EAW SB150 Specifications

DESCRIPTION
A dedicated subwoofer system with a 15-in transducer in a
vented rectangular enclosure. Available in a portable ver-
sion ('R' with handles and NL4 connectors) or a permanent
installation version ('P' with mounting/suspension points).
APPLICATIONS
The SB150 provides high output sub bass response in a com-
pact enclosure. Tuned enclosure venting extends LF response
and minimizes driver strain. MX Series processors extend LF
response and safeguard against cone excursion damage. Six
year warranty.
Applications include:
Band PA
Ballroom Events
MultiMedia
Boardrooms
Restaurants
Small Retail Spaces
PERFORMANCE
Frequency Response (Hz)
3 db 33 Hz to 300 Hz (43 Hz w/out CCEP)
-10 dB 29 Hz (32 Hz w/out CCEP)
Axial Sensitivity (dB SPL/1 Watt/1m)
95
Impedance (Ohms)
8
Power Handling (Watts)
AES Standard 1000
Calculated Maximum Output (dB SPL, @ 1m)
Peak 131.0
Long Term 125.0
EASTERN ACOUSTIC WORKS
One Main Street, Whitinsville, MA 01588 • (508) 234 - 6158 • FAX (508) 234 - 8251 • Email info@eaw.com • Web http://www.eaw.com
EAW products are continually improved. All specifications are therefore subject to change without notice. • PUB# SB150-888090 (A)/2 pp/2/1/99 • Printed In USA
SPECIFICATIONS SB150
PHYSICAL
Part Number 999067 (P)
999068 (R)
Product Group L
Components & Loading 1x 15-in, vented
System Configuration Dedicated subwoofer
Recommended High-Pass
Frequency (24 dB/Octave) 25 Hz
Cabinet Type (shape) Rectangular
Enclosure Materials Baltic birch plywood
Finish Black catalyzed polyurethane
Connectors P: 2-terminal barrier strip
R: (2) Neutrik NL4 Speakon
Suspension Hardware P: (16) 3/8"-16 threaded mount-
ing/suspension points (4 each top,
bottom, sides)
R: no points, handles, corner
protectors
Grille Vinyl coated perforated steel
Dimensions inches
Height 24.62
Width 19.69
Depth 19
Weights pounds kilograms
Net Weight 76
Shipping Weight 85
R Version Shown
millimeters
625
498
483
34.6
38.7
