Introduction Instrument Cluster Warning and control lights Gauges Entertainment Systems AM/FM stereo cassette with CD CD changer Climate Controls Electronic automatic temperature control Lights Headlamps Turn signal control Bulb replacement Driver Controls Windshield wiper/washer control Steering wheel adjustment Power windows Mirrors Speed control Locks and Security...
Page 2 Table of Contents Driving Starting Brakes Traction control/AdvanceTrac Air suspension Transmission operation Vehicle loading Trailer towing Roadside Emergencies Getting roadside assistance Hazard flasher switch Fuel pump shut-off switch Fuses and relays Changing tires Jump starting Wrecker towing Customer Assistance Reporting safety defects (U.S. only) Cleaning Maintenance and Specifications Engine compartment...
Page 3 Accessories Index All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company. Ford may change the contents without notice and without incurring obligation.
Page 4: Introduction
State of California to cause cancer and birth defects or other reproductive harm. CONGRATULATIONS Congratulations on acquiring your new Mercury. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle the greater the safety and pleasure you will derive from driving it.
Page 5 Fuel pump shut-off switch In the event of an accident the safety switch will automatically cut off the fuel supply to the engine. The switch can also be activated through sudden vibration (e.g. collision when parking). To reset the switch, refer to the Fuel pump shut-off switch in the Roadside emergencies chapter.
Page 6 Introduction BREAKING-IN YOUR VEHICLE Your vehicle does not need an extensive break-in. Try not to drive continuously at the same speed for the first 1,600 km (1,000 miles) of new vehicle operation. Vary your speed to allow parts to adjust themselves to other parts.
Page 7 Any of this information could potentially including information regarding how the driver operates the vehicle potentially including but not limited to information regarding vehicle speed, brake or accelerator application or steering input. This information may be stored during regular operation or in a crash or near crash event. This stored information may be read out and used by: Ford Motor Company.
Page 8 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert Fasten Safety Belt Air Bag-Side Child Seat Installation Warning Child Seat Tether Anchor Anti-Lock Brake System Traction Control Master Lighting Switch Fog Lamps-Front Fuel Pump Reset Windshield Defrost/Demist...
Page 9 Vehicle Symbol Glossary Power Windows Front/Rear Child Safety Door Lock/Unlock Panic Alarm Engine Coolant Do Not Open When Hot Avoid Smoking, Flames, or Sparks Explosive Gas Power Steering Fluid Emission System Passenger Compartment Air Filter Check fuel cap Introduction Power Window Lockout Interior Luggage Compartment Release Symbol...
Page 10: Instrument Cluster
Instrument Cluster WARNING LIGHTS AND CHIMES Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works.
Page 11 should turn off. (A driving cycle consists of a cold engine startup followed by mixed city/highway driving.) No additional vehicle service is required. If the light remains on, have your vehicle serviced at the first available opportunity. Light is blinking: Engine misfire is occurring which could damage your catalytic converter.
Page 12 Instrument Cluster Illumination after the parking brake is released indicates low brake fluid level or a brake system malfunction and the brake system should be serviced immediately by a qualified technician. Refer to Brakes in the Driving chapter for more information. Anti-lock brake system (ABS) To confirm the anti-lock brake system (ABS) warning light is...
Page 13 Engine coolant temperature Illuminates when the engine coolant temperature is high. Stop the vehicle as soon as safely possible, switch off the engine and let it cool. Never remove the coolant recovery cap while the engine is running or hot. Refer to Engine coolant in the Maintenance and specifications chapter.
Page 14 Instrument Cluster Turn signals Illuminates when the turn signals or the hazard lights are turned on. If the lights stay on continuously or flash faster, check for a burned-out bulb. High beams Illuminates when the high beam headlamps are turned on. Safety belt warning chime Sounds to remind you to fasten your safety belts.
Page 15: Gauges
GAUGES Engine coolant temperature gauge Indicates the temperature of the engine coolant. At normal operating temperature, the needle remains within the normal area (the area between the “H” and “C”). If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine immediately and let the engine cool.
Page 16 Instrument Cluster Engine oil pressure gauge Located in the lower center of the instrument panel, indicates engine oil pressure. If the pointer drops below the normal operating range (50–75 psi) or the minimum low (6 psi) pressure when the engine is running, stop your vehicle as soon as possible, shut off the engine and check the oil level.
Page 17 Instrument Cluster Fuel gauge Displays approximately how much fuel is in the fuel tank. The fuel gauge may vary slightly when the vehicle is in motion or on a grade. When refueling the vehicle from empty indication, the amount of fuel that can be added will be less than the advertised capacity due to the reserve fuel.
Page 18 Instrument Cluster Trip odometer Registers the kilometers (miles) of individual journeys. To reset, depress the control. Tachometer Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer continuously at the top of the scale may damage the engine.
Page 19: Entertainment Systems
AUDIOPHILE AM/FM STEREO/CASSETTE/SINGLE CD 1. Tape eject control 2. CD eject control 3. Bass/treble control 4. Balance/fade control 5. Compression/shuffle control 6. Select control 7. Side direction/Dolby control 8. Rewind/fast forward control 9. RDS/DSP control 10. Autoset control Volume/power control Press the control to turn the audio system on or off.
Page 20 Entertainment Systems Turn control to raise or lower volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on. Bass adjust The bass adjust control allows you to increase or decrease the audio...
Page 21 Press the BAL control then press: to shift sound to the left and to shift sound to the right. Speaker fade adjust Speaker sound can be adjusted between the front and rear speakers. Press the FADE control then press: to shift the sound to the front and to shift the sound to the rear.
Page 22 Entertainment Systems Scan function The scan function works in radio, tape or CD mode. Scan function in radio mode Press the SCAN control to hear a brief sampling of all listenable stations on the frequency band. Press the control again to stop the scan mode. Scan function in tape mode Press the SCAN control to hear a short sampling of all selections on the tape.
Page 23 Entertainment Systems Setting memory preset stations 1. Select the frequency band with the AM/FM select control. 2. Select a station. Refer to Tune adjust or Seek function for more information on selecting a station. 3. Press and hold a memory preset control until the sound returns, indicating the station is held in memory of the control you selected.
Page 24 Entertainment Systems Setting the clock with radio data system (RDS) feature Press the RDS control until SELECT HOUR or SELECT MINS is displayed. Use the SEL control to manually set the time. to decrease hours/minutes to increase hours/minutes. Tune adjust The tune control works in radio mode.
Page 25 Rewind The rewind control works in tape and CD modes. In tape mode, radio play will continue until rewind is stopped (with the TAPE control) or the beginning of the tape is reached. In CD mode, pressing the REW control rewinds the CD within the current track.
Page 26 Entertainment Systems Press the control to activate (and deactivate) the Dolby noise reduction. Dolby noise reduction is manufactured under license from Dolby Laboratories Licensing Corporation. “Dolby ” and the double-D symbol are registered trademarks of Dolby Laboratories Licensing Corporation. Compression adjust Compression adjust brings soft and loud CD passages together for a more consistent listening level.
Page 27 This feature also allows you to control the volume of traffic announcements. With the display reading TRAFFIC ON, adjust the volume (using the volume control) to the desired level. The volume level will show at the bottom of the display. Interrupting traffic announcements will be at the selected volume level.
Page 28: Cd Changer
Entertainment Systems Mute mode Press the MUTE control to mute the playing media. Press the MUTE control again to return to the playing media. Digital signal processing The digital signal processing (DSP) feature allows you to change the signal mode to suit your listening tastes.
Page 29 Entertainment Systems 2. Press to eject the magazine. 3. Turn the magazine (A) over. 4. Using the disc holder release knob (C), pull the disc holder (B) out of the magazine. If you pull too hard on the disc holder, the disc holder may come completely out of the magazine.
Page 30 Entertainment Systems 5. Line up the CD with the groove of the disc holder. Ensure that the label on the CD faces downwards. 6. Press in on the disc holder until it locks securely into the magazine. If the disc holders are not fully locked into the magazine, the unit will not operate.
Page 31 If your changer does not work, it may be that: A disc is already loaded where you want to insert a disc. The disc is inserted with the label surface downward. The disc is dusty or defective. The player’s internal temperature is above 60°C (140°F). Allow the player to cool down before operating.
Page 32 Entertainment Systems Tighten very loose tapes by inserting a finger or pencil into the hole and turning the hub. Remove loose labels before inserting tapes. Do not leave tapes in the cassette player for a long time when not being played. RADIO FREQUENCY INFORMATION The Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission(CRTC) establish the frequencies...
Page 33: Climate Controls
ELECTRONIC AUTOMATIC TEMPERATURE CONTROL (EATC) SYSTEM The EATC system will maintain a selected temperature and automatically control the fan speed and airflow location. Automatic operation Press AUTOMATIC and select the desired temperature. The selected temperature and the word AUTO will appear in the display window. The EATC system will either heat or cool to achieve the selected temperature.
Page 34 Climate Controls For continuous maximum cooling, push the blue button until 16°C (60°F) is shown in the display window. The EATC will continue maximum cooling (disregarding the displayed temperature) until a warmer temperature is selected by pressing the red control. For continuous maximum heating, push the red button until 32°C (90°F) is shown in the display window.
Page 35 If a manual override function is selected while the outside temperature is displayed, the new function will be displayed for four seconds after it is changed, then the outside temperature will return to the window along with the override selection. The outside temperature reading is most accurate when the vehicle is moving.
Page 36 Climate Controls Norm A/C- Distributes outside air through the instrument panel registers. The A/C compressor will only function if the outside temperature is above approximately 2°C (36°F). Norm A/C is more quiet than Max A/C, but not as economic and efficient. Vent-Distributes outside air through the instrument panel registers.
Page 37 To aid in side window defogging/demisting in cold weather conditions: 1. Select VENT 2. Set the temperature control to full heat 3. Set the fan speed to HI 4. Direct the outer panel vents towards to side windows To increase airflow to the outer panel vents, close the central panel vents.
Page 38: Lights
Lights HEADLAMP CONTROL Turns the lamps off. Turns on the parking lamps, instrument panel lamps, license plate lamps and tail lamps. Turns the headlamps on. Your vehicle’s headlamp system is equipped with a feature that will not dim the instrument panel lighting when the headlamps are on in the daytime.
Page 39 Foglamp control The foglamps can be turned on when the headlamp control is pulled toward you and is in any of the following positions: Parking lamps Low beams Autolamps Daytime running lamps (DRL) (if equipped) Turns the lowbeam headlamps on with a reduced output. To activate: the key must be in the ON position, the parking brake released, and the headlamp control is in the OFF or Parking lamps position.
Page 40: Headlamps
Lights Flash to pass Pull toward you slightly to activate and release to deactivate. PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel during headlight and parklamp operation. Rotate the thumbwheel from left to right to brighten the instrument panel.
Page 41 (1) Eight feet (2) Center height of lamp to ground (3) Twenty five feet (4) Horizontal reference line 2. Measure the height of the headlamp bulb center from the ground and mark a 2.5 meter (8 foot) horizontal reference line on the vertical wall or screen at this height (a piece of masking tape works well).
Page 42: Turn Signal Control
Lights TURN SIGNAL CONTROL Push down to activate the left turn signal. Push up to activate the right turn signal. The flash rate of the turn signal will speed up considerably if the left or right turn lamp bulb (front or rear) is burned out.
Page 43: Bulb Replacement
BULBS Replacing exterior bulbs Check the operation of all the bulbs frequently. Using the right bulbs Replacement bulbs are specified in the chart below. Headlamp bulbs must be marked with an authorized “D.O.T.” for North America and an “E” for Europe to assure lamp performance, light brightness and pattern and safe visibility.
Page 44 Lights Replacing headlamp bulbs To remove the headlamp bulb: 1. Make sure the headlamp control is in the OFF position, then open the hood 2. Remove the three pin type retainers and the radiator sight shield. 3. Disconnect the electrical connector.
Page 45 Lights The headlamp bulb should not be removed from the headlamp until just before a replacement bulb is installed. Removing the bulb for an extended period of time may affect headlamp bulb performance. Contaminants may enter the headlamp where they can settle on the lens and reflector.
Page 46 Lights 1. Make sure headlamp switch is in OFF position, then open the trunk and carefully pull the carpet away to expose the plastic retainer. 2. Remove plastic retainer to expose the lamp assembly hardware. 3. Remove three nut and washer assemblies and the lamp assembly from the vehicle.
Page 47 Lights Replacing foglamp bulbs 1. Remove the bulb socket from the foglamp by turning counterclockwise. 2. Disconnect the electrical connector from the foglamp bulb. 3. Connect the new foglamp bulb to the electrical connector. 4. Install the bulb socket in the foglamp turning clockwise. Replacing license plate lamp bulbs 1.
Page 48 Lights Replacing high-mount brakelamp bulbs 1. Remove two screws from the lamp assembly. 2. Carefully lift the lamp assembly up for access to the bulbs. 3. Carefully pull the bulb socket out of the lamp assembly. 4. Pull the bulb straight out of the socket and push in the new bulb.
Page 49: Driver Controls
Driver Controls WINDSHIELD WIPER/WASHER CONTROLS Rotate the windshield wiper control to the desired interval, low or high speed position. The bars of varying length are for intermittent wipers. When in this position rotate the control upward for fast intervals and downward for slow intervals.
Page 50: Steering Wheel Adjustment
Driver Controls To replace the wiper blades: 1. Pull the wiper arm away from the windshield and lock into the service position. 2. Press and hold the tab on the blade and slide the blade off the wiper arm pin. 3.
Page 51 Driver Controls ILLUMINATED VISOR MIRROR Lift the mirror cover to turn on the visor mirror lamps. OVERHEAD CONSOLE WITHOUT MOON ROOF (IF EQUIPPED) The appearance of your vehicle’s overhead console will vary according to your option package. Some of the features in the overhead console include a storage bin and compass.
Page 52 Driver Controls Compass zone adjustment 1. Determine which magnetic zone you are in by referring to the zone map. 2. Turn the ignition to the ON position. 3. Press and hold the MODE control until VAR appears in the display, then release.
Page 53 Driver Controls Compass mode The compass reading may be affected when you drive near large buildings, bridges, power lines and powerful broadcast antenna. Magnetic or metallic objects placed in, on or near the vehicle may also affect compass accuracy. 1. Turn ignition to the ON position. 2.
Page 54 Driver Controls 2. Hold down the MODE button for 5 seconds to enter zone mode. The display will read PRESS RESET TO SET ZONE XX where XX is the current zone. 3. Release the MODE button. 4. Repeatedly press and release the RESET button to scroll through the zones 1–15 until the desired zone is displayed.
Page 55 Driver Controls 4. Press the RESET button to de-calibrate the compass. The display will read CIRCLE SLOWLY TO CALIBRATE for a few seconds and then display a direction with CAL displayed on the right side. 5. Slowly drive the vehicle in a circle (less than 5 km/h [3 mph]).
Page 56 Driver Controls 3. After 20 seconds, the display will read CHANNEL X TRANING to indicate training has started. Continue to hold the button. Note: If the channel being trained has not been previously trained, the channel will immediately enter the training mode (no 20 second delay).
Page 57 Driver Controls brand. If there is difficulty locating the “learn” or “smart” button refer to the device’s owner manual or contact HomeLink at 1–800–355–3515 or on the Internet at www.homelink.com. 2. Press and release the “learn” or “smart” button on the garage door motor head unit.
Page 58 Driver Controls Erase mode To erase all three HomeLink channel codes: 1. Simultaneously press and hold buttons 1 and 3 for 20 seconds. 2. CLEARING CHANNELS will be displayed when the channel codes are being erased. 3. CHANNELS CLEARED will be displayed when the erase operation is complete.
Page 59 Driver Controls 2. After 20 seconds CHANNELS CLEARED is displayed. Continue to hold the buttons. 3. After 10 more seconds, CHANNELS DEFAULTED is displayed when all the channel default codes have been successfully loaded. Note: If you need to train the garage door opener, refer to “Train mode”...
Page 60: Power Windows
Driver Controls Always keep the power point caps closed when not being used. Power outlets are designed for accessory plugs only. Do not hang any type of accessory or accessory bracket from the plug. Improper use of the power outlet can cause damage not covered by your warranty.
Page 61: Mirrors
One touch down Press the bottom portion of the rocker switch completely down and release quickly. The driver’s window will open fully. Depress again to stop window operation. One touch down can be deactivated during operation by pushing down on the top part of the driver power window control.
Page 62 Driver Controls Heated outside mirrors Both mirrors are heated automatically to remove ice, mist and fog when the rear window defrost is activated. Do not remove ice from the mirrors with a scraper or attempt to readjust the mirror glass if it is frozen in place. These actions could cause damage to the glass and mirrors.
Page 63: Speed Control
POWER ADJUSTABLE FOOT PEDALS The accelerator and brake pedal should only be adjusted when the vehicle is stopped and the gearshift lever is in the P(Park) position. Press and hold the rocker control to adjust accelerator and brake pedal. Press the left side of the control to adjust the pedals toward you. Press the right side of the control to adjust the pedals away from you.
Page 64 Driver Controls To turn speed control off Press OFF or Turn off the vehicle ignition. Once speed control is switched off, the previously programmed set speed will be erased. To set a speed Press SET ACCEL. For speed control to operate, the speed control must be ON and the vehicle speed must be greater than 48 km/h (30 mph).
Page 65 To set a higher set speed Press and hold SET ACCEL. Release the control when the desired vehicle speed is reached Press and release SET ACCEL to operate the Tap-Up function. Each press will increase the set speed by 1.6 km/h (1 mph) or Accelerate with your accelerator pedal.
Page 66 Driver Controls To disengage speed control Depress the brake pedal. Disengaging the speed control will not erase the previously programmed set speed. Pressing OFF will erase the previously programmed set speed. To return to a previously set speed Press RESUME. For RESUME to operate, the vehicle speed must be faster than 48 km/h (30 mph).
Page 67 STEERING WHEEL CONTROLS Radio control features Press BAND/MODE to select AM, FM1, FM2, TAPE or CD (if equipped). In Radio mode: Press MEM/NEXT to select a preset station from memory. In Tape mode: Press MEM/NEXT to listen to the next selection on the tape. In CD mode: Press MEM/NEXT to listen to the next track on the disc.
Page 68 Driver Controls To close from the vent position, press and hold the rear portion of the control. Do not let children play with the moon roof. They may seriously hurt themselves. HOMELINK UNIVERSAL TRANSCEIVER The HomeLink Universal Transceiver, located on the driver’s visor, provides a convenient way to replace up to three hand-held transmitters with a single built-in device.
Page 69 Driver Controls 1. Press and hold the two outside buttons releasing only when the red light begins to flash after 20 seconds. Do not repeat step one to program additional hand-held transmitters to the remaining two HomeLink buttons. This will erase previously programmed hand-held transmitter signals into HomeLink .
Page 70 Driver Controls Note: There are 30 seconds in which to initiate step eight. 8. Return to the vehicle and firmly press, hold for two seconds and release the HomeLink button. Repeat the press/hold/release sequence again, and, depending on the brand of the garage door opener (or other rolling code equipped device), repeat this sequence a third time to complete the programming.
Page 71 1. Press and hold the desired HomeLink button. Do NOT release the button. 2. The red indicator light will begin to flash after 20 seconds. Without releasing the HomeLink button, follow step 2 in the “Programming” section. For questions or comments, contact HomeLink at www.homelink.com or 1–800–355–3515.
Page 72 Driver Controls Deactivating overdrive Overdrive can be deactivated by pressing the Transmission Control Switch (TCS) on the gearshift handle. The Transmission Control Indicator Light will illuminate on the instrument cluster. The transmission will operate in all gears except overdrive. To return to normal overdrive mode, press the Transmission Control Switch again.
Page 73 Driver Controls Fuel filler door override release If the remote release is inoperative, open the trunk, then pull the override release handle located inside the trunk to open the fuel filler door. INTERIOR TRUNK CONTROL The remote trunk release control is located on the driver’s door trim panel and can be operated at any time.
Page 74 Driver Controls A driver’s first responsibility is the safe operation of the vehicle. The most important thing you can do to prevent a crash is to avoid distractions and pay attention to the road. Wait until it is safe to operate Mobile Communications Equipment.
Page 75: Locks And Security
KEYS The key operates all locks on your vehicle. In case of loss, replacement keys are available from your dealer. You should always carry a second key with you in a safe place in case you require it in an emergency. Refer to SecuriLock Passive Anti-Theft System for more information.
Page 76 Locks and Security Childproof door locks When these locks are set, the rear doors cannot be opened from the inside. The rear doors can be opened from the outside when the doors are unlocked. The childproof locks are located on rear edge of each rear door and must be set separately for each door.
Page 77: Anti-Theft System
Keep vehicle doors and luggage compartment locked and keep keys and remote transmitters out of a child’s reach. Unsupervised children could lock themselves in the trunk and risk injury. Children should be taught not to play in vehicles. On hot days, the temperature in the trunk or vehicle interior can rise very quickly.
Page 78 Locks and Security Unlocking the doors Press this control to unlock the driver’s door. The interior lamps will illuminate. Press the control a second time within five seconds to unlock all doors. Locking the doors Press this control to lock all doors. The horn will chirp and the parklamps/taillamps will flash to confirm the control was pressed.
Page 79 7. After a five to ten second delay, the door locks will cycle lock/unlock to confirm successful programming. 8. Turn the ignition to OFF. Sounding a panic alarm Press this control to activate the alarm. To deactivate the alarm, press the control again or turn the ignition to ACC or ON.
Page 80 Locks and Security To replace the battery: 1. Twist a thin coin between the two halves of the transmitter near the key ring. DO NOT TAKE THE FRONT PART OF THE TRANSMITTER APART. 2. Place the positive (+) side of new battery in the same orientation.
Page 81 Illuminated entry The interior lamps illuminate: when the remote entry system is used to unlock the door(s) or sound the panic alarm, or when the driver door is unlocked using the key in the driver door key cylinder. The system automatically turns off after 25 seconds after the UNLOCK button on the RUN or ACC position.
Page 82 Locks and Security 1. Enter the keyless entry keypad factory code. 2. Within 5 seconds, press and hold control 7/8. 3. Within 5 seconds (while holding down control 7/8), press and release control 3/4. 4. Release control 7/8. The door will lock/unlock to confirm the feature has been disabled. Once disabled, the feature can be enabled by repeating the same sequence.
Page 83 At your dealer. When using the keyless entry keypad, press the middle of each button in order to ensure a good activation. Programming your own entry code 1. Enter the factory-set code (keypad will illuminate when pressed). 2. Press the 1/2 control within five seconds of step 1.
Page 84 Locks and Security To unlock all doors, enter the factory-set code or personal code (driver door unlocks) and press 3/4 within five seconds. To release the trunk, enter the factory-set code or personal code (driver door unlocks) and press 5/6 within five seconds.
Page 85 When the ignition is in the OFF position, the indicator will flash once every 2 seconds to indicate the SecuriLock a theft deterrent. When the ignition is in the ON position, the indicator will glow for 3 seconds to indicate normal system functionality. If a problem occurs with the SecuriLock rapidly or glow steadily when the ignition is in the ON position.
Page 86 Locks and Security If any of these items are present, you need to keep these objects from touching the coded key while starting the engine. These objects and devices cannot damage the coded key, but can cause a momentary “no start”...
Page 87 Locks and Security 1. Insert the first previously programmed coded key into the ignition and turn the ignition from 3 (OFF) to 4 (ON) (maintain ignition in 4 (ON) for at least one second). 2. Turn ignition to 3 (OFF) then 2 (LOCK) and remove the first coded key from the ignition.
Page 88: Seating And Safety Restraints
Seating and Safety Restraints SEATING Adjustable head restraints Your vehicle’s seats are equipped with head restraints which are vertically adjustable. The purpose of these head restraints is to help limit head motion in the event of a rear collision. To properly adjust your head restraints, lift the head restraint so that it is located directly behind your head or as close to that position as possible.
Page 89 Seating and Safety Restraints Heated seats (if equipped) To operate the heated seats: Push the indicated side of the control for maximum heat. Push again to deactivate. Push the indicated side of the control for minimum heat. Push again to deactivate. The heated seat module resets at every ignition run cycle.
Page 90 Seating and Safety Restraints Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. Press the control to recline the seatback forward or backward. Press to move the seat forward or backward.
Page 91: Safety Restraints
Seating and Safety Restraints Press to move the rear portion of the seat cushion up or down. SAFETY RESTRAINTS Personal Safety System The Personal Safety System provides an improved overall level of frontal crash protection to front seat occupants and is designed to help further reduce the risk of air bag-related injuries.
Page 92 Seating and Safety Restraints information to the Restraints control module (RCM). During a crash, the RCM activates the safety belt pretensioners and/or either one or both stages of the dual-stage air bag supplemental restraints based on crash severity and occupant conditions. The fact that the pretensioners or air bags did not activate for both front seat occupants in a collision does not mean that something is wrong with the system.
Page 93 Seating and Safety Restraints injuries is to make sure all occupants are properly restrained. Accident statistics suggest that children are much safer when properly restrained in the rear seating positions than in the front. Air bags can kill or injure a child in a child seat. NEVER place a rear-facing child seat in front of an active air bag.
Page 94 Seating and Safety Restraints risk of force-related injuries to the occupant’s chest by limiting the load on the occupant. Refer to Energy management feature section in this chapter. Determining if the Personal safety system is operational The Personal safety system uses a warning light in the instrument cluster or a back-up tone to indicate the condition of the system.
Page 95 Seating and Safety Restraints All occupants of the vehicle, including the driver, should always properly wear their safety belts, even when an air bag (SRS) is provided. It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed.
Page 96 Seating and Safety Restraints Combination lap and shoulder belts 1. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) until you hear a snap and feel it latch. Make sure the tongue is securely fastened in the buckle.
Page 97 Seating and Safety Restraints Webbing extraction sensitive mode The webbing extraction sensitive mode stops the belt webbing from retracting if it is pulled out too quickly. Automatic locking mode In this mode, the shoulder belt is pre-locked. The belt will still retract to remove any slack in the shoulder belt.
Page 98 Seating and Safety Restraints How to disengage the automatic locking mode Ford Motor Company recommends that all passenger safety belt assemblies and attaching hardware should be inspected by a qualified technician after any collision to verify that the automatic locking retractor feature for child seats is still working properly. Safety belt assemblies should be inspected according to the procedures in the Workshop Manual and replaced if either damage or improper operation is noted.
Page 99 Seating and Safety Restraints Conditions of operation If... The driver’s safety belt is not buckled before the ignition switch is turned to the ON position... The driver’s safety belt is buckled while the indicator light is illuminated and the warning chime is sounding...
Page 100 Seating and Safety Restraints If... The driver’s and front passenger’s safety belts are buckled before the ignition switch is turned to the ON position or less than 1-2 minutes have elapsed since the ignition switch has been turned ON... The driver’s or front passenger’s safety belt is not buckled when the vehicle has reached at least 5 km/h (3 mph) and 1-2 minutes have...
Page 101 Seating and Safety Restraints Reasons given... Consider... “Belts are We design our safety belts to enhance comfort. If uncomfortable” you are uncomfortable - try different positions for the safety belt upper anchorage and seatback which should be as upright as possible; this can improve comfort.
Page 102 Seating and Safety Restraints same ignition cycle if the occupant buckles and remains buckled for approximately 30 seconds. Confirmation is not given for the one time disable. Deactivating/activating the BeltMinder feature The driver and front passenger BeltMinder are deactivated/activated independently. When deactivating/activating one seating position, do not buckle the other position as this will terminate the process.
Page 103 Seating and Safety Restraints This will enable the BeltMinder feature for that seating position if it is currently disabled. As confirmation, the restraint system warning light will flash 4 times per second for 3 seconds, followed by 3 seconds with the light off, then followed by the restraint system warning light flashing 4 times per second for 3 seconds again.
Page 104: Air Bags
Seating and Safety Restraints AIR BAG SUPPLEMENTAL RESTRAINT SYSTEM (SRS) Important SRS precautions The SRS is designed to work with the safety belt to help protect the driver and right front passenger from certain upper body injuries. Air bags DO NOT inflate slowly; there is a risk of injury from a deploying air bag.
Page 105 Do not attempt to service, repair, or modify the air bag supplemental restraint systems or its fuses. See your Ford or Lincoln Mercury dealer. The front passenger air bag is not designed to offer protection to an occupant in the center front seating position.
Page 106 Seating and Safety Restraints Children and air bags Children must always be properly restrained. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in the front seating position. Failure to follow these instructions may increase the risk of injury in a collision.
Page 107 Seating and Safety Restraints The air bags inflate and deflate rapidly upon activation. After air bag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder (to lubricate the bag) or sodium compounds (e.g., baking soda) that result from the combustion process that inflates the...
Page 108 Seating and Safety Restraints If the air bag has deployed, the air bag will not function again and must be replaced immediately. If the air bag is not replaced, the unrepaired area will increase the risk of injury in a collision.
Page 109 Do not attempt to service, repair, or modify the air bag SRS, its fuses or the seat cover on a seat containing an air bag. See your Ford or Lincoln Mercury dealer. All occupants of the vehicle should always wear their safety belts even when an air bag SRS is provided.
Page 110 Seating and Safety Restraints The side air bags are fitted on the outboard side of the seatbacks of the front seats. In certain lateral collisions, the air bag on the side affected by the collision will be inflated. The air bag was designed to inflate between the door panel and occupant to further enhance the protection provided occupants in side impact collisions.
Page 111: Child Restraints
Seating and Safety Restraints The readiness light will not illuminate immediately after ignition is turned on. A series of five beeps will be heard. The tone pattern will repeat periodically until the problem and/or light are repaired. If any of these things happen, even intermittently, have the SRS serviced at your dealership or by a qualified technician immediately.
Page 112 Seating and Safety Restraints Follow all the important safety restraint and air bag precautions that apply to adult passengers in your vehicle. If the shoulder belt portion of a combination lap and shoulder belt can be positioned so it does not cross or rest in front of the child’s face or neck, the child should wear the lap and shoulder belt.
Page 113 Seating and Safety Restraints Is the shoulder belt centered on the shoulder and chest? Can the child stay seated like this for the whole trip? Types of booster seats There are two types of belt-positioning booster seats: Those that are backless. If your backless booster seat has a removable shield, remove the shield and use the lap/shoulder...
Page 114 Seating and Safety Restraints never use a booster seat with a lap belt only. It is best to use a booster seat with lap/shoulder belts in the back seat- the safest place for children to ride. Follow all instructions provided by the manufacturer of the booster seat.
Page 115 Seating and Safety Restraints When installing a child safety seat: Review and follow the information presented in the Air bag supplemental restraint system (SRS) section in this chapter. Use the correct safety belt buckle for that seating position (the buckle closest to the direction the tongue is coming from).
Page 116 Seating and Safety Restraints Installing child safety seats with combination lap and shoulder belts Air bags can kill or injure a child in a child seat. NEVER place a rear-facing child seat in front of an active air bag. If you must use a forward-facing child seat in the front seat, move the seat all the way back.
Page 117 Seating and Safety Restraints 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted. 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until...
Page 118 Seating and Safety Restraints 7. Pull the lap belt portion across the child seat toward the buckle and pull up on the shoulder belt while pushing down with your knee on the child seat. 8. Allow the safety belt to retract to remove any slack in the belt.
Page 119 Seating and Safety Restraints The tether strap anchors in your vehicle are in the following positions (shown from top view): Attach the tether strap only to the appropriate tether anchor as shown. The tether strap may not work properly if attached somewhere other than the correct tether anchor.
Page 120 Seating and Safety Restraints 5. Clip the tether strap to the anchor as shown. If the tether strap is clipped incorrectly, the child safety seat may not be retained properly in the event of a collision. 6. Refer to the Installing child safety seats with combination lap and shoulder belts section of this chapter for further instructions to secure the child safety seat.
Page 121 LATCH attachments. Two plastic LATCH guides can be obtained at no charge from any Ford or Lincoln-Mercury dealer. They snap onto the LATCH lower anchors in the seat to help attach a child seat with rigid attachments. The guides hold the seat trim away to expose the anchor and make it easier to attach some child seats.
Page 122: Driving
Driving STARTING Positions of the ignition 1. ACCESSORY, allows the electrical accessories such as the radio to operate while the engine is not running. 2. LOCK, locks automatic transmission gearshift lever and allows key removal. 3. OFF, shuts off the engine and all accessories without locking the steering wheel.
Page 123 Do not park, idle, or drive your vehicle in dry grass or other dry ground cover. The emission system heats up the engine compartment and exhaust system, which can start a fire. Do not start your vehicle in a closed garage or in other enclosed areas.
Page 124 Driving Make sure the gearshift is in P (Park). Turn the key to 4 (ON) without turning the key to 5 (START). Make sure the corresponding lights illuminate or illuminate briefly. If a light fails to illuminate, have the vehicle serviced. If the driver’s safety belt is fastened, the light may not illuminate.
Page 125 Starting the engine 1. Turn the key to 4 (ON) without turning the key to 5 (START). 2. Turn the key to 5 (START), then release the key as soon as the engine starts. Excessive cranking could damage the starter. Note: If the engine does not start within five seconds on the first try, turn the key to 3 (OFF), wait 10 seconds and try again.
Page 126: Brakes
Driving BRAKES Your service brakes are self-adjusting. Refer to the scheduled maintenance guide for scheduled maintenance. Occasional brake noise is normal and often does not indicate a performance concern with the vehicle’s brake system. In normal operation, automotive brake systems may emit occasional or intermittent squeal or groan noises when the brakes are applied.
Page 127 Using ABS In an emergency or when maximum efficiency from the four-wheel ABS is required, apply continuous force on the brake. The four wheel ABS will be activated immediately, thus allowing you to retain full steering control of your vehicle and, providing there is sufficient space, will enable you to avoid obstacles and bring the vehicle to a controlled stop.
Page 128: Traction Control/Advancetrac
Driving The BRAKE warning lamp in the instrument cluster illuminates and remains illuminated (when the ignition is turned ON) until the parking brake is released. Always set the parking brake fully and make sure that the gearshift is securely latched in P (Park). The parking brake is not recommended to stop a moving vehicle.
Page 129 Wheel-speed sensors allow excess rear wheel spin to be detected by the Traction Control portion of the ABS computer. Any excessive wheel spin is controlled by automatically applying and releasing the rear brakes in conjunction with engine torque reductions. Engine torque reduction is realized via the fully electronic spark and fuel injection systems.
Page 130: Air Suspension
Driving To prevent damage to the power steering pump: Never hold the steering wheel to the extreme right or the extreme left for more than a few seconds when the engine is running. Do not operate the vehicle with the power steering pump fluid level below the MIN mark on the reservoir.
Page 131: Transmission Operation
The air suspension shut-off switch is located on the left side of the trunk. If this switch is in the OFF position, the rear air suspension will not operate. On vehicles equipped with Air Suspension, turn OFF the Air Suspension switch prior to jacking, hoisting or towing your vehicle.
Page 132 Driving Do not drive your vehicle until you verify that the brakelamps are working. Always set the parking brake fully and make sure the gearshift is latched in P (Park). Turn the ignition to the LOCK position and remove the key whenever you leave your vehicle. If the parking brake is fully released, but the brake warning lamp remains illuminated, the brakes may not be working properly.
Page 133 R (Reverse) With the gearshift lever in R (Reverse), the vehicle will move backward. Always come to a complete stop before shifting into and out of R (Reverse). N (Neutral) With the gearshift lever in N (Neutral), the vehicle can be started and is free to roll.
Page 134 Driving Overdrive can be deactivated by pressing the transmission control switch on the gearshift handle. The transmission control indicator light (TCIL) will illuminate on the instrument cluster. Drive Not shown on the display. Activate by pressing the transmission control switch on the gearshift lever with the gearshift in the Drive position. The O/D OFF indicator will illuminate in the instrument cluster.
Page 135 2 (Second) Use 2 (Second) to start-up on slippery roads or to provide additional engine braking on downgrades. 1 (First) Use 1 (Low) to provide maximum engine braking on steep downgrades. Upshifts can be made by shifting to 2 (Second) or to Overdrive.
Page 136: Vehicle Loading
Driving Extended use of other than the manufacturer’s specified size tires on a limited slip rear axle could result in a permanent reduction in effectiveness. This loss of effectiveness does not affect normal driving and should not be noticeable to the driver. DRIVING THROUGH WATER Do not drive quickly through standing water, especially if the depth is unknown.
Page 137 GCW (Gross Combined Weight): The combined weight of the towing vehicle (including occupants and cargo) and the loaded trailer. GCWR (Gross Combined Weight Rating): Maximum permissible combined weight of the towing vehicle (including occupants and cargo) and the loaded trailer. Maximum Trailer Weight Rating: Maximum weight of a trailer the vehicle is permitted to tow.
Page 138: Trailer Towing
Driving The weight of your loaded trailer should not exceed 907 kg (2,000 lbs). The GCW of your vehicle and trailer should not exceed 2,993 kg (6,600 lbs). TRAILER TOWING Your vehicle is classified as a light duty towing vehicle. Do not tow a trailer until your vehicle has been driven at least 3,200 km (2,000 miles).
Page 139 Do not connect a trailer’s hydraulic brake system directly to your vehicle’s brake system. Your vehicle may not have enough braking power and your chances of having a collision greatly increase. The braking system of the tow vehicle is rated for operation at the GVWR not GCWR.
Page 140 Driving The trailer tongue weight should be 10–15% of the loaded trailer weight. After you have traveled 80 km (50 miles), thoroughly check your hitch, electrical connections and trailer wheel lug nuts. To aid in engine/transmission cooling and A/C efficiency during hot weather while stopped in traffic, place the gearshift lever in P (Park).
Page 141 Driving Maximum distance is 80 km (50 miles) If a distance of 80 km (50 miles) or a speed of 56 km/h (35 mph) must be exceeded, you must disconnect the driveshaft. Ford recommends the driveshaft be removed/installed only by a qualified technician. See your local dealer for driveshaft removal/installation.
Page 142: Roadside Emergencies
In the United States, this card is found in the Owner Guide portfolio in the glove compartment in Ford vehicles and is mailed to you if you own a Mercury or Lincoln. In Canada, the card is found in the Owner Information Guide in the glove compartment.
Page 143: Hazard Flasher Switch
If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount. To obtain reimbursement information, U.S. Ford or Mercury vehicles customers call 1-800-241-3673; Lincoln vehicle customers call 1–800–521–4140. Canadian customers who need to obtain reimbursement information, call 1–800–665–2006.
Page 144: Fuses And Relays
Roadside Emergencies The fuel pump shut-off switch is located on the left side of the trunk behind the left rear tail light and the trunk liner. Use the following procedure to reset the fuel pump shut-off switch. 1. Turn the ignition to the OFF position. 2.
Page 145 Note: Always replace a fuse with one that has the specified amperage rating. Using a fuse with a higher amperage rating can cause severe wire damage and could start a fire. Standard fuse amperage rating and color Fuse Mini Standard rating fuses fuses...
Page 146 Roadside Emergencies The fuses are coded as follows. Fuse/Relay Fuse Amp Location Rating Audio, CD changer Audio 7.5A Mirrors Air bags — Not used Instrument cluster warning lamps module, Overdrive control switch, Lighting Control Module (LCM), Police vehicle option Driver’s Door Module (DDM), Audio (Start) Powertrain Control Module (PCM) power relay, Coil-on plugs, Radio noise capacitor,...
Page 147 Fuse/Relay Fuse Amp Passenger Compartment Fuse Panel Location Rating Traction control indicator relay (ABS w/traction control only) Multi-function switch for turn/hazard lamps Audio (Run/Accy) Anti-lock Brake System (ABS), Instrument Cluster Speed control, Police vehicle option, LCM, Clock, EATC blower motor relay, Door lock switch illumination Reversing lamps, Shift lock, DRL module, VAP Steering, Electronic day/night mirror,...
Page 148 Roadside Emergencies Fuse/Relay Fuse Amp Location Rating — Not used — Not used * Circuit breaker Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. Always disconnect the battery before servicing high current fuses.
Page 149 The high-current fuses are coded as follows. Fuse/Relay Fuse Amp Power Distribution Box Description Location Rating 25A* Audio 20A* Power point 25A* Heated seats 15A* Horns 20A* Fuel pump – Not used 25A* Moonroof 20A* Driver’s Door Module (DDM) – Not used —...
Page 150 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Description Location Rating 40A** Anti-lock Brake System (ABS) — Not used — Not used – Not used – Not used – Not used 50A** Ignition switch 50A** Feeds IP fuses 3, 5, 21, 23, 25, 27 30A** VAP Steering, Air suspension compressor, Instrument cluster...
Page 151: Changing Tires
Fuse/Relay Fuse Amp Power Distribution Box Description Location Rating — Not used 20A** Adjustable pedals, Power seat, Locks, Decklid, Lumbar * Mini fuse ** Circuit breaker/Maxi fuse Relays Relays are located in the power distribution box and should be replaced by qualified technicians.
Page 152 Roadside Emergencies use the wheel for any other type of vehicle. use more than one temporary spare tire at a time. Use of a temporary spare tire at any one wheel location can lead to impairment of the following: Handling, stability and braking performance Comfort and noise Ground clearance and parking at curbs Winter driving capability...
Page 153 3. To remove the mini-spare tire, remove the spare tire cover, turn the hold-down nut counterclockwise, then remove the spare tire. The jack is located under the spare tire. The tie-down fastener for the road tire is located in the bag under the spare tire.
Page 154 Roadside Emergencies 5. Loosen each wheel lug nut one-half turn counterclockwise but do not remove them until the wheel is raised off the ground. Before placing the jack under the vehicle, NOTE the jack location markings: JACK LOCATION-FRONT The jack location markings can be found on the lower outer edge of the body.
Page 155 Position the jack according to the following guides and turn the jack handle clockwise until the wheel is completely off the ground. To lessen risk of personal injury, do not put any part of your body under the vehicle while changing a tire. Do not start the engine when your vehicle is on the jack.
Page 156: Jump Starting
Roadside Emergencies 9. Remove the jack and fully tighten the lug nuts in the order shown. 10. Put flat tire, jack and lug wrench away. When stowing the flat tire, be sure to tie down the tire by turning the fastener clockwise until snug. Note: To make sure the road wheel is properly stowed: Place the jack bag on the trunk shelf as shown in the illustration.
Page 157 Roadside Emergencies Preparing your vehicle When the battery is disconnected or a new battery is installed, the transmission must relearn its shift strategy. As a result, the transmission may have firm and/or soft shifts. This operation is considered normal and will not affect function or durability of the transmission.
Page 158 Roadside Emergencies 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery. 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery.
Page 159 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system. Do not use fuel lines, engine rocker covers or the intake manifold as grounding points. Do not connect the end of the second cable to the negative (-) terminal of the battery to be jumped.
Page 160 Roadside Emergencies Removing the jumper cables Remove the jumper cables in the reverse order that they were connected. 1. Remove the jumper cable from the ground metal surface. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2.
Page 161 Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 162: Wrecker Towing
Roadside Emergencies WRECKER TOWING If you need to have your vehicle towed, contact a professional towing service or, if you are a member of a roadside assistance program, your roadside assistance service provider. It is recommended that your vehicle be towed with a wheel lift or flatbed equipment.
Page 163: Customer Assistance
Ford Customer Relationship Center. Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
Page 164 P.O. Box 2000 Oakville, Ontario L6J 5E4 1-800-565-3673 (FORD) www.ford.ca In order to help you service your Ford or Lincoln Mercury vehicle, please have the following information available when contacting a Customer Relationship Center: Your telephone number (home and business)
Page 165 Warranty expires. You may purchase Ford ESP from any participating Ford and Lincoln Mercury and Ford of Canada dealer. There are several plans available in various time, distance and deductible combinations which can be tailored to fit your own driving needs. Ford ESP also offers reimbursement benefits for towing and rental coverage.
Page 166 What kinds of cases does the Board review? Unresolved warranty repair concerns or vehicle performance concerns as on Ford and Lincoln Mercury cars and Ford and Lincoln Mercury light trucks which are within the terms of any applicable written new vehicle...
Page 167 A Ford or Lincoln Mercury dealership representative Consumer candidates for Board membership are recruited and trained by an independent consulting firm. The dealership Board member is chosen from Ford and Lincoln Mercury dealership management, recognized for their business leadership qualities. What the Board needs...
Page 168 Customer Assistance Oral presentations If you would like to make an oral presentation, indicate YES to question 6 on the application. While it is your right to make an oral presentation before the Board, this is not a requirement and the Board will decide the case whether or not an oral presentation is made.
Page 169 Customer Assistance UTILIZING THE MEDIATION/ARBITRATION PROGRAM (CANADA ONLY) In those cases where you continue to feel that the efforts by Ford and the dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 170 Customer Assistance If your vehicle must be serviced while you are traveling or living in Central or South America, the Caribbean, or the Middle East, contact the nearest Ford dealership. If the dealership cannot help you, write or call: FORD MOTOR COMPANY WORLDWIDE DIRECT MARKET OPERATIONS 1555 Fairlane Drive Fairlane Business Park #3...
Page 171 Customer Assistance IN CALIFORNIA (U.S. ONLY) California Civil Code Section 1793.2(d) requires that, if a manufacturer or its representative is unable to repair a motor vehicle to conform to the vehicle’s applicable express warranty after a reasonable number of attempts, the manufacturer shall be required to either replace the vehicle with one substantially identical or repurchase the vehicle and reimburse the buyer in an amount equal to the actual price paid or payable by the consumer (less a reasonable allowance for consumer...
Page 172: Reporting Safety Defects (U.s. Only)
Customer Assistance REPORTING SAFETY DEFECTS (U.S. ONLY) If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Ford Motor Company. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 173: Cleaning
WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral Ph shampoo, such as Motorcraft Detail Wash (ZC-3–A), which is available from your dealer. Never use strong household detergents or soap, such as dish washing or laundry liquid.
Page 174 Cleaning PAINT CHIPS Your dealer has touch-up paint and sprays to match your vehicle’s color. Take your color code (printed on a sticker in the driver’s door jam) to your dealer to ensure you get the correct color. Remove particles such as bird droppings, tree sap, insect deposits, tar spots, road salt and industrial fallout before repairing paint chips.
Page 175 Do not spray a hot engine with cold water to avoid cracking the engine block or other engine components. Spray Motorcraft Engine Shampoo and Degreaser (ZC-20) on all parts that require cleaning and pressure rinse clean. Cover the highlighted areas to prevent water damage when cleaning the engine.
Page 176 Cleaning WINDOWS AND WIPER BLADES The windshield, rear window and wiper blades should be cleaned regularly. If the wiper does not wipe properly, substances on the windshield, rear window or the wiper blades may be the cause. These may include hot wax treatments used by commercial car washes, tree sap, or other organic contamination.
Page 177 INTERIOR For fabric, carpets, cloth seats, safety belts and seats equipped with side air bags: Remove dust and loose dirt with a vacuum cleaner. Remove light stains and soil with Ford Extra Strength Upholstery Cleaner (E8AZ-19523–AA). If grease or tar is present on the material, spot-clean the area first with Motorcraft Spot and Stain Remover (ZC-14).
Page 178 Cleaning FORD, LINCOLN AND MERCURY CAR CARE PRODUCTS Your Ford, Lincoln or Mercury dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and appearance of your vehicle.
Page 179: Maintenance And Specifications
Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle: We highlight do-it-yourself items in the engine compartment for easy location. We provide a scheduled maintenance guide which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide the necessary parts and service.
Page 180 Maintenance and Specifications OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located under the instrument panel. 2. Go to the front of the vehicle and release the auxiliary latch that is located under the front of the hood. 3.
Page 181: Engine Compartment
Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 4.6L DOHC V8 engine 1. Automatic transmission fluid dipstick 2. Engine oil filler cap 3. Engine oil dipstick 4. Brake fluid reservoir 5. Windshield washer fluid reservoir 6. Air filter assembly 7.
Page 182: Engine Oil
Maintenance and Specifications WINDSHIELD WASHER FLUID Add fluid to fill the reservoir if the level is low. In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specification WSB-M8B16–A2. Refer to Lubricant specifications in this chapter.
Page 183 Maintenance and Specifications 5. Locate and carefully remove the engine oil level indicator (dipstick). 6. Wipe the indicator clean. Insert the indicator fully, then remove it again. If the oil level is between the MIN and MAX marks, the oil level is acceptable.
Page 184 Maintenance and Specifications Adding engine oil 1. Check the engine oil. For instructions, refer to Checking the engine oil in this chapter. 2. If the engine oil level is not within the normal operating range, add only certified engine oil of the recommended viscosity. Remove the engine oil filler cap and use a funnel to pour the engine oil into the opening.
Page 185 Maintenance and Specifications SAE 5W-20 engine oil is recommended. Only use oils “Certified For Gasoline Engines” by the American Petroleum Institute (API). Use Motorcraft or an equivalent oil meeting Ford specification WSS-M2C153–H. SAE 5W-20 oil provides optimum fuel economy and durability performance meeting all requirements for your vehicle’s engine.
Page 186: Battery
Maintenance and Specifications BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which normally does not require additional water during its life of service. However, for severe usage or in high temperature climates, check the battery electrolyte level. Refer to the scheduled maintenance guide for the service interval schedules.
Page 187 Maintenance and Specifications When lifting a plastic-cased battery, excessive pressure on the end walls could cause acid to flow through the vent caps, resulting in personal injury and/or damage to the vehicle or battery. Lift the battery with a battery carrier or with your hands on opposite corners.
Page 188 Maintenance and Specifications Always dispose of automotive batteries in a responsible manner. Follow your local authorized standards for disposal. Call your local authorized recycling center to find out more about recycling automotive batteries. ENGINE COOLANT Checking engine coolant The concentration and level of engine coolant should be checked at the mileage intervals listed in the scheduled maintenance guide.
Page 189 Maintenance and Specifications When the engine is cold, check the level of the engine coolant in the reservoir. The engine coolant should be at the “cold fill level” or within the “cold fill range” as listed on the engine coolant reservoir (depending upon application).
Page 190 Maintenance and Specifications ESE-M97B44–A or yellow-colored Motorcraft Premium Gold Engine Coolant meeting Ford Specification WSS-M97B51–A1. To determine your vehicle’s coolant type (color), check your coolant reservoir. Add Motorcraft Premium Engine Coolant (green-colored), VC-4–A (U.S.) or CXC-10 (Canada) or Motorcraft Premium Gold Engine Coolant (yellow-colored), VC-7–A (VC-7–B in Oregon), depending on the type of coolant originally equipped in your vehicle.
Page 191 Maintenance and Specifications To reduce the risk of personal injury, make sure the engine is cool before unscrewing the coolant pressure relief cap. The cooling system is under pressure; steam and hot liquid can come out forcefully when the cap is loosened slightly. 1.
Page 192 Maintenance and Specifications 7. Install the coolant bypass bleed plug. Be sure plug is tight. 8. Fill the coolant reservoir slowly with the proper coolant mixture (see above), to within the “cold fill range” or the “cold full” level on the reservoir.
Page 193 Maintenance and Specifications Used engine coolant should be disposed of in an appropriate manner. Follow your community’s regulations and standards for recycling and disposing of automotive fluids. Coolant refill capacity To find out how much fluid your vehicle’s cooling system can hold, refer to Refill capacities in this chapter.
Page 194: Fuel Information
Maintenance and Specifications WHAT YOU SHOULD KNOW ABOUT AUTOMOTIVE FUELS Important safety precautions Do not overfill the fuel tank. The pressure in an overfilled tank may cause leakage and lead to fuel spray and fire. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
Page 195 Maintenance and Specifications Avoid getting fuel liquid in your eyes. If fuel is splashed in the eyes, remove contact lenses (if worn), flush with water for 15 minutes and seek medical attention. Failure to seek proper medical attention could lead to permanent injury. Fuels can also be harmful if absorbed through the skin.
Page 196 Maintenance and Specifications Fuel Filler Cap Your fuel tank filler cap has an indexed design with a 1/8 turn on/off feature. When fueling your vehicle: 1. Turn the engine off. 2. Carefully turn the filler cap counterclockwise 1/8 of a turn until it stops.
Page 197 Maintenance and Specifications Your vehicle was not designed to use fuel or fuel additives with metallic compounds, including manganese-based compounds containing MMT. Repairs to correct the effects of using a fuel for which your vehicle was not designed may not be covered by your warranty. Octane recommendations Your vehicle is designed to use “Premium”...
Page 198 Maintenance and Specifications Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality. Running out of fuel Avoid running out of fuel because this situation may have an adverse affect on powertrain components. If you have run out of fuel: You may need to cycle the ignition from OFF to ON several times after refueling, to allow the fuel system to pump the fuel from the tank to the engine.
Page 199 Maintenance and Specifications amount of fuel in a full tank and a tank when the fuel gauge indicates empty. Empty reserve is the small amount of fuel remaining in the fuel tank after the fuel gauge indicates empty. The amount of usable fuel in the empty reserve varies and should not be relied upon to increase driving range.
Page 200 Maintenance and Specifications economy under current driving conditions. Additionally, keeping records during summer and winter will show how temperature impacts fuel economy. In general, lower temperatures give lower fuel economy. Driving style — good driving and fuel economy habits Give consideration to the lists that follow and you may be able to change a number of variables and improve your fuel economy.
Page 201 Maintenance and Specifications Perform all regularly scheduled maintenance items. Follow the recommended maintenance schedule and owner maintenance checks found in your vehicle scheduled maintenance guide. Conditions Heavily loading a vehicle or towing a trailer may reduce fuel economy at any speed. Carrying unnecessary weight may reduce fuel economy (approximately 0.4 km/L [1 mpg] is lost for every 180 kg [400 lb] of weight carried).
Page 202 Maintenance and Specifications Do not turn off the ignition while your vehicle is moving, especially at high speeds. Have the items listed in your scheduled maintenance guide performed according to the specified schedule. The scheduled maintenance items listed in the scheduled maintenance guide are essential to the life and performance of your vehicle and to its emissions system.
Page 203 Maintenance and Specifications If the vehicle’s powertrain system or its battery has just been serviced, the on-board diagnostics system is reset to a “not ready for I/M test” condition. To ready the on-board diagnostics system for I/M testing, a minimum of 30 minutes of city and highway driving is necessary as described below: First, at least 10 minutes of driving on an expressway or highway.
Page 204 Maintenance and Specifications 4. Check the fluid level in the reservoir. It should be between the MIN and MAX lines. Do not add fluid if the level is in this range. 5. If the fluid is low, add fluid in small amounts, continuously checking the level until it reaches the range between the MIN and MAX lines.
Page 205 Maintenance and Specifications 2. Park the vehicle on a level surface and engage the parking brake. 3. With the parking brake engaged and your foot on the brake pedal, start the engine and move the gearshift lever through all of the gear ranges.
Page 206: Air Filter(S)
Maintenance and Specifications High fluid level Fluid levels above the safe range may result in transmission failure. An overfill condition of transmission fluid may cause shift and/or engagement concerns and/or possible damage. High fluid levels can be caused by an overheating condition. Adjusting automatic transmission fluid levels Before adding any fluid, make sure the correct type is used.
Page 207 Maintenance and Specifications 4. Wipe the air filter housing and cover clean to remove any dirt or debris and to ensure good sealing. 5. Install a new air filter element. Be careful not to crimp the filter element edges between the air filter housing and cover.
Page 208 Maintenance and Specifications Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 1/2) times as well on the government course as a tire graded 100.
Page 209 Maintenance and Specifications SERVICING YOUR TIRES Checking the tire pressure Use an accurate tire pressure gauge. Check the tire pressure when tires are cold, after the vehicle has been parked for at least one hour or has been driven less than 5 km (3 miles).
Page 210 Maintenance and Specifications Replacing the tires Replace the tires when the wear band is visible through the tire treads. When replacing full size tires, never mix radial bias-belted, or bias-type tires. Use only the tire sizes that are listed on the Certification or Tire Label.
Page 211: Part Numbers
Maintenance and Specifications MOTORCRAFT PART NUMBERS Component Air filter element Fuel filter Battery-standard Oil filter PCV valve Spark plugs* * Refer to Vehicle Emissions Control Information (VECI) decal for spark plug gap information. REFILL CAPACITIES Fluid Ford Part Name Engine oil (includes Motorcraft SAE 5W-20 filter change) Premium Synthetic...
Page 212: Lubricant Specifications
Maintenance and Specifications Fluid Ford Part Name Windshield washer Motorcraft Premium fluid Windshield Washer Concentrate Use only brake fluids certified to meet Ford specifications. Refer to Lubricant Specifications in this chapter. DOT 3 fluid is recommended. However, if DOT 3 is not available, DOT 4 fluid can be used. Ensure the correct automatic transmission fluid is used.
Page 213 Maintenance and Specifications Item Ford part name Engine coolant Motorcraft Premium Engine Coolant (green-colored) Motorcraft Premium Gold Engine Coolant (yellow-colored) Engine oil Motorcraft SAE 5W-20 Premium Synthetic Blend Motor Oil Hinges, latches, Multi-Purpose striker plates, Grease fuel filler door hinge and seat tracks Lock cylinders Penetrating and...
Page 214 Maintenance and Specifications Use only brake fluids certified to meet Ford specifications. DOT 3 fluid is recommended. However, if DOT 3 is not available, DOT 4 fluid can be used. Add 118 ml (4 oz.) of Additive Friction Modifier XL-2 or equivalent meeting Ford specification EST-M2C118-A for complete refill of Traction-Lok rear axles.
Page 215 Maintenance and Specifications...
Page 216 Maintenance and Specifications IDENTIFYING YOUR VEHICLE Certification label The National Highway Traffic Safety Administration Regulations require that a Certification label be affixed to a vehicle and prescribe where the Certification label may be located. The Certification label is located on the front door latch pillar on the driver’s side.
Page 217 Maintenance and Specifications 1. World manufacturer identifier 2. Brake type and gross vehicle weight rating (GVWR) 3. Vehicle line, series, body type 4. Engine type 5. Check digit 6. Model year 7. Assembly plant 8. Production sequence number Engine number The engine number (the last eight numbers of the vehicle identification number) is stamped on the engine block, transmission, frame and transfer case (if equipped).
Page 218: Accessories
FORD ACCESSORIES FOR YOUR VEHICLE A wide selection of genuine Ford accessories are available for your vehicle through your local authorized Ford, Lincoln, Mercury or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
Page 219 Accessories Travel equipment Cargo net Daytime running lights (DRL) Protection and appearance equipment All-weather floor mats “B” Pillar ecterior trim Carpeted floor mats Car cover with Marauder logo Decklid spoiler Door edge guards First aid kit Flat splash guards Highway safety kit Locking gas cap Molded splash guards Rear spoiler...
Page 220 Accessories For maximum vehicle performance, keep the following information in mind when adding accessories or equipment to your vehicle: When adding accessories, equipment, passengers and luggage to your vehicle, do not exceed the total weight capacity of the vehicle or of the front or rear axle (GVWR or GAWR as indicated on the Safety compliance certification label).
Page 221: Index
ABS (see Brakes) ...126 Air bag supplemental restraint system ...104, 108 and child safety seats ...106 description ...104, 108 disposal ...111 driver air bag ...106, 109 indicator light ...12, 108, 110 operation ...106, 109 passenger air bag ...106, 109 side air bag ...108 Air cleaner filter ...206, 211 Air conditioning ...33 Air suspension ...130...
Page 222 Index Child safety seats ...114 attaching with tether straps ...118 in front seat ...116 in rear seat ...116 Cleaning your vehicle engine compartment ...174 instrument panel ...176 interior ...177 interior trim ...176 plastic parts ...175 washing ...173 waxing ...173 wheels ...174 wiper blades ...176 Climate control (see Air conditioning or Heating) ...33...
Page 223 idle speed control ...186 lubrication specifications ...212, 214 refill capacities ...211 service points ...181 starting after a collision ...143 Engine block heater ...125 Engine oil ...182 change oil soon warning, message center ...182 checking and adding ...182 dipstick ...182 filter, specifications ...184, 211 recommendations ...184 refill capacities ...211 specifications ...212, 214...
Page 224 Index Hazard flashers ...143 Head restraints ...88 Headlamps ...38 aiming ...40 autolamp system ...38 bulb specifications ...43 daytime running lights ...39 flash to pass ...40 high beam ...14, 39 replacing bulbs ...44 turning on and off ...38 warning chime ...14 Heating heating and air conditioning system ...33...
Page 225 traction control active ...13 turn signal indicator ...14 Limited-slip axle ...135 Load limits ...136 GAWR ...136 GVWR ...136 trailer towing ...136 Locks autolock ...81 childproof ...76 doors ...75 Lubricant specifications ...212, 214 Lumbar support, seats ...88 Mirrors ...51 automatic dimming rearview mirror ...62 fold away ...62 heated ...62...
Page 226 Index Safety restraints ...91, 94, 96–98 belt minder ...99 cleaning the safety belts ...103 extension assembly ...103 for adults ...96–98 for children ...111 Occupant Classification Sensor ...92 warning light and chime ...12, 14, 98–99 Safety seats for children ...114 Seat belts (see Safety restraints) ...91 Seats ...88 child safety seats ...114...
Page 227 Warning chimes ...14 Warning lights (see Lights) ...10 Washer fluid ...182 Water, Driving through ...136 Windows power ...60 Index Windshield washer fluid and wipers checking and adding fluid ...182 checking and cleaning ...49 operation ...49 replacing wiper blades ...49 Wrecker towing ...162...

Mercury 2003 Marauder Owner's Manual

Introduction

Instrument Cluster

Entertainment Systems

Climate Controls

Lights

Driver Controls

Locks and Security

Seating and Safety Restraints

Driving

Roadside Emergencies

Customer Assistance

Cleaning

Maintenance and Specifications

Quick Links

Table of Contents

Related Manuals for Mercury 2003 Marauder

Summary of Contents for Mercury 2003 Marauder

Table of Contents
