CSIW SUB10
OWNER'S GUIDE
www.psbspeakers.com

Advertisement

loading

Related Manuals for PSB CSIW SUB10

Summary of Contents for PSB CSIW SUB10

  • Page 1 CSIW SUB10 OWNER’S GUIDE www.psbspeakers.com...
  • Page 2 IMPORTANT SAFETY INSTRUCTIONS The lightning flash with arrowhead symbol within an equilateral triangle, is intended to alert you to the 1. Read these instructions. presence of uninsulated “dangerous voltage” within the 2. Keep these instructions. product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

  • Page 3: Required Items

    Introduction PSB subwoofers are designed to provide the flattest possible frequency response, full bass extension, low distortion and high output. Beyond these characteristics there are a few other parameters that we feel are very important in the design of a subwoofer.
  • Page 4 For stud wall constructed on larger than 16” centres For stud walls exceeding 16” (40 cm) spacing, cross braces must be used. The vertical distance between the two cross braces must be 27½”. The subwoofer driver opening should be located at the bottom of the box. The cross braces must be even with the backside of the stud wall.
  • Page 5 Secure the cable so that it cannot rattle against the studding or drywall panels and tighten the cable nut to secure the cable to the cabinet. Wire from PSB CustomSound CS500W...

  • Page 6: Step 5: Install The Driver

    Stage 2 – After Drywall Completion Required Items: Step 5: Install the Driver The subwoofer driver is installed after the installation of the drywall and final decorating has been completed. Remove woofer opening cover. remove woofer opening cover Connect the speaker wires to the driver. Note: the positive and negative wires have specific connectors and will only connect to the subwoofer driver in one way.
  • Page 7 Place the driver into the cabinet opening and secure using the eight (8) supplied screws. Installing the subwoofer driver Step 6: Install the Grill Determine whether the round or square grills will be used. For square grills, place the square bracket against the driver, then For round grills, install the magnetic trim ring using the four (4) For square grills, place the square bracket against the driver, then install the magnetic trim ring using the four (4) supplied screws.
  • Page 8 CSIW SUB10 is stored within the amplifier. Note: When setting up the amplifier, it is necessary to set the profile to CSIW SUB10. Do not play the subwoofer until the profile has been set. Refer to the CS 500W owner’s manual for detailed instructions.
