Page 1
Koninklijke Philips Electronics N.V. or their respective owners. TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust earlier supplies accordingly. PHILIPS and the PHILIPS’ Shield Emblem are used under license from Koninklijke Philips Electronics N.V.
Page 2
Koninklijke Philips Electronics N.V. or their respective owners. TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust earlier supplies accordingly. PHILIPS and the PHILIPS’ Shield Emblem are used under license from Koninklijke Philips Electronics N.V.
Page 3
Koninklijke Philips Electronics N.V. or their respective owners. TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust earlier supplies accordingly. PHILIPS and the PHILIPS’ Shield Emblem are used under license from Koninklijke Philips Electronics N.V.
Page 4
Product information is subject to change without notice. HDMI 2 in – ARC –Ultra HD – HDR • detailed product information, please visit TV Bottom www.philips.com/support Audio out – Optical Toslink • Network LAN – RJ45 • YPbPr, L/R • Display Type HDMI 4 in – ARC •...
Page 5
Supported media server software(DMS) (Windows-1251),Greek (Windows-1253),Turkish You can use any DLNA V1.5 certified media server – (Windows-1254),Western Europe (Windows-1252) software(DMS class) You can use the Philips TV Remote app (iOS and • Image Codecs : JPEG – Limitations : Android) on mobile devices.
Page 6
Refer to the diversity tables for the correct values. two pins of the Mains/AC Power plug. • The correct component values are listed on the Philips • Check the cabinet for defects, to prevent touching of any Spare Parts Web Portal.
Page 7
• Mix of lead-free soldering tin/parts with leaded soldering tin/parts is possible but PHILIPS recommends strongly to avoid mixed regimes. If this cannot be avoided, carefully clear the solder-joint from old tin and re-solder with new tin.
Page 8
originating from the USA and used e.g. in • Always respect voltages. While some may not be dangerous in themselves, they can cause unexpected LATAM and AP-NTSC countries reactions that are best avoided. Before reaching into a B-TXT Blue TeleteXT powered TV set, it is best to test the high voltage Centre channel (audio) insulation.
Page 9
G-TXT Green TeleteXT distance is 6.5 MHz. L' is Band I, L is all H_sync to the module bands except for Band I High Definition LG.Philips LCD (supplier) Hard Disk Drive Loudspeaker HDCP High-bandwidth Digital Content Protection: LVDS Low Voltage Differential Signalling A “key”...
Page 10
Serial Peripheral Interface bus; a 4-wire module, implementing the CA system for a synchronous serial data link standard host (e.g. a TV-set) S/PDIF Sony Philips Digital InterFace Power On Reset, signal to reset the uP SRAM Static RAM PSDL Power Supply for Direct view LED...
Page 11
Thin Film Transistor toward external amplifier Total Harmonic Distortion Vestigial Side Band; modulation method TMDS Transmission Minimized Differential WYSIWYR What You See Is What You Record: record Signalling selection that follows main picture and Transport Stream sound TeleteXT WXGA 1280 × 768 (15:9) TXT-DW Dual Window with TeleteXT XTAL...
Page 17
3.2 Assembly/Panel Removal 3.2.1 Stand/Base removal Common: 1. Remove the fixation screws [1] that secure the stand. 2. Take the stand bracket out from the set. OLED 973 Series: 1. Remove all fixation screws [1] then take out rear cover. 2.
Page 19
3.2.2 IR board Control Unit Common: 1. Unplug the connector from the SSB. Caution: be careful, as these are very fragile connectors! 2. Remove all the fixation screws [1] and connector from the IR board control unit. 3. Remove the IR lens, IR board from the DECO_REAR_COVER. When defective, replace the whole unit.
Page 20
3. Gently lift the rear cover from the TV. Make sure that wires and cables are not damaged while lifting the rear cover from the set. (7303/7503 series) Remark: Pictures above are taken from model 43PUS7303/12, but instructions will be similar for other 7303/7503 series models.
Page 21
OLED 873 series: 1. Remove all fixation screws [2] and [3] that secure the Back cover assy. 2. Unplug the connector [2] that marked by red box below from SSB. 3. Gently lift the rear cover from the TV. Make sure that wires and cables are not damaged while lifting the rear cover from the set. (OLED 873 series) OLED 973 series: Clarified in...
Page 22
Remove all the fixation screws [1] and connectors [2] from the keyboard control panel then take it out from the Back cover. When defective, replace the whole unit. Remark: Picture above is taken from model 43PUS7303/12, but instructions will be similar for other series models. OLED 973 series:...
Page 23
3.2.6 Power Supply Unit (PSU) Caution: it is mandatory to remount all different screws at their original position during re-assembly. Failure to do so may result in damaging the PSU. 1. Gently unplug all connectors from the PSU. 2. Remove all fixation screws from the PSU. 3.
Page 24
4. Service Modes 4.1 Service Modes The Service Mode feature is split into following parts: Service Alignment Mode (SAM). Factory Mode. Customer Service Mode (CSM).SAM and the Factory mode offer features, which can be used by the Service engineer to repair/align a TV set. ...
Page 25
With the “LEFT/RIGHT” keys, it is possible to: – (De) activate the selected menu item. – (De) activate the selected sub menu. – Change the value of the selected menu item. When you press the MENU button once while in top level SAM, the set will switch to the normal user menu (with the SAM mode still active in the ...
Page 26
Public Broadcasting Service password Reset. etc. How to Activate the Factory mode To activate the Factory mode, use the following method: Press the following key sequence on the remote control transmitter: from the “menu/home” press “1999”, directly followed by the ...
Page 27
Line number for every line (to make CSM language independent). Set the screen mode to full screen (all contents on screen is visible). After leaving the Customer Service Mode, the original settings are restored. Possibility to use “CH+” or “CH-” for channel surfing, or enter the specific channel number on the RC. ...
Page 28
5. Software Upgrading, Error code and Panel Code 5.1 Software Upgrading Step 1: Ready for F/W Upgrade 1. Rename the software as “autorun.upg”. 2. Prepare a USB memory (File format: FLAT, Size: 1G~8G). 3. Copy the software to USB flash disk (root directory). Note the version of this F/W before you change the software file name.
Page 29
4. Press OK to start software upgrade 5. Upgrade in progress...
Page 30
Step 3: Check the SW version 1. After burning software, TV will restart. 2. Press “123654”, enter Customer Service Mode to check if the software version is correct. Caution: Please make sure that software upgrade is finished before unplug the USB and AC power! 5.2 Error Code 5.2.1 Introduction Error codes are required to indicate failures in the TV set.
Page 31
5.2.3 Error codes overview In this chassis only “layer 2” error codes are available and point to problems on the SSB. They are triggered by LED blinking when CSM is activated. Only the following layer 2 errors are defined: 5.2.4 How to Clear the Error Buffer The error code buffer is cleared in the following cases: •...
Page 32
“Display Code” in below tab. After resetting the Display Code, restart the set immediately. Setting Set CTN_ALT BOM# Panel Type Display Code Option Code 43PUS7303/12 TPT430U3-QVN03.U S0B0K 49PUS7503/12 TPT490F2-FN02.S S802A 50PUS7303/12 TPT500U1-QVN03.U S5B0Y 55PUS7303/12 TPT550U1-QVN05.U S57B0F...
Page 33
Trouble shooting 2016年12月10日 2016/4/8 Picture-related Intermittent Ask Photo Picture ? problem ? Menu Smarkt Signal SW latest ? Backlight? issue function? issue SSB+LVDS+Panel Update SW LED working ? PSU/SSB Problem solved ? Sound ? PSU+ Panel Finish SW+SSB...
Page 34
Trouble shooting 2016年12月10日 2016/4/8 Audio/Sound- related Intermittent Sound ? problem ? Setting SW latest ? Mute ? issue issue Update SW Extra device Check extra connect? device Problem solved ? Factory setting Finish Sound back ? Setting issue SSB+SPK...
Page 35
6.Slow response to user interaction 7.Switches ON by itself 8.Switches Off by itself 9.Stuck in standby mode / unable to start up 10.Stuck on PHILIPS / ANDROID logo 11.CAM not recognized by TV 12.CAM authentication issue 13.Misc CAM issue 14.IP-EPG issues 15.BC-EPG issues...
Page 37
7.2 Power Supply Power architecture of this platform. AUDIO LVDS 24V for 715G9058M Platform power Display power CN8601 ON/OFF PS_ON CN8603 for 715G9324P Platform CN9201 & CN9102 for 12V_A 715G8886P/715G9106P MT5596 24V_A 3.5_STB CN1190 AC-input + Main filter AC IN...
Page 38
7.3 Power tree WiFi & BT/ VCC U4251 +5V-WIFI RT6217 MT5596/ AVDD1V0-STB U4308 +3V5-SB +1V0-AVDD G9661 U4309 MT5596/ AVDD33-ETH-STB +3V5-SB RT6217 U4304 +3V5-SB MT5596/ AVDD33-STB +3V3-STANDBY RT9193-33GB power for RC off MT5596/ DDRV U1701 U4302 +5V_SW +12V +1V5-DDR 600 mA DDR (X 5)/ VDD SY8368 RT8079ZQW...
Page 84
9-6-11 BE-NT72333f-GND NT72333 GND U3100H Y 10 Y 11 Y 12 Y 13 Y 14 Y 15 Y 16 Y 17 Y 18 Y 19 AA10 AA11 AA12 AA13 AA16 AA20 AA21 AB15 AB20 AB21 AC20 AC21 AC22 AC25 AC26 AD20 AD21 AD22...
Page 148
9.12 E 715G8555 Keyboard control panel (For 7303/7503/OLED873 Series) 9-12-1 Key Joystick key define CONN TO SSB JOYSTICK Direction switch Key function Resistance Voltage Range Center 2-5 short Menu 0.0 to 0.22 V CN01 CN04 Right 1-5 short 0.5V 0.39 to 0.60 V KEY1 AMBI_SPI_CLK Left...
Page 149
9.13 E 715G9116 Keyboard control panel (For OLED973 Series) 9-13-1 Key CONN TO SSB JOYSTICK Direction switch Key function Resistance Voltage Center 2-5 short Menu CN01 CN04 Right 1-5 short 0.5V KEY1 AMBI_SPI_CLK Left 4-5 short 0.81V AMBI_SPI_MOSI 100PF 50V +12V_AMBI Down 3-5 short...
