- Page 1 Air Purifier User manual AX60R5080WD / AX60T5080WF ꞏ Thank you for purchasing this Samsung air purifier. ꞏ Before operating this unit, please read this user manual carefully and retain it for future reference.
-
Page 2: Table Of Contents
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic accessories should not be mixed with other commercial wastes for disposal. For information on Samsung’s environmental commitments and product-specific regulatory obligations, e.g. REACH, WEEE, Batteries, visit: www.samsung.com/uk/aboutsamsung/sustainability/environment/our-... -
Page 3: Package Content
The product design and specifications are subject to change without prior notice for quality improvement. Dimensions Model name Area coverage (width × height × depth) AX60R5080WD / AX60T5080WF 360 mm x 783 mm x 293 mm 60 m²... -
Page 4: At A Glance
At a Glance General 01 Air outlet (top) 08 Air outlet (side) 02 Display and buttons 09 Laser PM sensor 03 Display lighting 10 Gas sensor 04 Filter holder 11 2-in-1 filter(Deodorization Filter+Dust Collecting Filter) 05 Air inlet / Front panel 12 Pre-filter 06 Handle (rear side) 07 Dongle mount... -
Page 5: Display And Buttons
* Diameter of a human hair: 50 to 70 ㎛ Bixby is the name of a Samsung AI solution and allows you to control the product with voice. To use the voice recognition function, you must connect the SmartThings app on your smartphone to the product. -
Page 6: Removing The Filter
At a Glance Removing the filter When using the 2-in-1 filter for the first time or replacing them with a new set, remove the vinyl packaging first. STEP 1 Remove the front panel. • Use your thumbs to press on the top of the product and pull the front panel forward with other fingers. -
Page 7: Assembling The Filter
Assembling the filter STEP 1 Place the 2-in-1 filter. • Let the filter sit inside the grooves at the bottom. • Check the insert direction before placing the filter. STEP 2 Secure the 2-in-1 filter. • Rotate the filter holder 90° clockwise to hold the filter in place. - Page 8 At a Glance STEP 5 Before using new filter, reset the filter replacement reminders. • Press and hold the Lighting [ ] button for 3 seconds or longer. NOTE • The product is not as effective when it is operated without filter. •...
- Page 9 – The 2-in-1 filter is a comsumable material, and even if the warranty period is free, replacement of filter that occurs during use will be charged. • You can purchase new replacement filter from a Samsung Service Centre.
-
Page 10: Operation Features
Operation Features Turning the power on/off • Press the Power button. The air purifier turns on with a notification sound and automatically begins operation. – Sensor preparation begins upon startup with a display indication and continues for 12 seconds. The air quality is then indicated by colour and the concentration level. -
Page 11: Sleep Mode / Timed On/Off Function / Display Lighting
Sleep mode Sleep mode provides a clean, quiet and comfortable room for a good night's sleep. • Use Sleep mode to only allow the mode indicator and turn off all other display indicators. • Changing the fan speed when Sleep mode has been active for 10 seconds or more will cancel the mode and the sensor loading display will appear. -
Page 12: Turning The Wi-Fi Feature On/Off / Clearing The Filter Replacement Reminder / Lock Function
• Press and hold the Sleep mode [ ] button for 3 seconds or more to turn the Wi-Fi on or off. • To use this feature, first register the product to Samsung SmartThings app. Once connected, the Wi-Fi icon will automatically light up. -
Page 13: Checking The Air Quality
Checking the air quality You can review the current air quality from the display panel with the colour (reflecting the PM10 / PM2.5 / PM1.0 / gas pollution) and the concentration level indicators. • By default, the colour and PM10 / PM2.5 / PM1.0 level indicators reflect the PM10 concentration. •... -
Page 14: Cleaning And Maintenance
Cleaning and Maintenance Be sure to disconnect the power plug from the socket before cleaning the product. Cleaning the air purifier exterior • Dampen a soft cloth with lukewarm water and wring it out, and then wipe the product exterior with it. •... -
Page 15: Cleaning And Drying The Filter
Cleaning and drying the filter NOTE • About removing/assembling the filter, see pages 6 and 7. Cleaning the pre-filter • Depending on the dust accumulation, first remove dust with a vacuum cleaner and gently wash the filter with a pH-neutral detergent diluted in lukewarm water. –... -
Page 16: Smartthings App
1 To connect the product to a Wi-Fi network, Downloading the SmartThings turn on Wi-Fi at "Settings > Wi-Fi", and then app and registering your Samsung select the access point to connect to account • Only alphanumeric characters are supported for wireless access point names (SSIDs). - Page 17 Air purifier Select Select NOTE • If you already have a Samsung account, log in 2 Connecting the SmartThings app to your to the account. If you have a smartphone that product is a Samsung device and you have a Samsung •...
- Page 18 It is also possible to obtain the complete • The product supports the IEEE802.11 b/g/n (2.4 GHz) communication protocol. (Samsung corresponding source code in a physical medium such recommends IEEE802.11n.) as a CD-ROM; a minimal charge will be required.
- Page 19 Controlling your air purifier with SmartThings app Smartly control your air purifier using the SmartThings app. Category Function Description Check the indoor air cleanliness. • Touch the icon to view the PM10 / PM2.5 / PM1.0 levels and gas cleanliness. Indoor air quality •...
-
Page 20: Appendix
Before Requesting Service Check the following before requesting service from the Service Centre. Operation The air purifier does not operate. • Check the power supply and turn on the air purifier again. • Make sure that the power plug is plugged in, and then turn on the air purifier again. - Page 21 • If the indicator colour stays in red after you have followed all the provided instructions and solutions, it may be a sensor issue. In this case, please contact your local Samsung Service Centre. • When humidifiers, electric pressure cookers, sprayers and such are being used in the same room, the pollution level may be measured as Poor.
- Page 22 Strange indications appear on the display. • If any of the indications appears, contact a Samsung Service Centre. Air circulation The fan does not seem to circulate the air evenly. • Your air purifier is designed to send the clean air upwards for effective circulation.
-
Page 23: Safety Precautions
Safety Precautions These safety precautions are for owner’s safety and preventions of property damage. Therefore, please read this manual thoroughly before using your product. WARNING Hazards or unsafe practices that may result in severe personal injury or death. CAUTION Hazards or unsafe practices that may result in minor personal injury or property damage. Follow directions. - Page 24 Please contact your local Samsung Service Centre if the power plug or cord is damaged. Make sure that the power plug is securely fitted in the socket. Do not use it when the plug or cord is damaged.
- Page 25 • Follow instructions to avoid electric shock or fire. Product installation must be handled by official Samsung service personnel or a certified local technician to avoid power cord or plug damage, which can be dangerous. Disconnect the air purifier from the power source before cleaning or repairing.
- Page 26 • Follow instructions to avoid malfunction or noise. If any of the electric components inside the air purifier has contacted liquid or water, disconnect the product from the power source and contact your local Samsung Service Centre. • Follow instructions to avoid electric shock or fire.
- Page 27 CAUTION Keep your air purifier at least 2 meters away from a TV or other audio/visual media. • They can be affected by video or audio noise. Secure enough space around the air purifier when operating. • Clear space from each side: at least 60 cm and the front: at least 25 cm •...
-
Page 28: Reference
Reference Wi-FI ¹⁾ Frequency Range ²⁾ Transmitter Power (Max) 2412 - 2472 MHz 20 dBm ¹⁾ Frequency Range English ²⁾ Transmitter Power(Max) ¹⁾ Plage de fréquence French ²⁾ Puissance de l’ é metteur (Max.) ¹⁾ Intervallo frequenza Italian ²⁾ Potenza trasmettitore (Max) ¹⁾... - Page 29 The official Declaration of conformity may be found at http:// www.samsung.com, go to Support > Search Product Support and enter the model name. Par la présente, Samsung déclare que cet équipement radio est conforme à la directive 2014/53/UE et aux exigences réglementaires applicables au Royaume-Uni. Le texte intégral de la déclaration de conformité...
- Page 30 Podpora a do pole Hledat Podporu zadejte název modelu. Spoločnosť Samsung týmto vyhlasuje, že toto zariadenie rádiového typu je v súlade so smernicou 2014/53/EÚ a náležitými zákonnými požiadavkami v Spojenom kráľovstve. Celé znenie Vyhlásenia o zhode v EÚ a Vyhlásenia o zhode v Spojenom kráľovstve je k dispozícii Slovak na nasledujúcej internetovej adrese: Oficiálne Vyhlásenie o zhode sa nachádza na lokalite...
- Page 31 Memo...
- Page 32 Atenţie: Dacă efectuaţi apelul din reţeaua Digi (RCS/RDS), vă rugăm să ne contactaţi formând numărul Telverde fără ultimele două cifre, astfel: 0800872678. CYPRUS 8009 4000 only from landline, toll free www.samsung.com/gr/support 80111-SAMSUNG (80111 726 7864) only from land line GREECE (+30) 210 6897691 from mobile and land line LITHUANIA 8-800-77777 www.samsung.com/lt/support...
