English
The power tools that you have acquired are equivalent to the power tool in the enclosed operating instructions with exception of the
following differing information.
Technical Data
Straight Screwdriver C-EXACT
Article number 0 602 495 ...
No-load speed
Rated torque
Lever start
Thrust-start

Noise/Vibration Information

Measured values determined according to EN 60745.
Typically the A-weighted sound pressure level of the product is
62 dB(A). Uncertainty K=3 dB.
The noise level when working can exceed 80 dB(A).
Wear hearing protection!
Vibration total values (triax vector sum) determined according to
EN 60745:
Screwdriving without impact: Vibration emission value a
2
Uncertainty K =1.5 m/s .
The vibration emission level given in this information sheet has been
measured in accordance with a standardised test given in EN 60745
and may be used to compare one tool with another. It may be used
for a preliminary assessment of exposure.
The declared vibration emission level represents the main applica-
tions of the tool. However if the tool is used for different applica-
tions, with different accessories or poorly maintained, the vibration
emission may differ. This may significantly increase the exposure lev-
el over the total working period.
An estimation of the level of exposure to vibration should also take
into account the times when the tool is switched off or when it is run-
ning but not actually doing the job. This may significantly reduce the
exposure level over the total working period.
Identify additional safety measures to protect the operator from the
effects of vibration such as: maintain the tool and the accessories,
keep the hands warm, organisation of work patterns.

Declaration of Conformity

We declare under our sole responsibility that the product described
under "Technical Data" is in conformity with the following standards
or standardization documents: EN 60745 according to the provisions
of the directives 2004/108/EC, 98/37/EC (until Dec. 28, 2009),
2006/42/EC (from Dec. 29, 2009 on).
Technical file at:
Robert Bosch GmbH, PT/ESC, D-70745 Leinfelden-Echterdingen
Dr. Egbert Schneider
Senior Vice President Engineering
19.05.2008, Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
3 609 929 B83 | (19.05.08)
4
... 200
rpm 1000
Nm 0.5 – 3.5 0.5 – 3.5 0.2 – 0.8
–
2
<2.5 m/s ,
h
Dr. Eckerhard Strötgen
Head of Product Certification
4 1 2
... 201 ... 202 ... 203 ... 205
1000 1000 500 1000
0.5 – 2 0.5 – 3.5 0.5 – 3.5 0.2 – 0.8
– – –
Switching On and Off
Thrust-start with Shut-off Clutch
To start the machine, position the tool bit onto the screw and apply
light axial pressure to the screwdriver. The machine switches off
automatically as soon as the preset torque is reached.
When the screwdriver is released too early, e.g., when the
machine's tool bit slips off of the screw, the preset torque is not
reached.
9
LED
Switching the power tool on or briefly pressing the rotational direc-
tion switch 9 activates an LED worklight. The LED goes out approx.
two minutes after the last screwdriving.
Do not look directly into the work area illumination – your sight
can be temporarily degraded!
Repeat Protection
The power tools are not equipped with restarting protection and can
be switched on directly again following an automatic shut-off.
Subject to change without notice.
4 4 1 2
... 206 ... 207 ... 208
1000 1000 500
0.5 – 2
– – – –
