Roland CUBE Street EX Owner's Manual

Battery powered stereo amp with high audio quality and high output
Hide thumbs Also See for CUBE Street EX:
Table of Contents

Advertisement

Quick Links

Owner's Manual
Battery powered stereo amp with high audio quality and high output
• Specially designed circuit allows up to 50 W output using eight AA batteries.
• ECO mode allows up to approximately 20 hours of use on rechargeable Ni-MH batteries.
• Two-way stereo speakers with woofer and tweeter allow wide-range sound to be produced.
Lightweight cabinet for convenient portability
• The cabinet is made of ABS injection molded resin, for a lightweight and tough design.
• A dedicated case CB-CS2 (sold separately) made of water-repellent material is also available.
A rich variety of inputs and outputs to support a variety of instruments
• Four inputs and AUX IN are provided, including XLR-compatible mic input jacks and line input jacks that support input from a
keyboard or other instrument.
• Three choices of COSM amp type optimized for electric guitar are provided: CLEAN, CRUNCH, and LEAD. These types cover the
tonal range from transparently clean sounds to hard distortion.
• A dedicated preamp optimized for acoustic guitar performance is provided, delivering a rich and natural sound.
• Line output and a STEREO LINK function allow the CUBE Street EX to be used for a variety of purposes such as a monitor or a
simple PA system.
i-CUBE LINK function makes it easy to enjoy recording or mixdown
By using the included four-conductor mini cable to connect your iPad or iPhone to the CUBE Street EX, you can use it as an audio
interface. You can further expand your performance possibilities by using the system in conjunction with apps on your device.
Before using this unit, carefully read the sections entitled "USING THE UNIT SAFELY" (p. 2) and "IMPORTANT NOTES" (p. 3). These sections provide important
information concerning the proper operation of the unit. Additionally, in order to feel assured that you have gained a good grasp of every feature of your
new unit, read Owner's Manual in its entirety. This manual should be saved and kept on hand as a convenient reference.
Copyright © 2014 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without the written permission of ROLAND CORPORATION.

Advertisement

Table of Contents
loading

Related Manuals for Roland CUBE Street EX

Summary of Contents for Roland CUBE Street EX

  • Page 1 A rich variety of inputs and outputs to support a variety of instruments • Four inputs and AUX IN are provided, including XLR-compatible mic input jacks and line input jacks that support input from a keyboard or other instrument. • Three choices of COSM amp type optimized for electric guitar are provided: CLEAN, CRUNCH, and LEAD. These types cover the tonal range from transparently clean sounds to hard distortion. • A dedicated preamp optimized for acoustic guitar performance is provided, delivering a rich and natural sound. • Line output and a STEREO LINK function allow the CUBE Street EX to be used for a variety of purposes such as a monitor or a simple PA system. i-CUBE LINK function makes it easy to enjoy recording or mixdown By using the included four-conductor mini cable to connect your iPad or iPhone to the CUBE Street EX, you can use it as an audio interface. You can further expand your performance possibilities by using the system in conjunction with apps on your device. Before using this unit, carefully read the sections entitled “USING THE UNIT SAFELY” (p. 2) and “IMPORTANT NOTES” (p. 3). These sections provide important information concerning the proper operation of the unit. Additionally, in order to feel assured that you have gained a good grasp of every feature of your new unit, read Owner’s Manual in its entirety. This manual should be saved and kept on hand as a convenient reference. Copyright © 2014 ROLAND CORPORATION All rights reserved. No part of this publication may be reproduced in any form without the written permission of ROLAND CORPORATION.

  • Page 2: Using The Unit Safely

    Connect mains plug of this model to a mains socket outlet with a protective Be sure to follow the instructions in the Immediately turn the unit off, remove the earthing connection. Owner’s Manual carefully when placing this AC adaptor from the outlet, and request unit on a stand (p. 10). servicing by your retailer, the nearest To completely turn off power to the unit, pull out Roland Service Center, or an authorized If it is not set up properly, you risk creating the plug from the outlet Roland distributor, as listed on the “Information” when: an unstable situation which could lead to the unit Even with the power switch turned off, this falling or the stand toppling, and may result in injury. • The AC adaptor or the power cord has been unit is not completely separated from its damaged; or Use only the supplied AC adaptor and the correct main source of power. When the power...

  • Page 3: Important Notes

    Use only the specified stand(s) • Carefully follow the installation Route all power cords and cables in such a way as This unit is designed to be used in instructions for batteries, and make sure to prevent them from getting entangled combination with specific stands (ST- you observe the correct polarity. A95) manufactured by Roland. If used Injury could result if someone were to trip • Avoid using new batteries together with in combination with other stands, you on a cable and cause the unit to fall or used ones. In addition, avoid mixing risk sustaining injuries as the result of this product topple. different types of batteries. dropping down or toppling over due to a lack of • Remove the batteries whenever the unit is to...

  • Page 4: About The Power Supply

    About the Power Supply Battery Operation Checking the Remaining Battery Amount When the [BATTERY CHECK/MUTE] switched on, you The CUBE Street EX can be powered with eight AA batteries (sold can check the amount of power remaining in the separately). We recommend that you keep batteries installed in the batteries. unit even though you’ll be powering it with the AC adaptor. That way, * When the [BATTERY CHECK/MUTE] switched on, the you’ll be able to continue a performance even if the cord of the AC indicator blinks, and sound will not produced from the adaptor gets accidently disconnected from the unit. CUBE Street EX’s speakers or from LINE OUT jacks and PHONES jack. * If you handle batteries improperly, you risk explosion and fluid leakage. * Sounds may distort easily or may cut off when played at high volume as Make sure that you carefully observe all of the items related to batteries the battery power begins to fade, but this is normal and does not indicate that are listed in “USING THE UNIT SAFELY” (p. 2) and “IMPORTANT NOTES” a malfunction. In such instances, either replace the batteries or use the AC (p. 3). adaptor included with the unit. * When operating on battery power only, the unit’s indicator will become blink when battery power gets too low. Replace the battery as soon as Battery indicator possible. * The remaining battery power Choosing Batteries indication is only an approximation.
  • Page 5 Connections * To prevent malfunction and equipment failure, always turn down the volume, and turn off all the units before making any connections. * When connection cables with resistors are used, the volume level of equipment connected to the inputs (AUDIO IN) may be low. If this happens, use connection cables that do not contain resistors. Top panel About plugs in figures iPhone, iPad, etc About combo jacks 1/4” phone You can connect either XLR Stereo 1/4” phone plugs or phone plugs to the combo jacks. (Included) 4-pole miniature phone Acoustic feedback could be produced depending on the location of microphones relative to speakers. This can be remedied by: • Changing the orientation of the microphone(s). • Relocating microphone(s) at a greater distance from speakers. • Lowering volume levels. Rear panel To prevent the inadvertent disruption of power to your unit (should the plug be pulled out accidentally), and to avoid applying undue stress to the DC IN jack, anchor the power cord using the cord hook, as shown in the illustration.

  • Page 6: Panel Description

    Panel Description Top Panel 17 18 Number Name Explanation MIC/INSTRUMENT CHANNEL INPUT Here you can connect a mic, guitar, keyboard, or other * This instrument is equipped with balanced (XLR/TRS) type jacks. INPUT jack Wiring diagrams for these jacks are shown below. Make connections electronic musical instrument (balanced connection). after first checking the wiring diagrams of other equipment you Switch this to choose the input level that’s appropriate for intend to connect. the device you’ve connected. [SELECT] switch Choose the “MIC” setting if you’re connecting a mic, or choose the “INST” setting if you’re connecting an acoustic guitar or a keyboard. [VOLUME] knob Adjusts the volume of the MIC/INSTRUMENT channel. EQUALIZER [BASS] knob Adjusts the sound level of the low-frequency range. [MIDDLE] knob Adjusts the sound level of the middle-frequency range. [TREBLE] knob Adjusts the sound level of the high-frequency range. REVERB [REVERB] knob Spacious-sounding stereo reverb is provided. Turn the knob to adjust the reverb level.
  • Page 7 Panel Description Number Name Explanation EQUALIZER [BASS] knob Adjusts the sound level of the low-frequency range. [MIDDLE] knob Adjusts the sound level of the middle-frequency range. [TREBLE] knob Adjusts the sound level of the high-frequency range. CHORUS/DELAY Turn this knob to CHORUS or DELAY to switch to that effect. Type Explanation This is a spacially synthesized chorus. With spacially synthesized chorus, a method available only in stereo, the chorus effect is created by taking the sound from the right speaker (from which the effect sound is CHORUS output), and the sound from the left speaker (which outputs the direct sound), and then mixing them in the actual space. This creates a greater lateral spread than that [CHORUS/DELAY] knob produced when the sounds are mixed electronically, providing a more natural sense of breadth. Turn the knob to change the time and amount of delay effects. DELAY REVERB Spacious-sounding stereo reverb is provided. [REVERB] knob Turn the knob to adjust the reverb level. OTHER JACKS AND KNOBS LINE IN L/MONO, R jacks Line-level devices such as a keyboard can be connected here.

  • Page 8: Turning The Power On/Off

    LINE OUT jacks and PHONES jack. malfunction. * When turning the power off, turn the volume to 0 for all devices that are connected to the CUBE Street EX and then turn off their power; finally, turn Turn all [VOLUME] knobs of the CUBE Street EX to 0. off the power of the CUBE Street EX. Minimize the volume of the devices connected to the CUBE Street EX. Turn on the power of the devices that are connected to the INPUT jacks, LINE IN (L/MONO, R) jacks, and AUDIO IN (i-CUBE LINK) jacks of the CUBE Street EX.

  • Page 9: Convenient Functions

    The sound of your guitar or mic will be sent from the CUBE Street EX to the iPad/iPhone. Open sixth string Open fifth string * If you want to hear only the sound that’s being input from the iPad/iPhone, Open fourth string turn down the [VOLUME] knob of each channel. Open third string Open second string For details on i-CUBE LINK and on iPhone/iPad apps that can use Open first string i-CUBE LINK, refer to Roland website. http://www.roland.com/ * Reference pitch: A4=440 Hz Tune the string until the green indicator lights. Flat Pitch is correct Sharp Lights red Lights green Lights red * The red indicator blinks if the pitch is substantially out of tune. When you have finished tuning, press the [TUNER] button once again.
  • Page 10 * Always use the ST-A95 with the stopper inserted into the upper tube. Tighten the height adjustment knob. Fit the hole on the CUBE Street EX onto the upper tube. On the L-side unit and the R-side unit, set the [LINE OUT/ STEREO LINK] switch to “STEREO LINK.”...

  • Page 11: Main Specifications

    Main Specifications Roland CUBE Street EX BATTERY POWERED STEREO AMPLIFIER Trademarks Roland, BOSS, COSM, CUBE, CUBE STREET are either registered trademarks or trademarks of Roland Corporation in the United States and/or other countries. Maximum Power 50 W (25 W + 25 W) Output Company names and product names appearing in this document are registered trademarks or trademarks of their respective owners. MIC/INSTRUMENT INPUT: -50/-10 dBu MIC/GUITAR INPUT: -10 dBu Nominal Input LINE IN: -10 dBu Level (1 kHz) AUDIO IN (i-CUBE LINK): -10 dBu AUX IN, STEREO LINK IN: -10 dBu LINE OUT (L/MONO, R): -10 dBu Nominal Output Level (1 kHz) STEREO LINK OUT (L, R): -10 dBu [OUTPUT POWER switch: MAX (Maximum power output: 50 W)] Alkaline battery: Approximately 4 hours Rechargeable Ni-MH battery: Approximately 5 hours (*1) [OUTPUT POWER switch: NORMAL (Maximum power output: 25 Alkaline battery: Approximately 8 hours...
  • Page 12 SPEAKER OUT L SPEAKER OUT R STEREO LINK IN...

  • Page 14: Federal Communications Commission Radio Frequency Interference Statement

    For the U.K. WARNING: THIS APPARATUS MUST BE EARTHED IMPORTANT: THE WIRES IN THIS MAINS LEAD ARE COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE. GREEN-AND-YELLOW: EARTH, BLUE: NEUTRAL, BROWN: LIVE As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The wire which is coloured GREEN-AND-YELLOW must be connected to the terminal in the plug which is marked by the letter E or by the safety earth symbol...
  • Page 15 For EU Countries For China...
