Operating Instructions
Air Conditioner
Model No.
Indoor Unit
CS-LZ25TKE
CS-LZ35TKE
Outdoor Unit
CU-LZ25TKE
CU-LZ35TKE
Operating Instructions
Air Conditioner
Before operating the unit, please read these operating
instructions thoroughly and keep them for future reference.
The included Installation Instructions should be kept and
read by the installer before installation.
Remote control is packaged in the indoor unit and
removed by the installer before installation.
Bruksanvisning
Luftkonditionering
Innan du använder enheten, läs noga igenom denna
bruksanvisning och spara den för framtida bruk.
De medföljande installationsanvisningarna ska sparas och
läsas av installatören före installationen.
Fjärrkontrollen fi nns i inomhusenheten och tas bort av
installatören före installationen.
Bruksanvisninger
Klimaanlegg
Les bruksanvisningen nøye før du bruker denne
enheten, og oppbevar den for fremtidig bruk.
Installatøren bør oppbevare og lese de medfølgende
installasjonsinstruksene før installasjon. Fjernkontrollen
skal pakkes inn i innendørsenheten og fjernes av
installatøren før installasjon.
Käyttöohjeet
Ilmastointilaite
Lue nämä käyttöohjeet huolellisesti ennen yksikön
käyttämistä ja säilytä ne tulevaisuutta varten.
Sisällytetyt asennusohjeet tulee pitää ja lukea asentajan
toimesta ennen asennusta.
Kaukosäädin on pakattu sisätilayksikköön ja poistetaan
asentajan toimesta ennen asennusta.
Betjeningsvejledning
Klimaanlæg
Læs brugsanvisningen grundigt igennem før du
benytter anlægget og gem den til fremtidig brug.
De inkluderede installationsinstruktioner skal opbevares og
læses af montøren før installationen.
Fjernbetjeningen er pakket i den indendørs enhed og
fjernet af montøren inden installationen.
2-15
16-29
30-43
44-57
58-71
ACXF55-11470
Advertisement
Related Manuals for Panasonic CU-LZ25TKE
Summary of Contents for Panasonic CU-LZ25TKE
- Page 1 Remote control is packaged in the indoor unit and Model No. removed by the installer before installation. Indoor Unit Outdoor Unit CS-LZ25TKE CU-LZ25TKE CS-LZ35TKE CU-LZ35TKE 16-29 Bruksanvisning Luftkonditionering Innan du använder enheten, läs noga igenom denna bruksanvisning och spara den för framtida bruk.
- Page 2 Provides maximum comfort and clean air with optimal energy saving methods. Use remote control within 8 m from the remote control receiver of control receiver of the indoor unit. the indoor unit. Quick Guide Inserting the batteries Clock setting 1 Press and set the time 1 Pull out the back cover...
-
Page 3: Table Of Contents
Thank you for purchasing Panasonic Air Conditioner. Table of contents Safety precautions ……………… 4-7 How to use ………………………… 8-9 To learn more... ……………………10 Cleaning instructions ……………11 Troubleshooting.....12-14 Information ………………………………15 This symbol shows that this equipment uses a fl ammable refrigerant. If the refrigerant... -
Page 4: Safety Precautions
Safety precautions To prevent personal injury, injury to WARNING others or property damage, please comply with the following: Incorrect operation due to failure to follow instructions below may cause Indoor unit and outdoor unit harm or damage, the seriousness of which is classifi... - Page 5 If the supply cord is damaged, Do not expose yourself directly it must be replaced by the to cold air for a long period to manufacturer, service agent or avoid excess cooling. similarly qualifi ed persons in order to avoid a hazard. Do not sit or step on the unit, you may fall down It is strongly recommended to...
- Page 6 Safety precautions Models that use refrigerant R32 WARNING and R410A have a different charging port thread diameter to prevent erroneous charging with Precaution for appliance fi lled refrigerant R22 and for safety. with R32 Therefore, check beforehand. [The charging port thread Pay careful attention to the following diameter for R32 and R410A is points when operating the appliances...
- Page 7 Prevent water leakage by CAUTION ensuring drainage pipe is: -Connected properly, - Kept clear of gutters and Indoor unit and outdoor unit containers, or -Not immersed in water Do not wash the indoor unit with water, benzine, thinner After a long period of use or use or scouring powder to avoid with any combustible equipment, damage or corrosion at the unit.
-
Page 8: How To Use
How to use To adjust airfl ow direction Upper direction AIR SWING Lateral direction Receiver Indicator • Do not adjust the fl ap by hand. • Do not insert fi nger into the air fl ow outlet to prevent injury. POWER TIMER DEICE... - Page 9 See "To learn more..." for details. To set the timer 2 sets of ON and OFF timers are available to turn ON or OFF the unit at different preset times. • To cancel ON or OFF timer, press to select respective then press •...
-
Page 10: To Learn More
To learn more... Operation mode HEAT : The POWER indicator blinks at the initial stage of this operation. Unit takes a while to warm up. Unit may stops warm air supply for deice. The deice indicator ON during this operation. •... -
Page 11: Cleaning Instructions
Cleaning instructions To ensure optimal performance of the unit, Indoor unit Aluminium fi n cleaning has to be carried out at regular Air Purifying Filter intervals. Dirty unit may cause malfunction and you may see error code “H 99”. Please Front panel consult authorised dealer. -
Page 12: Troubleshooting
Troubleshooting The following symptoms do not indicate malfunction. Symptom Cause Mist emerges from indoor unit. • Condensation effect due to cooling process. Water fl owing sound during operation. • Refrigerant fl ow inside the unit. The room has a peculiar odour. •... - Page 13 When... ■The remote control is missing or a malfunction has occurred 1.Raise the front panel. 2.Press the button once to use in AUTO mode. 3. Press and hold the button until you hear 1 beep, then release to AUTO use in forced COOL mode. OFF/ON 4.
- Page 14 Troubleshooting How to retrieve error codes If the unit stops and the TIMER indicator blinks, use the remote control to retrieve the error code. Press for Press until you hear beep 5 seconds sound, then write down the error code TIMER TIMER Press for 5...
-
Page 15: Information
Information English Information for Users on Collection and Disposal of Old Equipment and Used Batteries These symbols on the products, packaging, and/or accompanying documents mean that used electrical and electronic products and batteries should not be mixed with general household waste. For proper treatment, recovery and recycling of old products and used batteries, please take them to applicable collection points, in accordance with your national legislation.
