EAW FR152e Technical Specifications

DESCRIPTION
A 2-way full range system (passive LF/HF crossover) in a
vented rectangular enclosure. Includes a 15-in woofer and a
1-in exit compression driver on a 90 x 45 constant directiv-
ity horn.
APPLICATIONS
The FR152e provides high output full range response in a
versatile, compact system. Effective for both permanent and
portable applications, it comes with handles, a pole mount
cup and 3/8"-16 threaded mounting/suspension points. Six
Year Warranty.
Application include:
Band PA
Ballroom Events
Corporate Events
Small HOW's
Dance CLubs
Live Music Clubs
DESCRIPTIVE DATA
Part Number 999007
Product Group I
LF Subsystem & Loading 1x 15-in, Vented
HF Subsystem & Loading 1x 1-in Exit Compression Driver on
Constant Directivity Horn
System Configuration 2-way, Full Range
Powering Configuration(s) Passive LF/HF Crossover
Controls (switches, knobs) Midrange Presence Control
Recommended High-Pass
Frequency (24 dB/Octave) 40Hz
Cabinet Type (shape) Rectangular
Enclosure Materials Baltic Birch Plywood
Finish Black Catalyzed Polyurethane
Connectors 2x Neutrik NL4 Speakon
Suspension Hardware (3) 3/8-16 Threaded Mounting/
Suspension Points (2 top/1 back),
Stand Mount Cup for Ultimate
Brand Support Stand
Grill Vinyl Coated Perforated Steel
EASTERN ACOUSTIC WORKS
One Main Street, Whitinsville, MA 01588 • (508) 234 - 6158 • FAX (508) 234 - 8251 • Email info@eaw.com • Web http://www.eaw.com
EAW products are continually improved. All specifications are therefore subject to change without notice. • PUB# FR152e 999007 (A)/2p/3/14/97 • Printed In USA
TECHNICAL SPECIFICATIONS FR152e
NOMINAL DATA
Frequency Response (Hz)
Axial Sensitivity (dB SPL/1 Watt/1m)
Impedance (Ohms)
Power Handling (Watts)
Calculated Maximum Output (dB SPL, @ 1m)
Nominal Coverage Angle / -6 dB points (degrees)
Dimensions
Weights
Shipping Weight
3 db 70Hz to 17kHz
-10 dB 60Hz
98
8
AES Standard 450
Peak 130.5
Long Term 124.5
Horizontal 90
Vertical 45
inches millimeters
Height 25.25 641
Width 19.75 502
Depth 14.75 375
pounds kilograms
Net Weight 68 30.9
71 32.3
