Replacing and Purchasing
Consumable Parts
The inner stopper unit, direct drink cap unit
and gaskets are consumable parts. Check
once a year for damage/deterioration. If
heavily stained or loose, replace them.
For replacement parts, contact customer
service or the shop where you purchased
this product.
For the purpose of performance improvement, designs, specifications and parts shown in this
publication are subject to change without notice.
Specifications
Capacity
Inner
Greater than 45°C •113°F (24hours)
stopper
0.5 L / 16.9 oz
Greater than 73°C •163°F (6hours)
unit
Direct drink
0.54 L / 18.2 oz
cap unit
Heat retention has been calculated under the condition of adding hot water at 95°C ±1°C •
203°F±2°F and leaving it in a room temperature of 20°C±2°C • 68°F±4°F for 24hours or 6hours.
Cold retention has been calculated under the condition of adding cold water at 4°C ±1°C • 39°F±2°F
and leaving it in a room temperature of 20°C±2°C • 68°F±4°F for 6hours.
Capacity is the actual volume of water that can be stored into the product when the inner stopper
unit or direct drink cap unit is closed. This is not the "Maximum level" volume described in "Safety
Precautions".
TIGER CORPORATION
Head Office: 3-1 Hayamicho, Kadoma City, Osaka 571-8571, Japan
URL : http://www.tiger.jp/global.html
TIGER HANBAI (H.K.) CO.,LTD.
Rm. 1006B, 10/FI., Join-in Hang Sing Centre, 71 - 75 Container Port Road,
Kwai Chung, N.T.
Tel: (852) 2418-0912 Fax: (852) 2418-0911
JAPAN TIGER CORPORATION OF U.S.A.
2730 Monterey Street, Suite 105 Torrance, CA 90503
Tel: (310) 787-1985
Fax: (310) 787-1986
EMAIL: info@japantigercorp.com
Before contacting customer
service
The utmost measures have been taken to
ensure the quality of this product.
However, should the product be defective,
contact your dealer and provide the
following information.
1. Product name
2. Model Number
3. Description of trouble
(As detailed as possible)
4. Purchase date
Feel free to send any questions or
comments about this product to the shop
where you purchased it.
Heat retention
Cold retention
Less than 8°C •
46°F (6hours)
Stainless Steel Bottle
With carrying case
Instructions
Thank you for purchasing a "TIGER" Stainless Steel Bottle.
Please read the instructions completely before use.
Keep these instructions for future reference.
Lid gasket
Lid
Direct drink
cap unit
Spout
Button
Spout
gasket
Cold drinks only
Make sure that all parts are present before use.
MODEL
MBP-B
Open button
Squeeze button
Inner stopper A
Spout cap gasket
Spout
Inner stopper B
Stopper gasket
Hot/Cold drinks
Body
Protective sheet
Cup
Inner
stopper
unit
