi-
LCD displays and projectors.
als. Integrated DVD+R
You no longer have to worry
Double Layer/ DVD±RW
about fumbling with the resolu-
drive 4 , lets you record up to
tion or other settings when
8.5GB of your digital con-
you're about to give a big pres-
tent - up to 4 hours of
entation.
MPEG-2 video - on one
Double Layer DVD disc.
Optional Port Replicator
Interfaces
5
Two USB 2.0 ports, Monitor (VGA)
port, Printer port, DC in, RJ-45
Ethernet
Memory Stick Media Slot
®
Supports optional Memory Stick,
Memory Stick PRO™ and Memory
6
Stick DUO™ media
PC Card Slots
One PCMCIA - Type II/Type I card slot
with CardBus support
Other Interfaces
® 7 5
i.LINK connector(IEEE 1394) , 3 USB
2.0 ports, port replicator connector
Pointing Device
Electro-Static touch pad
Keyboard
QWERTY, 86 keys with 2.5mm stroke
and 19.05mm pitch
Action Buttons
S1, S2 (programmable), Wireless
LAN on/off
Power Requirements
110W + 10%
Battery
Standard Lithium-ion Battery
(VGP-BPS2A)
Estimated Battery Life
8
Standard Battery: 2.5 - 5.5 hours
Optional Floppy Drive
External 1.44 MB, 3.5" USB floppy
drive (VGP-UFD1)
Weight
6.28 lbs. with standard battery
(weight is approximate and may vary)
Size (W x H x D)
14.33" x 1"-1.41" x 10.41"
Supplied Accessories
Standard Lithium-ion battery (PCGA-
BPS2A), Power cord & AC adapter
(VGP-AC19V11)
Optional Accessories
Additional Standard Capacity Battery
(VGP-BPS2)
Large Capacity Battery (VGP-BPL2)
AC Adapter (VGP-AC19V10)
Port Replicator (VGP-PRFS1)
Visual Communication Camera
(PCGA-UVC11A)
Wireless optical mouse
(PCGA-WMS5/S)
USB Mobile Mouse- Black/Silver
(PCGA-UMS3/B/S)
Featuring One Year Onsite Service
and 24/7 Telephone Support
Superior Display
Technology
The VAIO
comes with a 15.4" wide-
screen
With Sony's Smart
XBRITE™ LCD technology.
® FS
It provides brilliant colors and
sharp contrasts to help you
deliver high-quality, profes-
sional presentations.
filter and anti-reflective coat-
ing minimize reflections, so
you're assured an exception-
ally clear image from any
viewing angle.
Wireless Keyboard and Mouse
(VGP-WKB1)
Memory Card Adapter
9
(VGP-MCA10)
512MB memory expansion module
(VGP-MM512G)
Universal Carrying Case
(VGP-AMB1)
Notebook Backpack
(PCGA-CCP3 Series)
Sport Backpack (VGP-AMB2)
Neoprene Notebook & AC Adapter
(VGP-AMC3)
Cleaning Kit (PCGA-CG10)
60GB External Hard Drive
(PCGA-HDM06)
2
External Floppy Disk Drive
(VGP-UFD1)
SOFTWARE
Operating System
Microsoft ® Windows ® XP
Professional with Service Pack 2
Sony Original Software
VAIO Zone™ with WinDVD™
Click to DVD™ - DVD Creation
DVGate Plus™ - Digital Video
SonicStage 2.1 - Digital Music
®
PictureGear Studio™ - Digital Photo
VAIO Media™ - Network File Sharing
VAIO ® FS Series Software Bundle
Intuit Quicken ® 2005 New User
Edition
(previous Quicken users may
require additional upgrade)
InterVideo ® WinDVD ®
Microsoft ® Works 8.0 -
Word
Processing, Spreadsheet, Calendar,
Scheduling, Contact Management, and
Database
Microsoft ® Office ® 2003 60-Day
Trial (Office/Small Business Edition)
Sonic RecordNow! ® 7
Anti-Virus & Recovery Software
Norton ® Internet Security™ 90-Day
Subscription -
Norton AntiVirus ® ,
Norton Personal Firewall, Norton
Privacy Control, Norton AntiSpam ® ,
Norton Parental Control
Intermute™ SpySubtract™ 30-Day
Trial
VAIO ® Update software
VAIO ® Recovery Wizard software
VAIO ® Help and Support software
VGN-FS540P
Sony
The VAIO
® FS Notebook
delivers powerful perform-
display with
ance
day essential computing
needs and growing multi-
media entertainment de-
mands. Easily manage,
Glare
and enjoy your digital pho-
tos, home videos, and
music on-the-go. Slim and
lightweight, it's your ideal
mobile companion.
Internet Services Computer Interface: The computer industry lacks stan-
dards, and therefore, there are a multitude of varying
AOL Online™ 90-Day Trial - New
software packages and add-on hardware options. This
Users Only
personal computer is not manufactured to operate any
specific software, and Sony does not and cannot make
any warranty or representation with respect to the per-
SERVICE AND WARRANTY
formance of this product with any particular software
INFORMATION
packages and/or non-Sony add-on hardware options
except those mentioned in this document. Sony hereby
Limited Warranty
disclaims any representations or warranty that this prod-
1 Year Limited Warranty with Onsite
uct is compatible with any combination of products you
10
Service
may choose to connect. While Sony representatives or
Telephone Support Sony authorized dealers may be able to assist you and
may make recommendations, they are NOT authorized to
1 year toll-free technical telephone
vary or waive this disclaimer. Purchasers must deter-
11
assistance, available 24/7 .
mine for themselves the suitability and compatibility of
On-line and Email Support
the hardware and software in each and every particular
Support available from
instance. Software titles pre-installed on the Sony
http://www.sony.com/pcsupport
Notebook Computer are subject to change without
notice. Simulated graphic shown on display.
Preinstalled software may not be identical to retail ver-
1. GHz denotes microprocessor internal clock speed;
sions or have all documentation. This product meets the
other factors may affect application performance. CPU
standards of the International Energy Star Program for
speed will be reduced under certain operating conditions.
energy efficiency. Features and specifications are sub-
2. GB means one billion bytes when referring to hard
ject to change without notice. Non-metric weights and
drive capacity. Accessible capacity may vary. A portion of
measurements are approximate.
hard disk space is reserved as a recovery partition.
3. Requires compatible wireless LAN access point, sold
©2005 Sony Electronics Inc. All rights reserved.
separately. Internet connection may require fees.
Reproduction in whole or in part without written permis-
4. DVD Media/Formats are not universally compatible.
sion is prohibited. Sony, i.LINK, Memory Stick,
5. Not all products with USB connectors may communi-
SonicStage, Giga Pocket, VAIO, VAIO Zone, XBRITE,
cate with each other due to chipset variations. ErgoBright, Memory Stick PRO, Memory Stick PRO Duo,
MagicGate, Click to DVD, S-Master, DVgate Plus, VAIO
6. Supports Memory Stick PRO™ high-capacity media test-
Media, PictureGear Studio and Like No Other are trade-
ed up to 1GB. Does not support MagicGate™ functionality.
marks of Sony. Intel and Pentium are registered trade-
7. i.LINK is a trademark of Sony used only to designate
marks, and Centrino is a trademark of Intel Corporation.
that a product contains an IEEE 1394 connector. All
Microsoft and Windows are registered trademarks of
products with an i.LINK connector may not communicate
Microsoft Corporation. All other trademarks are trade-
with each other.
marks of their respective owners.
8. Estimated battery life. Actual battery life may vary on
usage.
Printed in U.S.A. 1/05.
9. Does not support MemoryStick media and Memory
Stick PRO™ media using the MagicGate function or high-
speed data transfer. Supports memory cards with capaci-
ties up to 1GB. Does not support 5.0V SmartMedia media
or the ID function of SmartMedia media with IDs. Does
not support the SD Memory Card media copyright protec-
tion function.
10. When available, Sony will provide Onsite Service in
fulfillment of its limited warranty obligations. Any such
services are subject to the terms and conditions of the
limited warranty. See actual Limited Warranty for details.
Onsite Service will be provided via third-party technician
to be dispatched as needed following phone-based trou-
bleshooting. Some repairs may be accomplished with self
repair kits. Onsite Service may not be available in all loca-
tions.
11. For certain third party software applications, Sony
provides first level Phone Support. Additional telephone
support may be available from the applicable 3rd party
vendor. Availability and schedule for any such support is
determined by the applicable software vendor.
