Dukane ImagePro 8777 Appendix

PC Control Codes and Cable Connection

PC Control Codes (VT695/VT595)
Function
POWER ON
POWER OFF
INPUT SELECT COMPUTER 1
INPUT SELECT COMPUTER 2 (Digital) 02H
INPUT SELECT COMPUTER 2 (Analog) 02H
INPUT SELECT VIDEO
INPUT SELECT S-VIDEO
PICTURE MUTE ON
PICTURE MUTE OFF
SOUND MUTE ON
SOUND MUTE OFF
NOTE: Contact your local dealer for a full list of the PC Control Codes if needed.
Cable Connection
Communication Protocol
Baud rate ........................................ 19200 bps
Data length ..................................... 8 bits
Parity .............................................. No parity
Stop bit .......................................... One bit
X on/off .......................................... None
Communications procedure ........... Full duplex
NOTE: Depending on the equipment, a lower baud rate may be recommended for long cable runs.
8777 & 8779
Code Data
02H 00H 00H 00H
02H 01H 00H 00H
02H 03H 00H 00H
03H 00H 00H
03H 00H 00H
02H 03H 00H 00H
02H 03H 00H 00H
02H 10H 00H 00H
02H 11H 00H 00H
02H 12H 00H 00H
02H 13H 00H 00H
00H 02H
00H 03H
02H 01H 01H 09H
02H 01H 1AH 22H
02H 01H 02H 0AH
02H 01H 06H 0EH
02H 01H 0BH 13H
00H 12H
00H 13H
00H 14H
00H 15H
64
7. Appendix
