DA-E550 Wireless Audio with Dock user manual imagine the possibilities Thank you for purchasing this Samsung product. To receive more a complete service, please register your product at www.samsung.com/register...
Page 2
Dual Docking Audio Speaker System Using the system's dual docking station, dock, charge, and then play either Samsung Galaxy devices or Apple devices through the system's built-in speakers. ® aptX aptX enables high quality Bluetooth stereo audio, delivering wired audio quality wirelessly.
safety information safety Warnings TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER(OR BACK). NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates “dangerous voltage” inside the product that presents a risk of CAUTION electric shock or personal injury.
PrecaUtiOns 2.7 inch 68.6mm 99.1mm 3.9 inch 99.1mm 99.1mm 3.9 inch 3.9 inch Ensure that the AC power supply in your house complies with the power requirements listed on the identification sticker located on the back of your product. Install your product horizontally, on a suitable base (furniture), with enough space around it for ventilation (70~100 mm).
Using Rubber Connecting a device to the Dual Dock Connecting an audio device using AUX IN Connecting to Bluetooth devices plAying Using the docking mode with Samsung Galaxy and Apple Devices Using the Bluetooth mode functionS Advanced functions troubleShooting...
descriptions frOnt/rear PaneL <frOnt> DC 12V 2A AUX IN <rear> ONLY FOR SERVICE DC 12V 2A AUX IN ONLY FOR SERVICE DC 12V 2A AUX IN ONLY FOR SERVICE DC 12V 2A AUX IN ONLY FOR SERVICE...
Page 8
Controls the volume level. VOLUMe -/+ PLay/PaUse Play or pause a music file. Provides a 5 pin dock for Samsung Galaxy devices and a 30 pin dock DUaL DOcK for Apple devices. The standby LED lights up in standby mode.
remote control tOUr Of tHe reMOte cOntrOL power button function button FUNCTION Turns the unit on and off. Selects the Function mode. plAy/pAuSe button Play or pause a music file. control button MUTE Search for the next or previous music file. mute button Mutes the sound from this unit.
power on and volume control tUrning tHe POWer On/Off FUNCTION FUNCTION MUTE BASS MUTE BASS 1. To turn on this unit, touch any button on the unit's front panel when the unit is in Standby mode. Press power on the remote control. 2.
Using rUBBer Attach the Rubber to avoid direct contact with this set when you hold Samsung Galaxy Device and Apple Device. rubber-Support 1. Attach the Rubber to the proper place considering the size of the device which you want to use.
1. The DuAl DocK is located on the front of the product. To open, push it in gently. 2. If you have a Samsung Galaxy device, connect the device to the 5 pin (smaller) connector to connect to the Dual Dock.
Connect AUX IN (Audio) on the back of the unit to the earphone jack of the external device or audio device. if connected to an external device via AuX input while your Samsung galaxy device is docked or connected to a bluetooth device at the same time, the input source switches between the AuX and Samsung galaxy or bluetooth device by tapping the pAuSe button on the Samsung galaxy / bluetooth device.
Page 14
BLUetOOtH You can connect the Wireless Audio with Dock to Bluetooth devices and enjoy music with high quality stereo sound, all without wires! what is bluetooth? Bluetooth technology lets Bluetooth-compliant devices interconnect easily with each other using a short wireless connection. •...
3. Select "[Samsung]w_Audio XXXXXX" from the searched list. • If the Bluetooth device fails to pair with the Wireless Audio with Dock, delete the "[Samsung]W_Audio XXXXXX" found by the Bluetooth device, and search for the Wireless Audio with Dock again, and then repeat Steps 1, 2, and 3.
▪ When you connect other device to the Wireless Audio with Dock after connecting Samsung Galaxy device in docking mode, you may have to turn off the Bluetooth mode of the Samsung Galaxy device. ▪ If you have trouble connecting the Samsung Galaxy device to the Dual Dock, turn off the devices's Bluetooth mode.
compatibility list (Apple Device) Docking mode compatible iPod/iPhone models Update the software of your iPod/iPhone to the latest version before using it with this unit. iPod touch (4th generation) iPod touch (3rd generation) iPod nano (6th generation) iPod nano (5th generation) iPhone 4S iPhone 4 iPhone 3GS...
functions aDVanceD fUnctiOns play/pause POWER FUNCTION FUNCTION During playback, press the +# button. MUTE • Press the +# button to stop playing the file temporarily. MUTE BASS Press the +# button again to play the selected file. BASS ▪ This function does not operate in AUX mode. using function FUNCTION FUNCTION...
troubleshooting Before requesting service, please check the following. symptom check remedy the unit will not turn on. • Is the power cord plugged • Connect the power plug to into the outlet? the outlet. a function does not work when •...
Society) guidelines. * Nominal specification - Samsung Electronics Co., Ltd reserves the right to change the specifications without notice. - Weight and dimensions are approximate. - For the power supply and Power Consumption, refer to the label attached to the product.
Page 21
WOrLD WiDe If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Area Contact Centre Web Site ` Asia Pacific AUSTRALIA 1300 362 603 www.samsung.com NEW ZEALAND 0800 SAMSUNG (0800 726 786) www.samsung.com...
Page 22
DA-E550 Wireless Audio with Dock (Wireless Audio com Dock) manual do usuário imagine as possibilidades Obrigado por adquirir este produto Samsung. Para receber atendimento mais completo, registre seu produto no site www.samsung.com/register...
Page 23
Sistema de alto-falantes Dual Docking Audio Use a estação de dock duplo do sistema para conectar, carregar e reproduzir dispositivos Samsung Galaxy ou Apple, através dos alto-falantes embutidos do sistema. ® aptX O aptX permite um áudio estéreo Bluetooth de alta qualidade fornecendo a qualidade de áudio com fio através de uma conexão sem fio.
Page 24
informações de segurança aViSOS De SeGURança PARA REDUZIR O RISCO DE CHOQUE ELÉTRICO, NÃO RETIRE A TAMPA (NEM A PARTE TRASEIRA). NÃO HÁ PEÇAS QUE POSSAM SER REPARADAS PELO USUÁRIO NO INTERIOR DO APARELHO. CONSULTE A ASSISTÊNCIA TÉCNICA QUALIFICADA PARA OBTER MANUTENÇÃO. Este símbolo indica que há...
Page 25
PRecaUçÕeS 2.7 inch 68,6mm 99,1mm 3.9 inch 99,1mm 99,1mm 3.9 inch 3.9 inch Certifique-se de que a energia CA de sua residência esteja de acordo com os requisitos do produto na etiqueta lateral. Instale o produto horizontalmente, em uma base apropriada (mobília estável), com espaço suficiente ao redor para ventilação (70~100mm). Certifique-se de que os slots de ventilação não estão cobertos.
Page 26
Conectando um dispositivo ao dock duplo Conectando um dispositivo de áudio usando AUX IN (ENTRADA AUXILIAR) Estabelecendo uma conexão com dispositivos Bluetooth rePrODUZiNDO Usando o modo Docking com dispositivos Samsung Galaxy e Apple Usando o modo Bluetooth FUNÇÕeS Funções avançadas SOLUCiONANDO PrOBLeMAS Solucionando problemas APÊNDiCe...
Page 28
descrições PaineL FROnTaL/TRaSeiRO <FROnTaL> <TRaSeiRO> DC 12V 2A AUX IN ONLY FOR SERVICE DC 12V 2A AUX IN ONLY FOR SERVICE DC 12V 2A AUX IN ONLY FOR SERVICE DC 12V 2A AUX IN ONLY FOR SERVICE...
Page 29
VOLUme -/+ PLaY/PaUSe Reproduz ou pausa o arquivo de música. Oferece um dock de 5 pinos para dispositivos Samsung Galaxy e DOcK DUPLO outro de 30 pinos para dispositivos Apple. O LED de standby se acende no modo de standby.
Page 30
controle remoto TOUR PeLO cOnTROLe RemOTO BOtÃO POWer BOtÃO De FUNÇÃO FUNCTION (LiGA/DeSLiGA) Seleciona o modo de função. Liga e desliga a unidade. BOtÃO PArA rePrODUZir/PAUSAr Reproduz ou pausa o arquivo de música. BOtÃO De CONtrOLe MUTE Passar ao arquivo de música anterior ou seguinte.
Page 31
ligar e controlar o volume LiGANDO/DeSLiGANDO A UNiDADe FUNCTION FUNCTION MUTE BASS MUTE BASS 1. Para ligar a unidade, toque em qualquer botão do painel frontal da unidade quando ela estiver no modo Standby (Espera). Pressione POWer (Liga/Desliga) no controle remoto. 2.
Page 32
USanDO BORRacHa Afixe a borracha para impedir o contato direto do aparelho com o dispositivo Samsung Galaxy ou Apple. SUPOrte eMBOrrACHADO 1. Afixe a borracha no local adequado, levando em conta o tamanho do dispositivo que quer usar. 2. Depois de afixar o suporte emborrachado, coloque o dispositivo no dock duplo.
Page 33
1. O DOCK DUPLO se localiza na parte frontal do produto. Para abri-lo, empurre com cuidado. 2. Se você tiver um dispositivo Samsung Galaxy, conecte o dispositivo ao conector de 5 pinos (menor) para conectar ao Dual Dock. Se você tiver um dispositivo Apple, encaixe-o ao conector de 30 pinos (maior) no dock...
Page 34
Conecte o soquete de fones de ouvido do dispositivo externo ou do dispositivo de áudio em AUX IN (Áudio) na parte traseira da unidade. Se for ligada a um dispositivo externo através de uma entrada AUX, enquanto o dispositivo Samsung Galaxy estiver ancorado ou ligado a um dispositivo Bluetooth, pode alternar a origem de entrada entre a AUX e o dispositivo Samsung Galaxy/Bluetooth, tocando no botão de pausa do dispositivo Samsung...
Page 35
BLUeTOOTH Você pode conectar o Wireless Audio com Dock a um dispositivo Bluetooth e curtir sua música com som estéreo de alta qualidade e sem nenhum fio! O que é Bluetooth? A tecnologia Bluetooth permite a interconexão fácil de dispositivos compatíveis, usando uma conexão curta sem fio.
Page 36
• Se o dispositivo Bluetooth falhar no emparelhamento com o Wireless Audio com Dock, exclua o item "[Samsung]W_Audio XXXXXX" encontrado pelo dispositivo Bluetooth, faça com que ele procure o Wireless Audio com Dock novamente e repita as Etapas 1, 2 e 3.
Page 37
Samsung Galaxy no modo de docking, possivelmente será preciso desativar o modo Bluetooth no dispositivo Samsung Galaxy. ▪ Se tiver problemas ao conectar o dispositivo Samsung Galaxy ao Dock Duplo, desative o modo Bluetooth de todos os outros dispositivos. <Dispositivo Apple>...
Page 38
▪ Ao reproduzir um vídeo em seu dispositivo, as operações Play/Pause/Next/Back podem não estar disponíveis. Use o botão em seu dispositivo para operá-lo. Lista de compatibilidade (Dispositivo Apple) Modelos de iPod/iPhone compatíveis com o modo Docking Atualize o software de seu iPod/iPhone para a versão mais recente antes de usá-lo com esta unidade. iPod touch (4ª...
Page 39
funções FUnçÕeS aVançaDaS reproduzir / Pausa POWER FUNCTION FUNCTION Durante a reprodução, pressione o botão +#. MUTE • Para interromper temporariamente a execução do arquivo, pressione o MUTE BASS botão +#. Pressione o botão +# novamente para reproduzir o arquivo selecionado. BASS ▪...
Page 40
solucionando problemas Antes de solicitar manutenção, verifique o seguinte. Sintoma marque Solução a unidade não liga. • O cabo de alimentação está • Conecte o plugue de conectado à tomada? alimentação à tomada. Uma função não é aplicada • O Wireless Audio com Dock •...
Page 41
AES (Audio Engineering Society). * Especificação nominal - A Samsung Electronics Co., Ltd reserva-se o direito, sem aviso prévio, de fazer alterações nas especificações. - O peso e as dimensões são aproximados. - Para a fonte de alimentação e consumo de energia, consulte o rótulo anexado ao produto.
Page 42
SamSUnG nO mUnDO TODO Se tiver dúvidas ou comentários relacionados aos produtos Samsung, entre em contato com a Central de atendimento ao cliente SAMSUNG. Área Central de contato Site da Web ` Asia Pacific...
