Page 3 Mazda North American Operations Important Notes About This Manual Keep this manual in the glove box as a handy reference for the safe and enjoyable use of your Mazda. Should you resell the vehicle, leave this manual with it for the next owner.
Page 4: How To Use This Manual
Illustrations complement the words of the manual to best explain how to enjoy your Mazda. By reading your manual, you can find out about the features, important safety information, and driving under various road conditions.
Page 5: Table Of Contents
J56J_8S11-EA-03G_Edition1.book Page 5 Tuesday, June 24, 2003 6:29 PM Your Vehicle at a Glance Interior, exterior views and part identification of your Mazda. Essential Safety Equipment Use of safety equipment, including seats, seat belt system, SRS air bags and child-restraint systems.
Page 6 J56J_8S11-EA-03G_Edition1.book Page 6 Tuesday, June 24, 2003 6:29 PM...
Page 7: Your Vehicle At A Glance
J56J_8S11-EA-03G_Edition1.book Page 1 Tuesday, June 24, 2003 6:29 PM Your Vehicle at a Glance Interior, exterior views and part identification of your Mazda. Dashboard Overview ... 1-2 Interior Overview ... 1-3 Exterior Overview ... 1-4 Form No. 8S11-EA-03G...
Page 8: Dashboard Overview
J56J_8S11-EA-03G_Edition1.book Page 2 Tuesday, June 24, 2003 6:29 PM Your Vehicle at a Glance Dashboard Overview Driver-side air bag (page 2-36) Instrument cluster (page 5-25) Lighting control/Turn signals (page 5-40) Fog lights switch* (page 5-42) Power window switches (page 3-14) Power window lock switch (page 3-15) Hood release handle...
Page 9: Interior Overview
J56J_8S11-EA-03G_Edition1.book Page 3 Tuesday, June 24, 2003 6:29 PM Sunvisors (page 6-41) Curtain air bags* (page 2-36) Interior light (page 6-41) Rear seat (page 2-9) Seat belts (page 2-12) Form No. 8S11-EA-03G Your Vehicle at a Glance Interior Overview Map light (page 6-43) Rearview mirror (page 3-26)
Page 10: Exterior Overview
J56J_8S11-EA-03G_Edition1.book Page 4 Tuesday, June 24, 2003 6:29 PM Your Vehicle at a Glance Exterior Overview Antenna (page 6-16) High-mount brake light (page 8-30) Trunk lid (page 3-10) Taillight (page 8-30) License plate lights (page 8-30) Reverse lights (page 8-30) Headlights (page 8-30) Windshield wiper blades...
Page 11: Essential Safety Equipment
J56J_8S11-EA-03G_Edition1.book Page 1 Tuesday, June 24, 2003 6:29 PM Essential Safety Equipment Use of safety equipment, including seats, seat belt system, SRS air bags and child-restraint systems. Seats ... 2-2 Front Seats (Manually Operated Seats) ... 2-2 Front Seats (Electrically Operated Seats) ... 2-5 Rear Seat ...
Page 12: Seats
J56J_8S11-EA-03G_Edition1.book Page 2 Tuesday, June 24, 2003 6:29 PM Essential Safety Equipment Seats Front Seats (Manually Operated Seats) WARNING Securing the Seats: Adjustable seats and seatbacks that are not securely locked are dangerous. In a sudden stop or collision, the seat or seatback could move, causing injury.
Page 13 J56J_8S11-EA-03G_Edition1.book Page 3 Tuesday, June 24, 2003 6:29 PM M Seat Recline WARNING Reclining: Sitting in a reclined position while the vehicle is moving is dangerous because you don’t get the full protection from seat belts. During sudden braking or a collision, you can slide under the lap belt and suffer serious internal injuries.
Page 14 J56J_8S11-EA-03G_Edition1.book Page 4 Tuesday, June 24, 2003 6:29 PM Essential Safety Equipment Seats M Height Adjustment (Driver’s Seat) By moving the seat lever up or down, the seat bottom height can be adjusted. Down Lever Form No. 8S11-EA-03G M Head Restraint WARNING Head Restraints Adjustment: Driving with the head restraints...
Page 15: Front Seats (Electrically Operated Seats)
Such modification could damage the supplemental restraint system and result in serious injury. Consult an Authorized Mazda Dealer if there is any need to remove or reinstall the front seats. Damaged Front Seats: Driving with damaged front seats is dangerous.
Page 16 J56J_8S11-EA-03G_Edition1.book Page 6 Tuesday, June 24, 2003 6:29 PM Essential Safety Equipment Seats CAUTION • The seat-bottom power adjustment is operated by motors. Avoid extended operation because excessive use can damage the motors. • To prevent the battery from running down, avoid using the power adjustment when the engine is stopped.
Page 17 J56J_8S11-EA-03G_Edition1.book Page 7 Tuesday, June 24, 2003 6:29 PM M Height Adjustment (Driver’s Seat) Front height adjustment To adjust the front height of the seat- bottom, raise or lower the front of the slide lifter switch on the left side of the seat.
Page 18 J56J_8S11-EA-03G_Edition1.book Page 8 Tuesday, June 24, 2003 6:29 PM Essential Safety Equipment Seats M Head Restraint WARNING Head Restraints Adjustment: Driving with the head restraints adjusted too low or removed is dangerous. With no support behind your head, your neck could be seriously injured in a collision.
Page 19: Rear Seat
J56J_8S11-EA-03G_Edition1.book Page 9 Tuesday, June 24, 2003 6:29 PM Rear Seat WARNING Stacking Cargo: Stacking luggage or other cargo higher than the seatbacks, and placing articles on the rear package tray is dangerous. During sudden braking or a collision, objects can fly around and become projectiles that may hit and injure passengers.
Page 20 J56J_8S11-EA-03G_Edition1.book Page 10 Tuesday, June 24, 2003 6:29 PM Essential Safety Equipment Seats M Split-Folding Rear Seatback The seatbacks can be folded down to provide more space in the luggage compartment. To fold the seatbacks WARNING Folding Seatbacks with Remote Handle Levers: Not checking the rear seat area before folding the seatbacks with the remote...
Page 21 J56J_8S11-EA-03G_Edition1.book Page 11 Tuesday, June 24, 2003 6:29 PM To return the seatbacks to the upright position 1. Lift the seatbacks upright. Pull on the tops of the seatbacks from inside the vehicle to make sure they are locked. 2. Fasten the rear-center lap/shoulder belt and check that all seat belts are routed properly for passenger use (page 2-19).
Page 22: Seat Belt Systems
Seat belts help to decrease the possibility of severe injury during accidents and sudden stops. Mazda recommends that the driver and all passengers always wear seat belts. All of the seat belt retractors are designed to keep the lap/shoulder belts out of the way when not in use.
Page 23 J56J_8S11-EA-03G_Edition1.book Page 13 Tuesday, June 24, 2003 6:29 PM Belt retraction may become difficult if the belts and rings are soiled, so try to keep them clean. Ring M Pregnant Women and Persons with Serious Medical Conditions Pregnant women should wear seat belts. Ask your doctor for specific recommendations. The lap belt should be worn SNUGLY AND AS LOW AS POSSIBLE OVER THE HIPS.
Page 24 J56J_8S11-EA-03G_Edition1.book Page 14 Tuesday, June 24, 2003 6:29 PM Essential Safety Equipment Seat Belt Systems M Emergency Locking Mode If the belt has fully retracted, it will always be in the emergency locking mode until you move it into automatic locking mode by pulling the belt all the way out to its full length. In the emergency locking mode, the belt remains comfortable on the occupant and the retractor will lock in position during a collision.
Page 25: 3-Point Type Seat Belt
J56J_8S11-EA-03G_Edition1.book Page 15 Tuesday, June 24, 2003 6:29 PM 3-Point Type Seat Belt NOTE When using the rear center seat belt, refer to "Rear Center Position Seat Belt" (page 2-19). M Fastening the Seat Belts 1. Grasp the buckle and tongue. 2.
Page 26 NOTE If a belt does not fully retract, inspect it for kinks and twists. If it is still not retracting properly, have it inspected at an Authorized Mazda Dealer. 2-16 Form No. 8S11-EA-03G M Shoulder Belt Adjuster Adjust the height of the shoulder belt if the seat belt touches your neck, or if it crosses your arm instead of your shoulder.
Page 27: Front Seat Belt Pretensioner And Load Limiting Systems
If the seat belt pretensioners are not replaced, the risk of injury in a collision will increase. Always have an Authorized Mazda Dealer inspect the seat belt pretensioners and air bags after any collision. The seat belt pretensioners and air bags must be replaced after any collision, which causes them to deploy.
Page 28 Unless all safety procedures are followed, injury could result. Ask an Authorized Mazda Dealer how to safely dispose of the pretensioner system or how to scrap a pretensioner-equipped vehicle. 2-18 Form No.
Page 29: Rear Center Position Seat Belt
ON position. If any of these occur, consult an Authorized Mazda Dealer as soon as possible. The system may not work in an accident. WARNING...
Page 30 J56J_8S11-EA-03G_Edition1.book Page 20 Tuesday, June 24, 2003 6:29 PM Essential Safety Equipment Seat Belt Systems WARNING Fastening the Rear-Center Seat Belt with Only One Buckle: Fastening the rear-center seat belt with only one buckle is dangerous. If only one pair of seat belt tongue and buckle, either tongue (A) and anchor buckle (B) or tongue (C) and anchor buckle (D), is fastened, the seat belt...
Page 31: Seat Belt Extender
When ordering an extender, only order one that provides the necessary additional length to fasten the seat belt properly. Please contact your Authorized Mazda Dealer for more information. 2-21...
Page 32 J56J_8S11-EA-03G_Edition1.book Page 22 Tuesday, June 24, 2003 6:29 PM Essential Safety Equipment Seat Belt Systems WARNING Unnecessary Use of an Extender: Using a seat belt extender when not necessary is dangerous. The seat belt will be too long and not fit properly. In an accident, the seat belt will not provide adequate protection and you could be seriously injured.
Page 33: Seat Belt Warning Light
ON position, the seat belt warning light will remain on until the belt is fastened. If the system does not operate correctly, consult an Authorized Mazda Dealer. Form No. 8S11-EA-03G Essential Safety Equipment Seat Belt Systems Seat Belt Warning Beep If the driver’s seat belt is not fastened...
Page 34: Child-Restraint Systems
Essential Safety Equipment Child Restraint Child Restraint Precautions Mazda strongly urges the use of child-restraint systems for children small enough to use them. You are required by law to use a child-restraint system for children in the U.S. and Canada.
Page 35 J56J_8S11-EA-03G_Edition1.book Page 25 Tuesday, June 24, 2003 6:29 PM Essential Safety Equipment Child Restraint WARNING Proper Size of Child-Restraint System: For effective protection in vehicle accidents and sudden stops, a child must be properly restrained using a seat belt or child-restraint system depending on age and size.
Page 36 To avoid burning yourself or a child, check them before you or your child touches them. NOTE Your Mazda is equipped with LATCH lower anchors for attachment of specially designed LATCH child-restraint systems in the rear seat. When using these anchors to secure a child-restraint system, refer to "LATCH Child-Restraint Systems" (page 2-32).
Page 37: Installing Child-Restraint Systems
Some child-restraint systems now come with tethers and therefore must be installed on the seats that take tethers to be effective. In your Mazda, tethered child-restraint systems can only be accommodated in the three positions on the rear seat.
Page 38 J56J_8S11-EA-03G_Edition1.book Page 28 Tuesday, June 24, 2003 6:29 PM Essential Safety Equipment Child Restraint 3. Push the child-restraint system firmly into the vehicle seat. Be sure the belt retracts as snugly as possible. Clicking from the retractor will be heard during retraction if the system is in the automatic locking mode.
Page 39 NOTE To check if your Mazda front seats have side air bags: Every Mazda side air bag will have a "SRS-Air Bag" label on the outboard shoulder of the front seats. Form No. 8S11-EA-03G Essential Safety Equipment...
Page 40 J56J_8S11-EA-03G_Edition1.book Page 30 Tuesday, June 24, 2003 6:29 PM Essential Safety Equipment Child Restraint WARNING Children and Seating Position with Side and Curtain Air Bags: Allowing anyone to lean over or against the front or rear doors is dangerous. If the vehicle is equipped with side and curtain air bags, the impact of inflation could cause serious injury or death to the person.
Page 41 J56J_8S11-EA-03G_Edition1.book Page 31 Tuesday, June 24, 2003 6:29 PM NOTE • Inspect this function before each use of the child-restraint system. You should not be able to pull the shoulder belt out of the retractor while the system is in the automatic locking mode.
Page 42: Latch Child-Restraint Systems
Child Restraint LATCH Child-Restraint Systems Your Mazda is equipped with LATCH lower anchors for attachment of specially designed LATCH child-restraint systems in the rear seat. Both anchors must be used, otherwise the seat will bounce around and put the child in danger. Some LATCH child-restraint systems must also be used in conjunction with a tether to be effective.
Page 43 J56J_8S11-EA-03G_Edition1.book Page 33 Tuesday, June 24, 2003 6:29 PM M LATCH Child-Restraint System Installation Procedure (Rear Outboard Seats) 1. Expand the area between the seat bottom and the seatback slightly to verify the locations of the LATCH lower anchors. Marking For rear left seat LATCH lower anchor...
Page 44 J56J_8S11-EA-03G_Edition1.book Page 34 Tuesday, June 24, 2003 6:29 PM Essential Safety Equipment Child Restraint M LATCH Child-Restraint System Installation Procedure (Rear Center Seat) The LATCH lower anchors at the center of the rear seat are much further apart than the sets of LATCH lower anchors for child-restraint system installation at other seating positions.
Page 45 J56J_8S11-EA-03G_Edition1.book Page 35 Tuesday, June 24, 2003 6:29 PM Essential Safety Equipment Child Restraint WARNING Child-Restraint Tether Usage: Using the tether or tether anchor to secure anything but a child-restraint system is dangerous. This could weaken or damage the tether or tether anchor and result in injury.
Page 46: Srs Air Bags
J56J_8S11-EA-03G_Edition1.book Page 36 Tuesday, June 24, 2003 6:29 PM Essential Safety Equipment SRS Air Bags Supplemental Restraint Systems (SRS) Precautions Read this owner’s manual carefully to verify what air bags (driver-side air bag, passenger- side air bag, side and curtain air bags) are equipped in your vehicle. The front and side supplemental restraint systems (SRS) include up to 6 air bags (verify "SRS AIRBAG"...
Page 47 J56J_8S11-EA-03G_Edition1.book Page 37 Tuesday, June 24, 2003 6:29 PM Children should be protected by a child-restraint system. Laws vary on the size a child must be to use a child-restraint system (page 2-24). Carefully consider which child-restraint system is necessary for your child and follow the installation directions in this Owner’s Manual as well as the child-restraint system manufacturer’s instructions.
Page 48 J56J_8S11-EA-03G_Edition1.book Page 38 Tuesday, June 24, 2003 6:29 PM Essential Safety Equipment SRS Air Bags Seating Position with Side and Curtain Air Bags: Sitting too close to the side and curtain air bag storage compartments or placing hands on them is extremely dangerous. The side and curtain air bags inflate with great force and speed directly out of the outboard side of the front seat, and the front and rear window pillars along the roof edge, expanding along the front and rear doors on the side the car is hit.
Page 49 An Authorized Mazda Dealer can provide the special care needed in the removal and installation of front seats. It is important to protect the side and curtain air bag wiring and connections to assure that the bags do not accidentally deploy and that the seats retain an undamaged air bag connection.
Page 50 • Should you sell your Mazda, we urge you to tell the new owner of its air bag systems and that familiarization with all instructions about them, from the Owner’s Manual, is important.
Page 51: Air Bag System Description
J56J_8S11-EA-03G_Edition1.book Page 41 Tuesday, June 24, 2003 6:29 PM Air Bag System Description The supplemental restraint systems (SRS) have two basic subsystems: • The air bag system with inflators and air bags. • The electric system with crash sensors and diagnostic module. The air bags are mounted in the following locations: the center of the steering wheel, the passenger-side of the dashboard, in the outboard sides of the front seatbacks and the front and rear window pillars...
Page 52 The air bags will function only once. After that, the air bags will not work again and must be replaced. Only an Authorized Mazda Dealer can replace the systems. The front air bags will deploy only in a frontal or frontal offset impact.
Page 53 J56J_8S11-EA-03G_Edition1.book Page 43 Tuesday, June 24, 2003 6:29 PM M Air Bag Activation/Deactivation Front air bag activation A greater than moderate impact will cause the front air bags to inflate in the following cases: Hitting a solid wall straight on at greater than about 22 km/h (14 mph).
Page 54 J56J_8S11-EA-03G_Edition1.book Page 44 Tuesday, June 24, 2003 6:29 PM Essential Safety Equipment SRS Air Bags Limitations to front air bag activation Depending on the severity of impact, the front air bags may not inflate in the following cases: Impacts involving trees or poles cause severe cosmetic damage but may not have enough impact to activate the air bag.
Page 55 J56J_8S11-EA-03G_Edition1.book Page 45 Tuesday, June 24, 2003 6:29 PM Non-activation of front air bags Front air bags will not normally inflate in the following cases: Collision from the rear. Impact to the side, but it may deploy the side * and curtain * air bags. Side* and curtain* air bag activation Greater than moderate impact to one side of the vehicle (driver or passenger side areas) will cause the side and curtain air bags to inflate, but it will not normally deploy the front air...
Page 56 J56J_8S11-EA-03G_Edition1.book Page 46 Tuesday, June 24, 2003 6:29 PM Essential Safety Equipment SRS Air Bags Limitations to side* and curtain* air bag activation Depending on the severity of impact, the side and curtain air bags may not inflate in the following cases: Frontal offset impact may not provide enough side impact to deploy the side * and...
Page 57 ON position. If any of these occur, consult an Authorized Mazda Dealer as soon as possible. The system may not work in an accident. WARNING...
Page 58 The air bag systems do not require regular maintenance. But if any of the following occurs, take your vehicle to an Authorized Mazda Dealer as soon as possible: • The air bag system warning light flashes. • The air bag system warning light remains illuminated.
Page 59 J56J_8S11-EA-03G_Edition1.book Page 1 Tuesday, June 24, 2003 6:29 PM Knowing Your Mazda Explanation of basic operations and controls; opening/closing and adjustment of various parts. Doors and Locks ... 3-2 Keys ... 3-2 Keyless Entry System ... 3-3 Door Locks ... 3-7 Trunk Lid ...
Page 60: Knowing Your Mazda
Refer to Immobilizer System (page 3-20) for information regarding keys and engine starting on vehicles equipped with the immobilizer system. Form No. 8S11-EA-03G Your Mazda has two kinds of keys. Master key (Black) Valet key (Gray) Key code number plate Here’s what the keys are used for:...
Page 61: Keyless Entry System
To install a new battery, refer to Maintenance (page 3-5). • Additional transmitters can be obtained at an Authorized Mazda Dealer. Up to 3 transmitters can be used with the keyless entry system per vehicle. Bring all transmitters to...
Page 62 J56J_8S11-EA-03G_Edition1.book Page 4 Tuesday, June 24, 2003 6:29 PM Knowing Your Mazda Doors and Locks M Transmitter Lock button Panic button Unlock button Trunk button NOTE • (U.S.A.) This device complies with part 15 of the FCC Rules. Operation is...
Page 63 • The horn sounds intermittently. • The hazard warning lights flash. Turning off the alarm Press any button on the transmitter. Form No. 8S11-EA-03G Knowing Your Mazda Doors and Locks M Transmitter Maintenance CAUTION • Make sure the battery is installed with the correct pole facing upward.
Page 64 J56J_8S11-EA-03G_Edition1.book Page 6 Tuesday, June 24, 2003 6:29 PM Knowing Your Mazda Doors and Locks Replacing the transmitter battery 1. Insert a small screwdriver into the slot and gently pry open the transmitter. Slot Back cover 2. Press the portion of the battery indicated by A and remove the battery.
Page 65: Door Locks
Authorized Mazda Dealer. If your transmitter is lost or stolen, bring all remaining transmitters to an Authorized Mazda Dealer as soon as possible for a replacement and to make the lost or stolen transmitter inoperative. CAUTION...
Page 66 J56J_8S11-EA-03G_Edition1.book Page 8 Tuesday, June 24, 2003 6:29 PM Knowing Your Mazda Doors and Locks M Locking, Unlocking with Key The driver’s door can be locked/unlocked with the key. Turn the key toward the front to unlock, toward the back to lock.
Page 67: Power Door Locks
Form No. 8S11-EA-03G Knowing Your Mazda Doors and Locks Locking, unlocking with door-lock switch All doors lock automatically when LOCK is pushed.
Page 68: Trunk Lid
J56J_8S11-EA-03G_Edition1.book Page 10 Tuesday, June 24, 2003 6:29 PM Knowing Your Mazda Doors and Locks Trunk Lid WARNING Open Trunk and Exhaust Gas: Exhaust gas in the cabin of a vehicle is dangerous. This gas contains CO (carbon monoxide), which is colorless, odorless, and highly poisonous.
Page 69 Opening the trunk lid with the remote release button Push the release button. Form No. 8S11-EA-03G Knowing Your Mazda Doors and Locks Closing the trunk lid Use both hands to push the trunk lid down until the lock snaps shut. Do not slam it.
Page 70: Trunk Light
J56J_8S11-EA-03G_Edition1.book Page 12 Tuesday, June 24, 2003 6:29 PM Knowing Your Mazda Doors and Locks M Trunk Light The trunk light is on when the lid is open and off when it’s closed. NOTE To prevent the battery from being...
Page 71 Form No. 8S11-EA-03G Knowing Your Mazda Doors and Locks M Opening the Trunk Lid from the Inside Slide the illuminated trunk release slide lever in the direction of the arrow.
Page 72: Power Windows
J56J_8S11-EA-03G_Edition1.book Page 14 Tuesday, June 24, 2003 6:29 PM Knowing Your Mazda Doors and Locks Power Windows The ignition switch must be in the ON position for the power windows to operate. WARNING Closing Power Windows: Closing power windows are dangerous.
Page 73 To close the window to the desired position, pull up the switch. Close Open Form No. 8S11-EA-03G Knowing Your Mazda Doors and Locks Engine-off power window operation The power window can be operated about 40 seconds after the ignition switch is...
Page 74: Fuel-Filler Lid And Cap
CAUTION Always use only a genuine Mazda fuel cap or an approved equivalent, available at Authorized Mazda Dealers. The wrong cap can result in a serious malfunction of the fuel and emission control systems.
Page 75: Hood
(even after you have tightened the cap securely, driven, and restarted the engine several times), it may indicate a different problem. Contact an Authorized Mazda Dealer as soon as possible. Form No. 8S11-EA-03G Knowing Your Mazda Doors and Locks...
Page 76: Moonroof
J56J_8S11-EA-03G_Edition1.book Page 18 Tuesday, June 24, 2003 6:29 PM Knowing Your Mazda Doors and Locks 2. Slide the hood latch to the right and lift the hood. 3. Use the support rod to hold the hood open. Support rod Clip M Closing the Hood 1.
Page 77: Tilt Operation
J56J_8S11-EA-03G_Edition1.book Page 19 Tuesday, June 24, 2003 6:29 PM NOTE After washing your Mazda or after a rain, wipe the water off the moonroof before operating it. M Tilt Operation The rear of the moonroof can be tilted open to provide more ventilation.
Page 78: Security System
J56J_8S11-EA-03G_Edition1.book Page 20 Tuesday, June 24, 2003 6:29 PM Knowing Your Mazda Security System Immobilizer System The immobilizer system allows the engine to start only with a key the system recognizes. If someone attempts to start the engine with an unrecognized key, the engine will not start, thereby helping to prevent the theft of your vehicle.
Page 79 The security indicator light illuminates for about 3 seconds and goes out. If the engine doesn’t start with the correct ignition key, and the security indicator light keeps illuminating or flashing, the system may have a malfunction. Consult an Authorized Mazda Dealer. 3-21...
Page 80 • If the warning light flashes continuously while you are driving, don’t shut off the engine. Go to an Authorized Mazda Dealer and have it checked. If you shut off the engine while the light is flashing you won’t be able to restart it.
Page 81: Theft-Deterrent System
Form No. 8S11-EA-03G Knowing Your Mazda Security System M How to Arm the System 1. Remove the key from the ignition switch.
Page 82 Authorized Mazda Dealer. 3-24 Form No. 8S11-EA-03G M Theft-Deterrent Labels Labels indicating that your vehicle is equipped with a Theft-Deterrent System are in the glove box. Mazda recommends that you affix them to the lower rear corner of the front door windows.
Page 83: Steering Wheel And Mirrors
3. Push the wheel up and down to be certain it’s locked before driving. Form No. 8S11-EA-03G Knowing Your Mazda Steering Wheel and Mirrors Mirrors M Outside Mirrors Check the mirrors’ angles before driving.
Page 84: Rearview Mirror
J56J_8S11-EA-03G_Edition1.book Page 26 Tuesday, June 24, 2003 6:29 PM Knowing Your Mazda Steering Wheel and Mirrors After adjusting the mirror, lock the control by placing the selector switch in the middle position. Mirror defroster* To turn on the mirror defrosters, turn the...
Page 85 Light sensor Light sensor • For information regarding the 3 buttons ( ) on the auto- dimming mirror, refer to HomeLink Wireless Control System (page 5-46). Form No. 8S11-EA-03G Knowing Your Mazda Steering Wheel and Mirrors 3-27...
Page 86 J56J_8S11-EA-03G_Edition1.book Page 28 Tuesday, June 24, 2003 6:29 PM 3-28 Form No. 8S11-EA-03G...
Page 87 J56J_8S11-EA-03G_Edition1.book Page 1 Tuesday, June 24, 2003 6:29 PM Before Driving Your Mazda Important information about driving your Mazda. Fuel and Engine Exhaust Precautions ... 4-2 Fuel Requirements ... 4-2 Emission Control System ... 4-3 Engine Exhaust (Carbon Monoxide) ... 4-4 Before Starting the Engine ...
Page 88: Before Driving Your Mazda
• Never add fuel system additives. Never add cleaning agents other than those specified by Mazda. Other cleaning agents and additives may damage the system. Consult an Authorized Mazda Dealer. Gasoline blended with oxygenates such as alcohol or ether compounds are generally referred to as oxygenated fuels.
Page 89: Emission Control System
• USE ONLY UNLEADED FUEL. • Don’t drive your Mazda with any sign of engine malfunction. • Don’t coast with the ignition switch turned off. • Don’t descend steep grades in gear with the ignition switch turned off.
Page 90: Engine Exhaust (Carbon Monoxide)
When inhaled, it can cause loss of consciousness and death. If you smell exhaust gas inside your vehicle, keep all windows fully open and contact an Authorized Mazda Dealer immediately. Exhaust Gas in Enclosed Area: Running the engine inside an enclosed area, such as a garage, is dangerous. Exhaust gas, which contains poisonous carbon monoxide, could easily enter the cabin.
Page 91: Before Starting The Engine
See Maintenance, Section 8. Form No. 8S11-EA-03G Before Driving Your Mazda Before Starting the Engine After Getting In • Are all doors closed and locked? • Is the seat adjusted properly? •...
Page 92: Driving Tips
No special break-in is necessary, but a few precautions in the first 1,000 km (600 miles) may add to the performance, economy, and life of your Mazda. • Don’t race the engine. • Don’t maintain one constant speed for long.
Page 93: Hazardous Driving
• For more traction in starting on slippery surfaces, use sand, rock salt, chains, carpeting, or other nonslip material under the front wheels. Form No. 8S11-EA-03G Before Driving Your Mazda Driving Tips Rocking the Vehicle WARNING Spinning the Wheels: When the vehicle is stuck, spinning the wheels at high speed is dangerous.
Page 94: Winter Driving
• Carry emergency gear, including tire chains, window scraper, flares, a small shovel, jumper cables, and a small bag of sand or salt. Ask an Authorized Mazda Dealer to perform the following precautions: • Have the proper ratio of antifreeze in the radiator.
Page 95: Driving In Flooded Area
Make sure water does not enter the vehicle interior or the engine area. The vehicle interior could become wet or the engine could be damaged. Form No. 8S11-EA-03G Before Driving Your Mazda Driving Tips Overloading WARNING Vehicle Load Weight: The gross axle weight rating (GAWR)
Page 96: Towing
J56J_8S11-EA-03G_Edition1.book Page 10 Tuesday, June 24, 2003 6:29 PM Before Driving Your Mazda Towing Trailer Towing Never tow a trailer with your Mazda. 4-10 Form No. 8S11-EA-03G...
Page 97: Driving Your Mazda
J56J_8S11-EA-03G_Edition1.book Page 1 Tuesday, June 24, 2003 6:29 PM Driving Your Mazda Explanation of instruments and controls. Starting and Driving ... 5-2 Ignition Switch ... 5-2 Starting the Engine ... 5-3 Brake System ... 5-4 Manual Transaxle Operation ... 5-9 Automatic Transaxle Controls ...
Page 98: Starting And Driving
J56J_8S11-EA-03G_Edition1.book Page 2 Tuesday, June 24, 2003 6:29 PM Driving Your Mazda Starting and Driving Ignition Switch M Ignition Switch Positions LOCK The steering wheel locks to protect against theft. Only in this position can the key be removed. Manual transaxle...
Page 99: Starting The Engine
If the ignition switch is in the LOCK or ACC position, a beep sound will be heard when the driver’s door is opened. Form No. 8S11-EA-03G Driving Your Mazda Starting and Driving Starting the Engine NOTE Engine-starting is controlled by the spark ignition system.
Page 100: Brake System
Form No. 8S11-EA-03G Brake System M Foot Brake Your Mazda has power-assisted brakes that adjust automatically through normal use. Should power-assist fail, you can stop by applying greater force than normal to the brake pedal.
Page 101: Parking Brake
Dry the brakes by driving very slowly and applying the brakes lightly until brake performance is normal. Form No. 8S11-EA-03G Driving Your Mazda Starting and Driving M Parking Brake CAUTION Driving with the parking brake on will cause excessive wear of the brake linings or pads.
Page 102 J56J_8S11-EA-03G_Edition1.book Page 6 Tuesday, June 24, 2003 6:29 PM Driving Your Mazda Starting and Driving Releasing the parking brake Depress the brake pedal, then pull the handle up and press the button. Lower the handle to the release position while holding in the button.
Page 103 Don’t drive with this light on, and contact an Authorized Mazda Dealer to have the brakes inspected as soon as possible. ABS Warning Light and Brake...
Page 104: Abs Warning Light
If this occurs, your brakes will function normally as if the vehicle had no ABS. Should this happen, consult an Authorized Mazda Dealer as soon as possible. WARNING ABS Warning Light and Brake Warning Light on at the Same Time:...
Page 105: Manual Transaxle Operation
This causes a screeching noise to warn that the pads should be replaced. When you hear this noise, consult an Authorized Mazda Dealer as soon as possible. WARNING Driving with Worn Disc Pads: Driving with worn disc pads is dangerous.
Page 106 J56J_8S11-EA-03G_Edition1.book Page 10 Tuesday, June 24, 2003 6:29 PM Driving Your Mazda Starting and Driving CAUTION • Keep your foot off the clutch pedal except when shifting gears. Also, don’t use the clutch to hold the vehicle on an upgrade. Riding the clutch will cause needless clutch wear and damage.
Page 107: Automatic Transaxle Controls
ACC or ON position). Indicates the shift lever can be shifted freely into any position. Form No. 8S11-EA-03G Driving Your Mazda Starting and Driving M Transaxle Ranges The shift lever must be in P or N to operate the starter. P (Park) P locks the transaxle and prevents the front wheels from rotating.
Page 108 J56J_8S11-EA-03G_Edition1.book Page 12 Tuesday, June 24, 2003 6:29 PM Driving Your Mazda Starting and Driving N (Neutral) In N, the wheels and transaxle are not locked. The vehicle will roll freely even on the slightest incline unless the parking brake or brakes are on.
Page 109: Manual Shift Mode
M1, the gear will shift to M2. M2 is helpful for starting on slippery surfaces. Form No. 8S11-EA-03G Driving Your Mazda Starting and Driving Indicators Shift position indicator In manual shift mode, the "M" of the shift position indicator in the instrument panel illuminates.
Page 110 J56J_8S11-EA-03G_Edition1.book Page 14 Tuesday, June 24, 2003 6:29 PM Driving Your Mazda Starting and Driving Shifting Manually Shifting up (M1→M2→M3→M4→M5 To shift up to a higher gear, tap the shift lever back ( ) once. 3.0-liter engine model NOTE • When driving slowly, the gears may not shift up depending on vehicle speed.
Page 111 M2→M3 61 km/h (37 mph) M3→M4 154 km/h (95 mph) Form No. 8S11-EA-03G Driving Your Mazda Starting and Driving Shifting down If the vehicle speed is higher than the speed specified for each gear, the gear cannot be shifted down to a lower gear.
Page 112 J56J_8S11-EA-03G_Edition1.book Page 16 Tuesday, June 24, 2003 6:29 PM Driving Your Mazda Starting and Driving Shifting specification (3.0-liter engine model) Shifting up If the vehicle speed is lower than the speed specified for each gear, the gear cannot be shifted up to a higher gear.
Page 113 On a steep downgrade , downshifting helps maintain safe speed and prolongs brake life. Form No. 8S11-EA-03G Driving Your Mazda Starting and Driving M Driving Tips Passing For extra power when passing another vehicle or climbing steep grades, depress the accelerator fully.
Page 114: Power Steering
If the steering feels rigid during normal driving, consult an Authorized Mazda Dealer. CAUTION Never hold the steering wheel to the extreme left or right for more than 5 seconds with the engine running.
Page 115 To deactivate the system, press the switch again. The cruise main indicator light turns off. Form No. 8S11-EA-03G Driving Your Mazda Starting and Driving WARNING Cruise Main Switch: Leaving the ON/OFF switch on when not using the cruise control is dangerous as it may be switched on accidentally.
Page 116 J56J_8S11-EA-03G_Edition1.book Page 20 Tuesday, June 24, 2003 6:29 PM Driving Your Mazda Starting and Driving M To Set Speed 1. Activate the cruise control system. 2. Accelerate to the desired speed, which must be more than 40 km/h (25 mph).
Page 117 Multiple taps will decrease your vehicle speed 1.6 km/h (1 mph) for each tap. Form No. 8S11-EA-03G Driving Your Mazda Starting and Driving M To Resume Cruising Speed at More Than 40 km/h (25 mph) If some other method besides the ON/...
Page 118: Traction Control System (Tcs)
J56J_8S11-EA-03G_Edition1.book Page 22 Tuesday, June 24, 2003 6:29 PM Driving Your Mazda Starting and Driving M To Cancel To turn off the system, use one of these methods: • Press the ON/OFF switch. • Slightly depress the brake pedal. • Depress the clutch pedal. (Manual transaxle only) •...
Page 119 TCS is switched off. If the light stays on when the TCS is not switched off, take your vehicle to an Authorized Mazda Dealer. The TCS may have a malfunction. NOTE After starting the engine when the coolant temperature is extremely low, the TCS is automatically turned off.
Page 120 J56J_8S11-EA-03G_Edition1.book Page 24 Tuesday, June 24, 2003 6:29 PM Driving Your Mazda Starting and Driving M TCS OFF Switch Press the TCS OFF switch to turn off the TCS. The TCS OFF indicator light will illuminate. Press the switch again to turn the TCS back on.
Page 121: Instrument Cluster And Indicators
1 Speedometer ...5-26 2 Odometer, Trip Meter and Trip Meter Selector...5-26 3 Tachometer ...5-27 4 Engine Coolant Temperature Gauge...5-27 5 Fuel Gauge... 5-28 6 Instrument Cluster Dimmer Select Button (Black-out meter)...5-28 Form No. 8S11-EA-03G Driving Your Mazda Instrument Cluster and Indicators 5-25...
Page 122 J56J_8S11-EA-03G_Edition1.book Page 26 Tuesday, June 24, 2003 6:29 PM Driving Your Mazda Instrument Cluster and Indicators M Speedometer The speedometer indicates the speed of the vehicle. M Odometer, Trip Meter and Trip Meter Selector The display mode can be changed...
Page 123 CAUTION Don’t run the engine with the tachometer needle in the RED ZONE. This may cause severe engine damage. Form No. 8S11-EA-03G Driving Your Mazda Instrument Cluster and Indicators M Engine Coolant Temperature Gauge The engine coolant temperature gauge shows the temperature of the engine coolant.
Page 124: Dashboard Illumination
J56J_8S11-EA-03G_Edition1.book Page 28 Tuesday, June 24, 2003 6:29 PM Driving Your Mazda Instrument Cluster and Indicators M Fuel Gauge The fuel gauge shows approximately how much fuel is in the tank. We recommend keeping the tank over 1/4 full. When the low fuel warning light illuminates or when the needle is near E, refuel as soon as possible.
Page 125: Warning/Indicator Lights And Beep Sounds
Charging System Warning Light Engine Oil Pressure Warning Light Check Engine Light ABS Warning Light Air Bag/Front Seat Belt Pretensioner System Warning Light Low Fuel Warning Light Form No. 8S11-EA-03G Driving Your Mazda Page 5-31 5-32 5-33 5-33 5-34 5-34...
Page 126 J56J_8S11-EA-03G_Edition1.book Page 30 Tuesday, June 24, 2003 6:29 PM Driving Your Mazda Warning/Indicator Lights and Beep Sounds Signal Warning/Indicator Lights Seat Belt Warning Light Door-Ajar Warning Light Low Washer Fluid Level Warning Light Automatic Transaxle Warning Light Security Indicator Light...
Page 127 (page 8-16). 2. After adding fluid, check the light again. Form No. 8S11-EA-03G Driving Your Mazda If the warning light remains on, or if the brakes do not operate properly, do not drive the vehicle. Have it towed to an Authorized Mazda Dealer.
Page 128 Don’t drive with this light on, and contact an Authorized Mazda Dealer to have the brakes inspected as soon as possible. ABS Warning Light and Brake...
Page 129 • The emission control system has a problem. • The fuel-filler cap is missing or not tightened securely. If the check engine light remains on or flashes continuously, do not drive at high speeds and consult an Authorized Mazda Dealer as soon as possible. 5-33...
Page 130 If this occurs, your brakes will function normally as if the vehicle had no ABS. Should this happen, consult an Authorized Mazda Dealer as soon as possible. WARNING ABS Warning Light and Brake Warning Light on at the Same Time:...
Page 131: Warning Light
An air bag/ pretensioner could accidentally activate or become disabled. This could cause serious injuries. Never tamper with the systems and always have an Authorized Mazda Dealer performs all servicing and repairs. M Low Fuel Warning Light Low fuel warning light...
Page 132 CAUTION If the automatic transaxle warning light illuminates, the transaxle has an electrical problem. Continuing to drive your Mazda in this condition could cause damage to your transaxle. Consult an Authorized Mazda Dealer as soon as possible. M Security Indicator Light...
Page 133: Tcs Indicator Light
Form No. 8S11-EA-03G Driving Your Mazda M TCS Indicator Light* This indicator light stays on for a few seconds when the ignition switch is turned to the ON position.
Page 134: Tcs Off Indicator Light
TCS is switched off. If the light stays on when the TCS is not switched off, take your vehicle to an Authorized Mazda Dealer. The TCS may have a malfunction. NOTE After starting the engine when the coolant temperature is extremely low, the TCS is automatically turned off.
Page 135: Beep Sounds
(does not flash) or if it flashes abnormally, the turn signal bulb may be burned out. Form No. 8S11-EA-03G Driving Your Mazda Beep Sounds M Seat Belt Warning Beep If the driver’s seat belt is not fastened when the ignition switch is turned to the ON position, a beep sound will be heard for about 6 seconds.
Page 136: Switches And Controls
J56J_8S11-EA-03G_Edition1.book Page 40 Tuesday, June 24, 2003 6:29 PM Driving Your Mazda Switches and Controls Lighting Control M Headlights To turn on the lights, turn the headlight switch on the end of the control lever. Switch Position Headlights Taillights Parking lights...
Page 137: Turn And Lane-Change Signals
ON position. NOTE The running lights go off when the parking brake is applied. Form No. 8S11-EA-03G Driving Your Mazda Switches and Controls Turn and Lane-Change Signals M Turn Signal Move the signal lever down (for a left turn) or up (for a right turn) to the stop position.
Page 138: Fog Lights
If this happens, turn off the wiper switch and park off the right-of-way, and remove the snow and ice. After 5 minutes, turn on the switch and the blades should operate normally. If they don’t resume functioning, consult an Authorized Mazda Dealer as soon as possible.
Page 139 With the wiper lever in the OFF or INT position, the wipers will operate continuously until the lever is released. If the washer doesn’t work, inspect the fluid level (page 8-20). If it’s OK, consult an Authorized Mazda Dealer. Driving Your Mazda MIST 5-43...
Page 140: Rear Window Defroster
J56J_8S11-EA-03G_Edition1.book Page 44 Tuesday, June 24, 2003 6:29 PM Driving Your Mazda Switches and Controls Rear Window Defroster The rear window defroster clears frost, fog, and thin ice from the rear window. The ignition switch must be in the ON position.
Page 141: Horn
Horn To sound the horn, press around the mark of the steering wheel. Form No. 8S11-EA-03G Driving Your Mazda Switches and Controls Hazard Warning Flasher The hazard warning lights should always be used when you stop on or near a roadway.
Page 142: Homelink Wireless Control System
J56J_8S11-EA-03G_Edition1.book Page 46 Tuesday, June 24, 2003 6:29 PM Driving Your Mazda Switches and Controls HomeLink Wireless Control System* NOTE HomeLink and HomeLink house are registered trademarks of Johnson Controls. The HomeLink system replaces up to 3 hand-held transmitters with a single built- in component in the auto-dimming mirror.
Page 143 • Verify that there is a remote control transmitter available for the device you would like to program. • Disconnect the power to the device. Form No. 8S11-EA-03G Driving Your Mazda Switches and Controls M Programming the HomeLink System CAUTION...
Page 144 J56J_8S11-EA-03G_Edition1.book Page 48 Tuesday, June 24, 2003 6:29 PM Driving Your Mazda Switches and Controls 4. After the HomeLink indicator light changes from a slow to a rapidly blinking light, release both the HomeLink and hand-held transmitter buttons. NOTE If the HomeLink indicator light does...
Page 145 Proceed with "Programming" step 4 to complete. Form No. 8S11-EA-03G Driving Your Mazda Switches and Controls M Operating the HomeLink System Press the programmed HomeLink button to operate a programmed device. The code will continue being transmitted for a maximum of 20 seconds.
Page 146 J56J_8S11-EA-03G_Edition1.book Page 50 Tuesday, June 24, 2003 6:29 PM 5-50 Form No. 8S11-EA-03G...
Page 147: Interior Comfort
J56J_8S11-EA-03G_Edition1.book Page 1 Tuesday, June 24, 2003 6:29 PM Interior Comfort Use of various features for drive comfort, including climate control and audio system. Climate Control System ... 6-2 Operating Tips ... 6-2 Vent Operation ... 6-3 Types of the Climate Control System ... 6-5 Manual Type ...
Page 148: Climate Control System
Have the air conditioner checked before the weather gets hot. Lack of refrigerant may make the air conditioner less efficient. Consult an Authorized Mazda Dealer for refrigerant inspection. The air conditioner is filled with HFC134a (R134a), a refrigerant that will not damage the ozone layer.
Page 149: Vent Operation
J56J_8S11-EA-03G_Edition1.book Page 3 Tuesday, June 24, 2003 6:29 PM Vent Operation M Adjusting the Vents Directing airflow 1. Press the upper part of the air vent to open it. Form No. 8S11-EA-03G Interior Comfort Climate Control System 2. Rotate the air vent left and right to adjust the direction of airflow.
Page 150 J56J_8S11-EA-03G_Edition1.book Page 4 Tuesday, June 24, 2003 6:29 PM Interior Comfort Climate Control System M Selecting the Airflow Mode Dashboard Vents Dashboard and Floor Vents Floor Vents Form No. 8S11-EA-03G Defroster and Floor Vents Defroster Vents...
Page 151: Types Of The Climate Control System
J56J_8S11-EA-03G_Edition1.book Page 5 Tuesday, June 24, 2003 6:29 PM Interior Comfort Climate Control System Types of the Climate Control System Manual type and fully automatic type climate control systems are explained separately. Check your vehicle’s climate control type and read the appropriate pages. Climate control information is displayed on the information display.
Page 152: Manual Type
J56J_8S11-EA-03G_Edition1.book Page 6 Tuesday, June 24, 2003 6:29 PM Interior Comfort Climate Control System Manual Type A/C Switch Temperature control dial M Control Switches Temperature control dial Cold This dial controls temperature. Turn it clockwise for hot and counterclockwise for cold. Form No.
Page 153 J56J_8S11-EA-03G_Edition1.book Page 7 Tuesday, June 24, 2003 6:29 PM Mode selector dial Turn the mode selector dial to select airflow mode (page 6-4). A/C switch Push the switch to turn the air conditioner on. The indicator light on the switch will illuminate when the fan control dial is set at position 1, 2, 3, or 4.
Page 154 J56J_8S11-EA-03G_Edition1.book Page 8 Tuesday, June 24, 2003 6:29 PM Interior Comfort Climate Control System WARNING The Recirculated Air Position: Using the position in cold or rainy weather will cause the glass to fog up. Your vision will be hampered, which could lead to a serious accident.
Page 155 J56J_8S11-EA-03G_Edition1.book Page 9 Tuesday, June 24, 2003 6:29 PM NOTE • When maximum cooling is desired, set the temperature control dial to the extreme cold position and set the air intake selector to the position, then set the fan control dial to position 4.
Page 156 J56J_8S11-EA-03G_Edition1.book Page 10 Tuesday, June 24, 2003 6:29 PM Interior Comfort Climate Control System M Dehumidifying (With Air Conditioner) Operate the air conditioner in cool or cold weather to help defog the windshield and side windows. 1. Set the mode selector dial to the desired position.
Page 157: Fully Automatic Type
J56J_8S11-EA-03G_Edition1.book Page 11 Tuesday, June 24, 2003 6:29 PM Fully Automatic Type Fan control dial Rear window defroster switch OFF switch M Control Switches AUTO switch By pressing the AUTO switch the following functions will be automatically controlled in accordance with the set temperature: •...
Page 158 J56J_8S11-EA-03G_Edition1.book Page 12 Tuesday, June 24, 2003 6:29 PM Interior Comfort Climate Control System OFF switch Pressing the OFF switch shuts off the climate control system. Temperature control dial Cold This dial controls temperature.Turn it clockwise for hot and counterclockwise for cold.
Page 159 J56J_8S11-EA-03G_Edition1.book Page 13 Tuesday, June 24, 2003 6:29 PM NOTE The air conditioner may not function when the outside temperature approaches 0 °C (32 °F). (Indicator remains on even when system is off.) Air intake selector Outside or recirculated air positions can be selected.
Page 160 J56J_8S11-EA-03G_Edition1.book Page 14 Tuesday, June 24, 2003 6:29 PM Interior Comfort Climate Control System NOTE • For an optimal cabin temperature, set the temperature close to 25.0°C (77.0°F). Adjust to the desired temperature if necessary. • Setting the temperature to maximum high or low will not provide the desired temperature at a faster rate.
Page 161 J56J_8S11-EA-03G_Edition1.book Page 15 Tuesday, June 24, 2003 6:29 PM Interior Comfort Climate Control System M Sunlight/Temperature Sensor The fully automatic air conditioner function measures inside and outside temperatures, and sunlight. It then sets temperatures inside the passenger compartment accordingly. Don’t obstruct the sensor.
Page 162: Audio System
J56J_8S11-EA-03G_Edition1.book Page 16 Tuesday, June 24, 2003 6:29 PM Interior Comfort Audio System Antenna M Detachable Type To remove the antenna, turn it counterclockwise. To install the antenna, turn it clockwise. Make sure the antenna is securely installed. CAUTION To prevent damage to the antenna, remove it before entering a car wash facility or passing beneath a low overhead clearance.
Page 163 J56J_8S11-EA-03G_Edition1.book Page 17 Tuesday, June 24, 2003 6:29 PM M Radio Reception AM characteristics AM signals bend around such things as buildings or mountains and bounce off the ionosphere. Therefore, they can reach longer distances than FM signals. Because of this, two stations may sometimes be picked up on the same frequency at the same time.
Page 164 J56J_8S11-EA-03G_Edition1.book Page 18 Tuesday, June 24, 2003 6:29 PM Interior Comfort Audio System Flutter/Skip noise Signals from an FM transmitter move in straight lines and become weak in valleys between tall buildings, mountains, and other obstacles. When a vehicle passes through such an area, the reception conditions may change suddenly, resulting in annoying noise.
Page 165 Use a good quality head- cleaning tape or a liquid cleaner cassette tape to remove it. Should the unit not operate normally, consult an Authorized Mazda Dealer. Never attempt to repair it or insert a screwdriver or anything else. Handling the cassette tape player The following precautions should be observed.
Page 166 J56J_8S11-EA-03G_Edition1.book Page 20 Tuesday, June 24, 2003 6:29 PM Interior Comfort Audio System M Operating Tips for Mini Disc (MD) Player The following precautions should be observed. • Do not spill any liquid on the audio system. • Do not insert any objects, other than MDs, into the slot.
Page 167 J56J_8S11-EA-03G_Edition1.book Page 21 Tuesday, June 24, 2003 6:29 PM M Operating Tips for CD Player/In- Dash CD Changer Condensation phenomenon Immediately after turning on the heater when the vehicle is cold, the CD or optical components (prism and lens) in the CD player/changer may become clouded with condensation.
Page 168 J56J_8S11-EA-03G_Edition1.book Page 22 Tuesday, June 24, 2003 6:29 PM Interior Comfort Audio System • When driving over uneven surfaces, the sound may jump. • The CD player/changer has been designed to play CDs bearing the identification logo as shown. No other discs can be played.
Page 169: Audio Set
J56J_8S11-EA-03G_Edition1.book Page 23 Tuesday, June 24, 2003 6:29 PM CD Player* Cassette Tape Player* Power/Volume/Sound Controls ... 6-24 Operating the Radio ... 6-26 Operating the Cassette Tape Player* ... 6-28 Operating the Mini Disc (MD) Player* ... 6-30 Operating the Compact Disc (CD) Player* ... 6-32 Operating the In-Dash CD Changer* ...
Page 170 J56J_8S11-EA-03G_Edition1.book Page 24 Tuesday, June 24, 2003 6:29 PM Interior Comfort Audio System M Power/Volume/Sound Controls Power/Volume dial Power ON/OFF Turn the ignition switch to the ACC or ON position. Press the power/volume dial to turn the audio system on. Press the power/volume dial again to turn the audio system off.
Page 171 J56J_8S11-EA-03G_Edition1.book Page 25 Tuesday, June 24, 2003 6:29 PM 2. Turn the audio control dial to adjust the selected functions as follows: Indication Turn Left Turn Right Decrease Increase bass bass Decrease Increase mid-range mid-range Decrease Increase treble treble Shift the Shift the sound to sound to...
Page 172 J56J_8S11-EA-03G_Edition1.book Page 26 Tuesday, June 24, 2003 6:29 PM Interior Comfort Audio System M Operating the Radio Band selector buttons Seek tuning button Channel preset buttons Radio ON Press a band selector button ( ) to turn the radio on. Band selection Select a band by pressing the FM1 button ), FM2 button (...
Page 173 J56J_8S11-EA-03G_Edition1.book Page 27 Tuesday, June 24, 2003 6:29 PM Seek tuning Pressing the seek tuning button ( will cause the tuner to seek a higher or lower frequency automatically. NOTE If you continue to press and hold the button, the frequency will continue changing without stopping.
Page 174 J56J_8S11-EA-03G_Edition1.book Page 28 Tuesday, June 24, 2003 6:29 PM Interior Comfort Audio System M Operating the Cassette Tape Player* APC button: (next program) (one being played) Repeat button Dolby NR button Cassette tape insert Insert the cassette tape into the slot, open edge to the right and cassette tape will begin play, and "TAPE PLAY"...
Page 175 J56J_8S11-EA-03G_Edition1.book Page 29 Tuesday, June 24, 2003 6:29 PM NOTE The cassette tape can be ejected when the ignition switch is in the OFF position. Fast-forward/Rewind Press the fast-forward button ( fast-forward. Press the rewind button ( ) to rewind. To stop this operation and play the cassette tape, press the button again.
Page 176 J56J_8S11-EA-03G_Edition1.book Page 30 Tuesday, June 24, 2003 6:29 PM Interior Comfort Audio System M Operating the Mini Disc (MD) Player* Track up button Track down button MD slot Repeat button Inserting the MD Insert the MD, label-side up with the arrow pointed to the slot.
Page 177 J56J_8S11-EA-03G_Edition1.book Page 31 Tuesday, June 24, 2003 6:29 PM Music scan This feature helps to find a program by playing about the first 10 seconds of each track. Press the scan button ( ) during play to start scan play operation (the track number will flash).
Page 178 J56J_8S11-EA-03G_Edition1.book Page 32 Tuesday, June 24, 2003 6:29 PM Interior Comfort Audio System M Operating the Compact Disc (CD) Player* CD slot Track up button Track down button Repeat button Inserting the CD Insert the CD into the slot, label-side up. The auto-loading mechanism will set the CD and begin play.
Page 179 J56J_8S11-EA-03G_Edition1.book Page 33 Tuesday, June 24, 2003 6:29 PM Music scan This feature helps to find a program by playing about the first 10 seconds of each track. Press the scan button ( ) during play to start scan play operation (the track number will flash).
Page 180 J56J_8S11-EA-03G_Edition1.book Page 34 Tuesday, June 24, 2003 6:29 PM Interior Comfort Audio System M Operating the In-Dash CD Changer* Channel preset buttons Load button CD slot Track up button Track down button Disc down button Repeat button Disc up button Inserting the CD The CD must be label-side up when inserting.
Page 181 J56J_8S11-EA-03G_Edition1.book Page 35 Tuesday, June 24, 2003 6:29 PM Multiple insertion 1. Press and hold the load button ( for about 2 seconds until a beep is heard. 2. Wait 5 seconds or press the load button ) again within 5 seconds after the beep is heard.
Page 182 J56J_8S11-EA-03G_Edition1.book Page 36 Tuesday, June 24, 2003 6:29 PM Interior Comfort Audio System Playing Press the CD play button ( ) to start play when a CD is in the unit. If there isn’t a CD in the unit when the CD play button ( ) is pressed, "NO DISC"...
Page 183 J56J_8S11-EA-03G_Edition1.book Page 37 Tuesday, June 24, 2003 6:29 PM M Error Indications If you see an error indication on the display, find the cause in the chart. If you cannot clear the error indication, take the vehicle to an Authorized Mazda Dealer. Indication Cause...
Page 184: Audio Control Switch Operation
J56J_8S11-EA-03G_Edition1.book Page 38 Tuesday, June 24, 2003 6:29 PM Interior Comfort Audio System Audio Control Switch Operation* NOTE Mazda installed this system to help you avoid being too distracted using audio controls on the dashboard. Always make safe driving your first priority. M Adjusting the Volume To increase the volume, press volume button ( ).
Page 185 J56J_8S11-EA-03G_Edition1.book Page 39 Tuesday, June 24, 2003 6:29 PM M Seek Switch When listening to the radio Press the seek switch ( , ) to recall previously stored radio stations. Press the seek switch ( , ), the radio switches to the next/previous stored station in the order that it was stored (1~6).
Page 186: Safety Certification
• This CD player should not be adjusted or repaired by anyone except qualified service personnel. If servicing is required, contact an Authorized Mazda Dealer. • Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous laser exposure. Never operate the CD player with the top case of the unit removed.
Page 187: Interior Equipment
J56J_8S11-EA-03G_Edition1.book Page 41 Tuesday, June 24, 2003 6:29 PM Sunvisors When you need a sunvisor, lower it for use in front or swing it to the side. Sunvisor M Vanity Mirrors To use the vanity mirror, lower the sunvisor. The vanity mirror light will illuminate when you open the cover.
Page 188 J56J_8S11-EA-03G_Edition1.book Page 42 Tuesday, June 24, 2003 6:29 PM Interior Comfort Interior Equipment M Overhead Lights Front With sunroof DOOR Without sunroof DOOR Light off • Light on when any door is open DOOR • Light on or off when the illuminated entry system is on 6-42 Form No.
Page 189 J56J_8S11-EA-03G_Edition1.book Page 43 Tuesday, June 24, 2003 6:29 PM M Map Lights The map lights are switched on or off by pressing the switches. Front (with sunroof) Front (without sunroof) Center Form No. 8S11-EA-03G Interior Comfort Interior Equipment M Courtesy Lights Turns on when any door is open or the illuminated entry system is on.
Page 190: Information Display
J56J_8S11-EA-03G_Edition1.book Page 44 Tuesday, June 24, 2003 6:29 PM Interior Comfort Interior Equipment Information Display DIMMER button CLOCK button SET button AMB button M Information Display Functions The information display has the following functions: • Clock • Ambient Temperature Display (Outside Temperature Display) •...
Page 191 J56J_8S11-EA-03G_Edition1.book Page 45 Tuesday, June 24, 2003 6:29 PM M Clock When the ignition switch is in the ACC or ON position, the time is displayed. Time setting 1. Press the CLOCK button until a beep sounds, and "12Hr" and "24Hr" will be displayed.
Page 192 J56J_8S11-EA-03G_Edition1.book Page 46 Tuesday, June 24, 2003 6:29 PM Interior Comfort Interior Equipment M Ambient Temperature Display When the ignition switch is in the ON position, press the AMB button to display the ambient temperature. NOTE • The displayed ambient temperature may vary from the actual ambient temperature depending on the surrounding area and vehicle...
Page 193: Lighter
• Don’t use the lighter socket for plug-in accessories such as shavers and coffee pots. They may damage it or cause electrical failure. Use only a genuine Mazda lighter or the equivalent. • If the lighter doesn’t pop out within 30 seconds, remove it to prevent overheating.
Page 194: Ashtray
J56J_8S11-EA-03G_Edition1.book Page 48 Tuesday, June 24, 2003 6:29 PM Interior Comfort Interior Equipment Ashtray CAUTION Don’t use the ashtray for trash. You might start a fire. To use, open the cover. To remove, open the cover and pull up the ashtray.
Page 195: Bottle Holder
J56J_8S11-EA-03G_Edition1.book Page 49 Tuesday, June 24, 2003 6:29 PM M Front To use the cup holder, open the center console by pressing the lower center part of its cover. M Rear The rear cup holder is on the rear center armrest.
Page 196: Storage Compartments
J56J_8S11-EA-03G_Edition1.book Page 50 Tuesday, June 24, 2003 6:29 PM Interior Comfort Interior Equipment Storage Compartments WARNING Open Storage Boxes: Driving with the storage boxes open is dangerous. To reduce the possibility of injury in an accident or a sudden stop, keep the storage boxes closed when driving.
Page 197 J56J_8S11-EA-03G_Edition1.book Page 51 Tuesday, June 24, 2003 6:29 PM M Glove Box To open the glove box, pull the latch toward you. Insert the master key and turn it clockwise to lock, counterclockwise to unlock. Unlock Form No. 8S11-EA-03G Interior Equipment M Center Console To open, pull the lower release catch.
Page 198: Accessory Socket
Interior Equipment Accessory Socket The ignition switch must be in the ACC or ON position. Only use genuine Mazda accessories or the equivalent requiring no greater than 120 W (DC12 V, 10 A). CAUTION To prevent accessory socket damage or...
Page 199 J56J_8S11-EA-03G_Edition1.book Page 53 Tuesday, June 24, 2003 6:29 PM 5. Pass the plug cord through the hole of the tray and insert the plug in the socket. Plug 6. Make sure the plug cord is running through the cap slot; reinstall the cap and turn it clockwise (about 45°...
Page 200 J56J_8S11-EA-03G_Edition1.book Page 54 Tuesday, June 24, 2003 6:29 PM 6-54 Form No. 8S11-EA-03G...
Page 201: In Case Of An Emergency
J56J_8S11-EA-03G_Edition1.book Page 1 Tuesday, June 24, 2003 6:29 PM In Case of an Emergency Helpful information on what to do in an emergency. Parking in an Emergency ... 7-2 Parking in an Emergency ... 7-2 Flat Tire ... 7-3 Spare Tire and Tool Storage ... 7-3 Changing a Flat Tire ...
Page 202: Parking In An Emergency
J56J_8S11-EA-03G_Edition1.book Page 2 Tuesday, June 24, 2003 6:29 PM In Case of an Emergency Parking in an Emergency Parking in an Emergency The hazard warning lights should always be used when you stop on or near a roadway. The hazard warning lights warn other drivers that your vehicle is a traffic hazard and that they must take extreme caution when near it.
Page 203: Flat Tire
J56J_8S11-EA-03G_Edition1.book Page 3 Tuesday, June 24, 2003 6:29 PM In Case of an Emergency Flat Tire Spare Tire and Tool Storage Spare tire and tools are stored in the locations illustrated in the diagram. Spare tire Jack Lug wrench Conventional tire hold-down bolt Form No.
Page 204 Perform the removal procedure in reverse. Form No. 8S11-EA-03G M Spare Tire Your Mazda has a temporary spare tire. The temporary spare is lighter and smaller than a conventional tire, and is designed only for emergency use and should be used only for VERY short periods.
Page 205: Changing A Flat Tire
J56J_8S11-EA-03G_Edition1.book Page 5 Tuesday, June 24, 2003 6:29 PM To remove the spare tire 1. Remove the trunk board. Trunk board 2. Turn the tire hold-down bolt counterclockwise. Lug wrench To secure the spare tire Perform the removal procedure in reverse. Form No.
Page 206 J56J_8S11-EA-03G_Edition1.book Page 6 Tuesday, June 24, 2003 6:29 PM In Case of an Emergency Flat Tire NOTE Make sure the jack is well lubricated before using it. 1. Park on a level surface off the right-of- way and firmly set the parking brake. 2.
Page 207 Improper Jack: Using a jack that isn’t designed for your Mazda is dangerous. The vehicle could slip off the jack and seriously injure someone. Use only the jack provided with your Mazda. Placing Objects Under the Jack: Jacking the vehicle with an object under the jack is dangerous.
Page 208 Before removing the lug nuts, make sure your Mazda is firmly in position and that it cannot slip or move. 6. Remove the lug nuts by turning them counterclockwise;...
Page 209 J56J_8S11-EA-03G_Edition1.book Page 9 Tuesday, June 24, 2003 6:29 PM M Mounting the Spare Tire 1. Remove dirt and grime from the mounting surfaces of the wheel and hub, including the hub bolts, with a cloth. WARNING Removing Dirt and Grime from Wheels, Hubs and Hub Bolts: When changing or replacing a tire, not removing dirt and grime from the...
Page 210 Metric Studs and Lug Nuts: Because the wheel studs and lug nuts on your Mazda have metric threads, using a non-metric nut is dangerous. On a metric stud, it would not secure the wheel and would damage the stud, which could cause the wheel to slip off and cause an accident.
Page 211 J56J_8S11-EA-03G_Edition1.book Page 11 Tuesday, June 24, 2003 6:29 PM 5. Store the damaged tire, using the conventional tire hold-down bolt supplied in the tool bag to hold it in place. Have the damaged tire repaired as soon as possible. Conventional tire hold-down bolt Tire clamp NOTE...
Page 212: Overheating
If the cooling fan does not operate while the engine is running, the engine temperature will increase. Stop the engine and call an Authorized Mazda Dealer. 5. Make sure the cooling fan is operating, then turn off the engine after the...
Page 213 If it’s low, look for coolant leaks from the radiator and hoses. If you find a leak or other damage, or if coolant is still leaking: Stop the engine and call an Authorized Mazda Dealer. 2.3-liter engine Cooling system cap Coolant reservoir 3.0-liter engine...
Page 214: Emergency Starting
J56J_8S11-EA-03G_Edition1.book Page 14 Tuesday, June 24, 2003 6:29 PM In Case of an Emergency Emergency Starting Starting a Flooded Engine If the engine fails to start, it may be flooded (excessive fuel in the engine). Follow this procedure: 1. Depress the accelerator all the way and hold it there.
Page 215: Jump-Starting
J56J_8S11-EA-03G_Edition1.book Page 15 Tuesday, June 24, 2003 6:29 PM Jump-starting is dangerous if done incorrectly. So follow the procedure carefully. If you feel unsure about jump-starting, we strongly recommend that you have a competent service technician do the work. Eye Protection: Working without eye protection is dangerous.
Page 216 J56J_8S11-EA-03G_Edition1.book Page 16 Tuesday, June 24, 2003 6:29 PM In Case of an Emergency Emergency Starting Low Fluid Level or Frozen Battery: Jump-starting a frozen battery or one with a low fluid level is dangerous. It may rupture or explode, causing serious injury. Don’t jump-start a frozen battery or one with a low fluid level.
Page 217 J56J_8S11-EA-03G_Edition1.book Page 17 Tuesday, June 24, 2003 6:29 PM 1. Make sure the booster battery is 12 V and that its negative terminal is grounded. 2. If the booster battery is in another vehicle, don’t allow the vehicles to touch. Turn off the engine of the vehicle with the booster battery and all unnecessary electrical loads in both vehicles.
Page 218: Push-Starting
J56J_8S11-EA-03G_Edition1.book Page 18 Tuesday, June 24, 2003 6:29 PM In Case of an Emergency Emergency Starting Push-Starting WARNING Towing a Vehicle to Start It: Towing a vehicle to start it is dangerous. The vehicle being towed could surge forward when its engine starts, causing the two vehicles to collide.
Page 219: Emergency Towing
J56J_8S11-EA-03G_Edition1.book Page 19 Tuesday, June 24, 2003 6:29 PM Towing Description We recommend that towing be done only by an Authorized Mazda Dealer or a commercial tow-truck service. Proper lifting and towing are necessary to prevent damage to the vehicle.
Page 220: Recreational Towing
J56J_8S11-EA-03G_Edition1.book Page 20 Tuesday, June 24, 2003 6:29 PM In Case of an Emergency Emergency Towing CAUTION Do not use the hooks under the rear bumper for towing and tying down, as they cannot hold the load and it will damage the bumper.
Page 221: Maintenance And Care
J56J_8S11-EA-03G_Edition1.book Page 1 Tuesday, June 24, 2003 6:29 PM Maintenance and Care How to keep your Mazda in top condition. Introduction ... 8-2 Introduction ... 8-2 Scheduled Maintenance ... 8-3 Scheduled Maintenance ... 8-3 Owner Maintenance ... 8-7 Owner Maintenance Schedule ... 8-7 Owner Maintenance Precautions ...
Page 222: Introduction
Claims against the warranty resulting from lack of maintenance, as opposed to defective materials or authorized Mazda workmanship, will not be honored. Any auto repair shop using parts equivalent to your Mazda’s original equipment may perform maintenance. But we recommend that it always be done by an Authorized Mazda Dealer using genuine Mazda parts.
Page 223: Scheduled Maintenance
J56J_8S11-EA-03G_Edition1.book Page 3 Tuesday, June 24, 2003 6:29 PM Scheduled Maintenance Follow Schedule 1 if the vehicle is operated mainly where none of the following conditions apply. If any do apply, follow Schedule 2 (Canada and Puerto Rico residents follow Schedule 2). •...
Page 224 *1 According to state / provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or mileage / kilometer period to ensure long-term reliability.
Page 225 *1 According to state / provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or mileage / kilometer period to ensure long-term reliability.
Page 226 J56J_8S11-EA-03G_Edition1.book Page 6 Tuesday, June 24, 2003 6:29 PM Maintenance and Care Scheduled Maintenance I : Inspect and repair, clean, adjust, or replace if necessary. L: Lubricate Months Maintenance Interval (Number of months ×1000 km or kilometers (miles), whichever comes first) ×1000 miles ELECTRICAL SYSTEM Function of all lights...
Page 227: Owner Maintenance
The owner or a qualified service technician should make these vehicle inspections at the indicated intervals to ensure safe and dependable operation. Bring any problem to the attention of an Authorized Mazda Dealer or qualified service technician as soon as possible.
Page 228: Owner Maintenance Precautions
Improper owner maintenance during the warranty period may affect warranty coverage. For details, read the separate Mazda Warranty statement provided with the vehicle. If you’re unsure about any servicing or maintenance procedure, have it done by an Authorized Mazda Dealer.
Page 229: Engine Compartment Overview
J56J_8S11-EA-03G_Edition1.book Page 9 Tuesday, June 24, 2003 6:29 PM Engine Compartment Overview 2.3-liter engine Engine oil-filler cap Windshield washer fluid reservoir Power steering fluid reservoir Engine oil dipstick Engine coolant reservoir 3.0-liter engine Cooling system cap Engine coolant reservoir Windshield washer fluid reservoir Engine oil dipstick Engine oil-filler cap...
Page 230: Engine Oil
J56J_8S11-EA-03G_Edition1.book Page 10 Tuesday, June 24, 2003 6:29 PM Maintenance and Care Owner Maintenance Engine Oil M Recommended Oil Oil container labels provide important information. GASOLINE ENGINES (ILSAC) The quality designation SL or ILSAC must be on the label. Engine oil viscosity, or thickness, has an effect on fuel economy and cold-weather operation (starting and oil flow).
Page 231 J56J_8S11-EA-03G_Edition1.book Page 11 Tuesday, June 24, 2003 6:29 PM 3.0-liter engine 5. Pull it out again and examine the level. It’s OK between MIN and MAX. But if it’s near or below MIN, add enough oil to bring the level to MAX. CAUTION Don’t add engine oil over MAX.
Page 232 When adding or changing oil, verify the engine oil level with the oil dipstick. • Use only specified engine oil (page 10-3). Changing oil filter Because you need a special tool to retighten the filter, an Authorized Mazda Dealer should do the work.
Page 233: Engine Coolant
J56J_8S11-EA-03G_Edition1.book Page 13 Tuesday, June 24, 2003 6:29 PM Engine Coolant M Inspecting Coolant Level WARNING Hot Engine: A hot engine is dangerous. If the engine has been running, parts of the engine compartment can become very hot. You could be burned. Carefully inspect the engine coolant in the coolant reservoir, but do not open it.
Page 234 CAUTION Radiator coolant will damage paint. Rinse it off quickly. Do not overfill. If new coolant is required frequently, consult an Authorized Mazda Dealer. M Changing Coolant Change coolant according to Scheduled Maintenance (page 8-3). CAUTION • Use only soft (demineralized) water in the coolant mixture.
Page 235 J56J_8S11-EA-03G_Edition1.book Page 15 Tuesday, June 24, 2003 6:29 PM 1. Remove the cooling system cap. 2.3-liter engine Loosen Tighten Loosen Loosen Tighten Tighten 3.0-liter engine 2. Only when the engine is cool, remove the radiator drain plug and drain the coolant into a suitable container.
Page 236: Brake/Clutch Fluid
The level normally drops with accumulated distance, a condition associated with wear of brake and clutch linings. If it is excessively low, have the brake/clutch system inspected by an Authorized Mazda Dealer. 8-16 Form No. 8S11-EA-03G M Adding Brake/Clutch Fluid WARNING Spilled Brake Fluid: Spilled brake fluid is dangerous.
Page 237: Power Steering Fluid
• Using nonspecified brake and clutch fluids (page 10-3) will damage the systems. Mixing different fluids will also damage them. If the brake/clutch system frequently requires new fluid, consult an Authorized Mazda Dealer. Form No. 8S11-EA-03G Maintenance and Care Owner Maintenance Power Steering Fluid...
Page 238: Automatic Transaxle Fluid (Atf)
J56J_8S11-EA-03G_Edition1.book Page 18 Tuesday, June 24, 2003 6:29 PM Maintenance and Care Owner Maintenance If new fluid is required frequently, consult an Authorized Mazda Dealer. 3.0-liter engine Inspect the fluid level at each engine oil change. Add fluid if necessary; it does not require periodic changing.
Page 239 J56J_8S11-EA-03G_Edition1.book Page 19 Tuesday, June 24, 2003 6:29 PM WARNING Sudden Vehicle Movement: Shifting the shift lever without first depressing the brake pedal is dangerous. The vehicle could move suddenly and cause an accident. Make sure the brake pedal is applied before shifting the shift lever.
Page 240: Washer Fluid
J56J_8S11-EA-03G_Edition1.book Page 20 Tuesday, June 24, 2003 6:29 PM Maintenance and Care Owner Maintenance Washer Fluid M Inspecting Washer Fluid Level WARNING Substitute Washer Fluid: Using radiator antifreeze as washer fluid is dangerous. If sprayed on the windshield, it will dirty the windshield, affect your visibility, and could result in an accident.
Page 241: Body Lubrication
J56J_8S11-EA-03G_Edition1.book Page 21 Tuesday, June 24, 2003 6:29 PM Body Lubrication All moving points of the body, such as door and hood hinges and locks, should be lubricated each time the engine oil is changed. Use a nonfreezing lubricant on locks during cold weather.
Page 242 J56J_8S11-EA-03G_Edition1.book Page 22 Tuesday, June 24, 2003 6:29 PM Maintenance and Care Owner Maintenance 3.0-liter engine Clamp 2. Tilt or lift the air filter cover and remove the filter. 2.3-liter engine Air filter cover Air filter 3.0-liter engine Air filter cover Air filter 8-22 Form No.
Page 243: Wiper Blades
J56J_8S11-EA-03G_Edition1.book Page 23 Tuesday, June 24, 2003 6:29 PM Wiper Blades CAUTION • Hot waxes applied by automatic car washers have been known to affect the cleanability of windows. • To prevent damage to the wiper blades, don’t use gasoline, kerosene, paint thinner, or other solvents on or near them.
Page 244 J56J_8S11-EA-03G_Edition1.book Page 24 Tuesday, June 24, 2003 6:29 PM Maintenance and Care Owner Maintenance CAUTION To prevent damage to the windshield, don’t let the wiper arm fall on it. 2. Hold the end of the rubber and pull until the tabs are free of the metal support.
Page 245: Battery
J56J_8S11-EA-03G_Edition1.book Page 25 Tuesday, June 24, 2003 6:29 PM Maintenance and Care Owner Maintenance Battery WARNING Battery-Related Lead Materials: Battery posts, terminals and related accessories contain lead and lead compounds, chemicals known to the State of California to cause cancer and reproductive harm. Wash hands after handling.
Page 246: Tires
(radial, bias-belted, bias-type) on all four wheels. Using Wrong-Sized Tires: Using any other tire size than what is specified for your Mazda (page 10-6) is dangerous. It could seriously affect ride, handling, ground clearance, tire clearance, and speedometer calibration.
Page 247 J56J_8S11-EA-03G_Edition1.book Page 27 Tuesday, June 24, 2003 6:29 PM M Tire Inflation Pressure WARNING Incorrect Tire Inflation: Overinflation or underinflation of tires is dangerous. Adverse handling or unexpected tire failure could result in a serious accident. Always inflate the tires to the correct pressure (page 10-6).
Page 248 J56J_8S11-EA-03G_Edition1.book Page 28 Tuesday, June 24, 2003 6:29 PM Maintenance and Care Owner Maintenance M Tire Rotation To equalize tread wear, rotate the tires every 12,000 km (7,500 miles)/8,000 km* (5,000 miles) or sooner if irregular wear develops. During rotation, inspect them for correct balance.
Page 249 J56J_8S11-EA-03G_Edition1.book Page 29 Tuesday, June 24, 2003 6:29 PM M Temporary Spare Tire Inspect the temporary spare tire at least monthly to make sure it’s properly inflated and stored. The temporary spare tire is easier to handle because of its construction. It is lighter and smaller than a conventional tire and should be used only for an emergency and only for a short distance.
Page 250: Light Bulbs
J56J_8S11-EA-03G_Edition1.book Page 30 Tuesday, June 24, 2003 6:29 PM Maintenance and Care Owner Maintenance Light Bulbs Overhead light/Map lights Headlights(Low beam) Fog lights Headlights (High beam) Parking lights High-mount brake light Trunk light Taillights 8-30 Form No. 8S11-EA-03G Side-marker lights Front turn signal lights Brake lights/Taillights Courtesy lights...
Page 251 J56J_8S11-EA-03G_Edition1.book Page 31 Tuesday, June 24, 2003 6:29 PM Your Mazda’s headlights and fog lights have replaceable halogen bulbs. WARNING Handling Halogen Bulbs: When a halogen bulb breaks, it is dangerous. These bulbs contain pressurized gas. If one is broken, it will explode and serious injuries could be caused by the flying glass.
Page 252 J56J_8S11-EA-03G_Edition1.book Page 32 Tuesday, June 24, 2003 6:29 PM Maintenance and Care Owner Maintenance Side-marker lights 1. Turn the screw counterclockwise and remove it, then partially peel back the mudguard. 2. Turn the socket and bulb assembly counterclockwise and remove it. 3.
Page 253 J56J_8S11-EA-03G_Edition1.book Page 33 Tuesday, June 24, 2003 6:29 PM Reverse lights, Taillights 1. Pull the center section of the plastic retainer and remove the retainers, then remove the trunk rear trim. Removal Installation Trunk rear trim 2. Turn the socket and bulb assembly counterclockwise and remove it.
Page 254 J56J_8S11-EA-03G_Edition1.book Page 34 Tuesday, June 24, 2003 6:29 PM Maintenance and Care Owner Maintenance License plate lights 1. Wrap a flathead screwdriver with a soft cloth to prevent damage to the lens and remove the lens by carefully prying on the edge of the lens with a flathead screwdriver.
Page 255 J56J_8S11-EA-03G_Edition1.book Page 35 Tuesday, June 24, 2003 6:29 PM Overhead light/Map lights (Without overhead console) 1. Wrap a flathead screwdriver with a soft cloth to prevent damage to the trim and gently insert it in the overhead light as shown in the figure, and then remove the overhead light unit.
Page 256: Fuses
If the same fuse blows again, avoid using that system and consult an Authorized Mazda Dealer as soon as possible. M Fuse Replacement If the electrical system doesn’t work, first inspect fuses on the vehicle’s left side.
Page 257 Blown 5. Push in a new fuse of the same rating, and make sure it fits tightly. If it doesn’t, have an Authorized Mazda Dealer install it. If you have no spare fuses, borrow one of the same rating from a circuit not essential to vehicle operation, such as the SPARE circuit.
Page 258 Maintenance and Care Owner Maintenance 3. If a fuse is blown, replace it with a new one of the same rating . Normal Blown NOTE To replace the MAIN fuse, contact an Authorized Mazda Dealer (page 8-39). 8-38 Form No. 8S11-EA-03G...
Page 259: Fuse Panel Description
J56J_8S11-EA-03G_Edition1.book Page 39 Tuesday, June 24, 2003 6:29 PM M Fuse Panel Description Fuse block (Engine compartment) FUSE PROTECTED DESCRIPTION RATING COMPONENT SPARE — SPARE — SPARE — — — — — — — Injector Air flow sensor, ENG BAR EGR control valve sensor...
Page 260 J56J_8S11-EA-03G_Edition1.book Page 40 Tuesday, June 24, 2003 6:29 PM Maintenance and Care Owner Maintenance FUSE PROTECTED DESCRIPTION RATING COMPONENT BLOWER Blower motor Overhead light, Power door lock — — — Rear window DEFOG defroster AD FAN Cooling fan FAN2 Cooling fan FAN1 Brake/Taillights, License plate...
Page 261 J56J_8S11-EA-03G_Edition1.book Page 41 Tuesday, June 24, 2003 6:29 PM Fuse block (Vehicle’s left side) FUSE PROTECTED DESCRIPTION RATING COMPONENT Engine control ENGINE IG system Instrument METER IG cluster Seat warmer SEAT Rear window defroster M.DEF 7.5A Mirror defroster Windshield WIPER wiper and washer ABS unit...
Page 262: Appearance Care
Prevention It is necessary to have your Mazda washed and waxed to preserve its finish according to the instructions in this section. This should be done as soon as possible.
Page 263 • In low temperatures a vehicle’s finish hardens. This increases the chance of paint chipping. • Chipped paint can lead to rust forming on your Mazda. Before this happens, repair the damage by using Mazda touch-up paint according to the instructions in this section.
Page 264: Exterior Care
• Cleansers or wax containing abrasives are used. NOTE • Mazda is not responsible for scratches caused by automatic car washes or improper washing. • Scratches are more noticeable on vehicles with darker paint finishes.
Page 265 J56J_8S11-EA-03G_Edition1.book Page 45 Tuesday, June 24, 2003 6:29 PM Pay special attention to removing salt, dirt, mud, and other foreign material from the underside of the fenders, and make sure the drain holes in the lower edges of the doors and rocker panels are clean. Insects, tar, tree sap, bird droppings, industrial fallout, and similar deposits can damage the finish if not removed...
Page 266: Underbody Maintenance
Exposed metal quickly rusts and can lead to major repairs. CAUTION If your Mazda is damaged and needs metal parts repaired or replaced, make sure the body shop applies anti- corrosion materials to all parts, both repaired and new.
Page 267: Interior Care
J56J_8S11-EA-03G_Edition1.book Page 47 Tuesday, June 24, 2003 6:29 PM M Aluminum Wheel Maintenance A protective coating is provided over the aluminum wheels. Special care is needed to protect this coating. NOTE • Don’t use a wire brush or any abrasive cleaner, polishing compound, or solvent on aluminum wheels.
Page 268 WARNING Damaged Seat Belt: Using damaged seat belts is dangerous. In a collision, damaged belts cannot provide adequate protection. Have an Authorized Mazda Dealer replace damaged belts immediately. 8-48 *Some models. Form No. 8S11-EA-03G M Cleaning the Window Interiors If the windows become covered with an oily, greasy, or waxy film, clean them with glass cleaner.
Page 269: Customer Information And Reporting Safety Defects
Mazda Importer/Distributors ... 9-8 Importer/Distributor ... 9-8 Distributor in Each Area ... 9-8 Warranty ... 9-9 Warranties for Your Mazda ... 9-9 Outside the United States ... 9-10 Outside Canada ... 9-11 Registering Your Vehicle in A Foreign Country (Except United States and Canada) ...
Page 270: Customer Assistance
M STEP 1: Contact Your Mazda Dealer Discuss the matter with an Authorized Mazda Dealer. This is the quickest and best way to address the issue. If your concern has not been resolved by the CUSTOMER RELATIONS, SALES, SERVICE, or PARTS MANAGER, then please contact the GENERAL MANAGER of the dealership or the OWNER.
Page 271 3. Vehicle Identification Number (17 digits, noted on your registration or title or located on the upper driver’s side corner of the dash) 4. Purchase date and current mileage 5. Your dealer’s name and location 6. Your question(s) If you live outside the U.S.A., please contact your nearest Mazda Distributor. Form No. 8S11-EA-03G...
Page 272: Customer Assistance (Canada)
Your complete and permanent satisfaction is of primary concern to Mazda. All Authorized Mazda Dealers have both the knowledge and tools to keep your Mazda in top condition. In our experience, any questions, problems, or complaints regarding the operation of your Mazda or any other general service transactions are most effectively resolved by your dealer.
Page 273 If a specific item of concern arises, where a solution cannot be reached between an owner, Mazda, and/or one of it’s dealers (that all parties cannot agree upon), the owner may wish to use the services offered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 274 British Columbia & Yukon Territories Alberta & Northwest Territories Saskatchewan Manitoba Ontario Atlantic Canada Quebec M Regional Offices REGIONAL OFFICES MAZDA CANADA INC. WESTERN REGION 8171 ACKROYD ROAD SUITE 2000 RICHMOND B.C. V6X 3K1 (604) 303-5670 MAZDA CANADA INC. CENTRAL/ATLANTIC REGION...
Page 275: Customer Assistance (Puerto Rico)
M STEP 1 Discuss the matter with an Authorized Mazda Dealer. This is the quickest and best way to address the issue. If your concern has not been resolved by the CUSTOMER RELATIONS, SALES, SERVICE, or PARTS MANAGER, then please contact the GENERAL MANAGER of the dealership or the OWNER.
Page 276: Mazda Importer/Distributors
305 Milner Avenue, Suite 400 Scarborough, Ontario M1B 3V4 Canada TEL:1 (800) 263-4680 (in Canada) (416) 609-9909 (outside Canada) M PUERTO RICO Plaza Motors Corp. (Mazda de Puerto Rico) P.O. Box 362722, San Juan, Puerto Rico 00936-2722 TEL: (787) 641-9300...
Page 277: Warranty
• California Emission Control Warranty (U.S.A. only) • Emission Control Warranty (Canada only) • Replacement Parts and Accessories Limited Warranty • Tire Warranty NOTE Detailed warranty information is provided with your Mazda. Form No. 8S11-EA-03G Customer Information and Reporting Safety Defects Warranty...
Page 278: Outside The United States
We strongly recommend that you NOT take your Mazda outside the United States. However, in the event that you are moving to Canada permanently, Mazda vehicles built for use in the United States could be eligible for exportation to Canada with specific vehicle modifications to comply with the Canadian Motor Vehicle Safety requirements (CMVSS).
Page 279: Outside Canada
We strongly recommend that you NOT take your Mazda outside Canada. However, in the event that you are moving to the United States permanently, Mazda vehicles built for use in Canada could be eligible for exportation to the United States with specific vehicle modifications to comply with the United States Federal Motor Vehicle Safety Standards (FMVSS).
Page 280: Registering Your Vehicle In A Foreign Country (Except United States And Canada)
Parts, servicing techniques, and tools necessary to maintain and repair your vehicle may be unavailable. There might not be an Authorized Mazda Dealer in the country you plan to take your vehicle. The Mazda warranty is valid only in certain countries.
Page 281: Add-On Non-Genuine Parts And Accessories
Non-genuine parts and accessories for Mazda vehicles can be found in stores. These may fit your vehicle, but they are not approved by Mazda for use with Mazda vehicles. When you install non-genuine parts or accessories, they could affect your vehicle’s performance or safety system;...
Page 282: Cell Phones
J56J_8S11-EA-03G_Edition1.book Page 14 Tuesday, June 24, 2003 6:29 PM Customer Information and Reporting Safety Defects Cell Phones Cell Phones Warning Use of Cell Phones and Other Devices by Driver: Use of any electrical devices such as cell phones, computers, portable radios, vehicle navigation or other devices by the driver while the vehicle is moving is dangerous.
Page 283: Type Approval Of Equipment
J56J_8S11-EA-03G_Edition1.book Page 15 Tuesday, June 24, 2003 6:29 PM Customer Information and Reporting Safety Defects Type Approval of Equipment Type Approval of Equipment Immobilizer system 9-15 Form No. 8S11-EA-03G...
Page 284: Uniform Tire Quality Grading System (Utqgs)
J56J_8S11-EA-03G_Edition1.book Page 16 Tuesday, June 24, 2003 6:29 PM Customer Information and Reporting Safety Defects Uniform Tire Quality Grading System (UTQGS) Uniform Tire Quality Grading System (UTQGS) This information relates to the tire grading system developed by the U.S. National Highway Traffic Safety Administration for grading tires by tread wear, traction, and temperature performance.
Page 285: Uniform Tire Quality Grading
These grades will be added to the sidewalls of passenger vehicle tires over the next several years according to a schedule established by the NHTSA and the tire manufacturers. The grade of tires available as standard or optional equipment on Mazda vehicle may vary with respect to grade.
Page 286: Reporting Safety Defects
Customer Information and Reporting Safety Defects Reporting Safety Defects Reporting Safety Defects NOTE If you live in the U.S.A., all correspondence to Mazda Motor Corporation should be forwarded to: Mazda North American Operations 7755, Irvine Center Drive Irvine, California 92618-2922 P.O.
Page 287: Wiring Diagram
Factory-authorized Mazda service publications are available for owners who wish to do some of their own maintenance and repair. When requesting any of our publications through an Authorized Mazda Dealer, refer to the chart below. If they don’t have what you need in stock, they can order it for you.
Page 288 J56J_8S11-EA-03G_Edition1.book Page 20 Tuesday, June 24, 2003 6:29 PM 9-20 Form No. 8S11-EA-03G...
Page 289: Specifications
J56J_8S11-EA-03G_Edition1.book Page 1 Tuesday, June 24, 2003 6:29 PM Specifications Technical information about your Mazda. Identification Numbers ... 10-2 Vehicle Information Labels ... 10-2 Specifications ... 10-3 Specifications ... 10-3 Form No. 8S11-EA-03G 10-1...
Page 290: Identification Numbers
J56J_8S11-EA-03G_Edition1.book Page 2 Tuesday, June 24, 2003 6:29 PM Identification Numbers Vehicle Information Labels M Vehicle Identification Number The vehicle identification number legally identifies your vehicle. The number is on a plate attached to the left top side of the dashboard.
Page 291: Electrical System
J56J_8S11-EA-03G_Edition1.book Page 3 Tuesday, June 24, 2003 6:29 PM M Engine Item Type DOHC-16V in-line, 4-cylinder Bore×Stroke 87.5 × 94.0 mm (3.44 × 3.70 in) Displacement 2,261 ml (2,261 cc, 137.9 cu in) Compression ratio M Electrical System Item Battery 2.3-liter engine Alternator 3.0-liter engine...
Page 292: Air Conditioner
J56J_8S11-EA-03G_Edition1.book Page 4 Tuesday, June 24, 2003 6:29 PM Specifications M Capacities (Approximate Quantities) Item 2.3-liter engine Engine oil 3.0-liter engine 2.3-liter engine Coolant 3.0-liter engine 2.3-liter engine Manual transaxle oil 3.0-liter engine 2.3-liter engine Automatic transaxle fluid 3.0-liter engine Fuel tank Check oil and fluid levels with dipsticks or reservoir gauges.
Page 293 J56J_8S11-EA-03G_Edition1.book Page 5 Tuesday, June 24, 2003 6:29 PM M Light Bulbs Exterior light Light bulb High beam Headlights Low beam Front turn signal lights Parking lights Fog lights Side-marker lights Type A High-mount brake lights Type B Rear turn signal lights Brake lights/Taillights Taillights Reverse lights...
Page 294 NOTE The tires have been optimally matched with the chassis of your vehicle. When replacing tires, Mazda recommends that you replace tires of the same type originally fitted to your vehicle. For details, contact an Authorized Mazda Dealer. Check the tire pressure label for tire size and inflation pressure. Refer to Tire Inflation...
Page 295: Index
J56J_8S11-EA-03G_Edition1.book Page 1 Tuesday, June 24, 2003 6:29 PM Index 11-1 Form No. 8S11-EA-03G...
Page 296 J56J_8S11-EA-03G_Edition1.book Page 2 Tuesday, June 24, 2003 6:29 PM Index Accessory Socket ... 6-52 Add-On Non-Genuine Parts and Accessories ... 9-13 Air Bag Systems ... 2-36 Air Filter ... 8-21 Ambient Temperature Display ... 6-46 Antenna ... 6-16 Anti-Lock Brake System (ABS) ... 5-8 Warning light ...
Page 297 J56J_8S11-EA-03G_Edition1.book Page 3 Tuesday, June 24, 2003 6:29 PM Cup Holder ...6-48 Customer Assistance ...9-2 Dashboard Illumination ... 5-28 Daytime Running Lights ...5-41 Defroster Rear window ...5-44 Dimensions ...10-4 Door Locks ...3-7 Driving In Flooded Area ...4-9 Driving Tips ...4-6 Automatic transaxle ...5-17 Break-in period ...4-6 Driving in flooded area ...
Page 298 J56J_8S11-EA-03G_Edition1.book Page 4 Tuesday, June 24, 2003 6:29 PM Index Hazard Warning Flasher ... 5-45 Hazardous Driving ... 4-7 Headlights Control ... 5-40 Flashing ... 5-40 High-low beam ... 5-40 On reminder ... 5-40 HomeLink Wireless Control System ... 5-46 Hood Release ...
Page 299 J56J_8S11-EA-03G_Edition1.book Page 5 Tuesday, June 24, 2003 6:29 PM Meters and Gauges ...5-25 Mirrors Outside mirrors ...3-25 Rearview mirror ...3-26 Money-Saving Suggestions ... 4-6 Moonroof ...3-18 Odometer and Trip Meter ... 5-26 Outside Mirrors ...3-25 Overhead Console ...6-50 Overhead Lights ...6-42 Overheating ...7-12 Overloading ...4-9 Paint Damage ...8-42...
Page 300 J56J_8S11-EA-03G_Edition1.book Page 6 Tuesday, June 24, 2003 6:29 PM Index Storage Compartments ... 6-50 Center box ... 6-50 Center console ... 6-51 Glove box ... 6-51 Overhead console ... 6-50 Storage pocket ... 6-50 Storage Pocket ... 6-50 Sunshade ... 3-19 Sunvisors ...
Page 301 J56J_8S11-EA-03G_Edition1.book Page 7 Tuesday, June 24, 2003 6:29 PM Windows Power windows ...3-14 Windshield Washer ...5-43 Windshield Wipers ...5-43 Blades replacement ... 8-23 Winter Driving ...4-8 Form No. 8S11-EA-03G Index 11-7...
Page 302 J56J_8S11-EA-03G_Edition1.book Page 8 Tuesday, June 24, 2003 6:29 PM 11-8 Form No. 8S11-EA-03G...

Mazda 2004 MAZDA6 Owner's Manual

Table of Contents

2 Essential Safety Equipment

Seats

Seat Belt Systems

Child Restraint

SRS Air Bags

3 Knowing Your Mazda

Doors and Locks

Security System

Steering Wheel and Mirrors

4 Before Driving Your Mazda

Fuel and Engine Exhaust Precautions

Before Starting the Engine

Driving Tips

Towing

5 Driving Your Mazda

Starting and Driving

Instrument Cluster and Indicators

Warning/Indicator Lights and Beep Sounds

Switches and Controls

6 Interior Comfort

Climate Control System

Audio System

Interior Equipment

7 In Case of an Emergency

Parking in an Emergency

Flat Tire

Overheating

Emergency Starting

Emergency Towing

8 Maintenance and Care

Introduction

Scheduled Maintenance

Owner Maintenance

Appearance Care

Customer Information and Reporting 9

Customer Assistance

Mazda Importer/Distributors

Warranty

Cell Phones

Type Approval of Equipment

Uniform Tire Quality Grading

Reporting Safety Defects

Service Publications

Quick Links

Chapters

Related Manuals for Mazda 2004 MAZDA6

Summary of Contents for Mazda 2004 MAZDA6
