AVS-3

3 IN / 1 OUT HDMI SWITCHER

Owner's Manual

Front panel

Rear panel

Side panel

Remote

Table of Contents

Summary of Contents for Denon AVS-3

Page 1 Contents Connections Operations Troubleshooting Appendix Specifications AVS-3 3 IN / 1 OUT HDMI SWITCHER Owner’s Manual Front panel Rear panel Side panel Remote...
Page 2 Contents Connections Operations Troubleshooting Appendix Specifications Appendix Confirming the accessories Inserting the batteries Trademark information Operating range of the remote control unit Specifications Part names and functions Front panel Specifications Rear panel Side panel Remote control unit Connections Connections Basic connections Connecting an external control device Operations Operations...
Page 3: Confirming The Accessories
Operations Troubleshooting Appendix Specifications Thank you for purchasing this Denon product. To ensure proper operation, please read this owner’s manual carefully before using the product. After reading this manual, be sure to keep it for future reference. Confirming the accessories Check that the following parts are supplied with the product.
Page 4 Contents Connections Operations Troubleshooting Appendix Specifications 0 There are 5 types of supplied AC adapter plugs. Use the plug appropriate to the region you live in. Front panel Rear panel Side panel Remote...
Page 5: Inserting The Batteries
Contents Connections Operations Troubleshooting Appendix Specifications Inserting the batteries While pressing down on the battery cover from above, turn the coin or other item clockwise. Insert a coin or other item into the slot on the battery cover, turn counterclockwise, and remove the battery cover.
Page 6: Operating Range Of The Remote Control Unit
Contents Connections Operations Troubleshooting Appendix Specifications Operating range of the remote control unit Point the remote control unit at the remote sensor when operating it. Approx. 23 ft/7 m 30° 30° Front panel Rear panel Side panel Remote...
Page 7: Part Names And Functions
Contents Connections Operations Troubleshooting Appendix Specifications Part names and functions Front panel A Remote control sensor This receives signals from the remote control unit. (v p. 6) 0 The power of this unit is linked to the power status of the HDMI devices Point the remote control unit at this sensor when operating it.
Page 8: Rear Panel
Contents Connections Operations Troubleshooting Appendix Specifications Rear panel 5V/1A REMOTE CONTROL (FLASHER) HDMI IN HDMI OUT DC IN A Remote control jack (REMOTE CONTROL (FLASHER) IN) B HDMI input connectors (HDMI IN 1 - 3) This jack can be used to connect and control this unit externally with a These connect game consoles, media players, or other HDMI source separately sold IR repeater when this unit is positioned where the devices.
Page 9: Side Panel
A AVR control switch (AVR CONTROL) B HDMI control switch (HDMI CONTROL) You can use the remote control unit for your Denon AV receiver/AV If using the HDMI control (CEC) function, turn this ON. This links to amplifier to switch the HDMI input of this unit.
Page 10: Remote Control Unit
Contents Connections Operations Troubleshooting Appendix Specifications Remote control unit A HDMI input source select buttons (1 - 3) These select the HDMI input. INPUT INPUT Front panel Rear panel Side panel Remote...
Page 11: Basic Connections
Contents Connections Operations Troubleshooting Appendix Specifications Connections Basic connections Game console Game console This unit AC adapter AV receiver / 5V/1A AV amplifier REMOTE CONTROL (FLASHER) HDMI IN HDMI OUT DC IN HDMI IN HDMI cable Power supply cable (sold separately) (supplied) HDMI cable (sold separately)
Page 12 Contents Connections Operations Troubleshooting Appendix Specifications Use separately sold HDMI cables to connect game consoles or other source devices to HDMI input 0 When connecting this unit to devices that are compatible with the 8K and 4K 120Hz video, use certified Ultra High Speed HDMI cables. If you use a different connectors 1 to 3 of this unit.
Page 13 Fix this unit to the wall using separately sold wall- 0 Denon does not bear responsibility for any injuries or accidents due to mount screws. inappropriate mounting locations or mounting methods.
Page 14: Connecting An External Control Device
Contents Connections Operations Troubleshooting Appendix Specifications Connecting an external control device Even if you put this unit in a cabinet or another location where the remote control signal cannot reach, if you connect a commercially available IR repeater (separately sold), you can operate this unit using the remote control unit. This will disable remote sensor reception of this unit.
Page 15 Contents Connections Operations Troubleshooting Appendix Specifications Operations Operate using one of the following methods. Turn on the power of the source device you want to Operating with the HDMI control (CEC) use, and then confirm that the power of this unit, the function AV receiver/AV amplifier, and the TV turn on, and that the HDMI input switches correctly.
Page 16 Contents Connections Operations Troubleshooting Appendix Specifications Operating with the remote control unit Turn on the power of the source device you want to use. On the supplied remote control unit, press the HDMI input source select button (1 to 3) to perform playback. The indicator for the selected HDMI input is lit in blue.
Page 17 Positioning If you have an 8K-compatible Denon AV receiver/AV amplifier, you can use the remote control unit for the AV receiver/AV amplifier to switch the HDMI input for this unit. Turn the AVR CONTROL switch on the side panel of The 8K, GAME, and MEDIA PLAYER buttons on the remote control unit this unit ON.
Page 18 Contents Connections Operations Troubleshooting Appendix Specifications o Connecting Connect the source devices connected to the HDMI input connectors for 8K, GAME, and MEDIA PLAYER on 0 The number of the 8K-compatible HDMI input connector varies depending on the the back of the AV receiver/AV amplifier to HDMI input specifications of AV receiver/AV amplifier.
Page 19 Contents Connections Operations Troubleshooting Appendix Specifications o Configuring the settings for an AV receiver/AV o Operating amplifier Press the 8K, GAME, or MEDIA PLAYER button on the remote control unit for the AV receiver/AV amplifier. Open the “Inputs” - “Input Assign” settings screen The inputs for this unit and for the AV receiver/AV amplifier switch from the menu for the AV receiver/AV amplifier.
Page 20: Troubleshooting
Contents Connections Operations Troubleshooting Appendix Specifications Troubleshooting If a problem should arise, first check the following: 1. Are the connections correct? 2. Is the set being operated as described in the owner’s manual? 3. Are the other devices operating properly? 0 If steps 1 to 3 above do not improve the problem, restarting the device may improve the problem.
Page 21 Contents Connections Operations Troubleshooting Appendix Specifications o Power automatically turns off This unit is linked to the power of the source device connected to the HDMI input connector, and automatically turns to standby. o Operations cannot be performed through the remote control unit The battery is used up.
Page 22 Contents Connections Operations Troubleshooting Appendix Specifications o Inputs of this unit cannot be switched with the HDMI control (CEC) function Check whether the HDMI CONTROL switch on the side panel of this unit is turned ON. Check whether the HDMI control function settings are enabled for all devices connected to this unit. In the settings for the connected source devices, if there are settings to link to and turn on other devices when the power is turned on, enable those settings as well.
Page 23: Trademark Information
Contents Connections Operations Troubleshooting Appendix Specifications Trademark information The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. HDR10+™ logo is a trademark of HDR10+ Technologies, LLC. Front panel Rear panel Side panel Remote...
Page 24: Specifications
Contents Connections Operations Troubleshooting Appendix Specifications Specifications o Video Resolution: 480i, 480p, 576i, 576p, 720p 50/60, 1080i 50/60, 1080p 24/25/30/50/60/100/120 4K 24/25/30/50/60/100 /120 , 8K 24 Color: Deep Color, x.v. Color, Adobe RGB, Adobe YCC601, sYCC601, BT.2020 HDR: HDR10, HDR10+, Dynamic HDR, Hybrid Log-Gamma HDMI features: HDMI control (CEC), 3D, ALLM (Auto Low Latency Mode), VRR (Variable Refresh Rate), QMS (Quick Media Switching), QFT(Quick Frame Transport)
Page 25 Contents Connections Operations Troubleshooting Appendix Specifications o AC adapter Manufacturer: CUI INC Address: 20050 SW 112th Ave. Tualatin, OR 97062 Model identifier: SMI5-5-V-I38-C9 Input voltage: AC 100 - 240 V Input AC frequency: 50/60 Hz Output voltage: 5.0 V Output current: 1.0 A Output power: Average active efficiency:...
Page 26 Contents Connections Operations Troubleshooting Appendix Specifications Dimensions (Unit : in. (mm)) 5.5 (140) (17.5) 4.1 (105) (17.5) Front panel Rear panel Side panel Remote...
Page 27 Contents Connections Operations Troubleshooting Appendix Specifications When mounting a wall-mount bracket 6.1 (154) 6.7 (169) (14.5) 5.5 (140) (14.5) (17.5) 4.1 (105) (17.5) o Weight: 0.7 lb (300 g) (When not mounting a wall-mount bracket) Front panel Rear panel Side panel Remote...
