Quick Start Guide
Easy steps to getting started
Unpack Contents
Unpack your digitizer package and check for
major components.
1. Medi-6000 Plus
2. Output Basket
3. Feed Tray
4. Output Guide
5. Power Cord
6. Software CD
7. Hi-Speed USB Cable
Install Software
Important: You must install software before connecting
your digitizer. Always close any open programs and turn
off Anti-virus utilities before installing software.
A. Turn on your computer.
B. Place the Microtek CD-ROM into the CD-ROM drive, and follow the on-screen
instructions to install the driver and software.
C. Restart your computer at the end of installation.
NOTE: If the Software Installer screen does not come up automatically, double-click the following
in succession: "My Computer"; the CD-ROM icon; then cdsetup.exe to start the installer program.
Copyright © 2019 Microtek International, Inc.
I49-004790 C, September 2019
1
5
1
2
4
3
6
7
Advertisement
Related Manuals for Microtek Medi-6000 Plus
Summary of Contents for Microtek Medi-6000 Plus
- Page 1 Anti-virus utilities before installing software. A. Turn on your computer. B. Place the Microtek CD-ROM into the CD-ROM drive, and follow the on-screen instructions to install the driver and software. C. Restart your computer at the end of installation.
- Page 2 Install Digitizer Feed Tray Install Feed Tray A. Look for two sets of the Feed Tray Feed Tray Holes Holes at both ends of the front-top of the digitizer. B. Insert and push down both sides of the Feed Tray into its compartment holes, making sure the Feed Tray snaps into place.
- Page 3 Connect Digitizer To the power cord A. Connect the power cord to the left side of the digitizer. B. Plug one end of the power cord into a wall outlet or other power source. To the Hi-Speed USB cable C. Connect one end of the Hi-Speed USB cable to your computer. D.
-
Page 4: Scanning Basics
Scanning Basics Warning: Do not place more than one piece of X-ray film into the Feed Tray, for doing so will damage the original film during the feeding process. 1. Launch ScanWizard Medi To launch ScanWizard Medi as a stand-alone program, double-click the ScanWizard Medi icon on your desktop. - Page 5 Fixing Film Jams 1. Open the front cover by pressing the Release buttons on the both sides of the front cover. Release button 2. After opening the front cover, let the jammed film fall into the Output Basket Front cover and then remove it from the Output Basket.
- Page 6 Scanning lamp or image sensor circuit failure. Please don't select fast preview or draft scan!” This error message appears when the luminance of lamps is insufficient or surpassed. Click OK first; then contact the professional technician or call the Microtek Customer Service Department for the further help.
- Page 7 1. Using your Medi-6000 Plus 2. Using the ScanWizard Medi scanning software To access the electronic manuals: Insert the Medi-6000 Plus CD-ROM into your computer’s CD-ROM drive. Next, locate and click the “Manuals” option when the software installer window appears on your screen. Finally, select and click the title of the manual you wish to view.
