MASTERTEMP
INSTALLATION AND USER'S GUIDE
FOR YOUR SAFETY - READ BEFORE OPERATING
If you do not follow these instructions exactly, a fire or explosion may result, causing
property damage, personal injury or loss of life. For additional free copies of this
manual; call USA (800) 831-7133
FOR YOUR SAFETY - This product must be installed and serviced by authorized personnel, qualified in pool/spa
heater installation. Improper installation and/or operation can create carbon monoxide gas and flue gases which can
cause serious injury, property damage, or death. For indoor installations, as an additional measure of safety, Pentair
Aquatic Systems strongly recommends installation of suitable Carbon Monoxide Detectors in the vicinity of this
appliance and in any adjacent occupied spaces. Improper installation and/or operation will void the warranty.
Models
Natural Gas
(240 VAC)
(G20, G25)
461078
MT125, EURO
MT125HD, EURO
460902
Improper installation, adjustment,
alteration, service or maintenance
can cause property damage, personal injury or death.
Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
NOx CLASS 5
FOR YOUR SAFETY
•
If you do not follow these instructions exactly, a fire or explosion may result, causing property damage,
personal injury or loss of life.
•
Improper installation, adjustment, alteration, service or maintenance can cause property damage, personal
injury or death. Installation and service must be performed by a qualified installer, service agency or the
gas supplier.
•
Do not place articles or against this appliance.
•
Do not use or store flammable materials near this appliance.
•
Do not spray aerosols in the vicinity of this appliance while it is in operation.
FOR
YOUR
SAFETY
Pentair Water Pool and Spa, Inc. EMEA – Head Office: Industriepark, Wolfstee, Toekomstlaan 30, 2200 Herentals - Belgium.
Pentair Water Pool and Spa, Inc. USA
www. pentaireurope.com - www.pentairwater.com.au - www.pentairpool.com - www.staritepool.com
125 POOL AND SPA EURO
™
Propane Gas
COUNTRY OF DESTINATION:
(G31)
461079
460903
WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not use any phone in your building.
•
Immediately call your gas supplier from a neighbor's phone.
Follow the gas supplier's instructions.
•
If you cannot reach your gas supplier, call the fire department.
DO NOT store or use gasoline or other flammable vapors and liquids in the vicinity
of this or other appliances.
– 1620 Hawkins Ave., Sanford, NC 27330, USA • (919) 566-8000 • (800) 831-7133 –
10951 W. Los Angeles Ave., Moorpark, CA 93021, USA • (805) 553-5000 • (800) 831-7133
GB, BE, FR, DE
MasterTemp Pool and Spa Heater Installation and User's Guide
1 1
OWNER:
Retain For
Future
Reference
