Acer Aspire 3050 Service Manual page 49

Battery
Package configuration
Normal voltage
Charge voltage
LCD 14.1" inch
Item
Vendor & model name
Screen Diagonal (mm)
Active Area (mm)
Display resolution (pixels)
Pixel Pitch
Pixel Arrangement
Display Mode
Typical White Luminance (cd/m
also called Brightness
Luminance Uniformity
Contrast Ratio
Response Time (Optical Rise
Time/Fall Time)msec
Nominal Input Voltage VDD
Typical Power Consumption (watt)
Weight
Physical Size(mm)
Electrical Interface
Support Color
Viewing Angle (degree)
Horizontal: Right/Left
Vertial: Upper/Lower
Temperature Range( C)
Operating
Storage (shipping)
Chapter 1
Item
QDI QD14TL01-03
(Non Glare)
QDI QD14TL01-02
(Glare)
14.1 inches
304.1x228.1
1280x800 WXGA
0.237x0.237
R.G.B. Vertical
Stripe
Normally White
185
2
)
N/A
300
25 (rising+falling)
+3.3V Typ.
N/A
420 (440max)
317.3x242.0x6.0
1 channel LVDS
262,144
40/40
10/30
°
0 to +50
-20 to +60
Specification
3 cells in series, 2 series in
parallel
3 cells in series, 3 series in
parallel
14.8V
16.8+-0.2v
Specification
CMO N141I1-L02
(Non Glare)
CMO N141I1-L03
(Glare)
14.1 inches
304.1x228.1
1280x800 WXGA
0.237x0.237
R.G.B. Vertical
Stripe
Normally White
185
N/A
500
5/11
+3.3V
4.02 (for backlight
unit only)
425
317.3x242.0x5.9
1 channel LVDS
262,144
45/45
20/45
0 to +50
-25 to +60
LG LPL
LP141WX1-TLA1
(Non Glare)
LG LPL
LP141WX1-TLA2
(Glare)
14.1 inches
304.1x228.1
1280x800 WXGA
0.237x0.237
R.G.B. Vertical
Stripe
Normally White
200
N/A
400
16
3.3V
Total 5.38 Watt
(Typ.) @ LCM
circuit 1.28Watt
(Typ.), Backlight
4.1 Watt (Typ.)
390(Typ.)
400(Max)
317.3x242.0x6.5
1 channel LVDS
262,144
40/45
25/30
0 to +50
-20 to +60
41
