2.1.5

Additional cooling kit installation

2
1
6
VRM_HS_FAN
8
When using high performance settings whilst overclocking, ensure to install the bundled
fan onto the MOS fan holder.
• You may install 12V (1A, 12W), 40mm x 40mm fans.
• You may adjust the height of the fan holder to your preference when installing the fan
holder.
• Ensure to the use the bundled screws that came with your accessory.
ROG STRIX Z490-E GAMING
7
4
4
3
5
5
2-9
