Cub Cadet CS202 Operator's Manual

Removing Unit From Carton Assemble The Unit
Slot
Bracket
1 1 2
Remove all contents from Slide shield's slot onto
carton. mounting bracket. Rotate
shield onto shaft. Push
square bolt through shield
and bracket. Tighten
washer and wing nut
onto bolt.
Assemble The Unit
40:1
1 Gallon 3.2 oz
5 6
Mix thoroughly in separate Place unit on a level surface.
fuel can: Fill fuel tank.
– 3.2 fl. oz. of 2-cycle
engine oil
– 1 gallon of unleaded
gasoline
NOTE: Do not mix directly in
fuel tank.
Starting The Unit
1 9 10
Crouch in starting position. SQUEEZE and HOLD
throttle for ALL further
steps.
Reloading The Line*
Outer
Bump
Spool
Knob
Spring
1 1 2
Unscrew the bump knob Remove the inner reel and
counterclockwise. spring.
Reloading The Line
For replacement line, call 1-877-282-8684 or go to
an authorized service dealer.
For single line installation or replacement spool
installation instructions, refer to the Replacing the
Trimming Line section of this manual.
*This is to assist in the reloading of Splitline® only. These instructions
are NOT part of the fast assembly instructions. Line does not need to
be installed on the initial assembly and start-up.
1 8
Hold the inner reel and outer
spool together. Firmly pull
the two line ends to release
them from the holding slots.
Screw the bump knob on
clockwise. Tighten the bump
knob securely.
IMPORTANT: READ OPERATOR'S MANUAL THOROUGHLY AND FOLLOW THE SAFE OPERATION PRACTICES BEFORE OPERATING THE UNIT.
NEED HELP?
769-07498 P00
Operator's Manual
3
Remove cap from lower
boom. Push cutting
attachment into coupler.
Turn coupler knob clockwise
to tighten.
Starting The Unit
Primer
Bulb
10 X
7
Press primer bulb 10 times,
or until fuel is visible
5 X
11
Pull rope 5 times.
Inner
Reel
3
Cut one 6-foot (1.8 m)
length of new 0.095" split
line trimming line. Split each
end about 6 inches (150
mm).
CALL 1-877-282-8684 IN U.S. OR 1–800–668–1238 IN CANADA
ASSEMBLY TOOLS REQUIRED:
• 3/8" Socket
Min. 6"
4
Put D-handle on shaft. Move
handle a minimum 6 inches
away from shaft grip. Insert
bolt and tighten.
Choke Lever
8
Cutting Head Shield
Move choke lever to
Position 1.
Choke Lever
12 13
Move choke lever to Pull rope 3-5 times to start
Position 2 and squeeze engine. Run unit for 30-60
throttle. seconds to warm up.
Top Hole
Split Wall
Bottom Hole
4 5
Insert the end of one line Wind the line tightly in the
into the top hole and the direction shown on the inner
end of the other line into the reel. The split wall will divide
bottom hole. the line. Wind the line until it
is completely divided and
about 6 inches (150 mm) of
line remains.
CS202
2-Cycle Trimmer
Starter Rope
On/ Off Switch
D-Handle
Rapid-link™
Need Help?
Call 1-877-282-8684
DIDN'T START?
Repeat these instructions.
IF engine fails to start after 2 attempts,
move choke lever to position 3 and pull
the starter rope until engine starts
IF unit still fails to start, refer to the
operator's manual for additional starting
and troubleshooting information
Choke Lever
3-5 X
14
Continue to squeeze
throttle. Move choke lever
to Position 3.
Holding Slots
6
Insert the two 6-inch
sections into the two .095
holding slots.
Fuel Cap
Throttle Control
15
Continue to squeeze
throttle. Run unit for an
additional 60 seconds to
complete warm-up. Unit
may be used during this
time.
Eyelets
7
Pass the two line ends
through the eyelets. Place
the spring inside the inner
reel. Insert the inner reel into
the outer spool. Push the
inner reel and outer spool
together.
(10/11)
