Introduction Package Contents • Touch Display • Power cord • Power adapter • HDMI cable • USB 2.0 upstream cable (Type B to Type A) • Quick start guide NOTE: The power cord and video cables included in your package may vary depending on your country.
Product Overview Front View ▲ Power Button Display Screen Rear View RS232 HDMI DC IN DisplayPort HDMI 6. USB Upstream RS-232 Audio Out For more information about the 1/2/ // key and its functions, refer to “Hot ▲ ▼ Keys” on page 20.
Refer to the table below for the standard dimensions for wall mount kits. NOTE: For use only with a UL certified wall mount kit/bracket. To obtain a wall- mounting kit or height adjustment base, contact ViewSonic® or your local dealer.
Making Connections This section guides you on how to connect the monitor with other equipment. Connecting to Power 1. Connect the power cord to the power adapter. 2. Connect the power adapter to the DC IN jack at the rear of the monitor. 3.
Connecting External Devices DisplayPort Connection Connect one end of a DisplayPort cable to the DisplayPort port. Then connect the other end of the cable to the DisplayPort or mini DP port of your computer. NOTE: To connect the monitor to the Thunderbolt port (v. 1&2) on your Mac, connect the mini DP end of the “mini DP to DisplayPort cable”...
HDMI Connection Connect one end of an HDMI cable to the HDMI port of your monitor. Then connect the other end of the cable to the HDMI port of your computer. NOTE: The monitor is equipped with one HDMI port. HDMI HDMI...
RS-232 Connection Connect one end of a RS-232 cable to the RS-232 port. Then connect the other end of the cable to the RS-232 port of your computer. RS232 RS232...
USB Connection Connect one end of a USB cable to a USB port of the monitor. Then connect the other end of the cable to a USB port of your computer. NOTE: The monitor supports one (1) type of USB ports. When making the connection(s), observe the following guidelines: •...
Touch Function Control Before using the touch function, ensure the USB Type B to Type A cable is connected to your computer and the Windows operating system is running. When using the touch function, please note: • The touch function may need about five (5) seconds to resume if the USB cable is removed and plugged in again, or the computer resumes from Sleep Mode.
Audio Connection Plug an audio cable into the Audio Out port of the monitor. Plug the other end into your ear-/headphones. NOTE: The monitor is also equipped with dual speakers.
Using the Monitor Adjusting the Viewing Angle When mounted, the display can be adjusted as below: Landscape Portrait Face-up NOTE: Do not mount the display upside down.
Turning the Device On/Off 1. Plug the power cord into a power outlet. 2. Press the Power key to turn on the monitor. 3. To turn the monitor off, press the Power key again. NOTE: The monitor will still consume some power as long as the power cord is connected to the power outlet.
Select one of the preset color settings. Color Adjust Displays the timing mode coming from the graphics card in the computer, the LCD model Information number, the serial number, and the ViewSonic® website URL. Manually set a variety of image quality Manual Image Adjust adjustments.
Hot Keys When the On-Screen Display (OSD) Menu is off, you can quickly access special functions by using the control panel keys. Description Press and hold the keys to lock/unlock the OSD Menu. When the menu appears on the screen, continue holding both keys for 10 seconds to lock/unlock the OSD Menu.
Page 21
Description Press the keys to toggle between DDC/CI and DDC/2B NOTE: DDC/CI is the default setting. Press the key to enter the Contrast menu. Press the key to enter the Color Adjust menu. Press the key to toggle between input sources.
Configuring the Settings General Operations 1. Press the 1 key to display the On-Screen Display (OSD) Menu. A S T / B R I G H T N E S S L E C T J U S T J U S T R M A I O N N U A L...
Page 23
3. Press the or key to select the desired menu option. Then press the 2 key to enter the sub-menu. M A N U A L I M A G E A D J U S T E C O M O D E S T A N D A R D O P T I M I Z E C O N S E R V E...
On-Screen Display (OSD) Menu Tree Main Menu Sub-menu Menu Option Contrast/Brightness Contrast (-/+, 0~100) Brightness (-/+, 0~100) Input Select HDMI DisplayPort Audio Adjust Volume (-/+, 0~100) Mute HDMI Audio Input DisplayPort Color Adjust sRGB Bluish Cool Native Warm (-/+, 0~100) User Color Green (-/+, 0~100)
Page 25
Main Menu Sub-menu Menu Option Manual Image Adjust Standard ECO Mode Optimize Conserve Blue Light Filter (-/+, 0~100) Setup Menu Language Select English Français Deutsch Español Italiano Suomi Русский Türkçe 日本語 한국어 繁體中文 简体中文 Česká Svenska Resolution Notice H. Position (-/+, 0~100) OSD Position V.
Page 26
Main Menu Sub-menu Menu Option Setup Menu 0° OSD Pivot +90° -90° OSD Timeout (-/+, 5/15/30/60) Background Auto Power Off Sleep 30 Minutes 45 Minutes 60 Minutes 120 Minutes Power Indicator Boot Up Screen Monitor ID (-/+, 1~98) Date/Time Real Time Clock¹...
Appendix Specifications Item Category Specifications Type a-si, TFT Active Matrix 1920 x 1080 LCD, 0.3637 mm x 0.3637 mm pixel pitch Display Size 80 cm, 31.5” (31.5” viewable) Surface Treatment Glossy treatment (Haze 2%, 7H) Input Signal Video Sync TMDS / Micro-packet HDMI: f :15-73 Khz, f :47-75 Hz...
Page 28
Item Category Specifications Resolution Supported • 1920 x 1080 @ 50, 60, 75Hz ¹ • 1680 x 1050 @ 60Hz • 1600 x 1200 @ 60Hz • 1600 x 900 @ 60Hz • 1440 x 900 @ 60, 75Hz • 1400 x 1050 @ 60Hz •...
Page 29
< 0.3W ¹ Do not set the graphics card in your computer to exceed these timing modes; doing so may result in permanent damage to the display. ² Please use the power adapter from ViewSonic® or an authorized source only.
This function, on some models, is disabled by default. Black Stabilization ViewSonic’s Black Stabilization provides heightened visibility and detail by brightening dark scenes. Blue Light Filter Adjusts the filter that blocks high-energy blue light for a more comfortable viewing experience.
Page 31
Color Adjust Provides several color adjustment modes to help adjust the color settings to fit the user’s needs. Color Format The monitor can detect the input signal color range automatically. You can manually change the color range options to fit the correct color range if the colors are not displayed correctly.
Page 32
Displays the timing mode (video signal input) coming from the graphics card in the computer, the LCD model number, the serial number, and the ViewSonic® website URL. See your graphics cards’s user guide for instructions on changing the resolution and refresh rate (vertical frequency).
Page 33
Sharpness Adjusts the picture quality of the monitor. ViewMode ViewSonic’s unique ViewMode feature offers “Game”, “Movie”, “Web”, “Text”, “MAC”, and “Mono” presets. These presets are specifically designed to deliver an optimized viewing experience for different screen applications.
Page 34
YUV Color Space YUV color space is used for color image and video processing; taking into account properties of the human eye that allow for reduced bandwidth of chroma components without perceptual distortion.
• Connect the monitor to another computer. • If you have an older graphics card, contact ViewSonic® for a non-DDC adapter. Screen image is too • Adjust brightness and contrast settings via the OSD light or dark Menu.
Page 36
Problem or Issue Possible Solutions The screen appears • Make sure the “Blue Light Filter” is Off. yellow The OSD Menu • Check whether the OSD Menu is locked. If yes, press and hold the 2 and 3 key for 10 seconds. does not appear on the screen/the •...
• ViewSonic® does not recommend the use of any ammonia or alcohol-based cleaners on the display screen or case. Some chemical cleaners have been reported to damage the screen and/or case of the monitor. • ViewSonic® will not be liable for damage resulting from use of any ammonia or alcohol-based cleaners.
