VA2418-smh
Display
User Guide
IMPORTANT: Please read this User Guide to obtain important information on installing and using your product in
a safe manner, as well as registering your product for future service. Warranty information contained in this User
Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at
http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right
corner of our website. "Antes de operar su equipo lea cu idadosamente las instrucciones en este manual"
Model No. VS16422
P/N: VA2418-SMH-7
Advertisement
Table of Contents
Related Manuals for ViewSonic VA2418-SMH
Summary of Contents for ViewSonic VA2418-SMH
- Page 1 Warranty information contained in this User Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right corner of our website.
- Page 2 As a world-leading provider of visual solutions, ViewSonic® is dedicated to exceeding the world’s expectations for technological evolution, innovation, and simplicity. At ViewSonic®, we believe that our products have the potential to make a positive impact in the world, and we are confident that the ViewSonic® product you have chosen will serve you well.
-
Page 3: Safety Precautions
Safety Precautions Please read the following Safety Precautions before you start using the device. • Keep this user guide in a safe place for later reference. • Read all warnings and follow all instructions. • Sit at least 18" (45 cm) away from the device. •... - Page 4 • If smoke, an abnormal noise, or a strange odor is present, immediately turn the device off and call your dealer or ViewSonic®. It is dangerous to continue using the device. •...
- Page 5 • Fastening the display to a wall or fixed object using cordage or other restraining devices can help support the weight of the display in order to prevent the display from falling over. Hole pattern Interface Pad Pad Hole Screw Specification & Quantity (W x H) (W x H x D) M4 x 10 mm...
-
Page 6: Table Of Contents
Contents Safety Precautions ............3 Introduction ..............8 Package Contents ....................8 Product Overview ....................9 Front and Rear View ....................9 I/O Ports ......................... 9 Initial Setup ............... 10 Installing the Stand ....................10 Wall Mounting ......................11 Using the Security Slot ..................12 Making Connections .......... - Page 7 Regulatory and Service Information ......34 Compliance Information ..................34 Declaration of RoHS2 Compliance................. 34 Indian Restriction of Hazardous Substances ............35 Product Disposal at End of Product Life ..............35 Copyright Information ..................36 Customer Service ....................37 Limited Warranty ....................38 Mexico Limited Warranty ..................
-
Page 8: Introduction
Introduction Package Contents • Monitor • Power cord • Video cable • Quick start guide NOTE: The power cord and video cables included in your package may vary depending on your country. Please contact your local reseller for more information. -
Page 9: Product Overview
Product Overview Front and Rear View I/O Ports HDMI 1. AC IN 2. HDMI 3. VGA 4. Audio In 5. Audio Out NOTE: For more information about the 1/ /2/5( ) key and its functions, refer to “Hot Keys” on page 17. -
Page 10: Initial Setup
Initial Setup Installing the Stand NOTE: Always place the device on a flat, stable surface. Failure to do so may cause the device to fall and damage the device and/or result in personal injury. -
Page 11: Wall Mounting
4 pieces NOTE: Wall mount kits are sold separately. To obtain a wall mounting kit, contact ViewSonic® or your local dealer. 1. Turn off the device and disconnect all cables. 2. Place the device on a flat, stable surface with the screen facing down. -
Page 12: Using The Security Slot
Using the Security Slot To help prevent the device from being stolen, use a security slot locking device to secure the device to a fixed object. Additionally, fastening the monitor to a wall or fixed object using a security cable can help support the weight of the monitor in order to prevent the monitor from falling over. -
Page 13: Making Connections
Making Connections This section guides you on how to connect the monitor with other equipment. Connecting to Power 1. Connect the power cord to the AC IN jack at the rear of the device. 2. Connect the power cord plug to a power outlet. -
Page 14: Connecting External Devices
Connecting External Devices HDMI HDMI... -
Page 15: Using The Monitor
Using the Monitor Adjusting the Viewing Angle Tilt Angle Adjustment Tilt the monitor forwards or backwards to the desired viewing angle (-5˚ to 20˚). NOTE: When adjusting, support the stand firmly with one hand while tilting the monitor forwards or backwards with the other hand. 14 14... -
Page 16: Turning The Device On/Off
Turning the Device On/Off 1. Plug the power cord into a power outlet. 2. Press the Power button to turn on the monitor. 3. To turn the monitor off, press the Power button again. NOTE: The monitor will still consume some power as long as the power cord is connected to the power outlet. -
Page 17: On-Screen Display (Osd) Menu
Select one of the preset color settings. Color Adjust Displays the timing mode coming from the graphics card in the computer, the LCD model Information number, the serial number, and the ViewSonic® website URL. Manually set a variety of image quality Manual Image Adjust adjustments. -
Page 18: Hot Keys
Hot Keys When the On-Screen Display (OSD) Menu is off, you can quickly access special functions by using the control panel keys. Description Press and hold the keys to lock/unlock the OSD Menu. When the menu appears on the screen, continue holding both keys for 10 seconds to lock/unlock the OSD Menu. - Page 19 Description Press and hold the key for 5 seconds to change the color space. Choose from: Auto/RGB(0-255)/RGB(16-235)/YCC(0-255)/YCC(16- (Hold for 235). 5 seconds) Press the key to enter the ViewMode menu. Press the key to adjust the Blue Light Filter function. Press the key to toggle between input sources.
-
Page 20: Configuring The Settings
Configuring the Settings General Operations 1. Press the 1 key to display the On-Screen Display (OSD) Menu. A U T O I M A G E A D J U S T A S T / B R I G H T N E S S L E C T J U S T J U S T... - Page 21 3. Press the ‚ or key to select the desired menu option. Then press the 2 key to enter the sub-menu. M A N U A L I M A G E A D J U S T V I E W M O D E S T A N D A R D G A M E M O V I E...
-
Page 22: On-Screen Display (Osd) Menu Tree
On-Screen Display (OSD) Menu Tree Main Menu Sub-menu Menu Option Auto Image Adjust Contrast/Brightness Contrast (-/+, 0~100) Brightness (-/+, 0~100) Input Select D-Sub HDMI Audio Adjust Volume (-/+, 0~100) Mute Color Adjust sRGB Bluish Cool Native Warm User Color (-/+, 0~100) Green (-/+, 0~100) Blue... - Page 23 Main Menu Sub-menu Menu Option Manual Image Adjust H./V. Position Horizontal Position (-/+, 0~100) Vertical Position (-/+, 0~100) Horizontal Size (-/+, 0~100) Fine Tune (-/+, 0~100) Sharpness (-/+, 0/25/50/75/100) Dynamic Contrast Response Time Standard Advance Ultra Fast Aspect Ratio Full Screen Overscan ECO Mode Standard...
- Page 24 Main Menu Sub-menu Menu Option Setup Menu Language Select English Français Deutsch Español Italiano Suomi Русский Türkçe 日本語 한국어 繁體中文 简体中文 Resolution Notice OSD H. Position H. Position (-/+, 0~100) V. Position (-/+, 0~100) OSD Time Out (-/+, 5/15/30/60) OSD Background Auto Power Off Power Indicator Sleep...
-
Page 25: Appendix
Appendix Specifications Item Category Specifications Type IPS, TFT Active Matrix 1920 x 1080 LCD; 0.2745 (H)mm x 0.2745 (V)mm pixel pitch Display Size 60.4 cm, 24" (23.8” viewable) Color Filter RGB vertical stripe Glass Surface Anti-Glare (Haze 25%), Hard Coating (3H) Input Signal Video Sync TMDS digital (100 Ω) - Page 26 Do not set the graphics card in your computer to exceed these timing modes; doing so may result in permanent damage to the display. Please use the power adapter from ViewSonic® or an authorized source only. The test condition follows EEI standards.
-
Page 27: Glossary
Glossary This section describes the standard glossary of terms used in all LCD display models. All terms are listed in alphabetical order. NOTE: Some terms may not be applicable to your monitor. Advanced DCR Advanced DCR technology automatically detects the image signal and intelligently controls the backlight brightness and color to improve on the ability to make the black blacker in a dark scene, and make the white whiter in a bright environment. - Page 28 Displays the timing mode (video signal input) coming from the graphics card in the computer, the LCD model number, the serial number, and the ViewSonic® website URL. See your graphics cards’s user guide for instructions on changing the resolution and refresh rate (vertical frequency).
- Page 29 Manual Image Adjust Displays the “Manual Image Adjust” menu. You can manually set a variety of image quality adjustments. Memory Recall Returns the adjustments back to factory settings if the display is operating in a factory preset timing mode listed in the “Specifications” of this manual. NOTE: ...
- Page 30 ViewMode ViewSonic’s unique ViewMode feature offers “Game”, “Movie”, “Web”, “Text”, “MAC”, and “Mono” presets. These presets are specifically designed to deliver an optimized viewing experience for different screen applications.
-
Page 31: Troubleshooting
• Connect the monitor to another computer. • If you have an older graphics card, contact ViewSonic® for a non-DDC adapter. Screen image is too • Adjust brightness and contrast settings via the OSD light or dark Menu. - Page 32 Problem or Issue Possible Solutions The screen appears • Make sure the “Blue Light Filter” is Off. yellow The OSD Menu • Check whether the OSD Menu is locked. does not appear • Turn off the monitor, unplug the power cord, plug it on the screen/the back in, and then turn on the monitor.
-
Page 33: Maintenance
• ViewSonic® does not recommend the use of any ammonia or alcohol-based cleaners on the display screen or case. Some chemical cleaners have been reported to damage the screen and/or case of the monitor. • ViewSonic® will not be liable for damage resulting from use of any ammonia or alcohol-based cleaners. -
Page 34: Regulatory And Service Information
Regulatory and Service Information Compliance Information This section addresses all connected requirements and statements regarding regulations. Confirmed corresponding applications shall refer to nameplate labels and relevant markings on the unit. Declaration of RoHS2 Compliance This product has been designed and manufactured in compliance with Directive 2011/65/EU of the European Parliament and the Council on restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS2 Directive) and is deemed to comply with the maximum concentration values issued... -
Page 35: Indian Restriction Of Hazardous Substances
Schedule 2 of the Rule. Product Disposal at End of Product Life ViewSonic® respects the environment and is committed to working and living green. Thank you for being part of Smarter, Greener Computing. Please visit the ViewSonic®... -
Page 36: Copyright Information
ENERGY STAR® is a registered trademark of the U.S. Environmental Protection Agency (EPA). As an ENERGY STAR® partner, ViewSonic® Corporation has determined that this product meets the ENERGY STAR® guidelines for energy efficiency. Disclaimer: ViewSonic® Corporation shall not be liable for technical or editorial errors or omissions contained herein;... -
Page 37: Customer Service
For technical support or product service, see the table below or contact your reseller. NOTE: You will need the product’s serial number. Country/ Region Website Country/ Region Website Asia Pacific & Africa Australia Bangladesh www.viewsonic.com/au/ www.viewsonic.com/bd/ 中国 (China) www.viewsonic.com.cn 香港 (繁體中文) www.viewsonic.com/hk/ Hong Kong (English) India www.viewsonic.com/hk-en/ www.viewsonic.com/in/... -
Page 38: Limited Warranty
How long the warranty is effective: ViewSonic® displays are warranted for between 1 and 3 years, depending on your country of purchase, for all parts including the light source and for all labor from the date of the first consumer purchase. - Page 39 (e) the serial number of the product. • Take or ship the product, freight prepaid, in the original container to an authorized ViewSonic® service center or ViewSonic®. • For additional information or the name of the nearest ViewSonic® service center, contact ViewSonic®. Limitation of implied warranties:...
- Page 40 Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic® shall not be liable for: • Damage to other property caused by any defects in the product, damages based upon inconvenience, loss of use of the product, loss of time, loss of...
-
Page 41: Mexico Limited Warranty
If a product proves to be defective in material or workmanship during the warranty period, ViewSonic® will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components &... - Page 42 Exclusion of damages: ViewSonic®’s liability is limited to the cost of repair or replacement of the product. ViewSonic® shall not be liable for: • Damage to other property caused by any defects in the product, damages...
- Page 43 Name, address, of manufacturer and importers: México, Av. de la Palma #8 Piso 2 Despacho 203, Corporativo Interpalmas, Col. San Fernando Huixquilucan, Estado de México Tel: (55) 3605-1099 http://www.viewsonic.com/la/soporte/index.htm NÚMERO GRATIS DE ASISTENCIA TÉCNICA PARA TODO MÉXICO: 001.866.823.2004 Hermosillo: Villahermosa: Distribuciones y Servicios Computacionales SA de CV.
- Page 44 C0 M91 Y72 K24 Process Color C0 M0 Y0 K100 Process Color C0 M91 Y72 K24 Process Color Pantone Black C Spot Color Pantone 187 C Spot Color...
