6-2. Model: AOHG36KMTA

NOTE: Values mentioned in the table are calculated based on the maximum capacity.
COOLING
Indoor unit is higher
than outdoor unit *1
Indoor unit is lower than
outdoor unit *2
HEATING
Indoor unit is higher
than outdoor unit *1
Indoor unit is lower than
outdoor unit *2
6-2. Model: AOHG36KMTA
5 7.5
30 — —
20 — —
10 — —
7.5 — 0.988
5 0.992 0.992
0 1.000 1.000
-5 1.000 1.000
-7.5 — 1.000
-10 — —
-20 — —
-30 — —
5 7.5
30 — —
20 — —
10 — —
7.5 — 1.000
5 1.000 1.000
0 1.000 1.000
-5 0.995 0.995
-7.5 — 0.993
-10 — —
-20 — —
-30 — —
- 44 -
Pipe length (m)
10 20 30
— — 0.902
— 0.938 0.917
0.973 0.953 0.933
0.977 0.957 0.936
0.981 0.961 0.940
0.989 0.968 0.947
0.989 0.968 0.947
0.989 0.968 0.947
0.989 0.968 0.947
— 0.968 0.947
— — 0.947
Pipe length (m)
10 20 30
— — 0.978
— 0.988 0.978
0.998 0.988 0.978
0.998 0.988 0.978
0.998 0.988 0.978
0.998 0.988 0.978
0.993 0.983 0.973
0.991 0.981 0.971
0.988 0.978 0.968
— 0.968 0.958
— — 0.949
6. Capacity compensation rate for pipe length and height difference
40 50
0.882 0.862
0.897 0.876
0.912 0.891
0.916 0.895
0.919 0.898
0.926 0.905
0.926 0.905
0.926 0.905
0.926 0.905
0.926 0.905
0.926 0.905
40 50
0.968 0.958
0.968 0.958
0.968 0.958
0.968 0.958
0.968 0.958
0.968 0.958
0.963 0.953
0.961 0.951
0.958 0.948
0.949 0.939
0.939 0.929
