Safety inStructionS Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
Page 3
• Do not clean any parts in a dishwasher. • Do not use a wet cloth of thinner, benzene or other volatile substance to clean the unit. • Do not immerse the motor housing, cable or charger in water or any other liquid. •...
Page 6
foLDaBLe HanDLe To lower the handle, press the folding Lift the handle to an upright position, handle release button. the handle will lock automatically. Press DetacHaBLe fLoor BruSH Floor Brush Motorized Brush LED Power Indicator aSSeMBLinG tHe cHarGer BaSe Storage area for screws and anchors Wall mounting: (Located on the back...
Page 7
inStruction for uSe Before using your vacuum cleaner for the first time, allow the battery to charge for 14-16 hours. cHarGinG Charge the battery for 14 - 16 hours when: • Using the product for the first time • After not using the product for a long period of time Make sure the vacuum cleaner switched off.
Page 8
3. connect tHe PoWer caBLe to tHe Main Socket The charging indicator will illuminate blue to indicate that the vacuum cleaner is being charging. HINT: It is recommended to charge the vacuum cleaner for at least 14-16 hours before use. It is normal that the charger base and the unit will get warm while charging.
Maintenance / cLeaninG • Always switch off the vacuum cleaner before cleaning. • Empty the container after use every time. 1. Detach the dust container 4. Clean the filters by brush (not included) Press the button at its bottom 2. Pull out the filters 5.
floor Brush Carry out the maintenance if any waste threads or hair gets tangled in the brush. Take out the brush cover to detach the floor brush from the upright unit. regular Maintenance Slowly rotate the brush manually and remove any foreign objects tangled around the brush.
SPecification Power Source : Re-chargeable battery Power consumption for charging battery : Input: AC 200V - 240V ~ 50Hz/60Hz Output: DC. 25V 200mA Operating Voltage : 14.4V Type of battery used : NiMH Battery Required time for battery charging : 14 - 16 Hours Usable temperature range for operation : 0˚C to 40˚C Product dimension : 1) Stickvac : 260mm (W) x 1110mm (H) x 205mm (D)
